Frigidaire GLGFS66C User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR MARKET
GLGFS66CBA GLGFS66C Gallery black North America
GLGFS66CQA GLGFS66C Gallery bisque North America
GLGFS66CSA GLGFS66C Gallery white North America
Publication No.
5995385662
030210
-EN/SERVICE /ECL
369
GAS
RANGE
Model No.
GLGFS66C
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY
PARTS CATALOG
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
SERVICE DATA SHEET - # 316218504
WIRING DIAGRAM - #316255216
OWNER’S GUIDE - # 316257503
INSTALLATION INSTRUCTIONS -# 316259315

02/03 2
Publication No. GLGFS66C
5995385662
BACKGUARD

# = Fast-moving Parts 3 02/03
* = Non-Illustrated Parts
GLGFS66C Publication No.
5995385662
A = GLGFS66C (GLGFS66CSA)
B = GLGFS66C (GLGFS66CBA)
C = GLGFS66C (GLGFS66CQA)
POS. NO PART NO DESCRIPTION
1 316239900 A B C Shield,backguard ,rear wall
2 316051600 A B C Shield,backguard ,inner
2A 316235100 A B C Shield,top ,inner
15 316220214 A - - Support,backguard ,white ,RH
15 316220216 - B - Support,backguard ,black ,RH
15 316220218 - - C Support,backguard ,bisque ,RH
15A 316220215 A - - Support,backguard ,white ,LH
15A 316220217 - B - Support,backguard ,black ,LH
15A 316220219 - - C Support,backguard ,bisque ,LH
19 316233856 A - - Panel,backguard ,white
19 316233857 - B - Panel,backguard ,black
19 316233858 - - C Panel,backguard ,bisque
20 # 316207500 A B C Clock/Timer,electronic
20A 316220804 A - - Overlay,clock ,white
20A 316220805 - B - Overlay,clock ,black
20A 316220806 - - C Overlay,clock ,bisque
23 316220900 A B C Bracket,clock mtg
24 316246000 A - - Switch,rocker ,white ,oven light
24 # 316246001 - B - Switch,rocker ,black ,oven light
24 316246002 - - C Switch,rocker ,bisque ,oven light
36 316220000 A - - Knob,top valve ,white ,(4)
36 316220002 - B - Knob,top valve ,black ,(4)
36 316220003 - - C Knob,top valve ,bisque ,(4)
40 316204917 A - - Panel,manifold ,white
40 316204918 - B - Panel,manifold ,black
40 316204919 - - C Panel,manifold ,bisque
42 316236601 A - C Trim,extrusion ,chrome
42 316236600 - B - Trim,extrusion ,black
56 316230701 A B C Shield,backguard ,inner
* 316021108 A B C Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021109 A B C Screw,8-18 x 0.5 ,chrome
* 316021110 A B C Screw,8-18 x 0.5 ,black
BACKGUARD

02/03 4
Publication No. GLGFS66C
5995385662
BURNER

# = Fast-moving Parts 5 01/03
* = Non-Illustrated Parts
GLGFS66C Publication No.
5995385662
A = GLGFS66C (GLGFS66CSA)
B = GLGFS66C (GLGFS66CBA)
C = GLGFS66C (GLGFS66CQA)
POS. NO PART NO DESCRIPTION
1 # 316204000 A B C Pipe,manifold
2A # 5303935211 A B C Valve,14K top burner ,w/mtg screw
2B # 5303935212 A B C Valve,5K top burner ,w/mtg screw
2C # 5303935213 A B C Valve,9.5K top burner ,w/mtg screw
* 316134300 A B C Screw,10-24 ,valve mounting
3 # 316219004 A B C Wiring Harness,w/igntr switch
8 # 316135701 A B C Module,spark
10A# 316212500 A B C Burner,sealed ,14K
10B# 316206400 A B C Burner,sealed ,5K
10C# 316212400 A B C Burner,sealed ,9.5K
11 # 316237701 A B C Ignitor/orifice assy.,top burner ,rear ,9.5K,w/holder ,tube
11A# 316237802 A B C Ignitor/orifice assy.,top burner ,front ,14K,w/holder ,tube
11B# 316237700 A B C Ignitor/orifice assy.,top burner ,rear ,5K,w/holder ,tube
11C# 316237800 A B C Ignitor/orifice assy.,top burner ,front 9.5K,w/holder ,tube
13 # 316207000 A B C Tube,3/8 ,aluminum ,rgltr to manf ,with fittings
14 # 316091706 A B C Regulator,pressure
14* 316021104 A B C Screw,hex ,8-18 x 3/8 ,nick ,(3) ,regulator brkt
15 316091600 A B C Bracket,regulator
16 # 316065003 A B C Tube,valve to regul. ,3/8
17 # 5303208499 A B C Valve,safety ,dual
17* 08068018 A B C Shield,wire ,safety valve
18 # 3131290 A B C Burner,oven
19 # 5303935066 A B C Ignitor,oven kit ,w/nut & instr
20 3131284 A B C Baffle,oven burner
21 5303013272 A B C Nut,hex head sems
22 # 316065002 A B C Tube,valve to mixer
23 # 08067935 A B C Burner,broiler
24 # 316070400 A B C Elbow,mixer
24* 316113400 A B C Spacer,mixer elbow
25 5303210379 A B C Baffle,broiler
26 # 316119302 A B C Ignitor,broiler
37 316240600 A B C Screw,assy mtg ,ignitor/orifice
44A 316237900 A B C Orifice,top burner ,14K
44B 316237903 A B C Orifice,top burner ,5K
44C 316237902 A B C Orifice,top burner ,9.5K
47 GRLP1 A B C LP Conversion Kit,w/instructions
47* 316248105 A B C Instructions,LP kit
* # 316253700 A B C Wiring Harness,ignitor module
BURNER

02/03 6
Publication No. GLGFS66C
5995385662
BODY

# = Fast-moving Parts 7 02/03
* = Non-Illustrated Parts
GLGFS66C Publication No.
5995385662
A = GLGFS66C (GLGFS66CSA)
B = GLGFS66C (GLGFS66CBA)
C = GLGFS66C (GLGFS66CQA)
POS. NO PART NO DESCRIPTION
1 316029416 A B C Panel,main back
2 3131314 A B C Shield,oven top
3 316216402 A - - Panel,bodyside ,white ,RH
3 316216403 A - - Panel,bodyside ,white ,LH
3 316216404 - B - Panel,bodyside ,black ,RH
3 316216405 - B - Panel,bodyside ,black ,LH
3 316216406 - - C Panel,bodyside ,bisque ,RH
3 316216407 - - C Panel,bodyside ,bisque ,LH
3* 316021131 A - - Screw,bodyside ,8-18 X 11/16 ,white
3* 316021132 - B - Screw,bodyside ,8-18 X 11/16 ,black
3* 316021133 - - C Screw,bodyside ,8-18 X 11/16 ,bisque
4 316201402 A B C Burner Box
5 316129200 A B C Screw,leveling ,plastic ,with stop
6 316067902 A B C Rack,oven
7 316216500 A B C Hinge,oven door ,RH
7A 316216501 A B C Hinge,oven door ,LH
8 5303300701 A B C Panel,oven bottom
8* 316064600 A B C Support,oven bottom
9 316081900 A B C Pan,broiler
10 316082000 A B C Insert,broiler pan
12 # 316209901 A B C Switch,oven light/door
14 316116400 A B C Receptacle,oven light
15 5303013071 A B C Bulb/Lamp,oven light
16 08011086 A B C Lens,oven light ,glass
17 316087500 A B C Retainer,lens
18 # 316213900 A B C Latch,oven door
21 3014099 A B C Spacer,bodyside
25A 5303288580 A B C Shield,heat ,lower
28 3011813 A B C Clip,wire ,bodyside
29 3051162 A B C Glide,drawer ,front
30 316217700 A B C Bracket,hinge ,RH ,main top
30A 316217701 A B C Bracket,hinge ,LH ,main top
33 316121001 A B C Shield,lower wire ,rear wall
35 316116600 A B C Gasket,flue
36 316133002 A B C Flue
37 # 316233900 A B C Probe,oven temp
38 316051700 A B C Shield,heat
39 3202006 A B C Cord,electric power
40 3200836 A B C Shield,heat baffle
40* 5303288570 A B C Screw,hd shldr sqdr ,8-18 X 1/2 ,heat shield
41 316233400 A B C Cover,hinge cutout ,RH
41A 316233500 A B C Cover,hinge cutout ,LH
42 5303288578 A B C Shield,bake burner
43 3131732 A B C Screw,8-18 x 1.438 ,oven bottom
44 316246500 A B C Spacer,oven door
49 316234200 A B C Clip,maintop mtg ,(2)
53 5303288579 A B C Shield,main front
53A 08067992 A B C Shield,insulation ,front frame
55 316107800 A B C Shield,flue
58A 316047705 A B C Insulation,oven wrapper
58B 316218303 A B C Insulation,oven back
58G 08067973 A B C Insulation,main front
88 316232700 A B C Rod,auto latch
89 # 316137500 A B C Motor,latch
151 316239300 A B C Shield,bodyside
170 5303935180 A B C Anti-tip Kit,w/bracket,screw
170* 316107200 A B C Bracket,anti-tip
170* 316112500 A B C Template,anti-tip
170* 316116000 A B C Screw,concrete ,1.75" ,anti-tip brkt
* # 316253410 A B C Wiring Harness,main
* 5303305324 A - - Paint,touch-up ,white
* 5303305345 - B - Paint,touch-up ,black
* 5304414035 - - C Paint,touch-up ,bisque
* 316021108 A B C Screw,cup pt ,8-18 x 0.375 ,chrome
* 5303280311 A B C Screw,wafer hd sq dr ,10-32 x 0.312
* 5303285179 A B C Screw,wafer head ,8-32T x 0.500 ,black
BODY

02/03 8
Publication No. GLGFS66C
5995385662
TOP/DRAWER

# = Fast-moving Parts 9 02/03
* = Non-Illustrated Parts
GLGFS66C Publication No.
5995385662
A = GLGFS66C (GLGFS66CSA)
B = GLGFS66C (GLGFS66CBA)
C = GLGFS66C (GLGFS66CQA)
POS. NO PART NO DESCRIPTION
1 316011503 A B C Drawer
2 316231400 A B C Liner,drawer
4 316231205 A - - Panel,drawer ,white
4 316231206 - B - Panel,drawer ,black
4 316231209 - - C Panel,drawer ,bisque
7 3051163 A B C Glide,drawer ,rear
16 316202337 A - - Main Top,white
16 316202338 - B - Main Top,black
16 316202339 - - C Main Top,bisque
20 316202401 A - - Grate,gray
20 316202400 - B - Grate,black
20 316202403 - - C Grate,brown
22A 316213701 A - - Cap,14K burner ,grey
22A 316213700 - B - Cap,14K burner ,black
22A 316213703 - - C Cap,14K burner ,brown
22B 316206601 A - - Cap,5K burner ,gray
22B 316206600 - B - Cap,5K burner ,black
22B 316206602 - - C Cap,5K burner ,brown
22C 316213501 A - - Cap,9.5K burner ,gray
22C 316213500 - B - Cap,9.5K burner ,black
22C 316213503 - - C Cap,9.5K burner ,brown
88 316099500 A B C Pin,guide ,(2)
* 316021108 A B C Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021109 A B C Screw,8-18 x 0.5 ,chrome
* 316021110 A B C Screw,8-18 x 0.5 ,black
* 5303280311 A B C Screw,wafer hd sq dr ,10-32 x 0.312
TOP/DRAWER

02/03 10
Publication No. GLGFS66C
5995385662
DOOR

# = Fast-moving Parts 11 02/03
* = Non-Illustrated Parts
GLGFS66C Publication No.
5995385662
A = GLGFS66C (GLGFS66CSA)
B = GLGFS66C (GLGFS66CBA)
C = GLGFS66C (GLGFS66CQA)
POS. NO PART NO DESCRIPTION
3 5303935192 A - - Trim kit-door,3 sided ,white ,w/tape and foil
3 5303935191 - B - Trim kit-door,3 sided ,black ,w/tape and foil
3 5303935193 - - C Trim kit-door,3 sided ,bisque ,w/tape and foil
4 5303935201 A - - Glass,door kit ,white ,outer ,w/foil tape
4 5303935200 - B - Glass,door kit ,black ,outer ,w/foil tape
4 5303935202 - - C Glass,door kit ,bisque ,outer ,w/foil tape
5 316237000 A B C Glass,oven door ,air wash
6 316222707 A B C Shield,wool ,oven door
7 316236700 A B C Insulation,oven door
8 316237100 A B C Glass,oven door ,clear ,heat barrier
9 316230605 A B C Liner,oven door
10 316001013 A B C Screw,wafer head ,10-24 X 1.375 ,handle mtg.
10B 316008401 A B C Washer,3/4 OD x 1/4 ID ,steel
12 316230901 A B C Seal,oven door
14 316102207 A - C Foil,1.5" x 29" ,aluminum ,clear
14 316102208 - B - Foil,1.5" x 29" ,aluminum ,black
14A 316102202 A - C Foil,4" x 5.5" ,aluminum ,clear ,(2)
14A 316102205 - B - Foil,4" x 5.5" ,aluminum ,black ,(2)
15 316237201 A B C Bracket,glass support ,(2)
16 316117501 A B C Glass,oven door ,inner
17 316117701 A B C Spacer,door glass ,(2)
39 316203001 A - - Handle,door ,white
39 316203000 - B - Handle,door ,black
39 316203003 - - C Handle,door ,bisque
52 316201003 A - - Cap,door trim ,white
52 316201005 - B - Cap,door trim ,black
52 316201009 - - C Cap,door trim ,bisque
60B 316021110 A B C Screw,8-18 x 0.5 ,black
* 316221001 A B C Label,anti-tip
* 316021109 A B C Screw,8-18 x 0.5 ,chrome
* 5303280311 A B C Screw,wafer hd sq dr ,10-32 x 0.312
* 5303285179 A B C Screw,wafer head ,8-32T x 0.500 ,black
DOOR

02/03 12
Publication No. GLGFS66C
5995385662
WIRING SCHEMATIC

# = Fast-moving Parts 13 02/03
* = Non-Illustrated Parts
GLGFS66C Publication No.
5995385662
WIRING DIAGRAM
