Frigidaire FGF367CG User manual

© 1998 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
GAS RANGE
P.O. Box 212378
Augusta, Georgia 30917
PRODUCT NO. BASE MODEL NO. COLOR MARKET
FGF367CGSC FGF367CG WHITE/WHITE USA
FGF367CGSD FGF367CG WHITE/WHITE USA
FGF367CGTC FGF367CG ALMOND/ALMOND USA
FGF367CGTD FGF367CG ALMOND/ALMOND USA
Publication No.
5995323549
WIRING DIAGRAM # - 316002168
OWNER’S GUIDE # - 316000286,316000296
INSTALLATION GUIDE # - 316105808,316105822 GAS - RANGE
FGF367CG

05/98 2
Publication number
5995323549 FGF367CG
CAUTION: Use the part number on all orders, not the position number.
BACKGUARD

# - Fast Moving Parts
* - Non Illustrated Parts 3 6/98
Publication number
FGF367CG 5995323549
CAUTION: Use the part number on all orders, not the position number.
BACKGUARD
A = FGF367CG (FGF367CGSC)
B = FGF367CG (FGF367CGSD)
C = FGF367CG (FGF367CGTC)
D = FGF367CG (FGF367CGTD)
POS. NO PART NO DESCRIPTION
* 316000286 A - C - Owner’s Manual
* 316000296 - B - D Owner’s Guide
* 316021108 A B C D Screw,cup pt ,#8-18 x 3/8 ,hinge ,
ind lght brkt,manifold pnl
* 316021110 A B C D Screw-8-18x1/2 Tr Sqd black
* 316105822 - B - D Installation Instr
* 316112500 A B C D Template, Anti-tip bracket
1 316028701 A B C D Shield-backguard, rear wall
2 316051600 A B C D Shield-backguard inner
2A 316053802 A B C D Shield-backguard,inner/top
11 316083722 A B - - Trim-wrapper gas white w/hole,textured
11 316083723 - - C D Trim-wrapper gas almond w/hole,almond
15 316023108 A B C D Support-backguard,RH
15A 316023109 A B C D Support-backguard,LH
19 316100525 A B - - Panel-control,metal ,painted ,white
19 316100547 - - C D Panel-control, almond
20 # 316101000 A B C D Clock/Timer,electronic
20* 316101502 A B - - Overlay-clock
20* 316101504 - - C D Overlay-clock
23 316100300 A B C D Bracket-clock mtg
24 # 316005607 A - - - Switch-rocker,oven light ,white
24 # 316005608 - - C - Switch-rocker,oven light ,almond
24# 316118101 A B - - Switch-rocker,oven light ,white
24# 316118102 - - C D Switch-rocker,oven light ,almond
36 316109503 A B - - Knob-top valve,white
36 316109504 - - C D Knob-top valve, almond
40 316009285 A B - - Panel-manifold
40 316009287 - - C D Panel-manifold
42 316055200 - - C D Trim-vent
42 316055201 A B - - Trim-vent
56 316074907 A B C D Deflector-flue, black

05/98 4
Publication number
5995323549 FGF367CG
CAUTION: Use the part number on all orders, not the position number.
BURNER

# - Fast Moving Parts
* - Non Illustrated Parts 5 05/98
Publication number
FGF367CG 5995323549
CAUTION: Use the part number on all orders, not the position number.
A = FGF367CG (FGF367CGSC)
B = FGF367CG (FGF367CGSD)
C = FGF367CG (FGF367CGTC)
D = FGF367CG (FGF367CGTD)
POS. NO PART NO DESCRIPTION
* 5303271648 A B C D Screw, wafer hd sq dr , 8-18AB x 1/2
1 316113801 A B C D Manifold-pipe
2 # 316127500 - B - D Valve-top burner
2 # 5303935130 A - C - Valve-top burner
2* 316048200 A B C D Screw-,hex washer head ,1/4-20 x 0.31 ,
w/gasket
2A # 316127502 - B - D Valve-top burner,large ,(2)
2A # 5303935132 A - C - Valve-top burner,large ,(2)
3 # 316103600 A B C D Switch-ignitor,(4)
4 # 316059612 A B C D Tube-burner,red ,RF
5 # 316059613 A B C D Tube-burner,green ,LF
6 # 316059614 A B C D Tube-burner,nat. ,RR
7 # 316059615 A B C D Tube-burner,black ,LR
8 # 5303280394 A B C D Spark Module
8* 5303289034 A B C D Harness-wiring, module/igniter
10 # 5303935025 A B C D Burner Assy-top,sealed ,small ,9000 BTU
10A 5303935075 A B C D Burner Assy-top,sealed ,large ,
11,100 BTU,(2), includes ,11,37,44,45
11 316011200 A B C D Ignitor-top burner,(4) ,w/mtg bracket
13 # 316065005 A B C D Tube,aluminum ,rgltr to manf ,
with fittings
14 # 316091706 A B C D Regulator-pressure
14* 316021104 A B C D Screw-regulator/brkt, hex , 8-18 x 3/8 ,
nick, 3
15 316091600 A B C D Bracket-regulator
16 # 316065003 A B C D Tube-valve to regulator,3/8
17 # 5303208499 A B C D Valve-safety,dual
18 # 3131290 A B C D Burner-oven
19 # 5303935066 A B C D Ignitor-oven
20 3131284 A B C D Baffle-oven burner
21 5303013272 A B C D Nut, hex head sems
22 # 316065002 A B C D Tube-valve to mixer
23 # 316087900 A B C D Burner-broiler
24 # 316070400 A B C D Mixer Elbow
25 5303210379 A B C D Baffle-broiler
26 # 5308067970 A B C D Ignitor-broiler
37 316069301 A B C D Screw-burner mtg
44 5303210090 A B C D Orifice-top burner,small
44A 316010801 A B C D Orifice-top burner large
45 316011100 A B C D Screw-ignitor mtg,self-tapping ,M3x5.8
46 316074700 A B C D Plate-burner tube
47 # 5303286386 A B C D LP Conversion Kit
BURNER

05/98 6
Publication number
5995323549 FGF367CG
CAUTION: Use the part number on all orders, not the position number.
BODY

# - Fast Moving Parts
* - Non Illustrated Parts 7 05/98
Publication number
FGF367CG 5995323549
CAUTION: Use the part number on all orders, not the position number.
BODY
A = FGF367CG (FGF367CGSC)
B = FGF367CG (FGF367CGSD)
C = FGF367CG (FGF367CGTC)
D = FGF367CG (FGF367CGTD)
POS. NO PART NO DESCRIPTION
* 08067757 A B C D Cover Plate
* 316001632 A B C D Harness-wiring,chassis
* 316021108 A B C D Screw,cup pt ,#8-18 x 3/8 ,hinge
1 316029412 A B C D Back-main
2 3131314 A B C D Shield-oven top
3 316081034 A B - - Panel-bodyside, white ,RH
3 316081035 A B - - Panel-bodyside, white , LH
3 316081036 - - C D Panel-bodyside,almond ,RH
3 316081037 - - C D Panel-bodyside,almond ,LH
4 316011912 A B C D Burner Box,black
5 316107300 A B C D Screw-leveling
6 316067902 A B C D Rack-oven
7 316007002 A B C D Hinge-oven door,(2)
8 5303212540 A B C D Panel-oven bottom
8* 316064600 A B C D Support-oven bottom
9 316073800 A B C D Pan-broiler
10 3205234 A B C D Insert-broiler pan
12 # 316027701 A B C D Switch-oven light
13 316026800 A B C D Rod-light switch /door
14 316116400 A B C D Socket-light
15 5303013071 A B C D Light Bulb/Lamp
16 08011086 A B C D Lens-light/lamp, glass , oven
17 316087500 A B C D Retainer-lens
18 # 316036300 A B C D Latch-door
21 3014099 A B C D Spacer-bodyside, (8)
25A 5303288580 A B C D Shield-heat,lower
28 3011813 A B C D Clip-wire, bodyside
29 3051162 A B C D Glide-drawer,front
30 316059200 A B C D Bracket-main top,RH
30A 316059201 A B C D Bracket-main top,LH
33 316014401 A B C D Shield,rear wall
35 316116600 A B C D Gasket-flue
36 5303272844 A B C D Flue
37 # 316111202 A B C D Probe-oven temp
38 316051700 A B C D Shield-heat
39 3202006 A B C D Cord-electric power
40 3200836 A B C D Shield-heat baffle
40* 5303288570 A B C D Screw-heat shield, hd shldr sqdr
41 3131570 A B C D Cover-hinge cutout
42 5303288578 A B C D Shield-bake burner
43 3131732 A B C D Screw-oven bottom, 8-18 x 1.438
44 3131903 A B C D Bumper-door/drawer, rubber
49 3051124 A B C D Clip-spring mtg
53 5303288579 A B C D Shield-main front
53A 08067992 A B C D Shield-insulation
55 316107800 A B C D Shield-flue
58A 316047705 A B C D Insulation,oven wrapper
58B 316054200 A B C D Insulation, 2" ,oven back
58G 08067973 A B C D Insulation,main front
72 5303285692 A B C D Cover-light/switch rod
88 316026400 A B C D Rod-latch,auto
89 # 316028101 A B C D Motor-latch/lock
170 316107200 A B C D Anti-tip bracket
170* 316116000 A B C D Screw-Anti tip, 1.75" concrete

05/98 8
Publication number
5995323549 FGF367CG
CAUTION: Use the part number on all orders, not the position number.
TOP/DRAWER

# - Fast Moving Parts
* - Non Illustrated Parts 9 05/98
Type your model numbers here
CAUTION: Use the Kenmore part number on all orders, not the position number.
TOP/DRAWER
A = FGF367CG (FGF367CGSC)
B = FGF367CG (FGF367CGSD)
C = FGF367CG (FGF367CGTC)
D = FGF367CG (FGF367CGTD)
POS. NO PART NO DESCRIPTION
* 316021108 A B C D Screw,cup pt ,#8-18 x 3/8 ,hinge ,
ind lght brkt,manifold pnl
* 316021110 A B C D Screw-8-18x1/2 Tr Sqd black
* 316021112 A B - - Screw-8-18x1/2 Tr Sqd White
* 316021113 - - C D Screw-8-18x1/2 Tr Sqd Almond
* 316089600 A B C D Spacer-drawer,(2)
* 5303280311 A B C D Screw, waf hd sdr , 10-32 x 5/16 , (2)
1 316011501 A B C D Drawer-utility
2 3131975 A B C D Shield-panel
4 316084405 A B - - Panel-drawer,white
4 316084406 - - C D Panel-drawer,almond
4* 08067785 - - C D Screw,hex washer head ,8-18AB x 1/2
7 3051163 A B C D Glide-drawer,rear
16 5303307709 A B - - Main Top,white
16 5303307710 - - C D Main Top,almond
19 # 316011413 A B - - Pan-burner,gray ,small ,(2)
19 # 316011414 - - C D Pan-burner,almond ,small ,(2)
19A# 316011417 A B - - Pan-burner,gray ,large ,(2)
19A# 316011418 - - C D Pan-burner,almond ,large ,(2)
20 # 316085304 A B C D Grate,(4)
22 316122101 A B C D Cap-burner glossy,glossy ,gray ,(4)
22A 316098509 A B C D Cap-burner,large ,gloss gray
48 316077401 A B C D Shield-maintop,(2)

05/98 10
Publication number
5995323549 FGF367CG
CAUTION: Use the part number on all orders, not the position number.
DOOR

# - Fast Moving Parts
* - Non Illustrated Parts 11 05/98
Publication number
FGF367CG 5995323549
CAUTION: Use the part number on all orders, not the position number.
DOOR
A = FGF367CG (FGF367CGSC)
B = FGF367CG (FGF367CGSD)
C = FGF367CG (FGF367CGTC)
D = FGF367CG (FGF367CGTD)
POS. NO PART NO DESCRIPTION
* 3203618 A B C D Rivet-pop,warning-plate
* 316021110 A B C D Screw-8-18x1/2 Tr Sqd black
* 316065306 A B C D Plate warning/caution
* 5303212762 - - C D Screw,8-18 X 1/2
* 5303271648 A B C D Screw, wafer hd sq dr , 8-18AB x 1/2
* 5303280311 A B C D Screw, waf hd sdr , 10-32 x 5/16 , (2)
3 316067803 - - C D Trim-oven door,almond
3 316067804 A B - - Trim-oven door,white
4 316089004 - - C D Glass-oven door,almond ,outer
4 316089005 A B - - Glass-oven door,white ,outer
5 316088700 A B C D Glass-oven door,airwash
6 316088401 A B C D Shield-wool
7 316076403 A B C D Insulation-door
8 316088600 A B C D Glass-oven door,inner
9 316066610 A B C D Liner-oven door
10 5303280308 A B C D Screw-handle mtg,wafer head ,10-24T x 2
12 # 5303131601 A B C D Seal-oven door
14 3131361 A B C D Reflector,aluminum foil
14A 3131360 A B C D Reflector,aluminum foil ,(2)
15 316081403 A B C D Bracket-glass mtg
16 316085701 A B C D Glass-oven door,heat barrier
39 316091115 A B - - Handle-door,white ,oven
39 316091116 - - C D Handle-door,almond ,oven
39* 316008401 A B C D Washer,3/4 x 1/4 ,steel
52 316081301 A B - - Shield-oven door,white ,top
52 316081302 - - C D Shield-oven door,almond ,top

05/98 12
Publication number
5995323549 FGF367CG
CAUTION: Use the part number on all orders, not the position number.
WIRING DIAGRAM
