Frigidaire FED355CC User manual

PRODUCT NO. FACTORY NO. COLOR MARKET
FED355CCSF 37854330E5016 WHITE CANADA
FED355CCSH 37854330E5018 WHITE CANADA
FED355CCBF 37854330E5066 BLACK CANADA
FED355CCBH 37854330E5068 BLACK CANADA
FED355CCTF 37854330E5036 ALMOND CANADA
FED355CCTH 37854330E5038 ALMOND CANADA
ELECTRIC - RANGE
Model No.
FED355CC
©1998 White Consolidated Industries,
Inc.
FACTORY PARTS CATALOG
ELECTRIC DROP-IN RANGE
WIRING DIAGRAM # - 318045021
OWNER’S GUIDE # - 318200805
TIMER INSTRUCTION GUIDE # - 318130805
INSTALLATION INSTR. # - 318064101
FRIGIDAIRE HOME PRODUCTS
7075 ORDAN DRIVE
MISSISSAUGA, ONTARIO
CANADA, L5T 1K6
TEL: [phone] Publication No.
5995315248
981120
-EN/SERVICE
377

Publication No. FED355CCS/B/T
5995315248
11/98 2
BACKGUARD
20
LAP23G0047B
54
54
14
23
69
18A
54 14
54
21
102
19
64 18
36
36
36
36 42
2424
46
46

FED355CCS/B/T Publication No.
5995315248
# = Functional Part 311/98
* = Non-Illustrated Part
BACKGUARD
POS. NO PART NO DESCRIPTION
14 5303051533 AB C D E F Light/Lamp
18 5303304668 AB End Cap white RH
18 5303300160 C D End Cap black RH
18 5303304669 E F End Cap almond RH
18A 5303304671 AB End Cap white LH
18A 5303300161 C D End Cap black LH
18A 5303304672 E F End Cap almond LH
19 318005501 AB Panel-control
19 318005500 C D Panel-control
19 318005547 E F Panel-control
20 # 318012915 AB Clock/Timer
20# 318012917 C D Clock/Timer
20# 318012918 E F Clock/Timer
21 318027804 ATrim-backguard
21 318027801 BTrim-backguard
21 318027803 C Trim-backguard
21 318027800 D Trim-backguard
21 318027805 E Trim-backguard
21 318027802 F Trim-backguard
23 318015020 AC E Bracket-clock mtg
23 318015505 B D F Bracket-clock mtg
24 # 316005607 AB Switch-rocker white
24# 316005602 C D Switch-rocker grey
24# 5303325952 E F Switch-rocker almond
36 318016300 AB Knob-surface unit white
36 5303299751 C D Knob-surface unit almond
36 318016304 E F Knob-surface unit black.
42 318106904 ATrim-vent
42 318106901 B Trim-vent
42 318106903 C Trim-vent
42 318106900 D Trim-vent
42 318106905 E Trim-vent
42 318106902 F Trim-vent
46 5308006417 AB C D E F Lens-light/lamp
54 # 318120501 AB C D E F Switch-surface unit
64 318112200 AB C D E F Plate
69 5303305528 AB C D E F Screw mtg 8-32 X 3/16
102 318055600 AB C D E F Bracket-mounting
*5303211311 AB C D E F Screw, #8 X ½
*08016432 AB C D E F Screw, 8-18 X 3/8
*5303323145 AB C D E F Nut
*5303311124 AB C D E F Screw, clock
A= FED355CC (FED355CCSF)
B= FED355CC (FED355CCSH)
C= FED355CC (FED355CCBF)
D= FED355CC (FED355CCBH)
E= FED355CC (FED355CCTF)
F= FED355CC (FED355CCTH)

FED355CCS/B/T Publication No.
5995315248
11/98 4
BODY
37
63
68
62
71
87
80
LAP23V005C
6
67
25
83
58B
58A
141
10
9
127
12
70
3
70
114
114
1A
62
14
54 15 16
17
81
81
1
59
56
56
41
86
86
76
217
41
66
4134
2A
129
128
88
89 108
142
218
221
220
103

FED355CCS/B/T Publication No.
5995315248
# = Functional Part 511/98
* = Non-Illustrated Part
BODY
POS. NO PART NO DESCRIPTION
1 5303310527 AB C D E F Back-main
1A 5303311161 AB C D E F Panel-back
2A 318108600 AB C D E F Shield-oven top
3 5303300143 AB C D E F Panel-bodyside
4318133400 AB C D E F Burner box
6 5303310522 AB C D E F Rack-oven
9 5303317977 AB C D E F Pan-broiler
10 5303317976 AB C D E F Insert-broiler pan
12 # 318089910 AB C D E F Switch-light
14 5308011085 AB C D E F Socket-light/lamp
15 3201908 AB C D E F Lamp-oven light
16 3201911 AB C D E F Glass-oven light lens
17 5304400195 AB C D E F Retainer-lens
25 5303311141 AB C D E F Shield-heat
37 # 316111201 AB C D E F Probe-oven temp
41 5303310526 AB C D E F Cover-hinge cutout
54 5303310514 AB C D E F Housing-oven light
56 318002702 AB Trim-oven front white
56 318002701 C D Trim-oven front almond
56 318002703 E F Trim-oven front black
58A 5303310539 AB C D E F Insulation
58B 5303310538 AB C D E F Insulation oven back
59 5303311139 AB C D E F Tube-oven vent
62 # 5303310518 AB C D E F Terminal Block
63 5303310517 AB C D E F Plate-ground strap
66 # 5303310513 AB C D E F Element-broil
67 # 5303310512 AB C D E F Element-bake
68 5304403015 AB C D E F Support-element
70 5303300142 AB C D E F Shield-insulation
71 5303310515 AB C D E F Cover-wiring
76 318124100 AB C D E F Front-oven
80 5303324473 AB C D E F Bracket-oven
81 5303301261 AB C D E F Spring-oven
83 318089608 AB C D E F Liner-oven
86 5303310524 AB C D E F Channel-hinge
87 318111800 AB C D E F Plate-mounting
88 5303311160 AB C D E F Rod-latch
89 * 318120702 AB C D E F Switch latch
89 # 5304404899 AB C D E F Motor-latch
103 5303300213 A B Trim-base
103 5303300217 C D Trim-base
103 5303300214 E F Trim-base
108# 318073001 AB C D E F Motor-fan
114 3051827 AB C D E F Plate-filler
127 5303310542 AB C D E F Adapter assy
128 5303311163 AB C D E F Bushing
129 5303311164 AB C D E F Spring
134 5303319029 AB C D E F Shield rear wall
141 # 5303284446 AB C D E F Switch
142 318123901 AB C D E F Air Deflector
217 316042300 AB C D E F Warning plate
220 5304401475 AB C D E F Bracket
221 5304401476 AB C D E F Bracket
* 5303211311 AB C D E F Screw #8 X ½
*5303311124 AB C D E F Screw
A= FED355CC (FED355CCSF)
B= FED355CC (FED355CCSH)
C= FED355CC (FED355CCBF)
D= FED355CC (FED355CCBH)
E= FED355CC (FED355CCTF)
F= FED355CC (FED355CCTH)

FED355CCS/B/T Publication No.
5995315248
11/98 6
TOP
143
17
18
18
16
19A
93
93
93
93
27
27
15A
15
15A
15
19
19A
19
LAP23T0002A
28
28
28
28

FED355CCS/B/T Publication No.
5995315248
# = Functional Part 711/98
* = Non-Illustrated Part
TOP
POS. NO PART NO DESCRIPTION
15# 5303309001 AB C D E F Element-surface 2600W
15A# 5303309000 AB C D E F Element-surface 1500W
16 5303300166 AB Main Top
16 5303307287 C D Main Top
16 5303300167 E F Main Top
17 3051554 AB C D E F Rod-Maintop
18 5303305530 AB C D E F Bracket-hinge
19 318067010 AB C D E F Pan-surface element large
19A 5303280336 AB C D E F Pan-surface element small
27# 5303323704 AB C D E F Terminal block
28 5303301461 AB C D E F Medaillon surface element
93 318122500 AB C D E F Support terminal block
143 5303300148 AB C D E F Bracket-hinge
*5303211311 AB C D E F Screw, #8 X ½/
*5303320848 A B C D E F Screw, 6-20 X ¼
A= FED355CC (FED355CCSF)
B= FED355CC (FED355CCSH)
C= FED355CC (FED355CCBF)
D= FED355CC (FED355CCBH)
E= FED355CC (FED355CCTF)
F= FED355CC (FED355CCTH)

Publication No. FED355CCS/B/T
5995315248
11/98 8
DOOR
54
3
23
17
16
16
23
7
9
31
6
29 3A
3B
1
39
20
20
42
18
12
LAP23D0017
4
10
7A
22

FED355CCS/B/T Publication No.
5995315248
# = Functional Part 911/98
* = Non-Illustrated Part
DOOR
POS. NO PART NO DESCRIPTION
1 318043100 AB C D E F Bracket-trim
3 318049202 AB Trim-oven door white
3318049201 C D Trim-oven door black
3318049203 E F Trim-oven door almond
3A 318028900 AB C D E F Trim-oven door
3B 318049020 AB Trim-oven door white
3B 318049019 C D Trim-oven door black
3B 318049021 E F Trim-oven door almond
4 5303311191 AB Glass-oven door white
45303311199 C D Glass-oven door black
45303311196 E F Glass-oven door almond
6 5303311192 AB C D E F Shield-wool
7 5303310532 AB C D E F Insulation-door
7A 5303311150 AB C D E F Insulation oven door
9 318112906 AB C D E F Liner-oven door
10 5303324305 AB C D E F Screw 10-24 X 5/8
12 318053103 AB C D E F Seal-oven door
16 5303310533 AB C D E F Glass-oven door
17 318139000 AB C D E F Spacer-glass
18 5303310531 AB C D E F Seal-window
20 318014301 AB Spacer-handle white
20 318014300 C D Spacer-handle black
20 318014302 E F Spacer-handle almond
22 5303310511 AB C D E F Retainer glass
23 318024700 AB C D E F Hinge-oven door
23* 3201899 AB C D E F Washer
29 5303310535 AB C D E F Bumper base
31 5303310536 AB C D E F Latch-door
39 316091119 AB Handle-door white
39 316091118 C D Handle-door black
39 316091120 E F Handle-door almond
42 5303311194 AB Trim-oven door white
42 5303311200 C D Trim-oven door black
42 5303311198 E F Trim-oven door almond
54 5303317175 AB Screw 8-18 X ½ white
54 5303308456 C D Screw, 8-18 X ½ black
54 5303300265 E F Screw, 8-18 X ½ chrome
*08016432 AB C D E F Screw, 8-18 X 3/8
*5303211311 AB C D E F Screw, #8 X ½
*5303307980 AB C D E F Screw, 8-32 X 7/16
A= FED355CC (FED355CCSF)
B= FED355CC (FED355CCSH)
C= FED355CC (FED355CCBF)
D= FED355CC (FED355CCBH)
E= FED355CC (FED355CCTF)
F= FED355CC (FED355CCTH)

Publication No. FED355CCS/B/T
5995315248
11/98 10
WIRING DIAGRAM
