Frigidaire FEF355D User manual

FEF366D.eps T20G0026.eps T20V0060.eps T20T0001.eps T20D0008.eps
316417700d.eps 316417700s.eps
Product No. FEF355DBA FEF355DBB FEF355DQA FEF355DQB FEF355DSA FEF355DSB
Series 30" f/s elec 30" f/s elec 30" f/s elec 30" f/s elec 30" f/s elec 30" f/s elec
Color black black black bisque white white
Market North America North America North America North America North America North America
Wiring Diagram 316417700 316417700 316417700 316417700 316417700 316417700
Owner's Guide 316417000 316417000 316417000 316417000 316417000 316417000
Installation Instructions 316259206 316259206 316259206 316259206 316259206 316259206
Service Data Sheet 316417613 316417613 316417613 316417613 316417613 316417613
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995419149
04/10/20
(EN/SERVICE/ECL)
369
30-INCH FREE-
STANDING ELECTRIC
RANGE
Model No.
FEF355D
Copyright ©2004 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995419149 FEF355D
10/04 2
BACKGUARD

FEF355D Publication No: 5995419149
# Functional Parts 3 10/04
* Non-Illustrated Parts
BACKGUARD
Model Index: AFEF355D (FEF355DBA)
BFEF355D (FEF355DBB)
CFEF355D (FEF355DQA)
DFEF355D (FEF355DQB)
EFEF355D (FEF355DSA)
FFEF355D (FEF355DSB)
POS. NO PART NO. DESCRIPTION
1 316416100 A B C D E F Shield, backguard, rear wall
14 316022500 A B C D E F Light/Lamp, indicator, 125 V
15 316411405 A B - - - - Support, backguard, black, RH
15 316411407 - - C D - - Support, backguard, bisque, RH
15 316411403 - - - - E F Support, backguard, white, RH
15A 316411404 A B - - - - Support, backguard, black, LH
15A 316411406 - - C D - - Support, backguard, bisque, LH
15A 316411402 - - - - E F Support, backguard, white, LH
19 316424143 A B - - - - Panel, control, black
19 316424144 - - C D - - Panel,control, bisque
19 316424142 - - - - E F Panel, control, white
20 # 316418200 A B C D E F Clock/Timer, electronic, ES300
20A 316419103 A B - - - - Overlay, clock, black, ES300
20A 316419105 - - C D - - Overlay,clock, bisque, ES300
20A 316419104 - - - - E F Overlay, clock, white, ES300
24 # 316246001 A B - - - - Switch, rocker, black, oven light
24 316246002 - - C D - - Switch, rocker, bisque, oven light
24 316246000 - - - - E F Switch, rocker, white, oven light
31 316223002 A B - - - - Knob, control, black
31 316223003 - - C D - - Knob,control, bisque
31 316223000 - - - - E F Knob, control, white
46 316040201 A B C D E F Lens, indicator light, red
54 # 316021500 A B C D E F Switch, infinite, small element
54A# 316021501 A B C D E F Switch, infinite, large element
56 316234003 A B - - - - Shield, backguard, black, inner
56 316234004 - - C D - - Shield, backguard, bisque, inner
56 316234001 - - - - E F Shield, backguard, white, inner
69 5303288565 A B C D E F Screw, truss sqdr, 8-32 x 3/16, switch mtg
* 316021105 A B C D E F Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 A B C D E F Screw, cup pt, 8-18 x 0.375, chrome
* 316021109 A B C D E F Screw, 8-18 x 0.5, chrome
* 316021110 A B C D E F Screw, 8-18 x 0.5, black

Publication No: 5995419149 FEF355D
10/04 4
BODY

FEF355D Publication No: 5995419149
# Functional Parts 5 10/04
* Non-Illustrated Parts
BODY
Model Index: AFEF355D (FEF355DBA)
BFEF355D (FEF355DBB)
CFEF355D (FEF355DQA)
DFEF355D (FEF355DQB)
EFEF355D (FEF355DSA)
FFEF355D (FEF355DSB)
POS. NO PART NO. DESCRIPTION
1 316401800 A B C D E F Panel, main back
3 316400104 A B - - - - Panel, bodyside, black, RH
3 316400105 A B - - - - Panel, bodyside, black, LH
3 316400106 - - C D - - Panel, bodyside, bisque, RH
3 316400107 - - C D - - Panel, bodyside, bisque, LH
3 316400102 - - - - E F Panel, bodyside, white, RH
3 316400103 - - - - E F Panel, bodyside, white, LH
4 316201401 A B C D E F Burner Box
5 316272900 A B C D E F Screw, leveling, plastic, rear, (2)
5A 316407200 A B C D E F Leveling Leg Assy, metal, front, (2), bracket & leg
6 316404500 A B C D E F Rack, oven
8 316400601 A B C D E F Panel, oven bottom
12 # 316407101 A B C D E F Switch, oven light/door
14 316116400 A B C D E F Receptacle, oven light
15 5303013071 A B C D E F Bulb/Lamp, oven light
16 08011086 A B C D E F Lens, oven light, glass
17 316087500 A B C D E F Retainer, lens
18 # 316405800 A B C D E F Latch Assembly, oven door
21 316408000 A B C D E F Clip, bodyside
25 5304403169 A B C D E F Shield, heat, lower
28 316045000 A B C D E F Clip, wiring harness, green, main top
29 316407301 A B C D E F Glide, drawer, front
37 # 316217001 A B C D E F Probe, oven temp
42 316407700 A B C D E F Shield, wool, lower
44 316246501 A B C D E F Spacer, oven door
57 316422400 A B C D E F Cover, access
58 316403800 A B C D E F Insulation, oven bottom
58A 316406600 A B C D E F Insulation, oven wrapper
58B 316406500 A B C D E F Insulation, oven back
59 316073606 A B C D E F Tube, oven vent
62 5303935238 A B C D E F Terminal Block Kit, w/ground plate
62* 316085600 A B C D E F Insulator
62* 316205500 A B C D E F Nut, hex flange, 3/8 10-32
63 316278800 A B C D E F Plate, grounding strap
66 # 316203200 A B C D E F Element, broil
67 316075103 A B C D E F Element, bake
68 316404000 A B C D E F Support, element, broil
71 316422300 A B C D E F Shield, rear wall
86 316407000 A B C D E F Receptacle, hinge
86* 316418901 A B C D E F Screw, trilobe, 10-32 x 5/16"
87 316081200 A B C D E F Bracket, cable mtg
88 316203500 A B C D E F Rod, auto latch
89 # 316415400 A B C D E F Motor, latch/lock
151 316404600 A B C D E F Shield, bodyside
170 5303935180 A B C D E F Anti-tip Kit, w/bracket, screw

Publication No: 5995419149 FEF355D
10/04 6
BODY

FEF355D Publication No: 5995419149
# Functional Parts 7 10/04
* Non-Illustrated Parts
BODY
Model Index: AFEF355D (FEF355DBA)
BFEF355D (FEF355DBB)
CFEF355D (FEF355DQA)
DFEF355D (FEF355DQB)
EFEF355D (FEF355DSA)
FFEF355D (FEF355DSB)
POS. NO PART NO. DESCRIPTION
170* 316107200 A B C D E F Bracket, anti-tip
170* 316112500 A B C D E F Template, anti-tip
170* 316116000 A B C D E F Screw, concrete, 1.75", anti-tip brkt
* # 316416401 A B C D E F Harness, wiring, main
* 3203550 A B C D E F Plug, button, oven bottom
* 5303305345 A B - - - - Paint, touch-up, black
* 5304414035 - - C D - - Paint, touch-up, bisque
* 5303305324 - - - - E F Paint, touch-up, white
* 316021105 A B C D E F Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 A B C D E F Screw, cup pt, 8-18 x 0.375, chrome
* 316021110 A B C D E F Screw, 8-18 x 0.5, black
* 316089500 A B C D E F Screw, 10-16 x .486
* 5303271648 A B C D E F Screw, wafer hd sq dr, 8-18AB x 0.5
* 5303285179 A B C D E F Screw, wafer head, 8-32T x 0.500, black
* 5308014215 A B C D E F Screw, 6-20 x 0.312

Publication No: 5995419149 FEF355D
10/04 8
TOP/DRAWER

FEF355D Publication No: 5995419149
# Functional Parts 9 10/04
* Non-Illustrated Parts
TOP/DRAWER
Model Index: AFEF355D (FEF355DBA)
BFEF355D (FEF355DBB)
CFEF355D (FEF355DQA)
DFEF355D (FEF355DQB)
EFEF355D (FEF355DSA)
FFEF355D (FEF355DSB)
POS. NO PART NO. DESCRIPTION
1 316408701 A B C D E F Drawer, utility
2 316403300 A B C D E F Liner, drawer
4 316403502 A B - - - - Panel, drawer front, black
4 316403503 - - C D - - Panel, drawer front, bisque
4 316403501 - - - - E F Panel, drawer front, white
7 316407400 A B C D E F Glide, drawer, rear
15 # 3051450 A B C D E F Element, surface, 8" large
15A# 3051449 A B C D E F Element, surface, 6" small
16 316202306 A B - - - - Main Top, black
16 316202309 - - C D - - Main Top, bisque
16 316202307 - - - - E F Main Top, white
17 316057601 A B C D E F Rod, support, main top
18 316235900 A B C D E F Hinge, main top, RH
18A 316235901 A B C D E F Hinge, main top, LH
19 5303935054 A B C D E F Pan, surface element, large/8 inch
19A 5303935057 A B C D E F Pan, surface element, small/6 inch
27 # 5303912666 A B C D E F Terminal Block Kit, surface element
28 5303017715 A B C D E F Medallion, 1 1/2"dia, black, surface element
* # 316253501 A B C D E F Wiring Harness, surface element
* 316058600 A B C D E F Clip, surface element, chrome, (4)
* 316021105 A B C D E F Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 A B C D E F Screw, cup pt, 8-18 x 0.375, chrome
* 316021109 A B C D E F Screw, 8-18 x 0.5, chrome
* 316021110 A B C D E F Screw, 8-18 x 0.5, black
* 5308014215 A B C D E F Screw, 6-20 x 0.312

Publication No: 5995419149 FEF355D
10/04 10
DOOR

FEF355D Publication No: 5995419149
# Functional Parts 11 10/04
* Non-Illustrated Parts
DOOR
Model Index: AFEF355D (FEF355DBA)
BFEF355D (FEF355DBB)
CFEF355D (FEF355DQA)
DFEF355D (FEF355DQB)
EFEF355D (FEF355DSA)
FFEF355D (FEF355DSB)
POS. NO PART NO. DESCRIPTION
3 5303935245 A B - - - - Trim kit-door, 3 sided, black, w/tape
3 5303935244 - - C D - - Trim kit-door, 3 sided, bisque, w/tape
3 5303935243 - - - - E F Trim kit-door, 3 sided, white, w/tape
4 316406401 A B - - - - Glass, oven door, black, outer
4 316406402 - - C D - - Glass, oven door, bisque, outer
4 316406400 - - - - E F Glass, oven door, white, outer
6 316406303 A - C - E - Shield, wool
6 316406307 - B - D - F Shield, wool
7 316405600 A B C D E F Insulation, oven door
9 316406003 A - C - E - Liner, oven door
9 316423701 - B - D - F Liner, oven door
10 316433300 A B C D E F Screw, 10-14 x 2.125", handle mtg.
12 316405000 A B C D E F Seal, oven door
16 316117500 A B C D E F Glass, oven door, heat barrier
17 316402403 A B C D E F Spacer, door glass, (2)
23 316406910 A B C D E F Hinge, oven door
23* 316418900 A B C D E F Screw, sims lp, #8-32 x 5/16", black
39 316270200 A B - - - - Handle, door, black
39 316270202 - - C D - - Handle, door, bisque
39 316270201 - - - - E F Handle, door, white
52 316405101 A B - - - - Cap, door trim, black
52 316405102 - - C D - - Cap, door trim, bisque
52 316405100 - - - - E F Cap, door trim, white
54 316427801 A B C D E F Deflector, door hinge, (2)
60B 316021110 A B C D E F Screw, 8-18 x 0.5, black
* 316433603 A B C D E F Label, anti-tip
* 316021109 A B C D E F Screw, 8-18 x 0.5, chrome
* 5303271648 A B C D E F Screw, wafer hd sq dr, 8-18AB x 0.5
* 5303285179 A B C D E F Screw, wafer head, 8-32T x 0.500, black

Publication No: 5995419149 FEF355D
10/04 12
WIRING SCHEMATIC

FEF355D Publication No: 5995419149
# Functional Parts 13 10/04
* Non-Illustrated Parts
WIRING DIAGRAM
