Frigidaire FAC065K7A1 User manual

PRODUCT NO. BASE MODEL NO. COLOR MARKET BTU-COOLING
FAC065K7A1 FAC065K7A white USA 6000BTU
Publication No.
5995348306
010111
-EN/SERVICE /DJH
345
ROOM AIR CONDITIONER
Model No.
FAC065K7A
©2001 White Consolidated Industries, Inc
All rights reserved
FACTORY PARTS CATALOG
ROOM AIR CONDITIONER
WIRING DIAGRAM - # 309341601
OWNER’S GUIDE - # 309000825
ELECTROLUX HOME PRODUCTS NORTHAMERICA
P.O.BOX 212378, AUGUSTA, GA 30917

06/01 2
Publication No. FAC065K7A
5995348306
CABINET FRONT AND WRAPPER

# = Fast-moving Parts 3 06/01
* = Non-Illustrated Parts
FAC065K7A Publication No.
5995348306
CABINET FRONT AND WRAPPER
POS. NO PART NO DESCRIPTION
1 5304413783 Cabinet
7 309638001 Link,vertical louver ,with handle
8 309640202 Louver Assy,horizontal ,Incl-7,8,9
8* 309639301 Louver,horizontal
9 309342001 Louver,vertical ,(6)
12 309343501 Filter-air,7.12 x 17.31 ,no frame
17 309640102 Front-cabinet,4 way ,complete assy
19 309340802 Overlay-compact
25 309328601 Door-vent,fresh air
26 309638201 Handle vent door
26* 309330201 Detent-vent
38 309639201 Panel,cabinet front
43 309639101 Frame,cabinet front
70 309342201 Enclosure,elec control mt
78 309350502 Remote Control,transmitter with batteries

06/01 4
Publication No. FAC065K7A
5995348306
CONTROLS

# = Fast-moving Parts 5 06/01
* = Non-Illustrated Parts
FAC065K7A Publication No.
5995348306
CONTROLS
POS. NO PART NO DESCRIPTION
7 309350301 #Control Box
10 309602404 Bulkhead
10* 309111201 Grommet,wire protector
13 # 5304420621 Capacitor,370 V ,35+5 microfarad
14 3015312 Screw,8-18AB x 0.500
15 5303303086 Strap-capacitor
17 # 309343101 Cord-electric power,18 AWG ,115 V
19 5303302855 Cover,capacitor
70 309342201 Enclosure,elec control mt
71 309350401 PC Board,power,Sagem
72 # 309350402 PC Board,input
72* 5304417643 Ribbon Protector
74 5303301590 Screw-bracket
75 5304413781 Support-pc board
76 309111601 Transformer,120/12 Volt
* 309341601 Wiring diagram

06/01 6
Publication No. FAC065K7A
5995348306
AIR HANDLING PARTS

# = Fast-moving Parts 7 06/01
* = Non-Illustrated Parts
FAC065K7A Publication No.
5995348306
AIR HANDLING PARTS
POS. NO PART NO DESCRIPTION
1 # 309624502 Fan Blade,with clamp
2 3202975 Screw,10-16 x 0.72 ,square drive
3 309624201 Housing-fan
4 5303270043 Seal,condenser
6 5300105402 Grommet,motor ,(3)
8 # 309627302 Motor-fan,3 speed
10 309602404 Bulkhead
11 # 309617101 Blower Wheel
12 309112101 Clamp-blower
12 5303012110 Clamp-blower
15 5304407653 Housing-blower
16 309100201 Clip
20 5304407654 Plate-blower housing,scroll plate

06/01 8
Publication No. FAC065K7A
5995348306
COMPRESSOR PARTS

# = Fast-moving Parts 9 06/01
* = Non-Illustrated Parts
FAC065K7A Publication No.
5995348306
COMPRESSOR PARTS
POS. NO PART NO DESCRIPTION
1 # 5304420589 Compressor,Goldstar
2 5303283877 Grommet,compressor mtg ,(3)
3 5308006948 Nut,compressor mtg ,(3)
6 5303291330 Gasket,terminal cover
7 5304416126 Cover-terminal,compressor
7* 5303293809 Washer
8 # 5304417320 Overload Protector
9 5303294292 Nut-terminal cover
10 # 5303317601 Start assist kit, compressor
11 # 309604211 Evaporator
12 # 5303303197 Condenser
13 5303302849 Tray-evaporator
14 5304413932 Base Plate,compressor mtg
16 # 5308017120 Capillary Tube,45 inch long ,cut to length
17 5304413857 Tube-process
19 309112501 Washer,metallic
19* 5303002664 Washer,compressor mtg

06/01 10
Publication No. FAC065K7A
5995348306
WINDOW MOUNTING PARTS

# = Fast-moving Parts 11 06/01
* = Non-Illustrated Parts
FAC065K7A Publication No.
5995348306
POS. NO PART NO DESCRIPTION
1 5304407729 Seal-window frame,stuffer
2 5303211056 Bracket
4 309644901 Extension Kit-frame,LH & RH with accordians
4 5304413847 Frame,LH ,w/o accordian
4* 5304414120 Extension-frame,LH ,w/accordian
5 08016226 Seal-top rail
14 5304414121 Extension-frame,RH ,with accordian
14* 5304413848 Frame,RH ,w/o accordian
15 309626504 Closure,accordian type ,window mount
16 5304417362 Rail-top
17 3002803 Screw,wood, type 17 ,10-12 x 0.750
18 5303303691 Screw,truss head ,8-18AB x 0.375 ,w/nibs
20 5303295750 Screw,pan head ,8-18 x 0.750
22 5304403252 Retainer,bottom
23 3001806 Screw,23(T) ,10-32 x 0.310
24 5308002974 Screw,wood,type 17 ,8-15 x 0.500
WINDOW MOUNTING PARTS

06/01 12
Publication No. FAC065K7A
5995348306
WIRING DIAGRAM
