Frigidaire FRS224YS2 User manual

frigidaire.com
Product Dimensions
Evaporator (Indoor) Model
Height 12-7/16"
Width 39-11/16"
Depth 8-7/8"
Product Dimensions
Condenser (Outdoor) Model
Height 31-1/8"
Width 36-1/4"
Depth 14-5/8"
More Easy-To-Use Features
Energy and Cost Savings
A split system helps avoid the energy
losses that normally come with ductwork.
This loss can amount to up to 40% due to
leaks, tears and long lengths.
Inverter Technology
Allows the unit to maintain room
temperatures while operating at a
lower and quieter speed.
Multi-Speed Fan
Features three different fan speeds, for
more cooling flexibility.
Sleep Mode
Quiet operation keeps you cool without
keeping you awake. Plus, Sleep Mode
gradually increases room temperature
after being activated.
Quickly Cools
Turbo Mode for that quick cool-down
when you first turn it on
Comfort Control Design
Easily control the direction of your cool air,
wherever your unit is.
Eortless™ Restart
Automatically resumes operating at its
previous settings when power is restored
to your unit.
24 Hour On/O Timer
ENERGY STAR®
1Photo may not represent actual model.
Signature Features
Eortless™ Temperature
Control
Our air conditioners maintain the preset
room temperature, so you will remain
comfortable at all times.
Ready-Select®Controls
Easily select options with the touch of a
button.
Eortless™ Clean Filter
Our anti-microbial filter cleans the air,
removing harmful bacteria.
Remote Control
Allows you to precisely control the
temperature and fan speed from across
the room.
FRS224YC21Outdoor
FRS224YW21Indoor
Performance
Cool
BTUs
21,500
Home Comfort
FRS224YS2
Ductless Mini-Split
Air Conditioner

RAC Indoor/Outdoor Ductless A/C Split Models
Frigidaire Baseline
B
A
C
A
B
C
Model Numbers
System Model Number
Indoor Unit Part Number
Outdoor Unit Part Number1
Performance
BTU (Cool)
Cooling Area (Sq. Ft.)
SEER (Air Conditioner)
Inverter Technology
Electrical
Volts
Amps (Cool) Indoor/Outdoor
Watts (Cool) Indoor/Outdoor
Fuse (Amps) Indoor/Outdoor
Features
Controls
Fan Speeds (Cool/Fan)
Low Voltage Start-Up
Turbo Fan
Auto Fan
Energy Saver
Sleep Mode
24 Hour On/O Timer
Remote Control
Air CFM (High/Med/Low) Indoor
Air Direction Control (Vert. / Horz.)
Air Discharge (Full-Width)
Filter Type
Filter Access
Air Direction Control - Horizontal
Air Direction Control - Vertical
dB (Indoor) (High/Med/Low)
dB (Outdoor)
Warranty2
Included Accessories
Drain Kit (Outdoor Unit)
Installation Plate (Indoor Unit)
Line Set (Indoor Unit)
Remote Holder (Indoor Unit)
Certifications
ENERGY STAR®
Performance
Specifications
Refrigerant
Shipping Weight (Approx.)
Home Comfort
FRS224YS2Ductless Mini-Split Air Conditioner
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FRS224YS206/11© 2011Electrolux Home Products, Inc. Printed in the U.S.A.
Specifications
subject to change.
FRS224YS2
FRS224YW2
FRS224YC2
21,500
1,430
18
Yes
230 / 208
0.5 / 7.9
38 / 1,835 (320-2,530)
3.15 / 25
Ready-Select®Controls
3 / 3
Yes
Yes
Yes
Yes
Yes
Yes
Full-Function
276 / 242 / 207
Yes / Yes
Bottom
Antimicrobial Mesh
Slide-Out
Manual
Swing
44 / 40 / 35
56
Yes
Yes
Yes
Yes
Yes
Yes
ARI
R410a
132
1Includes 16.4 ft. line set.
2Warranty 5 year sealed system / 1 year full parts and labor.
1Illustration may not represent actual model.
All refrigeration and electrical work must be performed by a certified and licensed
refrigeration technician for full parts and labor warranty validation. Insulated line sets
and control wires are required and available for Frigidaire split systems in 16.4 ft.
length. Each line set is equipped with flare nuts on both ends. Each system requires
one line set for each indoor unit installed.
NOTE: For planning purposes only. Always consult local and
national electric codes. Refer to Product Installation Guide for
detailed installation instructions on the web at frigidaire.com.
Product Dimensions
Indoor –
A - Height
B - Width
C - Depth
Max. Wall Thickness
Outdoor –
A - Height
B - Width
C - Depth
12-7/16"
39-11/16"
8-7/8"
18"
31-1/8"
36-1/4"
14-5/8"
FRS224YC21Outdoor
FRS224YW21Indoor
Accessories information available
on the web at frigidaire.com

TS-FRS224YS2-06/11-1
Ductless Mini-Split System Air Conditioners
Servicer Technical Data Sheet
FRS224YS2
REFRIGERANT SYSTEM
Refrigerant
Ounces
Control
Lineset
Maximum Height
Maximum Line length
Discharge Vapor Line (od)
Suction (od)
OUTDOOR UNIT
Sound rating
Net Weight
Shipping Weight
Dimensions (H x W x D)
Recommended Fuse
Minimum Amps
Running Current
Fan Type
Fan Diameter/Number of Speeds
Drive Type
Motor Watts
Number of Poles and RPM
CFM (High)
Coil Type
Fin Type
Pipe Type
Fin Rows (FPI)
Tube Size
OPERATING RANGE
Cooling
Heating
Cooling
Heating
R410A
63.49
electric expansion valve
16.4 ft
49.2 ft
98.43 ft
F 6 mm (1/4")
F 16 mm (5/8")
£ 56 dB (A)
119.04 lb
132.27 lb
27.56" x 35.04" x 13.38"
25 A
14 A
14.0/12.8 A
Axial
20.47"-2
dc motor
90 W
2-780/500 rpm
2500
aluminum fin & copper tube
flat
innergroove copper
2
¢ 7.15 mm (9/32")
Indoor Air
intake temp
90° F db/wb
41° F db/wb
81° F db/wb
32° F db/wb
Outdoor Air
intake temp
115° F db/wb
41° F db/wb
75° F db/wb
5° F db/wb
POWER
Circuit Amps
Maximum Fuse Size
CAPACITIES
Cooling
Amps
Watts
Min/Max Cooling
SEER
EER
Low Ambient Temperature
Voltage/Frequency/Phase
Dehumidification
INDOOR UNIT
Sound Rating
Net Weight
Shipping Weight
Dimensions (H x W x D)
Full Loaded Amps
Number of Fan Speeds
Fan Type
RPM at High Speed)
Motor Watts
Full Loaded Amps
Coil Type
Fin Type
Pipe Type
Fin Rows (FPI)
Tube Diameter
Drain Connection Size
FEATURES
Controls
Remote Control
Temperature Control
Timer
Air Louvers
Horizontal
Vertical
Low Voltage Restart
Self-Diagnosis
Quiet Operation
Air Filter
COMPRESSOR
Controls
Remote Control
Temperature Control
14.0/12.8 A
25 A
21500 Btu
9.05/8.19 A
1790 W
9600/25000 Btu
18
12
5° F £T £115° F
208V\230V /60Hz/1P
5.28PT/H
48/44/40/35dB (A)
35.27 lb
46.3 lb
12.4" x 39.68" x 8.622"
0.47 A
4
cross flow
1400 rpm
35 W
0.45 A
aluminum fin & copper tube
window
inner-wing
2
¢ 7.15 mm (9/32")
¢ 16 mm (5/8")
microprocessor
lcd wireless
16-30° C
24 hr
3 pieces
manual
swing
built-in
yes
no
washable, anti-mold
C-6RZ146H1A
twin rotary DC inverter
8.4 A
41 A
A
B
CFRS224YC2 Outdoor
B
A
C
FRS224YW2 Indoor
PRODUCT DIMENSIONS
Indoor –
A - Height
B - Width
C - Depth
Max. Wall Thickness
Outdoor –
A - Height
B - Width
C - Depth
12-7/16"
39-11/16"
8-7/8"
18"
31-1/8"
36-1/4"
14-5/8"

SS-FRS224YS2-06/11-1
POWER
Circuit Amps
Maximum Fuse Size
CAPACITIES
Cooling
Amps
Watts
Min/Max Cooling
SEER
EER
Low Ambient Temperature
Voltage/Frequency/Phase
Dehumidification
INDOOR UNIT
Sound Rating
Net Weight
Shipping Weight
Dimensions (H x W x D)
Full Loaded Amps
Number of Fan Speeds
Fan Type
Motor Watts
Full Loaded Amps
COMPRESSOR
Type
Amps
Locked Rotor Amps
14.0/12.8 A
25 A
21500 Btu
9.05/8.19 A
1790 W
9600/25000 Btu
18
12
5° F £T £115° F
208V\230V /60Hz/1P
5.28PT/H
48/44/40/35dB (A) B60
35.27 lb
46.3 lb
12.4" x 39.68" x 8.622"
0.47 A
4
cross flow
35 W
0.45 A
C-6RZ146H1A
twin rotary DC inverter
8.4 A
41 A
Job: ______________________________
Location:__________________________
Engineer:__________________________
Submitted to: ______________________
Reference:_________________________
Approval: _________________________
Date: _____________________________
Submitted by:______________________
Construction: ______________________
Unit Number: ______________________
Drawing Number:___________________
A
B
CFRS224YC2 Outdoor
B
A
C
FRS224YW2 Indoor
OUTDOOR UNIT
Sound Rating
Net Weight
Shipping Weight
Dimensions (H x W x D)
Recommended Fuse
Minimum Amps
Running Current
Drive Type
Motor Watts
CFM (high)
FEATURES
Controls
Remote Control
Temperature control
Timer
Air Louvers
Horizontal
Vertical
Low Voltage Restart
Self-Diagnosis
Quiet Operation
Air Filter
REFRIGERANT SYSTEM
Refrigerant
Ounces
Lineset
Maximum Height
Maximum Line length
Discharge Vapor Line (od)
Suction (od)
£ 56 dB (A)
119.04 lb
132.27 lb
27.56" x 35.04" x 13.38"
25 A
14 A
14.0/12.8 A
dc motor
90 W
2500
microprocessor
lcd wireless
16-30° C
24 hr
3 pieces
manual
swing
built-in
yes
no
washable, anti-mold
R410A
63.49
16.4 ft
49.2 ft
98.43 ft
F 6 mm (1/4")
F 16 mm (5/8")
Ductless Mini-Split System Air Conditioners
Submittal Sheet
FRS224YS2
PRODUCT DIMENSIONS
Indoor –
A - Height
B - Width
C - Depth
Max. Wall Thickness
Outdoor –
A - Height
B - Width
C - Depth
12-7/16"
39-11/16"
8-7/8"
18"
31-1/8"
36-1/4"
14-5/8"
