Frigidaire FED355E User manual

FED355E.eps la20bg0034.eps B79045482500.eps LA20CT0050.eps D79046592500.eps
318271906.eps
Product No. FED355EBA FED355ESA
37854335E5061 37854335E5011
Series 30" drop-in 30" drop-in
Color black white
Market North America North America
Wiring Diagram 318271906 318271906
Owner's Guide 318203810 318203810
Installation Instructions 318201613 318201613
Timer Guide 318200184 318200184
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995441572
05/07/13
(EN/SERVICE/ECL)
377
30-INCH DROP-IN
ELECTRIC RANGE
Model No.
FED355E
Copyright ©2005 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995441572 FED355E
07/05 2
BACKGUARD

FED355E Publication No: 5995441572
# Functional Parts 3 07/05
* Non-Illustrated Parts
BACKGUARD
Model Index: AFED355E (FED355ESA)
BFED355E (FED355EBA)
POS. NO PART NO. DESCRIPTION
14 # 318293900 A B Light, indicator, 125v, (2)
16 318299100 A - Console, assy., white
16 318299102 - B Console, assy., black
16* 5304447071 A B Clip, console, (2)
19 318235138 A - Panel, control, white
19 318235139 - B Panel, control, black
19A 318224401 A B Panel, control mtg.
20 # 318185452 A - Clock/Timer, electronic, white, ES300
20 # 318185454 - B Clock/Timer, electronic, black, ES300
20* 316419104 A - Overlay, clock, white, ES300
20* 316419103 - B Overlay, clock, black, ES300
24 # 316005607 A - Switch, rocker, white
24 # 316005602 - B Switch, rocker, black
35 318183101 A - Support, glass, white, (4)
35 318183100 - B Support, glass, black
36 316223028 A - Knob, control, white
36 316223027 - B Knob, control, black
42 318298011 A B Trim, vent, black, upper
46 318228300 A B Lens, indicator light
54 # 318220080 A B Switch, surface unit, single
54A# 318220081 A B Switch, surface unit, large
69 5303323134 A B Screw, 8-32 x 0.188
99A 318223900 A B Gasket, dark grey
* 318301100 A B Wiring Harness, backguard
* # 318224812 A B Harness, wiring, timer
* # 318224815 A B Harness, wiring, infinite switch
* 08016432 A B Screw, truss head, 8-18 x 0.375
* 5303300265 A B Screw, 8-18 x 0.500, chrome, (3)

Publication No: 5995441572 FED355E
07/05 4
BODY

FED355E Publication No: 5995441572
# Functional Parts 5 07/05
* Non-Illustrated Parts
BODY
Model Index: AFED355E (FED355ESA)
BFED355E (FED355EBA)
POS. NO PART NO. DESCRIPTION
1 318259202 A B Back, main
1A 318225110 A B Panel, main back, upper
2 318258900 A B Shield, insulation, upper
3 318225210 A B Panel, bodyside, upper RH
3A 318225211 A B Panel, bodyside, upper LH
4 318073906 A B Panel, subtop
6 318262502 A B Rack, oven
9 5303317977 A B Pan, broiler
10 5303317976 A B Insert, broiler pan
12 # 318089913 A B Switch, light
14 318224000 A B Receptacle, oven light
15 5303013071 A B Bulb/Lamp, oven light
16 3201911 A B Cover, oven light, glass
17 5304400195 A B Retainer, light cover
29 318147411 A B Bumper, (2)
37 # 316217002 A B Probe, oven temp
41 5303310526 A B Cover, hinge cutout
54 318222400 A B Housing, oven light
58A 318285055 A B Insulation, oven wrapper
58B 318285056 A B Insulation, oven back
59 318072572 A B Tube, vent, oven
62 5303935061 A B Terminal Block Kit
62* 5303323139 A B Screw, 10-24 x 0.906
62* 5303323144 A B Nut, 10-32
63 318264200 A B Plate, grounding strap
66 # 318255600 A B Element, broil, 2750W
67 # 318255401 A B Element, bake, 3400W
68 5304403015 A B Support, hanger, (2), broil element
70 318259100 A B Shield, insulation, sides, (2)
71 318260006 A B Panel, rear box
76 318056217 A B Front, oven
80 5303320846 A B Plate, oven mtg
81 318192400 A B Spring, oven
82 318258707 A B Shield, insulation, lower
83 318261403 A B Liner, oven assy
86 5303310524 A B Receptacle, hinge
87 318260600 A B Bracket, cable mtg.
89 # 318261202 A B Motor, latch assy
90 318296922 A - Panel, filler, white, RH
90 318296924 - B Panel, filler, black, RH
90A 318296923 A - Panel, filler, white, LH
90A 318296925 - B Panel, filler, black, LH
99 318256200 A B Bracket, side, bottom, (2)
108# 318073018 A B Motor, blower
108A 318251300 A B Bracket,fan support
119# 318005202 A B Switch, thermal cutout
127 318317100 A B Adapter Assembly, vent tube, w/converter
131 318272900 A B Box, vent
132 318003000 A B Plate, shield
142 318123910 A B Deflector
162 318225810 A B Box, extension
163 318014110 A B Spacer, (4)
185 318165800 A B Spacer, (2)
200 318330001 A - Trim, door opening, white, bottom
200 318330003 - B Trim, door opening, black, bottom
219# 318003606 A B Thermostat, safety
* # 318078526 A B Box & wires assy
* # 318224925 A B Harness, wiring, main
* 5303325856 A B Kit, anti-tip
* 3051050 A B Screw, shoulder
* 3201861 A B Screw, 6 x 0.375, (4)
* 08016432 A B Screw, truss head, 8-18 x 0.375
* 5303211311 A B Screw, 8 x 0.500
* 5303307980 A B Screw, 8-32 x 0.437
* 5303323129 A B Screw, 8 X 0.750
* 5304415832 A B Screw, 8-18 x 0.406
* 5304436875 A B Screw, 8-18 X 1/2, black

Publication No: 5995441572 FED355E
07/05 6
MAIN TOP

FED355E Publication No: 5995441572
# Functional Parts 7 07/05
* Non-Illustrated Parts
MAIN TOP
Model Index: AFED355E (FED355ESA)
BFED355E (FED355EBA)
POS. NO PART NO. DESCRIPTION
15 # 5303012223 A B Element, surface, 8", large
15A# 08067762 A B Element, surface, 6", small
16 318225602 A - Main Top, white
16 318225601 - B Main Top, black
17 3051554 A B Rod, support, main top panel
18 318227710 A B Hinge, maintop, (2)
19 # 318067056 A B Pan, surface element, large, chrome
19A# 318067046 A B Pan, surface element, small, chrome
27 # 5303912666 A B Terminal Block Kit, surface element
28 3017801 A B Medallion, stainless steel, surf elem
28 5303017715 A B Medallion, 1 1/2"dia, black, surface element
93 318122500 A B Support, terminal block, (4)
* # 318301000 A B Wiring Harness, surface units
* 5303211311 A B Screw, 8 x 0.500
* 5303300265 A B Screw, 8-18 x 0.500, chrome, (3)

Publication No: 5995441572 FED355E
07/05 8
DOOR

FED355E Publication No: 5995441572
# Functional Parts 9 07/05
* Non-Illustrated Parts
DOOR
Model Index: AFED355E (FED355ESA)
BFED355E (FED355EBA)
POS. NO PART NO. DESCRIPTION
3 318260201 A B Trim, oven door, black, upper
3A 318260401 A B Trim, oven door, side, (2)
4 318261301 A - Glass Assy., oven door, white, outer, w/trim
4 318261300 - B Glass Assy., oven door, black, outer, w/trim
6 318260500 A B Baffle, door
7 318285057 A B Insulation, oven door
7A 318285062 A B Insulation, oven door
8 316117500 A B Glass, oven door, heat barrier
9 318259601 A B Liner, oven door
10 5304416408 A B Screw, 10-24 x 1.750, handle mtg
12 318053130 A B Seal, oven door
17 316402403 A B Spacer, door glass, (2)
23 318024722 A B Hinge, upper door, (2)
29 318014402 A B Spacer, door
39 316203001 A - Handle, door, white
39 316270200 - B Handle, door, black
40 318242700 A B Bracket, glass holder, (2)
56 5304436875 A B Screw, 8-18 X 1/2, black
64 318165800 A B Spacer, (2)
* 316221001 A B Label, anti-tip
* 5304415832 A B Screw, 8-18 x 0.406

Publication No: 5995441572 FED355E
07/05 10
WIRING DIAGRAM
