Frigidaire FEF336E User manual

FEF336EC.eps T20G0057.eps L20V0134.eps T20T0054.eps T20D0036.eps
316255301d.eps 316255301s.eps
Product No. FEF336ECA FEF336ECB
Series 30" f/s elec 30" f/s elec
Color stainless stainless
Market North America North America
Wiring Diagram 316255301 316255301
Owner's Guide 316257130 316257130
Installation Instructions 316259206 316259206
Service Data Sheet 316218512 316218512
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995450433
05/10/05
(EN/SERVICE/ECL)
369
30-INCH FREE-
STANDING ELECTRIC
RANGE
Model No.
FEF336E
Copyright ©2005 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995450433 FEF336E
10/05 2
BACKGUARD

FEF336E Publication No: 5995450433
# Functional Parts 3 10/05
* Non-Illustrated Parts
BACKGUARD
Model Index: AFEF336E (FEF336ECA)
BFEF336E (FEF336ECB)
POS. NO PART NO. DESCRIPTION
1 316416100 A B Shield, backguard, rear wall
14 316022500 A B Light/Lamp, indicator, 125 V
15 316411405 A B Support, backguard, black, RH
15A 316411404 A B Support, backguard, black, LH
19 316453103 A B Panel, control, stainless/black, assembly, w/overlay
20 # 316222807 A B Clock/Timer, electronic, ES100
20A 316220701 A B Overlay, clock, black
23 316441600 A B Bracket-clock mtg, black
24 # 316246001 A B Switch, rocker, black
31 316223002 A B Knob, control, black
46 318228300 A B Lens, indicator light
54 # 316436000 A B Switch, infinite, small element
54A# 316436001 A B Switch, infinite, large element
56 316234013 A B Shield, backguard, black, inner
69 5303288565 A B Screw, truss sqdr, 8-32 x 3/16, switch mtg
* 316021105 A B Screw, hex head cup pt, 8-18 x 0.375, black
* 316021109 A B Screw, 8-18 x 0.5, chrome
* 316021110 A B Screw, 8-18 x 0.5, black

Publication No: 5995450433 FEF336E
10/05 4
BODY
66
68 68
67
1
NOTE: Oven Liner N/A
Ass. du four N/A
58A 58B
7
7A
57
71
87
6
41
41A
37
59
59A
45
L20V0134
26
8
60
58
42
14
15
29
62
63
5A
5A
ANTI-TIP
BRACKET
ANTI-TIP
BRACKET
21
3
5
170
5
170
3

FEF336E Publication No: 5995450433
# Functional Parts 5 10/05
* Non-Illustrated Parts
BODY
Model Index: AFEF336E (FEF336ECA)
BFEF336E (FEF336ECB)
POS. NO PART NO. DESCRIPTION
1 316201300 A B Back, main
3 316400104 A - Panel, bodyside, black, RH
3 316400105 A - Panel, bodyside, black, LH
3 316400118 - B Panel, bodyside, black, RH
3 316400119 - B Panel, bodyside, black, LH
5 316272900 A B Screw, leveling, plastic, rear, (2)
5A 316407200 A B Leveling Leg Assy, metal, front, (2), bracket & leg
6 316067902 A B Rack, oven
7 316216506 A B Hinge, oven door, RH
7A 316216507 A B Hinge, oven door, LH
8 3203540 A B Panel, oven bottom
14 316116400 A B Receptacle, oven light
15 5303013071 A B Bulb/Lamp, light
21 316408000 A B Clip, bodyside
26 316206300 A B Support, chassis, (2)
29 3051162 A B Glide, drawer, front
37 # 316233900 A B Probe, oven temp
41 316233400 A B Cover, hinge cutout, RH
41A 316233500 A B Cover, hinge cutout, LH
42 316206200 A B Shield, wool, lower
45 316234100 A B Shield, wire, vent tube
57 316422400 A B Cover, access
58 3200847 A B Insulation, oven bottom
58A 316047707 A B Insulation, 1", oven wrapper
58B 316054202 A B Insulation, 1", oven back
59 316208201 A B Tube, oven vent, lower
59A 316208304 A B Tube, oven vent, upper
60 316239100 A B Cover, oven front
62 5303935238 A B Terminal Block Kit, w/ground plate
62* 316205500 A B Nut, hex flange, 3/8 10-32
63 316278800 A B Plate, grounding strap
66 # 316203200 A B Element, broil
67 316075103 A B Element, bake
68 316203400 A B Support, broil element
71 316422300 A B Shield, rear wall
71* 316248900 A B Spacer, shield, rear wall
87 316081200 A B Bracket, cable mtg
170 5303935180 A B Anti-tip Kit, w/bracket, screw
170* 316107200 A B Bracket, anti-tip
170* 316112500 A B Template, anti-tip
170* 316116000 A B Screw, concrete, 1.75", anti-tip brkt
* # 316253145 A B Wiring Harness, main
* 3203550 A B Plug, button, oven bottom
* 316427400 A B Plate, weight, (4)
* 5303305345 A B Paint, touch-up, black
* 316021105 A B Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 A B Screw, cup pt, 8-18 x 0.375, chrome
* 316021110 A B Screw, 8-18 x 0.5, black
* 316089500 A B Screw, 10-16 x .486
* 5303271648 A B Screw, wafer hd sq dr, 8-18AB x 0.5
* 5303285179 A B Screw, wafer head, 8-32T x 0.500, black
* 5308014215 A B Screw, 6-20 x 0.312

Publication No: 5995450433 FEF336E
10/05 6
TOP/DRAWER

FEF336E Publication No: 5995450433
# Functional Parts 7 10/05
* Non-Illustrated Parts
TOP/DRAWER
Model Index: AFEF336E (FEF336ECA)
BFEF336E (FEF336ECB)
POS. NO PART NO. DESCRIPTION
1 316011503 A B Drawer
2 316231500 A B Liner, drawer
4 316231316 A B Panel, drawer, black
4A 316444700 A B Overlay, drawer, stainless, outer
7 3051163 A B Glide, drawer, rear
15 # 316010205 A B Element, surface, 6", 1200 W, radiant
15A# 316010206 A B Element, surface, 8", 2200 W, radiant
15B# 316224200 A B Element, surface, 9", 2500W, radiant
16 316251903 A B Main Top Assy, glass/steel, black
18 316436600 A B Hinge Bracket, maintop, (2)
26 316427600 A B Channel, element support, (2)
26A 316099202 A B Bracket, chassis support, rear
26B 316214200 A B Bracket, chassis support, front
39 316270200 A B Handle, door, black
39* 316437500 A B Screw, handle mtg., 10 14 x .4 trus, (2)
52 316278300 A B Clip, element mtg
* # 316416851 A B Harness, wiring, surface
* 316264000 A B Cleaner, cooktop
* 316279700 A B Cleaner, stainless steel
* 316021105 A B Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 A B Screw, cup pt, 8-18 x 0.375, chrome
* 316021109 A B Screw, 8-18 x 0.5, chrome
* 316021110 A B Screw, 8-18 x 0.5, black
* 5308014215 A B Screw, 6-20 x 0.312

Publication No: 5995450433 FEF336E
10/05 8
DOOR

FEF336E Publication No: 5995450433
# Functional Parts 9 10/05
* Non-Illustrated Parts
DOOR
Model Index: AFEF336E (FEF336ECA)
BFEF336E (FEF336ECB)
POS. NO PART NO. DESCRIPTION
3 5303935191 A B Trim kit-door, 3 sided, black, w/tape and foil
4 316453000 A B Glass Assembly, oven door, outer, w/ss overlay
6 316222711 A B Shield, wool, black, oven door
8 316237100 A B Glass, oven door, clear, heat barrier
9 316230617 A B Liner, oven door
10 316278700 A B Screw, wafer head, 10-14 x 1 3/8, handle mtg
10B 316008401 A B Washer, 3/4 OD x 1/4 ID, steel
12 316239700 A B Seal, oven door
17 316117701 A B Spacer, door glass, (2)
39 316270200 A B Handle, door, black
52 316201005 A B Cap, door trim, black
60B 316021110 A B Screw, 8-18 x 0.5, black
* 316279700 A B Cleaner, stainless steel
* 316433600 A B Label, anti-tip
* 316021109 A B Screw, 8-18 x 0.5, chrome
* 5303271648 A B Screw, wafer hd sq dr, 8-18AB x 0.5
* 5303285179 A B Screw, wafer head, 8-32T x 0.500, black

Publication No: 5995450433 FEF336E
10/05 10
WIRING SCHEMATIC

FEF336E Publication No: 5995450433
# Functional Parts 11 10/05
* Non-Illustrated Parts
WIRING DIAGRAM
