Frigidaire FGF375BH User manual

PRODUCT NO. BASE MODEL NO. COLOR MARKET
FGF375BHBB FGF375BH black North America
FGF375BHBC FGF375BH black North America
Publication No.
5995346342
001113
-EN/SERVICE /ECL
369
GAS
RANGE
Model No.
FGF375BH
©2002 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
RANGE
WIRING DIAGRAM - # 316002171
OWNER’S GUIDE - # 316135902
INSTALLATION INSTRUCTIONS - # 316105822
ELECTROLUX HOME PRODUCTS, INC.
P.O. BOX 212378, Augusta, GA 30917

05/02 2
Publication No. FGF375BH
5995346342
BACKGUARD

# = Fast-moving Parts 3 05/02
* = Non-Illustrated Parts
FGF375BH Publication No.
5995346342
BACKGUARD
A = FGF375BH (FGF375BHBB)
B = FGF375BH (FGF375BHBC)
POS. NO PART NO DESCRIPTION
1 316028700 A B Shield,backguard ,galv ,rear wall
2 316051600 A B Shield,backguard ,inner
2A 316053803 A B Shield-backguard,inner top
11 316061856 A B Trim,wrapper ,black ,textured
15 316023108 A B Support,backguard ,RH
15A 316023109 A B Support,backguard ,LH
18 5303935174 A B End Cap,black ,RH & LH
19 316115020 A B Panel-backguard
20 # 316131600 A B Clock/Timer,electronic
20A 316101527 A B Overlay-clock
23 316131501 A B Bracket-timer
24 # 316083101 A B Switch-rocker,oven light ,black ,RH
36 316109512 A B Knob-top valve,black
40 316086859 A B Panel-manifold,black ,40
42 316055202 A B Trim,extrusion ,black
56 316074907 A B Deflector,flue ,black
* 316001465 A B Wiring Harness,backguard
* 316021105 A B Screw,hex head cup pt ,8-18 x 0.375 ,black
* 316021108 A B Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021110 A B Screw,8-18 x 0.5 ,black

05/02 4
Publication No. FGF375BH
5995346342
BURNER

# = Fast-moving Parts 5 05/02
* = Non-Illustrated Parts
FGF375BH Publication No.
5995346342
BURNER
A = FGF375BH (FGF375BHBB)
B = FGF375BH (FGF375BHBC)
POS. NO PART NO DESCRIPTION
1 316113801 A - Manifold Pipe
1 316134501 - B Manifold Pipe,1
2 # 316127500 A - Valve,top burner
2 # 316134100 - B Valve-top burner
2A # 316127502 A - Valve-top burner,large ,(2)
2A # 316134102 - B Valve-top burner,large
* 316048200 A - Screw,hex washer head ,1/4-20 x 0.31 ,vlv mtg,w/gasket
* 316134300 - B Screw,10-24 ,valve mounting
3 316001826 A B Harness-ignitor,3
4 # 316059612 A B Tube,burner ,red ,RF
5 # 316059613 A B Tube,burner ,green ,LF
6 # 316059614 A B Tube,burner ,natural ,RR
7 # 316059615 A B Tube,burner ,black ,LR
8 # 316135701 A B Module,spark
10 # 5303935025 A B Burner Assy,sealed ,small ,9K
10A 5303935075 A B Burner Assy-top,sealed ,large ,11K
11 316011200 A B Ignitor,top burner ,(4) ,w/mtg bracket
13 # 316065005 A B Tube,3/8 ,aluminum ,rgltr to manf ,with fittings
14 # 316091706 A B Regulator,pressure
14* 316021104 A B Screw,hex ,8-18 x 3/8 ,nick ,(3) ,regulator brkt
15 316091600 A B Bracket,regulator
16 # 316065003 A B Tube,valve to regul. ,3/8
17 # 5303208499 A B Valve,safety ,dual
17* 08068018 A B Shield,wire ,safety valve
18 # 3131290 A B Burner,oven
19 # 5303935066 A B Ignitor,oven kit ,w/nut & instr
20 3131284 A B Baffle,oven burner
21 5303013272 A B Nut,hex head sems
22 # 316065002 A B Tube,valve to mixer
23 # 08067935 A B Burner,broiler
24 # 316070400 A B Elbow,mixer
24* 316113400 A B Spacer,mixer elbow
25 5303210379 A B Baffle,broiler
26 # 316119302 A B Ignitor,broiler
37 316069301 A B Screw,burner mtg
44 5303210090 A B Orifice,top burner ,9K
44A 316010804 A B Orifice-top burner,large ,11K
45 316011100 A B Screw,self-tapping ,M3x5.8 ,ignitor mtg
46 316074700 A B Plate,burner tube
47 5303307190 A B LP Conversion Kit
* 5303271648 A B Screw,wafer hd sq dr ,8-18AB x 0.5

05/02 6
Publication No. FGF375BH
5995346342
BODY

# = Fast-moving Parts 7 05/02
* = Non-Illustrated Parts
FGF375BH Publication No.
5995346342
BODY
A = FGF375BH (FGF375BHBB)
B = FGF375BH (FGF375BHBC)
POS. NO PART NO DESCRIPTION
1 316029416 A B Panel,main back
2 3131314 A B Shield,oven top
3 316081038 A B Panel,bodyside ,black
3 316081039 A B Panel,bodyside ,black
4 316011917 A B Burner Box,with hole
5 316129200 A B Screw,leveling ,plastic ,with stop
6 316067902 A B Rack,oven
7 316007002 A B Hinge,oven door ,(2)
8 5303300701 A B Panel,oven bottom
8* 316064600 A B Support,oven bottom
9 316081900 A B Pan,broiler
10 316082000 A B Insert,broiler pan
12 # 316027701 A B Switch,oven light
13 316026800 A B Rod,light switch
14 # 316116400 A B Receptacle,oven light
15 5303013071 A B Bulb/Lamp,oven light
16 08011086 A B Lens,oven light ,glass
17 316087500 A B Retainer,lens
18 # 316036300 A B Latch,door
21 3014099 A B Spacer,bodyside
25 5303288580 A B Shield,heat ,lower
26 08067757 A B Cover Plate,burner box
28 3011813 A B Clip,wire ,bodyside
29 3051162 A B Glide,drawer ,front
30 316059200 A B Bracket,main top ,RH
30A 316059201 A B Bracket,main top ,LH
33 5303288495 A B Shield,rear wall
35 316116600 A B Gasket,flue
36 316133002 A B Flue
37 # 316111202 A B Probe-oven temp
38 316051700 A B Shield,heat
39 # 3202006 A B Cord,electric power
40 3200836 A B Shield,heat baffle
40* 5303288570 A B Screw,hd shldr sqdr ,8-18 X 1/2 ,heat shield
41 3131570 A B Cover,hinge cut-out
42 5303288578 A B Shield,bake burner
43 3131732 A B Screw,8-18 x 1.438 ,oven bottom
44 3131903 A B Bumper,door/drawer , rubber
49 3051124 A B Clip,spring mtg
53 5303288579 A B Shield,main front
53A 08067992 A B Shield,insulation ,front frame
55 316107800 A B Shield,flue
58A 316047705 A B Insulation,oven wrapper
58B 316054200 A B Insulation,2" ,oven back
58G 08067973 A B Insulation,main front
72 5303285692 A B Cover,rod end ,lt switch rod
88 316026400 A B Rod,auto latch
89 # 316028101 A B Motor,latch
170 5303935180 A B Anti-tip Kit,w/bracket,screw
170* 316107200 A B Bracket,anti-tip
170* 316112500 A B Template,anti-tip
170* 316116000 A B Screw,concrete tpg ,1.75 inch ,anti-tip brkt
* 316001629 A B Wiring Harness,main
* 5303305345 A B Paint,touch-up ,black
* 316021105 A B Screw,hex head cup pt ,8-18 x 0.375 ,black
* 316021108 A B Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021123 A B Screw,8-18 X 3/8-8 ,TRUSS HD BLACK
* 5303271648 A B Screw,wafer hd sq dr ,8-18AB x 0.5
* 5303280311 A B Screw,wafer hd sq dr ,10-32 x 0.312
* 5303285179 A B Screw,wafer head ,8-32T x 0.500 ,black

05/02 8
Publication No. FGF375BH
5995346342
TOP/DRAWER

# = Fast-moving Parts 9 05/02
* = Non-Illustrated Parts
FGF375BH Publication No.
5995346342
TOP/DRAWER
A = FGF375BH (FGF375BHBB)
B = FGF375BH (FGF375BHBC)
POS. NO PART NO DESCRIPTION
1 316011501 A B Drawer
1* 316089600 A B Spacer,drawer ,(2)
2 5303288582 A B Liner,drawer ,galv steel ,front panel
4 316084407 A B Panel,drawer ,black
7 3051163 A B Glide,drawer ,rear
16 5303307708 A B Main Top,black
19 # 316011415 A B Pan-burner,black ,small ,(2)
19A# 316011419 A B Pan-burner,large ,black
20 # 316085201 A B Grate,black ,(4)
22 316122100 A B Cap-burner,small ,black ,(4)
22A 316098505 A B Cap-burner,black ,large
48 316077401 A B Shield,deflector ,main top panel ,(2)
* 316021105 A B Screw,hex head cup pt ,8-18 x 0.375 ,black
* 316021108 A B Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021110 A B Screw,8-18 x 0.5 ,black
* 5303280311 A B Screw,wafer hd sq dr ,10-32 x 0.312

05/02 10
Publication No. FGF375BH
5995346342
DOOR

# = Fast-moving Parts 11 05/02
* = Non-Illustrated Parts
FGF375BH Publication No.
5995346342
DOOR
A = FGF375BH (FGF375BHBB)
B = FGF375BH (FGF375BHBC)
POS. NO PART NO DESCRIPTION
3 316067802 A B Trim,oven door ,black
4 316089000 A B Glass,oven door ,black ,outer
5 316088700 A B Glass,oven door ,airwash
6 316088401 A B Shield,wool
7 316076403 A B Insulation,door
8 316088600 A B Glass,oven door ,inner
9 316066610 A B Liner,oven door
10 5303280308 A B Screw,wafer hd sq dr ,10-24T x 2.00 ,handle mtg
10* 316008401 A B Washer,3/4 OD x 1/4 ID ,steel
12 # 5303131601 A B Seal,oven door
14 5303208656 A B Reflector,aluminum foil ,black door
14A 5303208655 A B Reflector,aluminum foil ,black door
15 316081403 A B Bracket,glass mtg
16 316085701 A B Glass,oven door ,heat barrier
39 316091122 A B Handle-door,chrome
52 316081303 A B Shield,oven door ,black ,top
* 316065306 A B Plate,warning/caution
* 3203618 A B Rivet,pop
* 316132100 A B Spacer,sponge pad
* 316021109 A B Screw,8-18 x 0.5 ,chrome
* 316021110 A B Screw,8-18 x 0.5 ,black
* 5303271648 A B Screw,wafer hd sq dr ,8-18AB x 0.5
* 5303280311 A B Screw,wafer hd sq dr ,10-32 x 0.312
* 5303285179 A B Screw,wafer head ,8-32T x 0.500 ,black

05/02 12
Publication No. FGF375BH
5995346342
WIRING DIAGRAM
