Frigidaire GLEC30S8A User manual

PRODUCT NO. BASE MODEL NO. FACTORY NO. COLOR MARKET
GLEC30S8AQA GLEC30S8A 3805624361041 bisque North America
GLEC30S8ASA GLEC30S8A 3805623361011 white North America
Publication No.
5995360145
011018
-EN/SERVICE /ECL
377
ELECTRIC
COOKTOP
Model No.
GLEC30S8A
©2001 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
RANGE
WIRING DIAGRAM - # 318047024
OWNER’S GUIDE - # 318200612
INSTALLATION INSTRUCTIONS - # 318201410
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. BOX 212378, Augusta, GA 30917

10/01 2
Publication No. GLEC30S8A
5995360145
CONTROL PANEL

# = Functional Parts 3 10/01
* = Non-Illustrated Parts
GLEC30S8A Publication No.
5995360145
CONTROL PANEL
A = GLEC30S8A (GLEC30S8ASA)
B = GLEC30S8A (GLEC30S8AQA)
POS. NO PART NO DESCRIPTION
16 318096325 A B Box,instrument mtg
36 318196603 A - Knob,control ,white
36 318196605 - B Knob,control ,bisque
36A 318196600 A - Knob,dual control ,white
36A 318196602 - B Knob,dual control ,bisque
51 318044820 A B Light,indicator ,red
54 # 318120505 A B Switch,surface unit ,small/large
54A 318191000 A B Switch,infinite ,dual
69 5303323134 A B Screw,switch mtg. ,8-32 x 0.188
69A 5303305528 A B Screw,8-32 x 1/4
74 5303321205 A B Bushing
* 5303323131 A B Screw,8-32 x 7/16
* 5303323140 A B Screw,ground ,10-32 x 0.375

10/01 4
Publication No. GLEC30S8A
5995360145
MAINTOP / SURFACE UNITS

# = Functional Parts 5 10/01
* = Non-Illustrated Parts
GLEC30S8A Publication No.
5995360145
MAINTOP / SURFACE UNITS
A = GLEC30S8A (GLEC30S8ASA)
B = GLEC30S8A (GLEC30S8AQA)
POS. NO PART NO DESCRIPTION
15 # 316010205 A B Element,surface ,6" ,1200 W ,radiant
15A# 318177900 A B Element,bridge
15B# 316224300 A B Element,dual ,9"/6" ,surface ,2100W/700W,radiant
16 318079351 A - Main Top,white
16 318079352 - B Main Top,black
20 318121902 A B Bracket,retainer
23 318194701 A B Panel,Service ,black
46 318077214 A B Burner Box
52 318122008 A B Spring,element mtg
52A 318122010 A B Spring,element mtg ,1000W/2500W
52B 318122006 A B Spring,element mtg ,small
159 318125112 A B Deflector
162 318161400 A B Deflector
163 08007817 A B Spacer,(6)
170 318124911 A B Screen,thermal
* # 318078523 A B Box & wires assy
* 08016432 A B Screw,truss head ,8-18 x 0.375
* 5303323129 A B Screw,8 X 0.750
* 5303323131 A B Screw,8-32 x 7/16
* 5303323140 A B Screw,ground ,10-32 x 0.375

10/01 6
