Frigidaire FAS185J2A3 User manual

PRODUCT NO. BASE MODEL NO. MARKET BTU-COOLING
FAS185J2A3 FAS185J2A USA 18000BTU
Publication No.
5995355467
010630
-EN/SERVICE /DJH
345
ROOM AIR CONDITIONER
Model No.
FAS185J2A
©2001 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
ROOM AIR CONDITIONER
WIRING DIAGRAM - # 309343701
OWNER’S GUIDE - # 309000823
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O.BOX 212378, AUGUSTA, GA 30917

08/01 2
Publication No. FAS185J2A
5995355467
CABINET FRONT AND WRAPPER

# = Fast-moving Parts 3 08/01
* = Non-Illustrated Parts
FAS185J2A Publication No.
5995355467
CABINET FRONT AND WRAPPER
POS. NO PART NO DESCRIPTION
1 309632704 Cabinet,sleeve ,top louvers
2 309632804 Grille,rear ,with rail
7 309631104 Link,vertical louver
8 309633305 Louver Assy,horizontal
9 309631004 Louver
12 309631404 Filter-air,molded plastic
17 309633205 Front-cabinet,complete assy
19 309341002 Overlay,Frig Gallery
25 309321401 Door-vent,actuator
26 309330206 Detent Assy-vent,with adhesive
26 309330404 Handle-vent,gray
26A 309330202 Detent-vent
43 309630904 Panel,cabinet front
70 309342401 Enclosure,elec control mt
78 309350502 Remote Control,transmitter ,with batteries

08/01 4
Publication No. FAS185J2A
5995355467
CONTROLS

# = Fast-moving Parts 5 08/01
* = Non-Illustrated Parts
FAS185J2A Publication No.
5995355467
CONTROLS
POS. NO PART NO DESCRIPTION
7 309630403 Control Box
10 309623601 Bulkhead,control system
10* 309331801 Clip-control bulb,(2)
13 # 5303317228 Capacitor,370 V ,30+6
14 3015312 Screw,8-18AB x 0.500
15 5303303077 Strap-capacitor
16 # 5304408751 Wiring Harness
17 # 309343112 Cord-service,type C 16AWG
70 309342401 Enclosure,elec control mt
71 # 309350401 PC Board,power,Sagem
72 # 309350403 Board-input,Sagem HD
72* 5304417643 Ribbon Protector
74 5303301590 Screw-bracket
75 5304413781 Support-pc board
76 309111602 Transformer,240/12 Volt

08/01 6
Publication No. FAS185J2A
5995355467
AIR HANDLING PARTS

# = Fast-moving Parts 7 08/01
* = Non-Illustrated Parts
FAS185J2A Publication No.
5995355467
AIR HANDLING PARTS
POS. NO PART NO DESCRIPTION
1 # 5303311048 Fan Blade,with clamp
2 3202975 Screw,10-16 x 0.72 ,square drive
3 5303015305 Housing-fan,upper
4 3016696 Seal,fan housing ,upper
5 5303015311 Seal,fan housing ,lower
6 5303015304 Housing-fan,lower
8 # 309630603 Motor-fan,GE 3sp ,48/fr ,230/60
9 5303015306 Bracket,shroud/bulkhead
10 309623401 Bulkhead,air system
11 309633001 Blower Wheel,plastic ,with clamp
13 309630302 Cover-top
15 309630101 Housing-blower,evap scroll
20 309630201 Plate-blower housing,scroll plate

08/01 8
Publication No. FAS185J2A
5995355467
COMPRESSOR PARTS

# = Fast-moving Parts 9 08/01
* = Non-Illustrated Parts
FAS185J2A Publication No.
5995355467
COMPRESSOR PARTS
POS. NO PART NO DESCRIPTION
1 # 5304403268 Compressor
2 5303286606 Grommet,compressor mtg ,(3)
3 5308006948 Nut,compressor mtg ,(3)
5 5303002069 Wire-Bale,terminal cover
6 5303002068 Gasket,terminal cover
7 5303002067 Cover,compr terminal
11 # 309634101 Evaporator
12 # 5303306719 Condenser
13 309623501 Tray-evaporator
14 309632906 Base stud ASSY
16 5308017120 Capillary Tube,45 inch long ,cut to length
19 5303002664 Washer,compressor mtg
19* 309112501 Washer,metallic

08/01 10
Publication No. FAS185J2A
5995355467
WINDOW MOUNTING PARTS

# = Fast-moving Parts 11 08/01
* = Non-Illustrated Parts
FAS185J2A Publication No.
5995355467
POS. NO PART NO DESCRIPTION
1 5304407729 Seal-window frame,stuffer
4 5304414928 Frame,LH
4 309313303 Kit-window mounting,heavy duty
5 5304409250 Seal-top rail
6 5304414933 Retainer,accordian
7 309313204 Kit-mounting support
7 5304414105 Bracket-support,RH
7* 5304409248 Hardware-mounting
11 5304414106 Bracket-support,LH
14 5304414929 Frame,RH
15 5304414930 Closure,accordian type ,window mount
16 5304414116 Rail,top
18 5303303691 Screw,truss head ,8-18AB x 0.375 ,w/nibs
21 5303212504 Seal-sleeve/chassis,bottom
* 5304409249 Seal-hole,shipping screws
WINDOW MOUNTING PARTS

08/01 12
Publication No. FAS185J2A
5995355467
WIRING DIAGRAM
