Frigidaire FGB24T3E C User manual

FGB24T3E.eps CFGB24T3ESA.eps LA00BR84410-1.eps BFGB24T3ESC.eps
LA00D84410-1.eps 318046309.eps
"
Bake
Broil
Timer
On/Off
Clear
Off
Clock
Set
Product No. FGB24T3EBC FGB24T3ESC
38454412B5063 38454412B5013
Series 24" double gas 24" double gas
Color black white
Market North America North America
Wiring Diagram 318046309 318046309
Owner's Guide 318200956 318200956
Installation Instructions 318201554 318201554
Timer Guide 318200144 318200144
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995474862
06/09/22
(EN/SERVICE/ECL)
377
DOUBLE GAS WALL
OVEN
Model No.
FGB24T3E
Copyright ©2006 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995474862 FGB24T3E
09/06 2
CONTROL PANEL

FGB24T3E Publication No: 5995474862
# Functional Parts 3 09/06
* Non-Illustrated Parts
CONTROL PANEL
Model Index: AFGB24T3E (FGB24T3ESC)
BFGB24T3E (FGB24T3EBC)
POS. NO PART NO. DESCRIPTION
16 318116906 A B Plate, instrument mtg
19 318212504 A - Glass, control panel, white
19 318212505 - B Glass, control panel, black
20 # 316455461 A B Clock/Timer, electronic, ES100
* 08016432 A B Screw, truss head, 8-18 x 0.375
24 # 316090901 A - Switch, oven light, white
24 # 316090900 - B Switch, oven light, black
28 5304410865 A B Tube, timer knob
29 318017710 A - Knob, clock/timer, white
29 318017711 - B Knob, clock/timer, black
64 318110700 A B Bracket, light switch
* 5303211311 A B Screw, 8 x 0.500

Publication No: 5995474862 FGB24T3E
09/06 4
BURNER

FGB24T3E Publication No: 5995474862
# Functional Parts 5 09/06
* Non-Illustrated Parts
BURNER
Model Index: AFGB24T3E (FGB24T3ESC)
BFGB24T3E (FGB24T3EBC)
POS. NO PART NO. DESCRIPTION
14 # 5303210167 A B Regulator, pressure
17 # 5303210156 A B Valve, safety
18 # 5303207603 A B Burner,oven
20 5303317122 A B Baffle, oven burner
21 3201885 A B Nut, Keps, 10-24
26 # 318177710 A B Ignitor, oven burner
28 # 5303295305 A B Valve, shut off
49 5303317124 A B Bracket, safety valve
59 5303317123 A B Bracket, safety valve, support
64 5303295303 A B Retainer, oven burner
* 5303211311 A B Screw, 8 x 0.500
* 5303311333 A B Screw, 8-32 x 3/8
* 5303323135 A B Screw, 10 x 1-7/8

Publication No: 5995474862 FGB24T3E
09/06 6
BODY

FGB24T3E Publication No: 5995474862
# Functional Parts 7 09/06
* Non-Illustrated Parts
BODY
Model Index: AFGB24T3E (FGB24T3ESC)
BFGB24T3E (FGB24T3EBC)
POS. NO PART NO. DESCRIPTION
3 5303317132 A B Wrapper, side, outer
6 318345800 A B Rack, oven, upper & lower, (3)
7 5303298313 A B Hinge Assy, RH lower
7A 5303298312 A B Hinge Assy, LH lower
8 318136500 A B Panel, oven bottom
9 5303317977 A B Pan, broiler
10 5303317976 A B Insert, broiler pan
14 318224000 A B Receptacle, oven light
15 5303013071 A B Bulb/Lamp, light
25 5303317712 A B Shield, heat, lower
29 5303209887 A B Glide, broiler rack
33 5303317128 A B Shield, heat
36 5303298341 A B Flue
37 # 316217005 A B Probe, oven temp
39 318144008 A B Cord, service
56 318028201 A - Trim, oven top
56 318028200 - B Trim, oven top
58A 318285007 A B Insulation, oven back
58D 318285008 A B Insulation, oven wrapper
83 318109511 A B Liner, oven assy
85 5303317711 A B Spring, oven door, lower
85A 318113300 A B Bracket, door spring, lower
85B 5303317126 A B Bracket, door spring, upper
85C 5303207651 A B Spring, oven door, (1)
85D 318166900 A B Sleeve, door spring
97 5303317130 A B Wrapper, top, outer
98 318029003 A - Trim, bodyside, white, RH
98 318029001 - B Trim, bodyside, black, RH
98A 318029002 A - Trim, bodyside, white, LH
98A 318029000 - B Trim, bodyside, black, LH
103 5303316734 A - Trim, base, white, lower
103 5303316735 - B Trim, base, black, lower
121 5303317131 A B Wrapper, back
124 318076801 A B Box, horizontal flue
130 318034601 A - Cap, end top, white, (2)
130 318034600 - B Cap, end top, black, (2)
136 5303317129 A B Angle, rack guide
158 5303207644 A B Seal, door, black, top broiler
158A 5303295311 A B Seal, side, bake oven
216 318034502 A - Cap, end bottom, white, RH
216 318034500 - B Cap, end bottom, black, RH
216A 318034503 A - Cap, end bottom, white, LH
216A 318034501 - B Cap, end bottom, black, LH
242 318027201 A - Trim, center, satin
242 318027200 - B Trim, center, black
244 5303205940 A B Hinge Assy, oven door, RH upper
244A 5303205939 A B Hinge Assy, oven door, LH upper
246 318133600 A B Panel, oven bottom
247 3018717 A B Glide, oven rack
248 5303317121 A B Cap, flue
249 5304400385 A B Wrapper, top, inner
250 318285042 A B Insulation, 3" X 2" X 17.5", (2)
251 318285048 A B Insulation, 2"X 2.5"X 21.5"
* 318232522 A B Wiring Harness, main
* 5303211311 A B Screw, 8 x 0.500
* 5303300265 A B Screw, 8-18 X 1/2, (2)
* 5303311333 A B Screw, 8-32 x 3/8
* 5304400429 A B Screw (8-18 X 1 )

Publication No: 5995474862 FGB24T3E
09/06 8
DOOR

FGB24T3E Publication No: 5995474862
# Functional Parts 9 09/06
* Non-Illustrated Parts
DOOR
Model Index: AFGB24T3E (FGB24T3ESC)
BFGB24T3E (FGB24T3EBC)
POS. NO PART NO. DESCRIPTION
3 318026501 A - Trim, oven door, white
3 318026500 - B Trim, oven door, black
4 318178502 A - Glass, door, white, outer
4 318178503 - B Glass, door, black, outer
6 318116600 A B Shield, wool
7 318285009 A B Insulation, oven door
9 318048901 A B Liner, oven door
10 5304416408 A B Screw, 10-24 x 1.750, handle mtg
16 318042310 A B Glass, door, heat barrier
17 5304400397 A B Fastener, spacer
20 5303300173 A - Spacer, handle, white
20 5303300175 - B Spacer, handle, black
29 318014401 A B Spacer, door
39 318186100 A - Handle, door, white
39 318186101 - B Handle, door, black
54 5303317175 A - Screw, 8-18 X 17/32, white
54 5303308456 - B Screw, 8-18 x 0.531, black
62 08010463 A B Fastener, clip
* 08016432 A B Screw, truss head, 8-18 x 0.375
* 5303211311 A B Screw, 8 x 0.500
* 5303311333 A B Screw, 8-32 x 3/8

Publication No: 5995474862 FGB24T3E
09/06 10
WIRING DIAGRAM
