PRODUCT NO.
BASE MODEL NO.
VOLTS
BTU-COOLING
FAC084J7A1 FAC084J7A 115 8000
P.O. Box 212378
Augusta, GA 30917
All rights reserved
FACTORY PARTS CATALOG
ROOM AIR CONDITIONER
©2000 White Consolidated Industries, Inc.
ROOM AIR CONDITIONER
Model No.
FAC084J7A1
WIRING DIAGRAM # - 309341601
OWNERS GUIDE # - 309000825
Publication No.
000307
-EN/SERVICE /REP
345
5995339594

FAC084J7A1
CABINET FRONT AND WRAPPER
3/00 1

FAC084J7A1
15304413783 Cabinet
7309638001 Link / handle
8309639301 Louver-horizontal
9309342001 Louver, Vertical, (6)
12 3096343501 Filter-Mesh
17 309640102 Front, cabinet, complete
19 309340803 Overlay-Electronic control
25 309328601 Door-Vent Actuator HDTC
26 309639401 Handle-Vent
26A* 309330201 Vent-Detent
38 309639201 Panel-front
43 309639101 Frame- front
70 309342201 Enclosure
78 309342604 Remote Control
*309640202 Louver assy-includes 7, 8 & 9
# = Functional Parts
* = Non-illustrated Parts
CABINET FRONT AND WRAPPER
POS. NO. PART NO. DESCRIPTION
3/00 2

FAC084J7A1
CONTROL PARTS
3/00 3

FAC084J7A1
7309340402 Box-Control
10 309602403 Bulkhead
12 * 5304413782 Clip-thermister holder
13# 5303303576 Capacitor, 370V, 35+10 mfd
14 5303303691 Screw, truss head, 8-18AB x 0.38
15 5303303086 Strap-capacitor
17# 309343101 Cord-power 115v
19 5303302855 Cover, capacitor
70 # 309342201 Enclosure
71 # 309340503 Power board
72 # 309340505 Input board
74 5303301590 Screw, (2)
75 5304413781 Hardware, (4)
76 # 309111601 Transformer
POS. NO. PART NO. DESCRIPTION
CONTROL PARTS
# = Functional Parts
* = Non-illustrated Parts
3/00 4

FAC084J7A1
AIR HANDLING PARTS
3/00 5

FAC084J7A1
1# 309624502 Fan Blade, with clamp
23202975 Screw,10-16 x 0.72
2A 08007481 Nut, motor mtg
3309624201 Housing-fan
45303270043 Seal, condenser
608016225 Grommet-motor mounting
8# 309627301 Motor-Fan RAIDER 3SP
10 309602403 Bulkhead
11 309603301 Blower Wheel
12 5303012110 Clamp-blower
15 5304407653 Housing-blower
16 309100201 Clip
17 5308011040 Clamp (part of fan blade assy)
18 Not Separate Deflector-housing (part of housing)
20 5304407654 Plate-Scroll
# = Functional Parts
* = Non-illustrated Parts
AIR HANDLING PARTS
POS. NO. PART NO. DESCRIPTION
3/00 6

FAC084J7A1
COMPRESSOR PARTS
3/00 7

FAC084J7A1
1# 5304406829 Compressor
25303283877 Grommet-compressor,3
35308006948 Nut, compressor, 3
63200282 Gasket-cover
73200281 Cover,terminal
8# 3202920 Overload protector
908009077 Nut, cover
10 5303317601 Start Assist Kit, compressor
11# 309619305 Evap-Assy
12# 5303303195 Condenser
13 5303302849 Tray-Evap
14 5304413932 Base/Compressor-Stud Assy
16# 3019025 Capillary Tube
17 5304413933 Tube-process
19 5303002664 Washer,compressor
# = Functional Parts
* = Non-illustrated Parts
COMPRESSOR PARTS
POS. NO. PART NO. DESCRIPTION
3/00 8

FAC084J7A1
15304407729 Seal, frame, top
25303211056 Bracket
45304413847 Frame,LH
50806226 Seal-top rail
6Not Used Retainers are part of cabinet
14 5304413848 Frame,RH
15 309626504 Accordian
16 5304413784 Rail,top
17 3002803 Screw-wood
18 5303303691 Screw, 8-18AB x .38
20 5303295750 Screw, 8-18 x .75
22 5304403252 Retainer, bottom
23 3001806 Screw
24 530802974 Screw
WINDOW MOUNTING PARTS
POS. NO. PART NO. DESCRIPTION
# = Functional Parts
* = Non-illustrated Parts
3/00 9

FAC084J7A1
WIRING DIAGRAM
3/00 10
