Frigidaire FEF366B User manual

PRODUCT NO. BASE MODEL NO. COLOR MARKET
FEF366BCA FEF366B white North America
Publication No.
5995368395
020315
-EN/SERVICE /ECL
369

BACKGUARD

POS. NO PART NO DESCRIPTION
1 316239900 Shield,backguard ,rear wall
14 316022500 Light/Lamp,warmer,indicator ,drawer/zone,125 V
15 316220204 Support,backguard ,black ,RH
15A 316220205 Support,backguard ,black ,LH
19 316232630 Panel,backguard ,black
20 # 316222902 Clock/Timer,electronic
20A 316220805 Overlay,clock ,black
24 # 316246001 Switch,rocker ,black ,oven light
31 316223002 Knob,black
46 316040201 Lens,indicator light ,red
54 # 316021500 Switch,infinite ,small element
54A# 316021501 Switch,infinite ,large element
56 316234003 Shield,backguard ,black ,inner
69 5303288565 Screw,truss sqdr ,8-32 x 3/16 ,switch mtg
* 218490900 Cleaner,stainless steel
* 316021108 Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021109 Screw,8-18 x 0.5 ,chrome
* 316021110 Screw,8-18 x 0.5 ,black
BACKGUARD

BODY

POS. NO PART NO DESCRIPTION
1 316201300 Back,main
3 316230104 Panel,bodyside ,black ,RH
3 316230105 Panel,bodyside ,black ,LH
5 316129200 Screw,leveling ,plastic ,with stop
6 316067902 Rack,oven
6A 316214401 Rack,oven sump
7 316205000 Hinge,oven door ,RH
7A 316205001 Hinge,oven door ,LH
8 316201501 Panel,sump ,oven bottom
9 316081900 Pan,broiler
10 316082000 Insert,broiler pan
12 # 316027701 Switch,oven light
13 316238800 Rod,light switch
14 316116400 Receptacle,oven light
15 5303013071 Bulb/Lamp,oven light
16 08011086 Lens,oven light ,glass
17 316087500 Retainer,lens
18 # 316213900 Latch,oven door
21 3014099 Spacer,bodyside
25 3200848 Shield,heat ,lower
26 316206300 Support,chassis ,(2)
29 3051162 Glide,drawer ,front
30 316217700 Bracket,hinge ,RH ,main top
30A 316217701 Bracket,hinge ,LH ,main top
37 # 316233900 Probe,oven temp
41 316233400 Cover,hinge cutout ,RH
41A 316233500 Cover,hinge cutout ,LH
42 316206200 Shield,wool ,lower
44 316246500 Spacer,oven door
45 316234100 Shield,wire ,vent tube
57 316081100 Cover,access
58 316240300 Insulation,oven bottom
58A 316047708 Insulation,2" ,oven wrapper
58B 316240100 Insulation,oven back
58C 316240400 Insulation,oven sump
59 316208200 Tube,oven vent ,lower
59A 316208300 Tube,oven vent ,upper
59B 316247300 Catalyst,oven vent ,ceramic
62 # 5303935061 Terminal Block Kit
62* 316085600 Insulator
62* 5303308427 Nut,hex ,10-32
63 5301145190 Plate,grounding strap
66 # 316203200 Element,broil
67 # 316225000 Element,bake
68 316203400 Support,broil element
71 316015810 Shield,rear wall ,galv steel
72 316234500 Cover,rod end ,light switch
87 316081200 Bracket,cable mtg
88 316203500 Rod,auto latch
89 # 316135202 Motor,latch/lock
89A 316245800 Bracket,latch ,rear
170 5303935180 Anti-tip Kit,w/bracket,screw
170* 316107200 Bracket,anti-tip
170* 316112500 Template,anti-tip
170* 316116000 Screw,concrete tpg ,1.75 inch ,anti-tip brkt
* # 316253232 Wiring Harness,main
* 5303305345 Paint,touch-up ,black
* 316021108 Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021123 Screw,8-18 X 3/8-8 ,TRUSS HD BLACK
* 5303280311 Screw,wafer hd sq dr ,10-32 x 0.312
* 5303285179 Screw,wafer head ,8-32T x 0.500 ,black
* 5308014215 Screw,6-20 x 0.312
* 5303271648 Screw,wafer hd sq dr ,8-18AB x 0.5
BODY

TOP/DRAWER

POS. NO PART NO DESCRIPTION
1 316011503 Drawer
2 316231500 Liner,drawer
4 316248800 Panel,drawer ,stainless
7 3051163 Glide,drawer ,rear
15 # 316010205 Element,surface ,6" ,1200 W ,radiant
15A# 316010206 Element,surface ,8" ,2200 W ,radiant
15B# 316224200 Element,surface ,9" ,2500W ,radiant
16 316251903 Main Top Assy,glass/steel ,black
18 316235900 Hinge,main top ,RH
18A 316235901 Hinge,main top ,LH
26 316230200 Channel,element support ,(2)
26A 316099200 Bracket,chassis support ,rear
26B 316214200 Bracket,chassis support ,front
39 316203000 Handle,door ,black
52 316099400 Clip,element mtg
88 316099500 Pin,guide ,(2)
* 316253515 Wiring Harness,surface element
* 218490900 Cleaner,stainless steel
* 316112101 Cleaner,cooktop
* 316021108 Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021110 Screw,8-18 x 0.5 ,black
* 5303280311 Screw,wafer hd sq dr ,10-32 x 0.312
* 5308014215 Screw,6-20 x 0.312
TOP/DRAWER

DOOR

POS. NO PART NO DESCRIPTION
4 316240000 Glass,oven door ,black ,outer
5 316237000 Glass,oven door ,heat barrier
6 316222707 Shield,wool ,oven door
7 316236700 Insulation,oven door
8 316237100 Glass,oven door ,clear ,inner
9 316230605 Liner,oven door
10 316001015 Screw,waf hd sq ,10-24 x 1.25 ,(2) ,handle mtg
10* 316001016 Screw,handle mtg ,10-12 X .750
10B 316008401 Washer,3/4 OD x 1/4 ID ,steel
12 316230900 Seal,oven door
13 316209400 Panel,oven door ,stainless ,outer
14 316102208 Foil,1.5" x 29" ,aluminum ,black
14A 316102205 Foil,4" x 5.5" ,aluminum ,black ,(2)
15 316237201 Bracket,glass support ,(2)
15B 316085501 Bracket,glass support
16 316117500 Glass,oven door ,heat barrier
17 316117701 Spacer,door glass ,(2)
39 316203000 Handle,door ,black
60B 5303271648 Screw,wafer hd sq dr ,8-18AB x 0.5
* 218490900 Cleaner,stainless steel
* 316065306 Plate,warning/caution
* 3203618 Rivet,pop
* 316021109 Screw,8-18 x 0.5 ,chrome
* 316021110 Screw,8-18 x 0.5 ,black
* 5303280311 Screw,wafer hd sq dr ,10-32 x 0.312
* 5303285179 Screw,wafer head ,8-32T x 0.500 ,black
DOOR
