Frigidaire FGFL89C User manual

FGFL89CC.eps L24G0021.eps L24B0001.eps L24V0040.eps L24T0032.eps
L24D0020.eps 316255211d.eps 316255211s.eps
Product No. FGFL89CCA
Series 30" f/s gas
Color stainless
Market North America
Wiring Diagram 316255211
Owner's Guide 316257513
Installation Instructions 316259330
Service Data Sheet 316259130
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995400966
04/01/08
(EN/SERVICE/ECL)
369
30-INCH FREE-
STANDING GAS
RANGE
Model No.
FGFL89C
Copyright 2003 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995400966 FGFL89CCA
01/04 2
BACKGUARD

FGFL89CCA Publication No: 5995400966
# Functional Parts 3 01/04
* Non-Ilustrated Parts
BACKGUARD
POS. NO PART NO. DESCRIPTION
1 316239900 Shield, backguard, rear wall
2 316051600 Shield, backguard, inner
2A 316235100 Shield, top, inner
13A# 316095500 Switch, infinite, warmer
14 316022500 Light/Lamp, indicator, 125 V
15 316220216 Support, backguard, black, RH
15A 316220217 Support, backguard, black, LH
19 316233880 Panel, backguard, stainless
20 # 316207603 Clock/Timer, EOC
20A 316243301 Overlay, clock, black
23 316220900 Bracket, clock mtg
31 316223002 Knob, black
36 316220002 Knob, top valve, black, (4)
40 316249000 Panel, manifold, stainless steel
42 316270600 Trim, extrusion, black
46 316040201 Lens, indicator light, red
56 316230701 Shield, backguard, inner
69 5303288565 Screw, truss sqdr, 8-32 x 3/16, switch mtg
* 218490900 Cleaner, stainless steel
* 316021108 Screw, cup pt, 8-18 x 0.375, chrome
* 316021109 Screw, 8-18 x 0.5, chrome
* 316021110 Screw, 8-18 x 0.5, black

Publication No: 5995400966 FGFL89CCA
01/04 4
BURNER

FGFL89CCA Publication No: 5995400966
# Functional Parts 5 01/04
* Non-Ilustrated Parts
BURNER
POS. NO PART NO. DESCRIPTION
1 # 316219500 Pipe, manifold
2 # 5303935232 Valve, 12K burner, w/mtg screw
2A # 5303935236 Valve, 14K burner, w/mtg screw
2B # 5303935235 Valve, 5K burner, w/mtg screw
2C # 5303935234 Valve, 9.5K burner, w/mtg screw
* 316215600 Screw, valve mtg., 1/4 - 20
3 # 316219004 Wiring Harness, w/igntr switch
8 # 316135701 Module, spark
10 # 316212300 Burner, sealed, 12K
10A# 316223400 Burner, sealed, 14K
10B# 316206400 Burner, sealed, 5K
10C# 316212400 Burner, sealed, 9.5K
11 # 316237702 Ignitor/orifice assy., top burner, rear, 12K, w/holder, tube
11A# 316272000 Ignitor/orifice assy., top burner, front, 14K, w/holder, tube
11B# 316237700 Ignitor/orifice assy., top burner, rear, 5K, w/holder, tube
11C# 316237800 Ignitor/orifice assy., top burner, front, 9.5K, w/holder, tube
13 # 316207000 Tube, 3/8, aluminum, rgltr to manf, with fittings
14 # 316091706 Regulator, pressure
14* 316021104 Screw, hex, 8-18 x 3/8, nick, (3), regulator brkt
15 316091600 Bracket, regulator
16 # 316065003 Tube, valve to regul., 3/8
17 # 5303208499 Valve, safety, dual
17* 08068018 Shield, wire, safety valve
18 # 316269000 Burner, oven
19 # 5303935066 Ignitor, oven kit, w/nut & instr
20 3131284 Baffle, oven burner
21 5303013272 Nut, hex head sems
22 # 316065002 Tube, valve to mixer
23 # 08067935 Burner, broiler
24 # 316070400 Elbow, mixer
24* 316113400 Spacer, mixer elbow
25 5303210379 Baffle, broiler
26 # 316119302 Ignitor, broiler
26* 316401500 Cover, broil Ignitor
37 316240600 Screw, assy mtg, ignitor/orifice
44 316237901 Orifice, top burner, 12K
44A 316237900 Orifice, top burner, 14K
44B 316237903 Orifice, top burner, 5K
44C 316237902 Orifice, top burner, 9.5K
47 GRLP1 LP Conversion Kit, w/instructions
47* 316248105 Instructions, LP kit
* # 316253700 Wiring Harness, ignitor module
* 5303271648 Screw, wafer hd sq dr, 8-18AB x 0.5

Publication No: 5995400966 FGFL89CCA
01/04 6
BODY

FGFL89CCA Publication No: 5995400966
# Functional Parts 7 01/04
* Non-Ilustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
1 316029416 Panel, main back
2 3131314 Shield, oven top
3 316216404 Panel, bodyside, black, RH
3 316216405 Panel, bodyside, black, LH
3* 316021132 Screw, bodyside, 8-18 X 11/16, black
4 316201402 Burner Box
5 316129200 Screw, leveling, plastic, with stop
6 316216000 Rack, oven
6A 318219500 Rack, broiler pan
7 316216500 Hinge, oven door, RH
7A 316216501 Hinge, oven door, LH
8 5303300701 Panel, oven bottom
9 316081900 Pan, broiler
10 316082000 Insert, broiler pan
12 # 316209903 Switch, oven light/door
14 316116400 Receptacle, oven light
15 5303013071 Bulb/Lamp, oven light
16 08011086 Lens, oven light, glass
17 316087500 Retainer, lens
18 # 316213900 Latch, oven door
21 3014099 Spacer, bodyside
25A 316092300 Shield, warmer drawer, upper
28 3011813 Clip, wire, bodyside
30 316217700 Bracket, hinge, RH, main top
30A 316217701 Bracket, hinge, LH, main top
33 316232800 Shield, rear wall
35 316116600 Gasket, flue
36 316208901 Flue
37 # 316233900 Probe, oven temp
38 316051700 Shield, heat
39 # 3131425 Cord, electric power
40 3200836 Shield, heat baffle
41 316233400 Cover, hinge cutout, RH
41A 316233500 Cover, hinge cutout, LH
42 5303288578 Shield, bake burner
43 3131732 Screw, 8-18 x 1.438, oven bottom
44 316246500 Spacer, oven door
49 316234200 Clip, maintop mtg, (2)
53 5303288579 Shield, main front
53A 08067992 Shield, insulation, front frame
53B 316211100 Bracket, air dam
55 316404800 Shield, flue
58A 316047705 Insulation, oven wrapper
58B 316218303 Insulation, oven back
58G 08067973 Insulation, main front
77 316105500 Glide, warmer drawer, outer/RH & LH, (2)
88 316232700 Rod, auto latch
89 # 316135201 Motor, latch/lock
106 316026600 Bracket, motor mtg
107 316026701 Cover, fan
108# 316234601 Motor, fan

Publication No: 5995400966 FGFL89CCA
01/04 8
BODY

FGFL89CCA Publication No: 5995400966
# Functional Parts 9 01/04
* Non-Ilustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
109 316136400 Blade, fan
110 316136500 Washer, fan motor
111 316136600 Nut, fan retainer
151 316239300 Shield, bodyside
155 316095201 Shield, warmer drawer, front
161# 316211603 Element, convection fan, 350 W
170 5303935180 Anti-tip Kit, w/bracket, screw
170* 316107200 Bracket, anti-tip
170* 316112500 Template, anti-tip
170* 316116000 Screw, concrete, 1.75", anti-tip brkt
* # 316253417 Wiring Harness, main
* 5303305345 Paint, touch-up, black
* 316021108 Screw, cup pt, 8-18 x 0.375, chrome
* 5303271648 Screw, wafer hd sq dr, 8-18AB x 0.5
* 5303280311 Screw, wafer hd sq dr, 10-32 x 0.312
* 5303285179 Screw, wafer head, 8-32T x 0.500, black

Publication No: 5995400966 FGFL89CCA
01/04 10
TOP/DRAWER

FGFL89CCA Publication No: 5995400966
# Functional Parts 11 01/04
* Non-Ilustrated Parts
TOP/DRAWER
POS. NO PART NO. DESCRIPTION
1 316115901 Drawer, warmer
2 316231403 Liner, drawer
4 316238901 Panel, drawer, stainless
13 316231700 Glide, drawer, RH inner
13A 316231701 Glide, drawer, LH inner
14 316102211 Foil, 2" x 19", aluminum, clear
16 316202345 Main Top, black
20 316248500 Grate, black, (4)
20A 316239800 Grate, black, center
22 316213600 Cap, 12K burner, black
22A 316219900 Cap, 14K burner, black
22B 316206600 Cap, 5K burner, black
22C 316213500 Cap, 9.5K burner, black
39 316203000 Handle, door, black
81 # 316239201 Element, warmer drawer
82 316093200 Bracket, element mtg
83 316093300 Shield, terminal, warmer drawer
84 316093501 Thermo disc, warmer drawer
85 316093600 Rack, warmer drawer
86 316095800 Clip, hold down, warmer element
87 316091900 Base, warmer drawer
88 316099500 Pin, guide, (2)
* 316001917 Harness, warmer drawer
* 218490900 Cleaner, stainless steel
* 316021108 Screw, cup pt, 8-18 x 0.375, chrome
* 316021109 Screw, 8-18 x 0.5, chrome
* 316021110 Screw, 8-18 x 0.5, black
* 5303280311 Screw, wafer hd sq dr, 10-32 x 0.312

Publication No: 5995400966 FGFL89CCA
01/04 12
DOOR

FGFL89CCA Publication No: 5995400966
# Functional Parts 13 01/04
* Non-Ilustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
4 316240000 Glass, oven door, black, outer
5 316237000 Glass, oven door, air wash
6 316222707 Shield, wool, oven door
7 316236700 Insulation, oven door
8 316237100 Glass, oven door, clear, heat barrier
9 316230617 Liner, oven door
10 316001015 Screw, waf hd sq, 10-24 x 1.25, (2), handle mtg
10B 316008401 Washer, 3/4 OD x 1/4 ID, steel
12 316230901 Seal, oven door
13 316209401 Panel, oven door, stainless, outer
14 316102208 Foil, 1.5" x 29", aluminum, black
14A 316102205 Foil, 4" x 5.5", aluminum, black, (2)
15 316237201 Bracket, glass support, (2)
15B 316085501 Bracket, glass support
16 316117500 Glass, oven door, heat barrier
17 316117701 Spacer, door glass, (2)
39 316203000 Handle, door, black
60B 316021110 Screw, 8-18 x 0.5, black
* 316221001 Label, anti-tip
* 218490900 Cleaner, stainless steel
* 316021109 Screw, 8-18 x 0.5, chrome
* 5303271648 Screw, wafer hd sq dr, 8-18AB x 0.5
* 5303280311 Screw, wafer hd sq dr, 10-32 x 0.312
* 5303285179 Screw, wafer head, 8-32T x 0.500, black

Publication No: 5995400966 FGFL89CCA
01/04 14
WIRING SCHEMATIC

FGFL89CCA Publication No: 5995400966
# Functional Parts 15 01/04
* Non-Ilustrated Parts
WIRING DIAGRAM
