Frigidaire FEFB7ABD User manual

Product No. FEFB7ABDCB
Series 30" f/s elec
Color stainless
Market North America
Wiring Diagram 316417755
Owner's Guide 316417009
Installation Instructions 316259206
Service Data Sheet 316417614
FEFB7ABDC.eps T20G0039.eps T20V0081.eps T20T0036.eps T20D0017.eps
316417755d.eps 316417755s.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995425468
05/01/04
(EN/SERVICE/BJH)
369
30-INCH FREE-
STANDING ELECTRIC
RANGE
Model No.
FEFB7ABD
Copyright ©2004 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995425468 FEFB7ABDCB
01/05 2
BACKGUARD
13A
8.8.
8.8.
14
14
14
54B
54
46
69
31
31
54
54B
14
1414
T20G0039
56
1
15A
15
19
20A
20
36
55
55A
13

FEFB7ABDCB Publication No: 5995425468
# Functional Parts 3 01/05
* Non-Illustrated Parts
BACKGUARD
POS. NO PART NO. DESCRIPTION
1 316416100 Shield, backguard, rear wall
13 316414400 Control, bake, mini oven
13A 316095500 Switch, infinite, warmer
14 316022500 Light/Lamp, indicator, 125 V
15 316411405 Support, backguard, black, RH
15A 316411404 Support, backguard, black, LH
19 316424172 Panel, control, stainless
20 # 316418304 Clock/Timer, electronic, ES340
20A 316419303 Overlay, clock, black, ES340
31 316223002 Knob, control, black
36 316223019 Knob, control, black
46 316040201 Lens, indicator light, red
54 # 316021500 Switch, infinite, small element
54B# 316238200 Switch, infinite, dual element
55 316247700 Nut, hex control mtg, (4)
55A 316247800 Washer, lock, control mtg
56 316234003 Shield, backguard, black, inner
69 5303288565 Screw, truss sqdr, 8-32 x 3/16, switch mtg
* 316416906 Harness, mini oven cntl
* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 Screw, cup pt, 8-18 x 0.375, chrome
* 316021109 Screw, 8-18 x 0.5, chrome
* 316021110 Screw, 8-18 x 0.5, black

Publication No: 5995425468 FEFB7ABDCB
01/05 4
BODY
33A
5A
5A 5
12
ANTI-TIP
BRACKET
ANTI-TIP
BRACKET
NOTE: Oven Liner N/A
Ass. du four N/A
21
3
5
170
151
87
57
71
89
88
1
86
58A
58B
18
86
1716
15
14
68164
113
113
112
112
37
67
8A
58
6
6
42
170
3
151
T20V0081
59B
59
59A
45
6B
66
62
63
44

FEFB7ABDCB Publication No: 5995425468
# Functional Parts 5 01/05
* Non-Illustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
1 316401800 Panel, main back
3 316400104 Panel, bodyside, black, RH
3 316400105 Panel, bodyside, black, LH
5 316272900 Screw, leveling, plastic, rear, (2)
5A 316407200 Leveling Leg Assy, metal, front, (2), bracket & leg
6 316404500 Rack, oven
6B 316425400 Rack, oven
8A 316411102 Base, bake element
12 # 316407100 Switch, oven light/door
14 316116400 Receptacle, oven light
15 5303013071 Bulb/Lamp, oven light
16 08011086 Lens, oven light, glass
17 316087500 Retainer, lens
18 # 316405800 Latch Assembly, oven door
21 316408000 Clip, bodyside
33A 316402100 Shield, rear wall, lower
37 # 316217001 Probe, oven temp
42 316407700 Shield, wool, lower
44 316246501 Spacer, oven door
45 316234100 Shield, wire, vent tube
57 316422400 Cover, access
58 316403801 Insulation, oven sump
58A 316406600 Insulation, oven wrapper
58B 316406500 Insulation, oven back
59 316208200 Tube, oven vent, lower
59A 316208302 Tube, oven vent, upper
59B 316247300 Catalyst, oven vent, ceramic
62 5303935238 Terminal Block Kit, w/ground plate
62* 316085600 Insulator
62* 316205500 Nut, hex flange, 3/8 10-32
63 316278800 Plate, grounding strap
66 # 316430900 Element, broil, 4000W
67 316415900 Element, bake, 3500W, 6 pass
68 316429100 Support, element, broil
71 316422300 Shield, rear wall
86 316407000 Receptacle, hinge
86* 316418901 Screw, trilobe, 10-32 x 5/16"
87 316081200 Bracket, cable mtg
88 316203500 Rod, auto latch
89 # 316415400 Motor, latch/lock
112 316435200 Standoff, strike plate
113 316431600 Plate, strike, mini oven
113* 316436700 Screw, countersunk HD, #10-16 x 1/4, (2)
151 316404600 Shield, bodyside
164 316410301 Trim, front, mini oven
170 5303935180 Anti-tip Kit, w/bracket, screw
170* 316107200 Bracket, anti-tip
170* 316112500 Template, anti-tip
170* 316116000 Screw, concrete, 1.75", anti-tip brkt
* # 316416431 Harness, wiring, main

Publication No: 5995425468 FEFB7ABDCB
01/05 6
BODY
33A
5A
5A 5
12
ANTI-TIP
BRACKET
ANTI-TIP
BRACKET
NOTE: Oven Liner N/A
Ass. du four N/A
21
3
5
170
151
87
57
71
89
88
1
86
58A
58B
18
86
1716
15
14
68164
113
113
112
112
37
67
8A
58
6
6
42
170
3
151
T20V0081
59B
59
59A
45
6B
66
62
63
44

FEFB7ABDCB Publication No: 5995425468
# Functional Parts 7 01/05
* Non-Illustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
* 3203550 Plug, button, oven bottom
* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 Screw, cup pt, 8-18 x 0.375, chrome
* 316021110 Screw, 8-18 x 0.5, black
* 316089500 Screw, 10-16 x .486
* 5303271648 Screw, wafer hd sq dr, 8-18AB x 0.5
* 5303285179 Screw, wafer head, 8-32T x 0.500, black
* 5303305345 Paint, touch-up, black
* 5308014215 Screw, 6-20 x 0.312

Publication No: 5995425468 FEFB7ABDCB
01/05 8
TOP/DRAWER
60
37
100
4
33
14A
7
14A
14B
14
29
29
30
30
12
1
2
110
109
T20T0036
108
81
105
107
106
104
13
13
85
103
102
101
17
17
8
39
52
16
18A
18
26
26B
26
26A
15A
15
15A
15
15D

FEFB7ABDCB Publication No: 5995425468
# Functional Parts 9 01/05
* Non-Illustrated Parts
TOP/DRAWER
POS. NO PART NO. DESCRIPTION
1 316414101 Drawer, mini oven
2 316409803 Liner, drawer, mini oven, w/ window
4 316432103 Panel, drawer, stainless, front
7 316437200 Insolator, heat, drawer front
8 316431901 Glass, inner door, mini oven
12 316410700 Seal, door, mini oven
13 316414000 Glide, drawer, mini oven, (2)
14 316414202 Insulation, door top, mini oven
14A 316414201 Insulation, door sides, mini oven, (2)
14B 316414203 Insulation, door bottom, mini oven
15 # 316010205 Element, surface, 6", 1200 W, radiant
15A# 316418400 Element, dual, 6"/9", surface, 1200W/1300W, radiant
15D# 318198816 Element, surface, warmer, 100 W
16 316421271 Maintop, frame/glass, black
17 316431801 Spacer, glass, mini oven, (2)
18 316235900 Hinge, main top, RH
18A 316235901 Hinge, main top, LH
26 316427600 Channel, element support, (2)
26A 316099202 Bracket, chassis support, rear
26B 316214200 Bracket, chassis support, front
29 316429000 Spacer, handle, (2)
30 316431700 Magnet Assembly, mini oven
33 316432000 Glass, drawer, front
37 # 316217003 Probe, oven temp, mini oven
39 316246100 Handle, door/drawer, stainless
52 316278300 Clip, element mtg
60 316001015 Screw, waf hd sq, 10-24 x 1.25, (2), handle mtg
81 # 316413900 Element, bake, mini oven
85 316411000 Rack, mini oven
100 316410900 Insulation, wrapper, mini oven
101 316410201 Panel, top, mini oven
102 316431201 Panel, oven side, RH, mini oven
103 316431203 Panel, oven side, LH, mini oven
104 316431500 Light Assembly, mini oven
105 316431303 Panel, main back, mini oven
106 316431400 Insualtion, oven back, mini oven
107 316431307 Shield, main back, mini oven
108 316410101 Panel, bottom, mini oven
109 316410800 Insulation, floor, mini oven
110 316410400 Shield, floor, mini oven
* # 316416820 Harness, wiring, surface
* 316416901 Harness, mini oven, to probe
* 316416902 Harness, mini oven, to light
* 316264000 Cleaner, cooktop
* 316279700 Cleaner, stainless steel
* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 Screw, cup pt, 8-18 x 0.375, chrome
* 316021109 Screw, 8-18 x 0.5, chrome
* 316021110 Screw, 8-18 x 0.5, black
* 5308014215 Screw, 6-20 x 0.312

Publication No: 5995425468 FEFB7ABDCB
01/05 10
DOOR
60B
10B
10
4
13
39
7
6
T20D0017
17
17
53
53
55
55
23
23
8
9
20
20
12
14A
14
8

FEFB7ABDCB Publication No: 5995425468
# Functional Parts 11 01/05
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
4 316408503 Glass, door front, black
6 316406307 Shield, wool
7 316405600 Insulation, oven door
8 316117500 Glass, oven door, heat barrier
9 316423701 Liner, oven door
10 316001002 Screw, wafer head, 10-24 x 1.81, (2), handle mtg.
10B 316008401 Washer, 3/4 OD x 1/4 ID, steel
12 316405000 Seal, oven door
13 316407902 Panel, oven door, stainless, outer
14 316102208 Foil, 1.5" x 29", aluminum, black
14A 316102205 Foil, 4" x 5.5", aluminum, black, (2)
17 316402403 Spacer, door glass, (2)
20 316408600 Spacer, door handle, (2)
23 316406911 Hinge, oven door
23* 316418900 Screw, sims lp, #8-32 x 5/16", black
39 316246100 Handle, door/drawer, stainless
53 316408201 Shield, door filler, black, (2)
55 316408300 Bracket, glass support, (4)
60B 316021110 Screw, 8-18 x 0.5, black
* 316433603 Label, anti-tip
* 316431100 Baffle, fish paper, (2)
* 316279700 Cleaner, stainless steel
* 316021109 Screw, 8-18 x 0.5, chrome
* 5303271648 Screw, wafer hd sq dr, 8-18AB x 0.5
* 5303285179 Screw, wafer head, 8-32T x 0.500, black

Publication No: 5995425468 FEFB7ABDCB
01/05 12
WIRING SCHEMATIC

FEFB7ABDCB Publication No: 5995425468
# Functional Parts 13 01/05
* Non-Illustrated Parts
WIRING DIAGRAM
