Frigidaire FAH12EN2T User manual

Product No. FAH12EN2T2 FAH12EN2T3
Series TTW/Builder TTW/Builder
Volts 230/208 230/208
BTU-Cooling 12000/11700 12000/11700
BTU-Heating 10600/8600 10600/8600
Wiring Diagram 309201102 309201102
Market North America North America
P40L2012.eps cbnt-cntls02.eps syst06.eps 309201102.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995462990
06/03/09
(EN/SERVICE/WC)
099
ROOM AIR
CONDITIONER
Model No.
FAH12EN2
Copyright ©2006 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995462990 FAH12EN2
03/06 2
CABINET, FRONT, CONTROLS
Front Panel Assembly
55
54
53
52
51
25
24
23
22 21
20
19
32
31
30
29
27
28
26
Electric Control System
58
58
57
57
56
Cabinet and Shutter
3
4
2
1
Chassis
cbnt-cntls02

FAH12EN2 Publication No: 5995462990
# Functional Parts 3 03/06
* Non-Illustrated Parts
CABINET, FRONT, CONTROLS
Model Index: AFAH12EN2 (FAH12EN2T2)
BFAH12EN2 (FAH12EN2T3)
POS. NO PART NO. DESCRIPTION
1 309632006 A B Base, compressor mt., with studs
2 309628704 A B Tray, evap base
3 # 309363601 A B Valve, water drain
4 309629502 A B Shield, heat, 20.94 L, base
19 # 309201603 A B Sensor, thermistor, evap defrost
20 # 309201602 A B Sensor, thermistor, ambient temp
21 # 309201601 A B THERMISTER, defrost
22 # 309343130 A B Power Cord, LCDI-type D, 12 AWG, 230 V, with test/reset
23 309203101 A B Support, control box
24 # 5304430633 A B Capacitor, 370 V, 30+7.5 mfd
25 # 5303303708 A B Strap, capacitor
26 # 309201701 A B Relay, electric heater
27 # 309201001 A B PC Board, power, 230 V
28 309200301 A B Control Box
29 # 309201301 A B PC Board, input/display
30 309200201 A B Enclosure, input pcb, control panel
31 309201402 A B Overlay, control display
32 309205501 A B Remote Control
51 309324004 A B Link, vertical louver, with handle
52 309628004 A B Louver, horizontal
53 309628104 A B Louver, vertical
54 309628204 A B Filter, air, molded plastic, grey
55 309200101 A B Panel, front grille
56 309627504 A B Cabinet, wrapper
57 309628603 A B Trim, frame, side
58 309628604 A B Trim, frame, top & bottom

Publication No: 5995462990 FAH12EN2
03/06 4
COOLING & AIR FLOW SYSTEMS

FAH12EN2 Publication No: 5995462990
# Functional Parts 5 03/06
* Non-Illustrated Parts
COOLING & AIR FLOW SYSTEMS
Model Index: AFAH12EN2 (FAH12EN2T2)
BFAH12EN2 (FAH12EN2T3)
POS. NO PART NO. DESCRIPTION
5 # 309632403 A B Evaporator
6 # 309358101 A B Tube, anti gurgle, top
7 # 309358201 A B Tube, anti gurgle, bottom
8 # 309113304 A B Manifold Assembly, w/brazing rings
9 # 309376101 A B Tube, capillary, bottom
10 # 309376001 A B Tube, capillary, top
11 # 5304417604 A B Tube, process, cond. outlet
12 # 309373501 A B Tube, discharge
13 # 309632507 A B Condenser
14 # 309375901 A B Tube, suction
15 5304416126 A B Cover, elec terminal, compressor
16 # 5304430634 A B Overload Protector
17 # 309603121 A B Compressor
18 5303283877 A B Grommet, compressor mtg, (3)
33 # 5304409501 A B Wiring Harness, heater
34 # 309627002 A - Heater Assy, 3450 W, 230 V
34 # 309627005 - B Heater
35 309633401 A B Shield, elec. heater, vertical
36 309625501 A B Scroll Plate
37 309112101 A B Clamp, blower wheel mt, compression
38 # 309631701 A B Blower Wheel
39 309622802 A B Scroll
40 309627401 A B Bulkhead
41 309100301 A B Grommet, wire protector
42 309335001 A B Baffle, splash/motor
43 # 309647502 A B Motor, fan
44 # 309200501 A B Fan Blade
45 309906801 A B Clamp, fan blade, assembly
46 309629001 A B Partition, condenser, galv-steel
47 309628901 A B Shroud, condenser
48 309628802 A B Cover, condenser, top
49 309636101 A B Screen, safety, wire mesh, cabinet rear
50 309335201 A B Baffle, air

Publication No: 5995462990 FAH12EN2
03/06 6
WIRING DIAGRAM
