Frigidaire FAK123J1V1 User manual

PRODUCT NO.
BASE MODEL NO.
VOLTS
BTU-COOLING
FAK123J1V1 FAK123J1V 115 12000
P.O. Box 212378
Augusta, GA 30917
All rights reserved
FACTORY PARTS CATALOG
ROOM AIR CONDITIONER
©2000 White Consolidated Industries, Inc.
ROOM AIR CONDITIONER
Model No.
FAK123J1V1
WIRING DIAGRAM # - A232012
OWNERS GUIDE # - 309000816
Publication No.
000413
-EN/SERVICE /REP
345
5995338869

FAK123J1V1
CABINET FRONT AND WRAPPER
4/00 1

FAK123J1V1
1 309622004 Cabinet
2 5303317604 Grille,rear
7 5304414855 Link,louver
8 309622204 Louver,Horizontal
9 309622103 Louver,vertical ,(4)
10 309622104 Louver,vertical ,w/handle
12 309622304 Filter
17 309622404 Front,cabinet ,complete
19 309622609 Dial plate
20 309307011 Knob-control
39 3015312 Screw,8-18 x 0.47
CABINET FRONT AND WRAPPER
POS. NO. PART NO. DESCRIPTION
# = Functional Parts
* = Non-illustrated Parts
4/00 2

FAK123J1V1
CONTROL PARTS
4/00 3

FAK123J1V1
7309606501 Panel-mounting,controls
8 # 5303323284 Switch-selector
9 # 5303321674 Control-temperature
12 309321201 Clip-control bulb
13 # 5304403167 Capacitor,370 V ,35-15
15 5303303077 Strap-capacitor
17 # 309343106 Cord-electric power,type A
18 5303007754 Screw,.138-32 x .188
28 309625301 Control-vent door
29 309606402 Control Box
CONTROL PARTS
# = Functional Parts
* = Non-illustrated Parts
POS. NO. PART NO. DESCRIPTION
4/00 4

FAK123J1V1
AIR HANDLING PARTS
4/00 5

FAK123J1V1
2 3202975 Screw,10-16 x 0.72 ,square drive
3 309620501 Housing-fan
7 309626001 Fan Blade
8 # 309617703 Motor-fan
11 # 309625201 Blower Wheel,plastic
12 5303012110 Clamp-blower
15 309624801 Housing-blower
22 5303313964 Seal,condenser ,upper
29 309624901 Adaptor,housing-blower
30 309624601 Back Plate,housing-blower
AIR HANDLING PARTS
POS. NO. PART NO. DESCRIPTION
# = Functional Parts
* = Non-illustrated Parts
4/00 6

FAK123J1V1
COMPRESSOR PARTS
4/00 7

FAK123J1V1
1# 309616914 COMPR-TEC RGA5512EXA
2 5303015945 Grommet,compressor ,(3)
3 5303015946 Nut,plastic ,compressor ,(3)
6 3201668 Gasket-cover
7 5304405245 Protective Cover
8 # 5304403611 Overload Protector
9 3201670 Nut,cover
10 # 5303317601 Start Assist Kit,compressor
11# 309617007 Evaporator
12# 309617205 Condenser
13 309624101 Tray-evaporator
16 # 309327001 Capillary Tube
16A # 309327101 Capillary Tube
17 # 309325201 Drier-filter
22 5303313964 Seal,condenser ,upper
23 309614105 Base,compressor
COMPRESSOR PARTS
POS. NO. PART NO. DESCRIPTION
# = Functional Parts
* = Non-illustrated Parts
4/00 8

FAK123J1V1
1 5303313968
Seal,frame ,top
2 5303211056 Bracket
8 5304414856
Bracket-support
17 5308013771
Screw-wood,rnd hd ,8-15 x 0.750
20 5303295750
Screw,8-18 x 0.750
25 5308047516
Panel-window,plastic
33 5304414858
Frame-window,sliding
34 5304414861
Retainer-window panel
35 5304414857
Plate-mounting,unit
36 5308047524
Seal,mounting plate
37 5308047558 Screw,pan head ,8-32D x 0.75
38 5308047562
Screw-adjusting,mounting plate
39 5303313967
Seal,frame ,side ,(2)
40 5303302870 Bracket,safety
41 5300125233 Screw,pan head ,10-12A x 1.00
42 5300507212 Screw,pan head ,10-12A x 1.75
43 5300507693 Screw,flat head ,10-12A x 2.50
44 5300516543
Nut,hex flange ,1/4-20
48 309305302
Channel-slide,(2)
*309625802
Kit-window mtg.
# = Functional Parts
* = Non-illustrated Parts
WINDOW MOUNTING PARTS
POS. NO. PART NO. DESCRIPTION
4/00 9

FAK123J1V1
WIRING DIAGRAM
4/00 10
