Frigidaire FEF450WF User manual

PRODUCT NO. FACTORY NO. COLOR MARKET
FEF450WFWC 38154535C7013 WHITE U.S.A.
FEF450WFDC 38154535C7033 ALMOND U.S.A.
Publication No.
5995318119
990212
-EN/SERVICE /MG
377
ELECTRIC - RANGE
Model No.
FEF450WF
©1999 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
ELECTRIC RANGE
WIRING DIAGRAM # -318045306
OWNERS GUIDE #-318068801
INSTALLATION INSTRUCTION #-318200870
FRIGIDAIRE HOME PRODUCTS
7075 ORDAN DRIVE
MISSISSAUGA, ONTARIO
CANADA L5T1K6
TEL :[phone]

02/99 2
Publication No. FEF450WF
5995318119 BACKGUARD
98
99
99
10
4
14A
14A
69
1
4
6
6A
3
15A
15
18
21
18A
LA9923G05
24
54
54
54
54
46
46
36 36 36
36
19
32A
23
20
12

# = Functional Part 302/99
* = Non-Illustrated Part
FEF450WF Publication No.
5995318119
POS. NO PART NO. DESCRIPTION
15303304006 A B Shield-backguard
35303286690 A B Lamp-fluorescent
4318110300 A B Receptacle-lamp RH/LH
65308068062 A B Starter-lamp
6A 318110400 A B Holder, starter
10# 318122802 A B Ballast-lamp
12A 5304400505 A B Oven control
14A 3051539 A B Light/Lamp-oven
15 5303304000 A B Bracket-end cap RH
15A 5303304001 A B Bracket-end cap LH
18 5303304002 AEnd Cap,white ,RH
18 5303304003 BEnd Cap,almond ,RH
18A 5303304004 AEnd Cap,white ,LH
18A 5303304005 BEnd Cap,almond ,LH
19 318005718 APanel-control metal
19 318005719 BPanel-control metal
20 # 318013006 A B Electronic timer
21 318051302 ATrim-canopy white
21 318051303 BTrim-canopy almond
23 318015011 A B Bracket-timer
24# 316005602 A B Switch-oven light, rocker type
32A 318016325 A B Knob-thermostat
36 5303299751 A B Knob-surface unit black
46 5308006417 A B Lens-light/lamp
54 # 318120501 A B Switch-surface unit
69 5303323134 A B Screw,switch mtg. ,8-32 x 3/16
98 318092405 A B Harness wires
99 5303304544 A B Spacer-end cap
* 5303211311 A B Screw,#8 x ½
*08016432 A B Screw truss head, 8-18 x 3/8
*318052086 A B Harness wires
BACKGUARD
A= FEF450WF (FEF450WFWC)
B= FEF450WF (FEF450WFDC)

02/99 4
Publication No. FEF450WF
5995318119 BODY
81
81
217
80
170
170A
37
45
191
191
74
4
8A
8
84
84A
59A
58E
58F
102 262
5
142 62
134
1
260
LA9923V10
6
6A
87
67
261
67A
66A
58B 58A
10
9
127 14
54
15 1617
41
86
86
41
66 68
25
83A
139
30
57
140
83
76
3A
3
88
89
29
77
77A
29
59
84B
129
128
137
27 141
69
12
63

# = Functional Part 502/99
* = Non-Illustrated Part
FEF450WF Publication No.
5995318119
POS. NO PART NO
DESCRIPTION
1 5303310527 A B Back-main
3 5308012527 APanel-bodyside,white RH
3A 5308012528 APanel-bodyside,white LH
35308012529 BPanel-bodyside almond RH
3A 5308012530 BPanel-bodyside almond LH
4318073704 A B Burner box
5 318175500 A B Screw-levelling
6 5303310522 A B Rack-oven
6A 318119700 A B Rack-oven small
85303311141 A B Shield-heat insulation
8A 318071900 A B Panel-insulation bottom
9 5303317977 A B Pan-broiler
10 5303317976 A B Insert-broiler pan
12 # 318089910 A B Switch-light
14 5308011085 A B Socket-light/lamp
15 3201908 A B Lamp-oven light
16 3201911 A B Glass-oven light lens
17 5304400195 A B Retainer lens
25 318133000 A B Shield-heat lower
27 5303284616 A B Clip-thermo bulb
29 3051654 A B Guide-drawer front
30 318023909 A B Bracket main top
37 # 316111203 A B Probe-oven temp
41 5303310526 A B Cover-hinge cutout
45 318057401 A B Shield-wire
54 5303310514 A B Housing-oven light
57 318055700 A B Panel-back
58A 5303310539 A B Insulation,oven wrapper
58B 5303310538 A B Insulation,oven back
58E 5301305817 A B Insulation, oven wrapper
58F 5301167905 A B Insulation, oven back
59 318072501 A B Tube oven vent
59A 3017402 A B Tube oven vent LH
62 # 5303310518 A B Terminal Block
63 5303310517 A B Plate-ground strap
66 # 5303310513 A B Element-broil
66A# 318110100 A B Element-broil small
67 # 5303310512 A B Element-bake
67A# 318110600 A B Element bake small
68 5304403015 A B Support-element
69 318036400 A B Plate-oven light small
74 5308003107 A B Bumper door top
76 318056004 A B Frame-front
77 318018000 A B Rail-drawer RH
77A 318018001 A B Rail-drawer LH
80 5303324473 A B Bracket-oven
81 5303301261 A B Spring oven/ Attache four
83 318089600 A B Liner-oven assy
83A 318089200 A B Liner-oven assy small
84 3204822 A B Gusset-rear RH
84A 3204823 A B Gusset-rear LH
84B 318055901 A B Gusset-rear
86 5303310524 A B Channel-hinge
87 318111800 A B Plate-mounting cord
88 5303311160 A B Rod-latch
89 # 318095901 A B Motor-latch assy
89* 318120702 A B Switch latch
102 318111901 A B Support-oven front
127 5303310542 A B Adapter assy
128 5303311163 A B Bushing
129 5303311164 A B Spring
134 5303310515 A B Cover-wiring
137 3204318 A B Plate-strike
139 318042900 A B Braket-filler
140 318071300 A B Retainer-insulation
141# 318003600 A B Thermostat-safety
142 318123901 A B Deflector
170 3203575 A B Anti-tip bracket
170A 3203576 A B Anti-tip bracket
191 5303304030 A B Bracket corner
217 316042300 A B Plate-warning
BODY
A= FEF450WF (FEF450WFWC)
B= FEF450WF (FEF450WFDC)

02/99 6
Publication No. FEF450WF
5995318119 BODY
POS. NO PART NO. DESCRIPTION
191 5303304030 A B Bracket corner
217 316042300 A B Plate-warning
260 318055500 A B Support-gusset
261 08014183 A B Grill-broiler small
262 08011954 A B Support/ Support
*3204817 A B Plug button
*5303051099 A B Nut, hex #10-32
*5303211311 A B Screw, #8 X ½
*5303307980 A B Screw, 8-32 X 7/16
*5305151612 A B Nut
*3204817 A B Plug
A= FEF450WF (FEF450WFWC)
B= FEF450WF (FEF450WFDC)

02/99 7
Publication No. FEF450WF
5995318119 TOP/DRAWER
93
27
28
17
19A
27
93
93
93
27
27
15A
15
21
21A
21A
15A
28
28
21
138A
138 28
15
19
19A
19
LA9923T01
2A
30
29
63
69
60
5
65
63A
29
7
16
139
20
20
39A
4A
39
61
4
1
18
18

# = Functional Part 802/99
* = Non-Illustrated Part
FEF450WF Publication No.
5995318119
POS. NO PART NO DESCRIPTION
1 3202108 A B Drawer-utility
2A 318048204 A B Liner-small door
4 08011980 APanel-drawer,white
4 5303326191 BPanel-drawer,almond
4A 318009308 APanel-oven door white
4A 318009309 BPanel-oven door almond
5318014500 A B Spacer-handle
75301315217 A B Glide-drawer
15 # 5303309001 A B Element-surface,2600W
15A# 5303309000 A B Element-surface,1500W
16 08011961 AMaintop, white
16 08011984 BMaintop, almond
17 3051554 A B Rod-maintop support
18 3051745 A B Retainer-hinge
19 318138500 A B Pan-burner large
19A 318138501 A B Pan-burner small
20 3201572 A B Spacer, handle
21 5308003113 A B Trim-Ring small
21A 5308003114 A B Trim Ring large
27# 5303323704 A B Terminal block
28 5303301461 A B Medallion surface element
29 318141800 A B Spacer-hinge pin
30 5301311649 A B Insulation-door small
39 3201576 A B Handle drawer
39A 318040603 A B Handle-door
60 5303323139 A B Screw, 10-24 X 29/32
61 318107700 A B Toeplate
63 318024505 A B Hinge-lower
63A 318024507 A B Hinge-top
65 3204306 A B Latch-door
69 318053300 A B Seal-oven door
93 318122500 A B Support terminal block
138 5301315631 A B Bracket-hinge main top
138A 3051658 A B Bracket-hinge main top
139 08011955 A B Screw, 10-24 X 3/8
*08002868 A B Screw, 10-24 X ½
*5303211311 A B Screw, #8 X ½
*5303320848 A B Screw, 6-20 X ¼
*5303321106 A B Plug-button
*3051070 A B Screw, 10-24 X 7/16
*5303317975 A B Screw, 10 X ½
*318086002 A B Washer
TOP/DRAWER
A= FEF450WF (FEF450WFWC)
B= FEF450WF (FEF450WFDC)

02/99 9
Publication No. FEF450WF
5995318119 DOOR
54
39
20
20
35
35
13
7C
32
23
17
16
16
16
22
22
23
7
9
31
7A
6
5
15
15A
18A
7B
18
12
LA9923D08
60

# = Functional Part 10 02/99
* = Non-Illustrated Part
FEF450WF Publication No.
5995318119
POS. NO PART NO DESCRIPTION
55303310508 A B Glass-oven door
6 318057000 A B Baffle-door
7 5303310532 A B Insulation-door
7A 318106000 A B Insulation-door
7B 5304400472 A B Insulation-door
7C 3204813 A B Insulation-door
9 318048702 A B Liner-oven door
12 318053103 A B Seal-oven door
13 318009101 APanel-oven door white
13 318009102 BPanel-oven door almond
15 318024000 A B Bracket-glass mtg RH
15A 318024001 A B Bracket-glass mtg LH
16 5303310533 A B Glass-oven door, heat barrier
17 318139000 A B Spacer-glass
18 5303310531 A B Seal-rope
18A 5303310505 A B Seal (glass ext. door)
20 3201572 A B Spacer-handle
22 5303310511 A B Retainer-glass
23 318024700 A B Hinge
31 5303310536 A B Latch-door
32 318057202 A B Deflector-handle
35 5303310504 A B Spacer-door handle
39 318040602 A B Handle-door,oven
54 5303317975 A B Screw-oven door
60 3051070 A B Screw, 10-24 X 7/16
* 5303211311 A B Screw,#8 x 1/2
* 5303307980 A B Screw,8-32 x 7/16
*5303308450 A B Screw, 8 X 3/8
*318086002 A B Washer
*5303317975 A B Screw, 10 X ½
DOOR
A= FEF450WF (FEF450WFWC)
B= FEF450WF (FEF450WFDC)

02/99 11
Publication No. FEF450WF
5995318119 WIRING DIAGRAM
1
2
3
4
5
6
BA
t°
OVEN CIRCUIT / CIRCUIT DU FOUR
BL-4
Y-4 R-4
R-4
W-5
BK-4
BK-6
BK-6
R-4
LEFT OVEN
THERMOSTAT SAFETY
THERMOSTAT
LEFT OVEN
BROIL ELEMENT
L1 BR MDL NDLB
BAKE
RELAY BROIL
RELAY DOOR LOCK
RELAY
BR-5 O-5
V-5
V-5
GY-5
MTR
BK-6 W-6 BK-8
W-6 W-6
BK-6
BK-5 BR-5 W-5
BK-4 T-4 T-4 R-4
v-5 v-5
BL-4 BL-4 BL-4
BK-4
Y-5
Y-4 Y-4
BL-5
Y-4 R-4 R-4
BK-1 R-1 W-5
P
P
SW A
SEE LEGEND
R-4
v-5 v-5
BK-4
GY-5
NO
C
NC
BK-8
