Frigidaire FEC30C4ACB Instruction Manual

PRODUCT NO. BASE MODEL NO. FACTORY NO. COLOR MARKET
FEC30C4ACB FEC30C4A 38054211610C2 stainless North America
FEC30C4AQB FEC30C4A 3805421161042 bisque North America
FEC30C4ASB FEC30C4A 3805421161012 white North America
Publication No.
5995365862
020213
-EN/SERVICE /ECL
377
ELECTRIC
COOKTOP
Model No.
FEC30C4A
©2002 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
RANGE
WIRING DIAGRAM - # 318046901
OWNER’S GUIDE - # 318200612
INSTALLATION INSTRUCTIONS - # 318201410
ELECTROLUX HOME PRODUCTS, INC.
P.O. BOX 212378, Augusta, GA 30917

02/02 2
Publication No. FEC30C4A
5995365862
CONTROL PANEL

# = Functional Parts 3 02/02
* = Non-Illustrated Parts
FEC30C4A Publication No.
5995365862
CONTROL PANEL
A = FEC30C4A (FEC30C4ASB)
B = FEC30C4A (FEC30C4ACB)
C = FEC30C4A (FEC30C4AQB)
POS. NO PART NO DESCRIPTION
14 # 3200297 A B C Light/Lamp,indicator
16 5303301457 A B C Plate,instrument mtg
16A 5303301458 A B C Cover,instrument mtg.
19 318021611 A - - Panel,overlay ,white
19 318021613 - B - Panel,overlay ,black
19 318021612 - - C Panel,overlay ,bisque
36 318196633 A - - Knob,control ,white
36 318196634 - B - Knob,control ,black
36 318196635 - - C Knob,control ,bisque
46 5303299764 A B C Lens,indicator light
54 # 318120504 A B C Switch,surface unit ,(4)
69 5303305528 A B C Screw,8-32 x 1/4
74 318146010 A B C Bushing,switch
* 5304410665 A B C Screw,10-32 x 5/8

02/02 4
Publication No. FEC30C4A
5995365862
MAINTOP / SURFACE UNITS

# = Functional Parts 5 02/02
* = Non-Illustrated Parts
FEC30C4A Publication No.
5995365862
MAINTOP / SURFACE UNITS
A = FEC30C4A (FEC30C4ASB)
B = FEC30C4A (FEC30C4ACB)
C = FEC30C4A (FEC30C4AQB)
POS. NO PART NO DESCRIPTION
15 # 5308011964 A B C Element,surface ,large/8 inch ,(2) ,medallion incl
15A# 5303299749 A B C Element,surface ,small/6 inch ,(2) ,medallion incl
16 318159021 A - - Main Top,white
16 318159023 - B - Main Top,stainless
16 318159025 - - C Main Top,bisque
17 3016817 A B C Rod,maintop support
18 318074310 A B C Hinge,maintop ,(2)
19 # 318067056 A B C Pan,surface element ,large ,chrome
19A# 318067046 A B C Pan,surface element ,small ,chrome
27 # 5303323704 A B C Terminal Block,surface element
28 5303301461 A B C Medallion,surface element
46 318077401 A B C Burner Box
93 318122500 A B C Support,terminal block ,(4)
136 5303935029 A B C Support
137 5303323138 A B C Screw,10-24x1/2
140 318216000 A B C Spacer,installation
183 5304410665 A B C Screw,10-32 x 5/8
* # 5303323364 A B C Box & wires assy
* 5303300195 A B C Screw,10-32 x 0.375 ,terminal block ,(2)
* 5303308449 A B C Fastener
* 5303311532 A B C Screw,6-32 x 1/4" ,back

02/02 6
Publication No. FEC30C4A
5995365862
WIRING DIAGRAM
