Frigidaire FEF355A User manual

PRODUCT NO. BASE MODEL NO. COLOR MARKET
FEF355ABA FEF355A black North America
FEF355AQA FEF355A bisque North America
FEF355ASA FEF355A white North America
FEF355AUA FEF355A black/bisque North America
FEF355AWA FEF355A black/white North America
Publication No.
5995354395
010607
-EN/SERVICE /ECL
369
ELECTRIC
RANGE
Model No.
FEF355A
©2001 White Consolidated Industries, Inc.
All rights reserved
FACTORY
PARTS CATALOG
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
SERVICE DATA SHEET - # 316259142
WIRING DIAGRAM - #316255104
OWNER’S GUIDE - # 316257104
INSTALLATION INSTRUCTIONS -# 316259200

06/01 2
Publication No. FEF355A
5995354395
BACKGUARD

# = Fast-moving Parts 3 06/01
* = Non-Illustrated Parts
FEF355A Publication No.
5995354395
A = FEF355A (FEF355ASA)
B = FEF355A (FEF355AWA)
C = FEF355A (FEF355ABA)
D = FEF355A (FEF355AUA)
E = FEF355A (FEF355AQA)
POS. NO PART NO DESCRIPTION
1 316239900 A B C D E Shield-backguard,rear wall
1* 316248900 A B C D E Spacer,shield ,rear wall
14 316022503 A B C D E Light/Lamp,indicator ,surface ,250 V
15 316220202 A ---- Support-backguard,white ,RH
15 316220204 - B C D - Support-backguard,black ,RH
15 316220208 ----E Support-backguard,bisque ,RH
15A 316220203 A ---- Support-backguard,white ,LH
15A 316220205 - B C D - Support-backguard,black ,LH
15A 316220209 ----E Support-backguard,bisque ,LH
19 316232634 A ---- Panel-backguard,white
19 316232635 - B C D - Panel-backguard,black
19 316232636 ----E Panel-backguard,bisque
20 # 316222902 A B C D E Clock/timer,electronic
20A 316220804 A ---- Overlay,clock ,white
20A 316220805 - B C D - Overlay,clock ,black
20A 316220806 ----E Overlay,clock ,bisque
24 # 316246000 A ---- Switch-oven light,rocker ,white
24 # 316246001 - B C D - Switch-oven light,rocker ,black
24 # 316246002 ----E Switch-oven light,rocker ,bisque
31 316223000 A ---- Knob,control ,white
31 316223002 - B C D - Knob,control ,black
31 316223003 ----E Knob,control ,bisque
46 316040201 A B C D E Lens-light/lamp,indicator ,red
54 # 316021500 A B C D E Switch,infinite ,small element
54A# 316021501 A B C D E Switch,infinite ,large element
56 316234007 A ---- Shield-backguard,white ,inner
56 316234008 - B C D - Shield-backguard,black ,inner
56 316234009 ----E Shield-backguard,bisque ,inner
69 5303288565 A B C D E Screw,truss sqdr ,8-32 x 3/16 ,switch mtg
* 316021108 A B C D E Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021109 A B C D E Screw,8-18 x 0.5 ,chrome
* 316021110 A B C D E Screw,8-18 x 0.5 ,black
BACKGUARD

06/01 4
Publication No. FEF355A
5995354395
BODY

# = Fast-moving Parts 5 06/01
* = Non-Illustrated Parts
FEF355A Publication No.
5995354395
A = FEF355A (FEF355ASA)
B = FEF355A (FEF355AWA)
C = FEF355A (FEF355ABA)
D = FEF355A (FEF355AUA)
E = FEF355A (FEF355AQA)
POS. NO PART NO DESCRIPTION
1 316201300 A B C D E Back-main
3 316230102 A B - - - Panel-bodyside,white ,RH
3 316230103 A B - - - Panel-bodyside,white ,LH
3 316230104 - - C - - Panel-bodyside,black ,RH
3 316230105 - - C - - Panel-bodyside,black ,LH
3 316230108 ---DE Panel-bodyside,bisque ,RH
3 316230109 ---DE Panel-bodyside,bisque ,LH
4 316201401 A B C D E Burner Box
5 316129200 A B C D E Screw-leveling,plastic ,with stop
6 316067902 A B C D E Rack-oven
6A 316214401 A B C D E Rack-oven,sump
7 316205000 A B C D E Hinge-oven door,RH
7A 316205001 A B C D E Hinge-oven door,LH
8 316201501 A B C D E Panel-oven bottom,sump
9 316081900 A B C D E Pan-broiler
10 316082000 A B C D E Insert-broiler pan
12 # 316027701 A B C D E Switch-oven light
13 316238800 A B C D E Rod-light switch
14 316116400 A B C D E Receptacle-lamp,oven
15 5303013071 A B C D E Light Bulb/Lamp
16 08011086 A B C D E Lens-light/lamp, glass , oven
17 316087500 A B C D E Retainer-lens
18 # 316213900 A B C D E Latch-door
21 3014099 A B C D E Spacer-bodyside
25 3200848 A B C D E Shield-heat,lower
26 316211800 A B C D E Shield,chassis filler ,side lower ,(2)
29 3051162 A B C D E Glide-drawer,front
37 # 316233900 A B C D E Probe-oven temp
41 316233400 A B C D E Cover-hinge,cutout ,RH
41A 316233500 A B C D E Cover-hinge,cutout ,LH
42 316206200 A B C D E Shield-wool,lower
44 316246500 A B C D E Spacer-door
57 316081100 A B C D E Cover-access
58 316240300 A B C D E Insulation,oven bottom
58A 316047708 A B C D E Insulation,2" ,oven wrapper
58B 316240100 A B C D E Insulation,oven back
58C 316240400 A B C D E Insulation,oven sump
59 316073604 A B C D E Tube-oven vent
62 # 5303935061 A B C D E Terminal Block Kit
62* 316085600 A B C D E Insulator
62* 5303308427 A B C D E Nut,hex ,10-32
63 5301145190 A B C D E Plate-ground strap
66 # 316203200 A B C D E Element-broil
67 # 316225000 A B C D E Element-bake
68 316203400 A B C D E Support-element
71 316015810 A B C D E Shield-rear wall,galv steel
72 316234500 A B C D E Cover-rod end,light switch
87 316081200 A B C D E Bracket-cable mtg
88 316203500 A B C D E Rod-latch,auto
89 # 316135202 A B C D E Motor-latch/lock
89A 316245800 A B C D E Bracket-latch,rear
151 316239300 A B C D E Shield-bodyside
170 5303935180 A B C D E Anti-tip Kit,w/bracket,screw
170* 316107200 A B C D E Bracket,anti-tip
170* 316112500 A B C D E Template,anti-tip
170* 316116000 A B C D E Screw,concrete tpg ,1.75 inch ,anti-tip brkt
* # 316253202 A B C D E Wiring Harness,main
* 316021108 A B C D E Screw,cup pt ,8-18 x 0.375 ,chrome
* 5303280311 A B C D E Screw,wafer hd sq dr ,10-32 x 0.312
* 5303271648 A B C D E Screw,wafer hd sq dr ,8-18AB x 0.5
BODY

06/01 6
Publication No. FEF355A
5995354395
TOP/DRAWER

# = Fast-moving Parts 7 06/01
* = Non-Illustrated Parts
FEF355A Publication No.
5995354395
A = FEF355A (FEF355ASA)
B = FEF355A (FEF355AWA)
C = FEF355A (FEF355ABA)
D = FEF355A (FEF355AUA)
E = FEF355A (FEF355AQA)
POS. NO PART NO DESCRIPTION
1 316011503 A B C D E Drawer
2 316231500 A B C D E Liner,drawer
4 316231305 A B - - - Panel-drawer,white
4 316231306 - - C - - Panel-drawer,black
4 316231309 ---DE Panel-drawer,bisque
7 3051163 A B C D E Glide-drawer,rear
15 # 5303012223 A B C D E Element-surface,large-8"
15A# 08067762 A B C D E Element-surface,small-6"
16 316202307 A B - - - Main Top,white
16 316202306 - - C - - Main Top,black
16 316202309 ---DE Main Top,bisque
17 316057601 A B C D E Rod-maintop support
18 316235900 A B C D E Hinge-main top,RH
18A 316235901 A B C D E Hinge-main top,LH
19 318067053 A ---- Pan-surface element,large ,gray
19 318067051 - B C D - Pan-surface element,large ,black
19 318067057 ----E Pan-surface element,large ,bisque
19A 318067043 A ---- Pan-surface element,small ,gray
19A 318067041 - B C D - Pan-surface element,small ,black
19A 318067047 ----E Pan-surface element,small ,bisque
27 # 5303912666 A B C D E Terminal Block Kit,surface element
28 3017801 A B C D E Medallion,stainless steel ,surf elem
28 5303017715 A B C D E Medallion,1 1/2"dia ,black ,surface element
* # 316253501 A B C D E Wiring Harness,surface element
* 316058600 A ---E Clip-surface element,(4)
* 316058601 - B C D - Clip-surface element,(4)
* 316021108 A B C D E Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021110 A B C D E Screw,8-18 x 0.5 ,black
* 5303280311 A B C D E Screw,wafer hd sq dr ,10-32 x 0.312
TOP/DRAWER

06/01 8
Publication No. FEF355A
5995354395
DOOR

# = Fast-moving Parts 9 06/01
* = Non-Illustrated Parts
FEF355A Publication No.
5995354395
A = FEF355A (FEF355ASA)
B = FEF355A (FEF355AWA)
C = FEF355A (FEF355ABA)
D = FEF355A (FEF355AUA)
E = FEF355A (FEF355AQA)
POS. NO PART NO DESCRIPTION
3 5303935192 A ---- Trimkit-door,3 sided ,white ,w/tape and foil
3 5303935191 - B C D - Trim kit-door,3 sided ,black ,w/tape and foil
3 5303935193 ----E Trimkit-door,3 sided ,bisque ,w/tape and foil
4 5303935201 A ---- Glass-door kit,white ,outer ,w/ foil tape
4 5303935200 - B C D - Glass-door kit,black ,outer ,w/ foil tape
4 5303935202 ----E Glass-door kit,bisque ,outer ,w/ foil tape
5 316237100 A B C D E Glass-oven door,airwash
6 316222707 A B C D E Shield-wool,oven door
7 316236700 A B C D E Insulation-door
8 316117500 A B C D E Glass-oven door,inner
9 316230605 A B C D E Liner-door,oven
10 316001013 A B C D E Screw,wafer head ,10-24 X 1.375 ,handle mtg.
10B 316008401 A B C D E Washer,3/4 OD x 1/4 ID ,steel
12 316230900 A B C D E Seal-oven door
14 316102207 A ---E Foil-aluminum,1.5" x 29" ,clear
14 316102208 - B C D - Foil-aluminum,1.5" x 29" ,black
14A 316102202 A ---E Foil-aluminum,4" x 5.5" ,clear ,(2)
14A 316102205 - B C D - Foil-aluminum,4" x 5.5" ,black ,(2)
15 316237201 A B C D E Bracket-glass,airwash ,(2)
16 316237000 A B C D E Glass-oven door,heat barrier
17 316117701 A B C D E Spacer-glass,(2)
39 316203001 A ---- Handle-door,white
39 316203000 - B C D - Handle-door,black
39 316203003 ----E Handle-door,bisque
52 316201000 A ---- Cap-door trim,white
52 316201002 - B C D - Cap-door trim,black
52 316201007 ----E Cap-door trim,bisque
60B 5303271648 A B C D E Screw,wafer hd sq dr ,8-18AB x 0.5
* 316065306 A B C D E Plate-warning/caution
* 3203618 A B C D E Rivet-pop
* 316021109 A B C D E Screw,8-18 x 0.5 ,chrome
* 316021110 A B C D E Screw,8-18 x 0.5 ,black
* 5303280311 A B C D E Screw,wafer hd sq dr ,10-32 x 0.312
DOOR

06/01 10
Publication No. FEF355A
5995354395
WIRING DIAGRAM
