Frigidaire Gallery FGEF3055K F Instruction Manual

LGEF3045KFA.eps CLGEF3045KFA.eps VFGEF3055KBA.eps TLGEF3045KFA.eps
DLGEF3045KFA.eps
Product No. FGEF3055KFA
Series 30" f/s elec
Color stainless
Market North America
Owner's Guide 316902207
Installation Instructions 316454912
Service Data Sheet 316904401
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995539318
09/05/01
(EN/SERVICE/ECL)
369
30-INCH FREE-
STANDING ELECTRIC
RANGE
Model No.
FGEF3055K
Copyright ©2009 Home Products, Inc.
All rights reserved.

Publication No: 5995539318 FGEF3055KFA
05/09 2
BACKGUARD
20A
20
13A 14
14
14
54B
54
31
31
54
54B
14
1414
CLGEF3045KFA
56
1
15A
15
19
69
31
21
46

FGEF3055KFA Publication No: 5995539318
# Functional Parts 3 05/09
* Non-Illustrated Parts
BACKGUARD
POS. NO PART NO. DESCRIPTION
1 316557600 Shield, rear wall
13A# 316095503 Switch, infinite, warmer
14 316022500 Light/Lamp, indicator, 125 V
15 316546702 Cap, backguard, black, RH end
15A 316546703 Cap, backguard, black, LH end
19 316572418 Panel, backguard, stainless
20 # 316560105 Controller, electronic, ES540
* 316021110 Screw, 8-18 x 0.5, black
20A# 316419821 Overlay, clock, black, ES540
21 316546601 Cap, backguard, black, top
31 316564407 Knob, control, stainless, (5)
46 316557300 Lens-light/lamp, indicator, clear
54 316436000 Switch, infinite, small element
54B# 316238200 Switch, infinite radian, dual
56 316234013 Shield, backguard, black, inner
69 5303288565 Screw, truss sqdr, 8-32 x 3/16, switch mtg
* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black
* 316089500 Screw, 10-16 x .486

Publication No: 5995539318 FGEF3055KFA
05/09 4
BODY
5A
5A 5
12
ANTI-TIP
BRACKET
ANTI-TIP
BRACKET
NOTE: Oven Liner N/A
Ass. du four N/A
21
3
5
170
151
87
57
71
89
88
1
86
58A
58B
18
86
37
170
3
151
VFGEF3055KBA
45
17
16
15
14
29
44
44
109
111
106
108
10
9
107
161
62
63
59
59A
6
7
7
6A
6C
6D
66
68
43
43
8B
8B
8C 8A
8C
58E
58D
58C
58
42
264
67
67A
67B
26
8
25
6B

FGEF3055KFA Publication No: 5995539318
# Functional Parts 5 05/09
* Non-Illustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
1 316401801 Panel, main back
3 316400118 Panel, bodyside, black, RH
3 316400119 Panel, bodyside, black, LH
5 316272900 Screw, leveling, plastic, rear, (2)
5A 316498900 Leveling Leg Assy, metal, front, (2), bracket & leg
6 316496207 Rack, oven, (2)
6A 316556500 Rack, oven, auto
6B 316575600 Rack, oven, deep sump
6C 316425600 Rack, half, oven
6D 316419400 Rack, half insert, oven
7 316546300 Link, coupler, (2), auto rack
8 316549601 Bottom, oven
8A 316563501 Base, element, hidden bake
8B 316563400 Bracket, support, oven bottom, (2)
8C 316505801 Support, element
9 316081900 Pan, broiler, OPTIONAL ACCESS0RY
10 316082000 Insert, broiler pan, OPTIONAL ACCESS0RY
12 316445500 Switch, oven light, door frame
14 316116400 Receptacle, oven light
15 316538901 Lamp, oven light
16 318406100 Lens, oven light, glass
17 316087500 Retainer, lens
18 # 316405800 Latch Assembly, oven door
21 316408000 Clip, bodyside
25 316571000 Shield, drawer, upper
26 316563200 Shield, lower, hidden bake
29 316407301 Glide, drawer, front
37 # 316490000 Probe, oven temp
42 316564301 Shield, wool, lower, hidden bake
43 5303285179 Screw, wafer head, 8-32T x 0.500, black
* 3131737 Washer, black
44 316517600 Spacer, oven door
45 316234100 Shield, wire, vent tube
57 316457801 Cover, access
58 316565500 Insulation, lower, hidden bake
58A 316406601 Insulation, oven wrapper
58B 316406503 Insulation, oven back
58C 316565400 Insulation, sump, hidden bake
58D 316565200 Insulation, front & sides, hidden bake
58E 316565300 Insulation, rear, hidden bake
59 316208401 Vent Tube, assembly, w/catalyst
* 316089500 Screw, 10-16 x .486
59A 316208304 Tube, oven vent, upper
62 # 5303935271 Terminal Block Kit
62* 316001003 Screw, ground wire
62* 316205500 Nut, hex flange, 3/8 10-32
62* 316542200 Insulator
63 316542600 Plate, grounding strap
66 # 316430900 Element, broil, 4000W
67 # 316563600 Element, hidden bake
* # 316525631 Harness, wiring, bake element, connector

Publication No: 5995539318 FGEF3055KFA
05/09 6
BODY
5A
5A 5
12
ANTI-TIP
BRACKET
ANTI-TIP
BRACKET
NOTE: Oven Liner N/A
Ass. du four N/A
21
3
5
170
151
87
57
71
89
88
1
86
58A
58B
18
86
37
170
3
151
VFGEF3055KBA
45
17
16
15
14
29
44
44
109
111
106
108
10
9
107
161
62
63
59
59A
6
7
7
6A
6C
6D
66
68
43
43
8B
8B
8C 8A
8C
58E
58D
58C
58
42
264
67
67A
67B
26
8
25
6B

FGEF3055KFA Publication No: 5995539318
# Functional Parts 7 05/09
* Non-Illustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
67A 316574100 Cover, terminal, upper, hidden bake
67B 316563300 Cover, terminal, lower, hidden bake
68 316429100 Support, element, broil
71 316422304 Shield, rear wall
86 316530700 Receptacle, hinge
* 316418900 Screw, sims lp, #8-32 x 5/16", black
87 316081200 Bracket, cable mtg
88 316203500 Rod, auto latch
89 # 316464300 Motor-latch
106 316404100 Bracket, motor mtg.
107 316026701 Cover, fan
* 316021132 Screw, 8-18 X 11/16, black, (3)
108# 316415800 Motor, fan
* 316008401 Washer, 3/4 OD x 1/4 ID, steel
109 316136400 Blade, fan
111 316136600 Nut, fan retainer
151 316404600 Shield, bodyside
161# 316211603 Element, convection fan, 350 W
170 316112004 Anti Tip Kit, assembly
170* 316107200 Bracket, anti-tip
170* 316116000 Screw, concrete, 1.75", anti-tip brkt
170* 316541700 Template, anti-tip
264 316570901 Shield, front frame, black
* # 316506275 Wiring Harness, main
* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black
* 316021110 Screw, 8-18 x 0.5, black
* 316418901 Screw, trilobe, 10-32 x 5/16", (4)

Publication No: 5995539318 FGEF3055KFA
05/09 8
TOP/DRAWER
18
18
1
2
60
39
7
4
52
16
26
26B
26
26A
15B
15
15A
15
15C
TLGEF3045KFA

FGEF3055KFA Publication No: 5995539318
# Functional Parts 9 05/09
* Non-Illustrated Parts
TOP/DRAWER
POS. NO PART NO. DESCRIPTION
1 316408703 Drawer, utility
2 316403300 Liner, drawer
4 316409414 Panel, drawer front, stainless
7 316407400 Glide, drawer, rear
15 # 318178110 Element, surface, 6", 1200, (2), radiant
15A# 316465002 Element, surface, 9", 3000W, radiant
15B# 318198934 Element, surface, 12", 1700/2700W, dual radiant
15C# 318198832 Element, surface, warmer, 100 W
16 316531953 Maintop, steel/glass, black
18 316436600 Hinge Bracket, maintop, (2)
26 316427600 Channel, element support, (2)
26A 316498200 Bracket-support, chassis, aluminum
26B 316214202 Bracket, chassis support, front
* 316021109 Screw, 8-18 x 0.5, chrome
39 316554005 Handle, door/drawer, stainless
52 316461700 Clip, element mtg
52* 5308014215 Screw, 6-20 x 0.312
60 5304414648 Screw, handle mtg.
* # 316510647 Harness, wiring, surface
* 316468100 Cleaner, smoothtop, w/sponge
* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black
* 316021110 Screw, 8-18 x 0.5, black
* 316089500 Screw, 10-16 x .486

Publication No: 5995539318 FGEF3055KFA
05/09 10
DOOR
DLGEF3045KFA
6
7
8
9
12
16
17
17
23
23
20
40
40
53
53
55
21
21
39
60B
4
13
10
18

FGEF3055KFA Publication No: 5995539318
# Functional Parts 11 05/09
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
4 316452720 Glass, oven door, black, w/foil
6 316503800 Shield, wool
* 316021109 Screw, 8-18 x 0.5, chrome
7 316513000 Insulation, oven door
8 316502500 Glass, door, inner, (2)
9 316503609 Liner, oven door
10 316439500 Screw, handle mtg., #10-24 x 1.75", (2)
12 316405000 Seal, oven door
13 316566302 Panel Assembly, door, stainless, outer, w/badge
16 316502601 Glass, door, airwash
17 316502101 Spacer, door glass, (2)
18 316547900 Link, door, (2), auto rack
20 316533801 Plate, distribution, load
21 316408600 Spacer, door handle, (2)
23 316530600 Hinge, oven door, brown
23* 316418900 Screw, sims lp, #8-32 x 5/16", black
39 316554005 Handle, door/drawer, stainless
40 316530401 Bracket, airwash glass, (2)
53 316408201 Shield, door filler, black, (2)
55 316530800 Bracket, glass spacer, (4)
60B 316021110 Screw, 8-18 x 0.5, black
* 316433603 Label, anti-tip
