Product No. FES365ECF
37954336H50S6
Series 30" slide-in
Color stainless
Market North America
Wiring Diagram 318271958
Owner's Guide 318203821
Installation Instructions 318201611
Timer Guide 318200184
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995543385
09/06/22
(EN/SERVICE/BJH)
377
30-INCH SLIDE-IN
ELECTRIC RANGE
Model No.
FES365E
Copyright ©2009 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995543385 FES365ECF
06/09 2
BACKGUARD

FES365ECF Publication No: 5995543385
# Functional Parts 3 06/09
* Non-Illustrated Parts
BACKGUARD
POS. NO PART NO. DESCRIPTION
14 # 318293901 Light, indicator, 125v, (2)
16 318299102 Console, assy., black
19 318235119 Panel, control, black
19A 318224401 Panel, control mtg.
20 # 318185454 Clock/Timer, electronic, black, ES300
20* 316419103 Overlay, clock, black, ES300
24 # 316005602 Switch, rocker, black
35 318183100 Support, glass, black
36 316223027 Knob, control, black
42 318298001 Trim, vent, black, upper
46 318228301 Lens, indicator light
54 # 318293830 Switch, infinite, (2)
54A# 318293831 Switch, surface element, large
54B# 318191027 Switch, infinite, dual
55 318402901 Bushing, switch
69 5303323134 Screw, 8-32 x 3/16, (4)
99A 318223900 Gasket, dark grey
* # 318228860 Harness, wiring, main, backguard
* # 318224812 Harness, wiring, timer
* 08016432 Screw, truss head, 8-18 x 0.375
* 5303300265 Screw, 8-18 X 1/2, silver, (4)

Publication No: 5995543385 FES365ECF
06/09 4
BODY

FES365ECF Publication No: 5995543385
# Functional Parts 5 06/09
* Non-Illustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
1 318259220 Back, main
1A 318225110 Panel, main back, upper
2 318258902 Shield, insulation, upper
3 318225210 Panel, bodyside, upper RH
3A 318225211 Panel, bodyside, upper LH
5 318175508 Screw, leveling
6 318345207 Rack, oven
9 316081900 Pan, broilerOPTIONAL ACCESS0RY
10 316082000 Insert, broiler panOPTIONAL ACCESS0RY
12 # 318394801 Switch, light, door
14 318224000 Receptacle, oven light
15 5303013071 Bulb/Lamp, light
16 318406100 Lens, oven light, glass
17 5304400195 Retainer, light cover
29 316517600 Spacer, oven door
37 # 316217002 Probe, oven temp
54 318222400 Housing, oven light
58A 318386100 Insulation, oven wrapper
58B 318133791 Insulation, oven back, back/bottom
59 318072560 Duct, oven vent
59A 318261600 Bracket, vent tube
62 5303935061 Terminal Block Kit
62* 5303323139 Screw, 10-24 x 0.906
62* 5303323144 Nut, 10-32
63 318264200 Plate, grounding strap
66 # 318255600 Element, broil, 2750W
67 # 318255401 Element, bake, 3400W
68 5304403015 Support, hanger, (4), broil element
70 318259100 Shield, insulation, sides, (2)
71 318260007 Panel, rear box
76 318056292 Front, oven
80 5303320846 Plate, oven mtg
81 318192400 Spring, oven
82 318258707 Shield, insulation, lower
83 318261403 Liner, oven assy
86 318561100 Receptacle, hinge, (2)
87 318260608 Bracket, cable mtg.
87A 318111806 Plate, cord set mtg
89 # 318261205 Motor, latch assy
90 318296904 Panel, filler, black, RH
90A 318296905 Panel, filler, black, LH
108# 318073028 Motor, blower
* 08016432 Screw, truss head, 8-18 x 0.375
108A 318251300 Bracket, fan support
112# 318112703 Relay
119# 318005202 Switch, thermal cutout
127 318317100 Adapter Assembly, vent tube, w/converter
131 318272901 Box, vent
132 318003000 Plate, shield
166 318298410 Bracket, base support, (2)
166A 318298403 Bracket, base support, lower, (2)

Publication No: 5995543385 FES365ECF
06/09 6
BODY

FES365ECF Publication No: 5995543385
# Functional Parts 7 06/09
* Non-Illustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
170 318335500 Anti-tip & accessories
185 318165800 Spacer
200 318335600 Frame & Wheel Assembly, black
201 318298230 Frame, drawer, black
219# 318003614 Thermostat, safety
219A 318003613 Thermostat, safety, 1.375" mtg, 105/120
300 318326501 Shield, heat
* # 318224973 Harness, wiring, main
* 318235300 Connector assy., w/3 lugs, & instructions
* 5304400192 retainer wire
* 5303211311 Screw, 8 x 0.500
* 5303323129 Screw, 8 X 0.750
* 5304415832 Screw, 8-18 x 0.406
* 5304436875 Screw, 8-18 X 1/2, black

Publication No: 5995543385 FES365ECF
06/09 8
TOP/DRAWER
46
15B
15B
15A
52A
52B
15
16
51
165
52C
52A
TCFES365EC6
1
4
11
11
7
7
13
13A
39
10
10
90
90

FES365ECF Publication No: 5995543385
# Functional Parts 9 06/09
* Non-Illustrated Parts
TOP/DRAWER
POS. NO PART NO. DESCRIPTION
1 318107105 Drawer
4 318298812 Panel, drawer, stainless, front
7 318332200 Roller, nylon
10 5304452028 Screw, handle mtg, 10-14 x 1/2, (2)
11 318298601 Bracket, drawer support, (2)
13 318018100 Channel, drawer, RH
13A 318018101 Channel, drawer, LH
15 # 316418401 Element, dual, 9"/6", surface, 1300W/1200W, (2), radiant
15A# 318198834 Element, surface, 8" /large, 2200 W
15B# 318198830 Element, surface, 6", 1200W, (2), radiant
16 318223614 Main Top, glass assy., black
39 316270200 Handle, door, black
46 318225429 Box, burner
51 # 318044828 Light, indicator, 125v
52A 318122006 Spring, element mtg, small
52B 318122007 Spring, element mtg, large
52C 318122010 Spring, element mtg, 3000W
90 318368001 Channel, glass protector, (2)
165 318227503 Plate, mounting
* # 318228925 Harness, wiring, cooktop
* # 318231843 Harness, wiring, pilot light
* 5303211311 Screw, 8 x 0.500
* 5303300265 Screw, 8-18 X 1/2, silver, (4)

Publication No: 5995543385 FES365ECF
06/09 10
DOOR

FES365ECF Publication No: 5995543385
# Functional Parts 11 06/09
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
3A 318260401 Trim, oven door, side, (2)
3B 318262101 Cover, rear door, black, (2)
6 318260522 Baffle, door
7 318372000 Insulation, door, (2)
7A 318372002 Insulation, door, (2)
8 316117500 Glass, oven door, heat barrier
9 318360108 Liner, oven door, upper
10 5304452028 Screw, handle mtg, 10-14 x 1/2, (2)
12 318053130 Seal, oven door, lower
13 318272183 Door Assy, glass, stainless steel, outer
16 318212210 Glass, oven door, heat barrier, lower door
17 318264710 Spacer, glass, lower, (2)
23 318567100 Hinge, upper, oven door, (2)
24 318260301 Trim, door, black, lower
39 316270200 Handle, door, black
40 318242702 Bracket, glass holder, door, (2)
41 318370600 Bracket, glass retainer, (2)
42 318382301 Bracket, glass retainer, (4)
56 5304436875 Screw, 8-18 X 1/2, black
64 318165800 Spacer
* 316221001 Label, anti-tip
* 5304415832 Screw, 8-18 x 0.406

Publication No: 5995543385 FES365ECF
06/09 12
WIRING DIAGRAM

FES365ECF Publication No: 5995543385
# Functional Parts 13 06/09
* Non-Illustrated Parts
WIRING DIAGRAM
