Frigidaire FGEF3031KBA Service Instruction Manual

LGEF3031KBA.eps CFGEF3031KBA.eps VLGEF3031KBA.eps TFGEF3031KBA.eps
DLGEF3031KBA.eps
Product No. FGEF3031KBA FGEF3031KQA FGEF3031KWA
Series 30" f/s elec 30" f/s elec 30" f/s elec
Color black bisque white
Market North America North America North America
Owner's Guide 316902203 316902203 316902203
Installation Instructions 316454912 316454912 316454912
Service Data Sheet 316904414 316904414 316904414
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995539144
09/04/29
(EN/SERVICE/ECL)
369
30-INCH FREE-
STANDING ELECTRIC
RANGE
Model No.
FGEF3031K
Copyright ©2009 Home Products, Inc.
All rights reserved.

Publication No: 5995539144 FGEF3031K
04/09 2
BACKGUARD
13A 14
14
14
54B
54
31
31
54
54B
14
1414
CFGEF3031KBA
56
1
15A
15
19
20A
20
69
31
21
46

FGEF3031K Publication No: 5995539144
# Functional Parts 3 04/09
* Non-Illustrated Parts
BACKGUARD
Model Index: AFGEF3031K (FGEF3031KBA)
BFGEF3031K (FGEF3031KQA)
CFGEF3031K (FGEF3031KWA)
POS. NO PART NO. DESCRIPTION
1 316557600 A B C Shield, rear wall
13A# 316095503 A B C Switch, infinite, warmer
14 316022500 A B C Light/Lamp, indicator, 125 V
15 316546702 A - - Cap, backguard, black, RH end
15 316546706 - B - Cap, backguard, bisque, RH end
15 316546704 - - C Cap, backguard, white, RH end
15A 316546703 A - - Cap, backguard, black, LH end
15A 316546707 - B - Cap, backguard, bisque, LH end
15A 316546705 - - C Cap, backguard, white, LH end
19 316572420 A - - Panel, backguard, black
19 316572421 - B - Panel, backguard, bisque
19 316572419 - - C Panel, backguard, white
20 # 316418300 A B C Clock/Timer, electronic, ES330
* 316021110 A B C Screw, 8-18 x 0.5, black
20A 316419333 A - - Overlay, clock, black, ES330
20A 316419334 - B - Overlay, clock, bisque, ES330
20A 316419332 - - C Overlay, clock, white, ES330
21 316546601 A - - Cap, backguard, black, top
21 316546603 - B - Cap, backguard, bisque, top
21 316546602 - - C Cap, backguard, white, top
31 316564402 A - - Knob, control, black, (5)
31 316544210 - B - Knob, control, bisque, (5)
31 316544206 - - C Knob, control, white, (5)
46 316557300 A B C Lens-light/lamp, indicator, clear
54 316436000 A B C Switch, infinite, small element
54B# 316436001 A B C Switch, infinite, large element
56 316234013 A - - Shield, backguard, black, inner
56 316234014 - B - Shield, backguard, bisque, inner
56 316234012 - - C Shield, backguard, white, inner
69 5303288565 A B C Screw, truss sqdr, 8-32 x 3/16, switch mtg
* 316021105 A B C Screw, hex head cup pt, 8-18 x 0.375, black
* 316089500 A B C Screw, 10-16 x .486

Publication No: 5995539144 FGEF3031K
04/09 4
BODY
5A
5A 5
12
ANTI-TIP
BRACKET
ANTI-TIP
BRACKET
NOTE: Oven Liner N/A
Ass. du four N/A
21
3
5
170
151
87
57
71
89
88
1
86
58A
58B
18
86
66
68
10
9
37
8
67
8A
58
6
42
170
3
151
43
VLGEF3031KBA
59
59A
45
25
17
16
15
14
29
44
44
62
63
6
6A

FGEF3031K Publication No: 5995539144
# Functional Parts 5 04/09
* Non-Illustrated Parts
BODY
Model Index: AFGEF3031K (FGEF3031KBA)
BFGEF3031K (FGEF3031KQA)
CFGEF3031K (FGEF3031KWA)
POS. NO PART NO. DESCRIPTION
1 316401801 A B C Panel, main back
3 316400118 A - - Panel, bodyside, black, RH
3 316400119 A - - Panel, bodyside, black, LH
3 316400120 - B - Panel, bodyside, bisque, RH
3 316400121 - B - Panel, bodyside, bisque, LH
3 316400116 - - C Panel, bodyside, white, RH
3 316400117 - - C Panel, bodyside, white, LH
5 316272900 A B C Screw, leveling, plastic, rear, (2)
5A 316498900 A B C Leveling Leg Assy, metal, front, (2), bracket & leg
6 316496202 A B C Rack, oven, (1)
6A 316496206 A B C Rack, oven, (1)
8 316400601 A B C Panel, oven bottom
8* 316064600 A B C Support, oven bottom
8A 316411104 A B C Base, bake element
9 316081900 A B C Pan, broiler, OPTIONAL ACCESS0RY
10 316082000 A B C Insert, broiler pan, OPTIONAL ACCESS0RY
12 # 316445500 A B C Switch, oven light, door frame
14 # 316116400 A B C Receptacle, oven light
15 # 316538901 A B C Lamp, oven light
16 318406100 A B C Lens, oven light, glass
17 316087500 A B C Retainer, lens
18 # 316405800 A B C Latch Assembly, oven door
* 5303285179 A B C Screw, wafer head, 8-32T x 0.500, black
21 316408000 A B C Clip, bodyside
25 316406200 A B C Shield, heat, lower
29 316407301 A B C Glide, drawer, front
37 # 316490000 A B C Probe, oven temp
42 316407700 A B C Shield, wool, lower
43 3131732 A B C Screw, 8-18 x 1.438, oven bottom
44 316517600 A B C Spacer, oven door
45 316234100 A B C Shield, wire, vent tube
57 316457801 A B C Cover, access
58 316403802 A B C Insulation, oven sump
58A 316406602 A B C Insulation, oven wrapper
58B 316406500 A B C Insulation, oven back
59 316208401 A B C Vent Tube, assembly, w/catalyst
* 316089500 A B C Screw, 10-16 x .486
59A 316208304 A B C Tube, oven vent, upper
62 # 5303935271 A B C Terminal Block Kit
62* 316001003 A B C Screw, ground wire
62* 316205500 A B C Nut, hex flange, 3/8 10-32
62* 316542200 A B C Insulator
63 316542600 A B C Plate, grounding strap
66 # 316203301 A B C Element, broil
67 # 316413800 A B C Element, bake, hidden
68 316404000 A B C Support, element, broil
71 316422304 A B C Shield, rear wall
86 316441300 A B C Receptacle, hinge
* 316418900 A B C Screw, sims lp, #8-32 x 5/16", black
87 316081200 A B C Bracket, cable mtg
88 316203500 A B C Rod, auto latch
89 # 316464300 A B C Motor-latch
151 316404600 A B C Shield, bodyside
170 316112004 A B C Anti Tip Kit, assembly
170* 316107200 A B C Bracket, anti-tip
170* 316116000 A B C Screw, concrete, 1.75", anti-tip brkt
170* 316541700 A B C Template, anti-tip
* # 316506248 A B C Wiring Harness, main
* 316021105 A B C Screw, hex head cup pt, 8-18 x 0.375, black
* 316021110 A B C Screw, 8-18 x 0.5, black
* 316418901 A B C Screw, trilobe, 10-32 x 5/16", (4)

Publication No: 5995539144 FGEF3031K
04/09 6
TOP/DRAWER
18
18
1
2
4
52
16
26
26B
26
26A
15B
15
15A
15
15C
TFGEF3031KBA
7

FGEF3031K Publication No: 5995539144
# Functional Parts 7 04/09
* Non-Illustrated Parts
TOP/DRAWER
Model Index: AFGEF3031K (FGEF3031KBA)
BFGEF3031K (FGEF3031KQA)
CFGEF3031K (FGEF3031KWA)
POS. NO PART NO. DESCRIPTION
1 316408703 A B C Drawer, utility
2 316403300 A B C Liner, drawer
4 316403502 A - - Panel, drawer front, black
4 316403503 - B - Panel, drawer front, bisque
4 316403501 - - C Panel, drawer front, white
7 316407400 A B C Glide, drawer, rear
15 # 318198846 A B C Element, surface, small/6", 1200 W
15A# 316465001 A B C Element, surface, 9", 3000W, radiant
15B# 318198827 A B C Element, surface, 12", 2700 W
15C# 318198832 A B C Element, surface, warmer, 100 W
16 316531968 A - - Maintop, steel/glass, black
16 316531967 - B - Maintop, steel/glass, bisque/black
16 316531966 - - C Maintop, steel/glass, white/black
18 316436600 A B C Hinge Bracket, maintop, (2)
26 316427600 A B C Channel, element support, (2)
26A 316498200 A B C Bracket-support, chassis, aluminum
26B 316214202 A B C Bracket, chassis support, front
* 316021109 A B C Screw, 8-18 x 0.5, chrome
52 316461700 A B C Clip, element mtg
52* 5308014215 A B C Screw, 6-20 x 0.312
* # 316510672 A B C Harness, wiring, surface
* 316468100 A B C Cleaner, smoothtop, w/sponge
* 316021105 A B C Screw, hex head cup pt, 8-18 x 0.375, black
* 316021110 A B C Screw, 8-18 x 0.5, black
* 316089500 A B C Screw, 10-16 x .486

Publication No: 5995539144 FGEF3031K
04/09 8
DOOR
60B
10
3
4
52
39
7
6
DLGEF3031KBA
17
17
23
23
16
9
12
8

FGEF3031K Publication No: 5995539144
# Functional Parts 9 04/09
* Non-Illustrated Parts
DOOR
Model Index: AFGEF3031K (FGEF3031KBA)
BFGEF3031K (FGEF3031KQA)
CFGEF3031K (FGEF3031KWA)
POS. NO PART NO. DESCRIPTION
3 5303935317 A - - Trim kit-door, 3 sided, black, w/tape
3 5303935319 - B - Trim kit-door, 3 sided, bisque, w/tape
3 5303935318 - - C Trim kit-door, 3 sided, white, w/tape
4 316566408 A - - Glass Assembly, outer, black, w/badge
4 316566407 - B - Glass Assembly, outer, bisque, w/badge
4 316566406 - - C Glass Assembly, outer, white, w/badge
6 316406310 A B C Shield, wool
* 316021109 A B C Screw, 8-18 x 0.5, chrome
7 316405600 A B C Insulation, oven door
8 316117500 A B C Glass, oven door, heat barrier
9 316423701 A B C Liner, oven door
10 316433300 A B C Screw, 10-14 x 2.125", handle mtg.
12 316405000 A B C Seal, oven door
16 316117501 A B C Glass, oven door, inner
17 316402403 A B C Spacer, door glass, (2)
23 316456303 A B C Hinge, oven door, blue titan, (2)
23* 316418900 A B C Screw, sims lp, #8-32 x 5/16", black
39 316544500 A - - Handle, door, black
39 316544502 - B - Handle, door, bisque
39 316544501 - - C Handle, door, white
52 316468401 A - - Cap, door trim, black
52 316468402 - B - Cap, door trim, bisque
52 316468400 - - C Cap, door trim, white
60B 316021110 A B C Screw, 8-18 x 0.5, black
* 316433603 A B C Label, anti-tip
