  9. Frigidaire FFU21C4CW1 User manual

Frigidaire FFU21C4CW1 User manual

UPRIGHT FREEZER
Base Model:
FFU21C4CW
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
FREEZER
WIRING DIAGRAM - # 216803200
OWNER’S GUIDE - # 216802800 / ENERGY GUIDE - # 216795105
SERVICE DATA SHEET - # 216803200
PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FFU21C4CW1 FFU21C4CW 134A white 115
MARKET
North America
Publication No.
5995393328
030728
-EN/SERVICE /MLR
365
ELECTROLUX HOME PRODUCTS, INC.
P.O BOX 212378, AUGUSTA , GA 30917
07/03 2
Publication No FFU21C4CW1
5995393328
2
5
1
9
93
27
27
P08D0368
32
64
13
21A
22A
14
22
14
11
28
12
26
93
93 37A
37A
18
DOOR
# = Fast-moving Parts 3 07/03
* = Non-Illustrated Parts
FFU21C4CW1 Publication No.
5995393328
DOOR
POS. NO PART NO DESCRIPTION
1 216522312 Gasket-door,white
2 5303925107 Lock Assy
5 # 216702900 Key,lock
9 216528113 Panel-inner door,frzr
11 216531218 Panel-outer door,white
12 216892800 Nameplate
13 08016354 Door Stop
14 5303313518 Washer,sealing
18 218762701 Handle-door,white
21A 08005520 Screw,door stop mtg ,4.0 x 0.7-19.7 ,flat hd,metric
22 5303925197 Bearing,hinge ,top
22A 216503200 Bearing,hinge ,bottom
26 216524200 Gasket,secondary
27 5303212828 Clip,panel mtg
28 216807700 Rack-door,(6) ,wide
32 5309950074 Valve,breather ,door base
37A 215870619 Trim-handle,2.47" ,white ,w/chrome band
37A* 218676001 Band-decorative,chrome ,handle trim
64 216403700 Plug-button,hole filler ,door base
93 5303161215 Screw,ph truss head ,8-18AB x 0.500
07/03 4
Publication No FFU21C4CW1
5995393328
CABINET
6
9
9
59
68
69
59A
P08C0660
21
20
86
18
22
24
63
7
35
3
32
29
16
15
26
27 28
14
101
38
39
40
41
34
132
# = Fast-moving Parts 5 07/03
* = Non-Illustrated Parts
FFU21C4CW1 Publication No.
5995393328
POS. NO PART NO DESCRIPTION
3 216502600 Plug,drain ,interior
6 216604100 Breaker Kit w/corners
7 216603600 Breaker Kit w/corners,lock catch
9 216603300 Breaker Kit w/corners,32" ,top or bottom
14 216822900 Switch,light/lamp ,ramp
15 216846400 Light Bulb/Lamp
16 216817600 Socket,light/lamp ,25 W
18 216707200 Knob,temp control
20 216707300 Cover-control housing
21 # 216788100 Control-temperature
22 216823500 Clamp,cap tube ,cold control
24 5300052943 Screw-clamp,truss hd cr ,control
26 216503300 Ramp,door closer
27 5303205738 Screw,hinge mtg ,10 (A) x 0.875 ,btm
28 216247400 Hinge,bottom
29 216313502 Hose-drain
32 5308005500 Drain
34 216816200 Shield-light
35 216273000 Clip,drain hose
38 216808900 Hinge,plate ,top
39 5303294372 Nut-insert,1/4-20 UNC ,hinge
40 216809000 Cover-hinge
41 216850900 Screw,hex washer hd ,1/4 x 7/8 ,hinge mtg
59 216157200 Basket
59A 216486500 Stop-basket
63 216396900 Screw,leveling foot ,plastic ,adjustable
68 08009560 Glide-basket
69 5305878546 Bumper-basket
86 216036600 Screw,ph washer head ,8-32CA x 0.500 ,thread forming
101 216835200 Top Hinge Kit
132 5303283898 Screw,6-20AB x 3/8
* 09948773 Insulation,drain tube
* 5303305324 Paint,touch-up ,white
CABINET
07/03 6
Publication No FFU21C4CW1
5995393328
SYSTEM
# = Fast-moving Parts 7 07/03
* = Non-Illustrated Parts
FFU21C4CW1 Publication No.
5995393328
SYSTEM
POS. NO PART NO DESCRIPTION
1 # 5300083897 Condenser
3 216847806 Trim-shelf,evaporator ,(4)
4 216634500 Drier-filter
5 # 216910900 Harness-main
6 3091418 Support-shelf,front LH
7 08037928 Support-shelf,front RH
11 216474600 Support-rear shelf
12 216225700 Grommet-spacer
13 216138900 Screw,hex sems ,8-18AB x 1.00 ,evap
15A# 216401500 Heat Exchanger
26 5303298960 Spacer-tube,0.237" ID
27 218513300 Grommet-compr mtg,(4)
29 # 216836600 Compressor,w/o electricals
30 # 216649316 Controller
32 218973501 Clamp,elec cont mtg ,compressor
35 240491501 Screw-compr mtg,hex washer hd ,1/4-28 x 1.16,shoulder,typ CF
36 # 216070900 Grid-top evaporator
37 # 216071000 Shelf-top evaporator
38 # 216071100 Shelf-middle evaporator
39 # 216071200 Shelf-third evaporator
40 216071300 Shelf-bottom evaporator
43A 216629700 Clip
55 # 218909913 Capacitor-run,220 VAC ,15 microfarad
86 216036600 Screw,ph washer head ,8-32CA x 0.500 ,thread forming
* 216502500 Sleeve,suction line
