Frigidaire FEF312B User manual

PRODUCT NO. BASE MODEL NO. COLOR MARKET
FEF312BSA FEF312B white North America
Publication No.
5995384962
030130
-EN/SERVICE /ECL
369
ELECTRIC
RANGE
Model No.
FEF312B
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY
PARTS CATALOG
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
WIRING DIAGRAM - #316255169
OWNER’S GUIDE - # 316257101
INSTALLATION INSTRUCTIONS -# 316259200

01/03 2
Publication No. FEF312BSA
5995384962
BACKGUARD

# = Fast-moving Parts 3 01/03
* = Non-Illustrated Parts
FEF312BSA Publication No.
5995384962
POS. NO PART NO DESCRIPTION
1 5303289640 Shield,backguard ,rear wall
12 # 316032403 Thermostat
14 316022503 Light/Lamp,indicator ,surface ,250 V
18 316263404 End Cap,white ,RH
18A 316263405 End Cap,white ,LH
19 316263304 Panel,backguard ,white
31 316223000 Knob,control ,white
46 316040201 Lens,indicator light ,red
54 # 316021500 Switch,infinite ,small element
54A# 316021501 Switch,infinite ,large element
69 5303288565 Screw,truss sqdr ,8-32 x 3/16 ,switch mtg
* 316021108 Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021109 Screw,8-18 x 0.5 ,chrome
* 316021110 Screw,8-18 x 0.5 ,black
BACKGUARD

01/03 4
Publication No. FEF312BSA
5995384962
BODY

# = Fast-moving Parts 5 01/03
* = Non-Illustrated Parts
FEF312BSA Publication No.
5995384962
POS. NO PART NO DESCRIPTION
1 316201300 Back,main
3 316230114 Panel,bodyside ,white ,RH
3 316230115 Panel,bodyside ,white ,LH
3* 316021131 Screw,bodyside ,8-18 X 11/16 ,white
4 316201401 Burner Box
5 316129200 Screw,leveling ,plastic ,with stop
6 316067902 Rack,oven
7 316216502 Hinge,oven door ,RH
7A 316216503 Hinge,oven door ,LH
8 3203540 Panel,oven bottom
9 316081900 Pan,broiler
10 316082000 Insert,broiler pan
12 # 316209902 Switch,oven light/door
14 316116400 Receptacle,oven light
15 5303013071 Bulb/Lamp,oven light
21 3014099 Spacer,bodyside
26 316206300 Support,chassis ,(2)
27 5303284616 Clip,thermo bulb mtg
29 3051162 Glide,drawer ,front
41 316233400 Cover,hinge cutout ,RH
41A 316233500 Cover,hinge cutout ,LH
42 316206200 Shield,wool ,lower
57 316081100 Cover,access
58 3200847 Insulation,oven bottom
58A 316047707 Insulation,1" ,oven wrapper
58B 316054202 Insulation,1" ,oven back
59 316073605 Tube,oven vent
60 316239100 Cover,oven front
62 # 5303935061 Terminal Block Kit
62* 316205500 Nut,hex flange ,3/8 10-32
63 316208500 Plate,grounding strap
66 # 316203200 Element,broil
67 316075103 Element,bake
68 316203400 Support,broil element
71 316015810 Shield,rear wall ,galv steel
87 316081200 Bracket,cable mtg
170 5303935180 Anti-tip Kit,w/bracket,screw
170* 316107200 Bracket,anti-tip
170* 316112500 Template,anti-tip
170* 316116000 Screw,concrete ,1.75" ,anti-tip brkt
* # 316253132 Wiring Harness,main
* 3203550 Plug,button ,oven bottom
* 316246400 Plug,button ,oven probe
* 316073400 Plate,weight ,(3)
* 5303305324 Paint,touch-up ,white
* 316021108 Screw,cup pt ,8-18 x 0.375 ,chrome
* 5303271648 Screw,wafer hd sq dr ,8-18AB x 0.5
* 5303280311 Screw,wafer hd sq dr ,10-32 x 0.312
* 5303285179 Screw,wafer head ,8-32T x 0.500 ,black
* 5308014215 Screw,6-20 x 0.312
BODY

01/03 6
Publication No. FEF312BSA
5995384962
TOP/DRAWER

# = Fast-moving Parts 7 01/03
* = Non-Illustrated Parts
FEF312BSA Publication No.
5995384962
TOP/DRAWER
POS. NO PART NO DESCRIPTION
1 316011503 Drawer
2 316231500 Liner,drawer
4 316231305 Panel,drawer ,white
7 3051163 Glide,drawer ,rear
15 # 3051450 Element,surface ,8" large
15A# 3051449 Element,surface ,6" small
16 316245402 Main Top,white
17 316066900 Rod,maintop support
18 08067747 Bracket,hinge ,main top RH
18A 08067746 Bracket,hinge ,main top LH
19 # 316048413 Pan-surface element,chrome ,large/8 inch,(2)
19A# 316048414 Pan-surface element,chrome ,small/6 inch,(2)
27 # 5303912666 Terminal Block Kit,surface element
28 5303017715 Medallion,1 1/2"dia ,black ,surface element
* # 316253524 Wiring Harness,surface element
* 316021108 Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021109 Screw,8-18 x 0.5 ,chrome
* 316021110 Screw,8-18 x 0.5 ,black
* 5303280311 Screw,wafer hd sq dr ,10-32 x 0.312
* 5308014215 Screw,6-20 x 0.312

01/03 8
Publication No. FEF312BSA
5995384962
DOOR

# = Fast-moving Parts 9 01/03
* = Non-Illustrated Parts
FEF312BSA Publication No.
5995384962
DOOR
POS. NO PART NO DESCRIPTION
6 316222705 Shield,wool ,oven door
7 316236801 Insulation,oven door
9 316230603 Liner,oven door
10 316001009 Screw,waf hd sq ,10-24 x 1.88 ,(2) ,handle mtg
10B 316008401 Washer,3/4 OD x 1/4 ID ,steel
12 316239700 Seal,oven door
13 316202603 Panel,oven door ,white
39 316020202 Handle,oven door ,white
49 316137000 End Cap,handle ,white ,(2)
60B 316021110 Screw,8-18 x 0.5 ,black
* 316021109 Screw,8-18 x 0.5 ,chrome
* 5303271648 Screw,wafer hd sq dr ,8-18AB x 0.5
* 5303280311 Screw,wafer hd sq dr ,10-32 x 0.312
* 5303285179 Screw,wafer head ,8-32T x 0.500 ,black

01/03 10
Publication No. FEF312BSA
5995384962
WIRING SCHEMATIC

# = Fast-moving Parts 11 01/03
* = Non-Illustrated Parts
FEF312BSA Publication No.
5995384962
WIRING DIAGRAM
