Trouble Shooting TipsExploded View of Wash System
Tub and Door Seal
The door seal is pressed into the tub channel for
aninterferencefit.Centerthegasket(markedon
back) at the tub top center and press in place
ProductSpecifications
Electrical
Rating...................................120 Volts, 60Hz
Separate Circuit..15 amp min.- 20 amp max.
Motor (Amps) ........................................... 1.8
Heater Wattage.......................................900
Total Amps (load rated).........................10.0
TempAssure .............................. 140°F ±5°F
(60°C±3°C) [with outer door in place]
TempBoost.............145°F ±5°F (63°C ±3°C)
Heated Wash/Heated Rinse
Sanitize ..................150°F ±5°F (66°C ±3°C)
Hi-Limit Thermostat ................ 200°F (93°C)
Water Supply
Suggested minimum incoming water
temperature............................. 120°F (49°C)
Pressure (PSI) min./max.................... 20/120
Connection (NPT) .....................................3/8"
Consumption (Normal Cycle).......................
.............4.9 - 9.7 U.S. gal., 18.5 - 36.7 liters
Water valve flow rate (U.S. GPM)........... .83
Water recirculation rate (U.S. GPM) ..............
.................................................... approx. 12
Water fill time.....................................87 sec.
To replace dispenser:
• shut off electricity to dishwasher,
• remove outer door panel assembly,
• disconnect wiring to the actuator,
• remove the six screws,
• remove the dispenser,
• replace and reinstall screws,
• rewire actuator.
Check the Following
1. Fuse (blown or tripped).
2. 120 VAC supply wiring connection
faulty.
3. Electronic control board defective.
4. No 12 VAC power to control.
5. Motor (inoperative).
6. Door switch (open contacts).
7. Door latch not making contact with
door switch.
8. Touch pad circuit defective.
9. No indicator lamps illuminate when
STARTorOPTIONSarepressed.
1. Motor(badbearings).
2. Motor stuck due to prolonged
non-use.
1. Improper voltage.
2. Motor windings shorted.
3. Glass or foreign items in pump.
1. Heaterelement (open).
2. Electronic control board defective.
3. Wiring or terminal defective.
4. Hi-Limit thermostat defective.
1. Latch mechanism defective.
2. Electronic control board defective.
3. Wiring or terminal defective.
4. Broken spring(s).
5. Defective actuator.
1. Drain restricted.
2. Electronic control board defective.
3. Defective drain pump.
4. Blockedimpeller.
5. Openwindings.
6. Wiring or terminal defective.
1. Water supply turned off.
2. Defective water inlet fill valve.
3. Check fill valve screen for
obstructions.
4. Defective float switch.
5. Electronic control board defective.
6. Wiring or terminal defective.
7. Float stuck in “UP” position.
1. Drain hose (high) loop too low.
2. Drain line connected to a floor drain
not vented.
1. Detergentallowedtostandtoolongin
dispenser.
2. Dispenser wet when detergent was
added.
3. Detergentcoverheldclosedorblocked
by large dishes.
4. Improperincoming water
temperature to properly dissolve
detergent.
5. See "Detergent cover will not open."
Always disconnect the dishwasher from the electrical power source before adjusting or
replacing components.
Personal Injury Hazard
900WattHeater
Refer to the cycle chart on the reverse side to
determinewhentheheaterisonduringthewash
cycle. The heater cycles ON and OFF for brief
periods during the drying cycle.
Voltage checks of the heater should be made in
the dry portion of the service test mode.
isattachedbyawormgearclamptothedischarge
end of the drain pump.
The drain hose must have a loop at a
minimum
height of 32 inches
in order to insure proper
drainage.
The main pump can easily be removed by
disconnecting the upper spray arm supply tube
hose,the drain pumpconnector hose, thewiring
harness connections made at the circulation
motor, the water heat thermistor located on the
bottom of the pump and rotating the four sump
retainers toward the middle of the sump.
PumpAssembly
The pump assembly is driven by a synchronous
motor. Rotation is in the counterclockwise
directionat3600RPM. The motor drives apump
which supplies 100 percent filtered water at a
rate of approximately 12 GPM to one spray arm
atatime.Thesprayarm’soperationisalternated
by small “pauses” of the motor during the wash
cycle.
Draining is accomplished by using a small
separate synchronous drain pump mounted to
the side of the sump. The drain pump is
connected to the main pump by a small rubber
hose. The drain check valve is located at the
dischargeendofthe drain pump. The drain hose
withoutstretchingorbunching.Thegaskettakes
a short turn at the bottom of the tub channel
before ending at the channel end wall.
Short Turn
Gasket Cross Section
DetergentandRinseAidDispenser
The detergent and rinse aid dispenser is a one
piece component consisting of a molded
detergent cup and a built-in rinse aid dispenser.
The detergent cup has a spring loaded cover
and the rinse aid dispenser has a removable
cover.
Liquid rinse aid is added to the dispenser up to
the fill line indicator. The amount of rinse aid
released can be adjusted by turning the arrow
indicator from one, being the least amount, to
four, being the greatest amount.
Mounting
Rib
Tub
Interior
Remedy
1. Replace fuse or reset breaker.
2. Repair or replace wire fasteners at
dishwasher junction box.
3. Replace controlboard.
4. Replace controlboard.
5. Replacemotor/impeller assembly.
6. Replace latch assembly.
7. Replace latch assembly.
8. Replace console assembly.
9. Replace console assembly.
1. Replace motor assembly.
2. Rotatemotor impeller.
1. Check voltage.
2. Replacemotor/impeller assembly.
3. Clean and clear blockage.
1. Replace heaterelement.
2. Replace controlboard.
3. Repair or replace.
4. Replacethermostat.
1. Replacedispenser.
2. Replace controlboard.
3. Repair or replace.
4. Replacedispenser.
5. Replacedispenser.
1. Clear restrictions.
2. Replace controlboard.
3. Replacepump.
4. Check for blockage, clear.
5. Replacepumpassembly.
6. Repair or replace.
1. Turn water supply on.
2. Replace water inlet fill valve.
3. Disassemble and clean screen.
4. Repair or replace.
5. Replace controlboard.
6. Repair or replace.
7. Clean float.
1. Repair to proper
32-inch minimum
height
.
2. Install air gap at counter top.
1. Instruct customer/user.
2. Instruct customer/user.
3. Instruct customer/user on proper
loading of dishes.
4. Incoming watertemperatureof
120°F is required to properly
dissolve dishwashing detergents.
Symptom
Dishwasherwill notoperate when
turnedon.
Motor hums but will not start or run.
Motortripsout oninternalthermal
overloadprotector.
Dishwasherrunsbut willnotheat.
Detergent cover will not latch or
open.
Dishwasherwill notpumpout.
Dishwasher will not fill with water.
Dishwasherwatersiphonsout.
Detergentleft indispenser.
StandardDry AirFlow
Whenthecontroladvancestothe“dry”portion of
thecycle,alinearactuatorretractsavalve,which
opens a vent path through the console into the
kitchen. The heated, moist air leaving the
dishwasher through the console vent causes
drierairto be drawn into theunitbywayof intake
020905
ventslocatedatthebottomofthedoor.Thewater
on the dishes is evaporated into drier air and the
ventingprocess continues. Theheatingelement
is turned ON and OFF during the entire drying
cycle.
TUB
TUB
TUB
TUB
Lower
Spray Arm
Middle
Spray Arm
Assy.
3rd Level
Spray Arm
Assy.
Delivery
Tube
Soil
Director
Volute
Cover
Check
Ball
Glass
Trap Spray Arm
Support
Soil
Filter Filter
Sump
Housing
Sump
Gasket
Heating
Element
Water
Bottle
Water
Valve
Water
Inlet Tube
Circulation
Motor
Motor
Bracket Drain
Pump
S
E
R
V
I
C
E DATA
S
H
EET
P/N: 154768401
Electronic Series
Color Code
BK......................... Black
BU............................Blue
PK............................Pink
R...............................Red
R-BK...............Red/Black
R-Y................Red/Yellow
VIO.........................Violet
W...........................White
Wiring Diagram
Display Codes (LED)Display Codes (Readout)
SENSING
WAS HING
SANITIZED
DRYING
CLEAN
OPTION LED's Flashing
STATUS LED's Flashing
---------------------- Turbidity sensor is checking the condition of the wash/rinse water.
No sensing for LIGHT WASH (UPPER RACK), LIGHT WASH (LOWER RAC K) and CHINA/CRYSTAL.
---------------------- Wash portion of cycle.
-------------------- The SANITIZED criteria has been met. Indicator light will switch off when door is opened.
------------------------ Drying portion of cycle.
------------------------ Shows completion of cycle. Indicator light will switch off when door is opened.
-- HI-TEMP WASH and NO HEAT DRY/POWER DRY OFF LED's flashing indicates power failure has
occurred. Press START/CANCEL pad and reselect desired options and cycle.
-- The STATUS LED's that are lit when the door is opened will flash. Close door.
RINSE AGENT LOW
------- The liquid rinse agent is low. Light will switch off after 5 complete wash cycles or dispenser is filled.
This information is in tended for use by
persons having electrical and
mechanical training and a level of
knowledge of these subjects generally
considered acceptable in the appliance
repair trade. Electrolux Home Products
North America cannot be responsible,
nor assume any liability, for injury or
damage of any kind arising from the
use of this Service Data Sheet.
Operation
LO
PF
Hd or HO
CL
'01-24'
.........Low liquid in the rinse aid dispenser
..........A power failure has occurred
.........Water heating delay
..........Close and latch the door
....Hour(s) delay before start
'01-10’
....Hour(s) delay before start
PUMP MOTOR
DRAIN MOTOR VIO
120VAC
60HZ
USER INTERFACE SWITCH
ELECTRONIC
CONTROL
BOARD
*SOME MODELS
P3-4
P6
*
BU
DISPENSER R-YWP3- 1
W
W
R-BKWP3- 2
*VENT SYSTEMS
HEATER W
HI-LIMIT
THERMOSTAT
*TURBIDITY SENSOR/
THERMISTOR
RP8
WATER VALVE
FLOAT
SWITCH PK P3- 3
W
Y
P3-10
P3-9
*RINS E AID
LEVEL SENSE
BK
BK P2- 6
P2- 5
P3-5
P-5
P3-7
DOOR
SWITCH
W
NEUT W
L1 BK
BK
BK
P3-6
P1
BK P2-1
WP2-2
RP2-3
W
The water/service test is a special function
initiated from the power failure mode or idle
mode.
While in power failure or idle mode
-
simultaneously press the NO HEAT DRY and
START/CANCEL pads for 1 1/2 seconds.
The dishwasher will then step through the test
cycle per the chart. Pushing the START/CANCEL
pad will advance the dishwasher to the next step.
Water/Service Test
(Some models)
(Some models)
(Some models)
Y
*THERMISTOR
Cycle Selection Options

This manual suits for next models

5

Other Frigidaire Dishwasher manuals

Frigidaire FGBD2438PB0A User manual

Frigidaire

Frigidaire FGBD2438PB0A User manual

Frigidaire FDB130RG User manual

Frigidaire

Frigidaire FDB130RG User manual

Frigidaire FDPC4314AS User manual

Frigidaire

Frigidaire FDPC4314AS User manual

Frigidaire Gallery 600 Series User manual

Frigidaire

Frigidaire Gallery 600 Series User manual

Frigidaire FDB949GFT2 User manual

Frigidaire

Frigidaire FDB949GFT2 User manual

Frigidaire FFBD1821MB Owner's manual

Frigidaire

Frigidaire FFBD1821MB Owner's manual

Frigidaire FDB658RA User manual

Frigidaire

Frigidaire FDB658RA User manual

Frigidaire FDBB2865FC0 User guide

Frigidaire

Frigidaire FDBB2865FC0 User guide

Frigidaire FDB736GFS5 User manual

Frigidaire

Frigidaire FDB736GFS5 User manual

Frigidaire FDBS956C User manual

Frigidaire

Frigidaire FDBS956C User manual

Frigidaire Dishcare User manual

Frigidaire

Frigidaire Dishcare User manual

Frigidaire FDB641RA User manual

Frigidaire

Frigidaire FDB641RA User manual

Frigidaire Gallery LGID2475QF Owner's manual

Frigidaire

Frigidaire Gallery LGID2475QF Owner's manual

Frigidaire FDB510LC S User manual

Frigidaire

Frigidaire FDB510LC S User manual

Frigidaire FBD2400K W User manual

Frigidaire

Frigidaire FBD2400K W User manual

Frigidaire DWM-33 Quick reference guide

Frigidaire

Frigidaire DWM-33 Quick reference guide

Frigidaire FPHD2481KF - Professional 24" -Built User guide

Frigidaire

Frigidaire FPHD2481KF - Professional 24" -Built User guide

Frigidaire FDB935RH User manual

Frigidaire

Frigidaire FDB935RH User manual

Frigidaire FDB949GFT1 User manual

Frigidaire

Frigidaire FDB949GFT1 User manual

Frigidaire LFID2422RF4B Owner's manual

Frigidaire

Frigidaire LFID2422RF4B Owner's manual

Frigidaire FDB857RJ User manual

Frigidaire

Frigidaire FDB857RJ User manual

Frigidaire GLDB958A User manual

Frigidaire

Frigidaire GLDB958A User manual

Frigidaire Gallery FGHD2455LF User manual

Frigidaire

Frigidaire Gallery FGHD2455LF User manual

Frigidaire FDB954SD Instruction Manual

Frigidaire

Frigidaire FDB954SD Instruction Manual

Popular Dishwasher manuals by other brands

Electrolux MDB125RHD3 Use & care manual

Electrolux

Electrolux MDB125RHD3 Use & care manual

Electrolux 534058 user manual

Electrolux

Electrolux 534058 user manual

Zanussi 534324 Technical data

Zanussi

Zanussi 534324 Technical data

Fisher & Paykel DISHDRAWER DD24DAX9N user guide

Fisher & Paykel

Fisher & Paykel DISHDRAWER DD24DAX9N user guide

Bosch S187TC800E INFORMATION FOR USE

Bosch

Bosch S187TC800E INFORMATION FOR USE

Electrolux FAVORIT 40860 user manual

Electrolux

Electrolux FAVORIT 40860 user manual

Baumatic BDW1W/SS instruction manual

Baumatic

Baumatic BDW1W/SS instruction manual

Miele G4780 operating instructions

Miele

Miele G4780 operating instructions

Whirlpool WDF590SAJW user guide

Whirlpool

Whirlpool WDF590SAJW user guide

Kuppersberg GS 4555 Technical Passport

Kuppersberg

Kuppersberg GS 4555 Technical Passport

Siemens SN73HX48VE INFORMATION FOR USE

Siemens

Siemens SN73HX48VE INFORMATION FOR USE

Electrolux ESL 66010 user manual

Electrolux

Electrolux ESL 66010 user manual

Electrolux ESL 679 Instruction book

Electrolux

Electrolux ESL 679 Instruction book

IKEA DW45 owner's manual

IKEA

IKEA DW45 owner's manual

Bosch SHE68M02UC - Semi-Integrated Dishwasher With 6 Wash... Energy guide

Bosch

Bosch SHE68M02UC - Semi-Integrated Dishwasher With 6 Wash... Energy guide

IKEA VILLKORLIG manual

IKEA

IKEA VILLKORLIG manual

Asko D5122 operating instructions

Asko

Asko D5122 operating instructions

Siemens iQ300 SN23HI60AG INFORMATION FOR USE

Siemens

Siemens iQ300 SN23HI60AG INFORMATION FOR USE

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
