Frigidaire FFC07C2CW User manual

P08F0026.EPS P08d0288.e
p
s
p
08c0675.e
p
s P08S0305.e
p
s
Product No. FFC07C2CW1
Series 134A
Color white
Volts 115
Wiring Diagram 216787900
Owner's Guide 216802800
Market North America
Energy Guide 216793908
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995399747
03/12/05
(EN/SERVICE/LR)
365
FREEZER CHEST
Model No.
FFC07C2CW
Copyright 2003 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995399747 FFC07C2CW1
12/03 2
DOOR

FFC07C2CW1 Publication No: 5995399747
# Functional Parts 3 12/03
* Non-Ilustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
1 216480901 Gasket, door seal, white
9 216061602 Panel-inner lid, white
10 216141101 Plug button, white
11 216113100 Panel-lid
12A 216816801 Insert-nameplate
18 216446600 Handle
27 5303212828 Clip, panel mtg
40 216922700 Fastener, .330 dia stud, handle, (2)
* 5303917276 Insulation-door, fiberglass, (bulk)

Publication No: 5995399747 FFC07C2CW1
12/03 4
CABINET

FFC07C2CW1 Publication No: 5995399747
# Functional Parts 5 12/03
* Non-Ilustrated Parts
CABINET
POS. NO PART NO. DESCRIPTION
3 216502600 Plug, drain, interior
4 216073905 Plug-drain, exterior
6 216855702 Breaker, side
11 216855706 Breaker-ends, white
18 216707200 Knob, temp control
21 # 216787700 Control-temperature
27 216337700 Screw, hex washer head, 10-24 x 0.500
28 216478800 Hinge Assy
30 216105500 Breaker-corners, white
59 216848200 Basket
71 131168200 Screw, pan head, 8-18B x 0.31
75 216782000 Panel-access, white
* 5303305324 Paint, touch-up, white
* 216793908 Energy Guide

Publication No: 5995399747 FFC07C2CW1
12/03 6
SYSTEM

FFC07C2CW1 Publication No: 5995399747
# Functional Parts 7 12/03
* Non-Ilustrated Parts
SYSTEM
POS. NO PART NO. DESCRIPTION
1 # 5300120780 Condenser
4 216634500 Drier-filter
5 # 216711500 Harness-main
22 216056400 Clip, compressor mtg, SPRING
27 5308002681 Grommet, compressor
29 # 216784200 Compressor, w/o electricals
30 216649314 Controller
32 216649200 Clip, controller
55 # 218909912 Capacitor-run, 220 VAC, 12 microfarad
85 216818300 Wire-ground
86 216707700 Screw, 8-18 X 1/2
