Frigidaire FPEF4085KF Installation instructions

frigidaire.com
Signature Features
Product Dimensions
Height (Max.) 48-1/8"
Width 40-1/8"
Depth (Including Handle) 28-1/2"
More Easy-To-Use Features
One-Touch Keep Warm Setting
Just one touch of a button keeps food
warm until everything — and everyone —
is ready.
Real Stainless Steel
Real stainless steel with a protective
coating that reduces fingerprints and
smudges so it’s easy to clean.
Delay Start
Set your oven to begin cooking on
your schedule. It can be programmed
from 1 to 24 hours.
Eortless™ Convection
Takes the guesswork out of convection
cooking — our oven does the converting
for you.
“My Favorite” Setting
Easily program your most used setting
with the touch of a button.
SpaceWise® Expandable Elements
Flexible elements expand to your
cooking needs.
SpaceWise® Bridge Element
A flexible element lets you combine two
elements into one to fit larger cookware.
Even Baking Technology
Our latest technology ensures even
baking every time.
Sabbath Mode (Star-K® Certified)
Available in:
Stainless
(F)
SpaceWise® Side Oven
This range features an extra 1.7 cu. ft.
SpaceWise® side oven that gives you
more space to cook multiple dishes
at the same time.
True Convection
Multi-rack baking is faster and more
even with True Convection.
Keep Warm Zone
Keep food warm until everything —
and everyone — is ready.
Pro-Select® Controls
Precise control at your fingertips.
Freestanding Range
FPEF4085K F 40" Electric
Elements
Right Front
Right Rear
Left Front
Left Rear
Left Bridge
Center
Watts
1,000 / 2,000
1,200
1,800
1,800
700
100
Size
6"/ 8"
Expandable
6"
7"
7"
SpaceWise®
Bridge
Keep Warm
Zone

Specifications
subject to change.
Accessories information available
on the web at frigidaire.com
Features
Oven Control / Timing System
Surface Type
Window
Exterior Door Finish
Handle Design
Exterior Finish (Side Panels)
Convection System
Oven Cleaning System
Drawer Functionality
Auxiliary Oven
Oven Controls
Bake / Broil
Eortless™ Convection Conversion
Convection Bake / Broil / Roast
Quick Bake Convection
PowerPlus® Preheat
My Favorite
Chicken Nugget Button
Pizza Button
Keep Warm
Add-a-Minute
Delay Bake
Self Clean
Rapid Clean Option
Delay Clean
Kitchen Timer / Timed Cook Option
Auto Oven Shuto
Lower Drawe r Control
Auxiliary Oven Control
Cooktop Features
Right Front Element (Watts)
Right Rear Element (Watts)
Left Front Element (Watts)
Left Rear Element (Watts)
Left Bridge Element (Watts)
Center Element (Watts)
Oven Features
Main / Auxiliary Capacity (Cu. Ft.)
Main / Auxiliary Oven Light
Hidden Bake Element
Rack Configuration
Baking System
Broiling System
Main Bake / Broil Elements (Watts)
Aux. Bake / Broil Elements (Watts)
Auxiliary Oven Racks
Certifications
Sabbath Mode (Star-K® Cert.)
Specifications
Main Oven Interior ( H x W x D )
Auxiliary Oven Interior ( H x W x D )
Power Supply Connection Location
Voltage Rating
Connected Load (kW Rating)
@ 240 / 208 Volts
Amps @ 240 / 208 Volts
Minimum Circuit Required (Amps)
Shipping Weight (Approx.)
Pro-Select® Controls (Main)
Black Ceramic Glass
Extra-Large with
Pro-Tint Finish
Real Stainless Steel
Stainless Steel
Black
True Convection (Main)
Self Clean (Main)
Storage
SpaceWise® Side Oven
Yes / Low and High
Yes (Main)
Yes / No / Yes (Main)
Yes
Yes
Yes
Yes
Yes
Yes
Yes / Yes
6 Hours
Mechanical
SpaceWise® Expandable
6" / 8" – 1,000 / 2,000
6" – 1,200
7" – 1,800
7" – 1,800
SpaceWise® Bridge – 700
Keep Warm Zone – 100
3.7 / 1.7
2 / 1
3 Heavy Duty
Even Baking Technology
Vari-Broil™ Hi/Lo
3,000 / 2,750
1,500 / 1,500
1 Standard
Yes
15-3/4" x 22-5/8" x 17-3/4"
16" x 9-9/16" x 19-1/2"
Middle Bottom Rear
240V / 208V / 60 Hz
12.8 / 9.6
53.0 /46.0
40
235 Lbs.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FPEF4085K 01/11 © 2011 Electrolux Home Products, Inc. Printed in the U.S.A.
Freestanding Range
FPEF4085K F 40" Electric
Cutout Dimensions
Height (Standard)
Width (Min.)
Depth (Min.)
36"
40-1/4"
24"
Product Dimensions
A - Height (Max.)
B - Width
C - Depth (Including Handle)
Depth with Door Open 90˚
48-1/8"
40-1/8"
28-1/2"
44-5/8"
NOTE: For planning purposes only. Always consult local and national electric codes.
Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.
40" Dual Fuel/Electric Freestanding Ranges
Frigidaire Professional
C
A
B

Specifications
subject to change.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FPEF4085K 10/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
Freestanding Range Specifications
•Product Shipping Weight (approx.) – 235 Lbs.
•Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt,
60 Hertz, fused on both sides of line with ground. (If local code
permits, range may be connected by hard-wiring or by means
of power supply cord kit.)
•Connected Load (kW Rating) @ 240 / 208 Volts = 12.8 / 9.6 kW
•Amps @ 240 / 208 Volts = 53.0 / 46.0 Amps
•Recommended Circuit Breaker – 50 Amps (40 Amps minimum)
•Always consult local and national electric codes.
•Make sure wall coverings around range can withstand heat generated
by range.
•Linoleum or any other synthetic floor covering located beneath range,
must be capable of withstanding minimum heat of 90° F above room
temperature without shrinking, warping or discoloring. Insulating pad
or 1/4"-thick plywood required between range and a carpeted floor.
•Absolute minimum horizontal distance between overhead cabinets
installed to either side of appliance must be no less than maximum
width of appliance.
•Allow 24" minimum clearance between rangetop and bottom of cabinet
when bottom of wood or metal cabinet is protected by not less than
1/4" flame-retardant millboard covered with not less than No. 28 MGS
sheet steel, 0.015" stainless steel, 0.024" aluminum or 0.020" copper.
Allow 30" minimum clearance when cabinet is unprotected.
•To reduce risk of fire when using overhead cabinetry, install
range hood that projects horizontally a recommended minimum
of 5" beyond bottom of cabinets.
•0" clearance required (minimum 2" recommended) from edge
of rangetop to nearest combustible wall on either side of range
above 36" height.
•Range can be installed flush to wall with 0" minimum rear clearance.
•For installation against left side wall that extends to or beyond
range's side panel, allow 2-3/4" minimum clearance to allow
auxiliary oven door to open.
•Follow all dimension requirements provided to prevent property
damage, potential fire hazard, and incorrect countertop and
cabinet cuts.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at frigidaire.com for detailed instructions.
Freestanding Range
FPEF4085K F 40" Electric
40" Electric Freestanding Ranges
Professional

Specifications
subject to change.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
INSTGDLNS_SSR FR 10/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
General Installation Guidelines
with Side-by-Side Refrigerator
Top
Use these dimensions and clearance instructions for planning purposes only. For detailed installation
instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.
Front
Top
Front

Specifications
subject to change.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
INSTGDLNS_TMR FR 10/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
Use these dimensions and clearance instructions for planning purposes only. For detailed installation
instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.
Front
Top
Front
Top
General Installation Guidelines
with Top Mount Refrigerator
