Frigidaire FPGH3077RF Owner's manual

All about the
Use&Care
of your
www.frigidaire.com USA 1-800-944-9044 www.frigidaire.ca Canada 1-800-265-8352
Gas Range
A02992502 Rev B (April 2018)
TABLE OF CONTENTS
Product Record and Registration . . . . . . . . . . . . . . 2
Important Safety Instructions . . . . . . . . . . . . . . . . . 3
Before Setting Surface Controls . . . . . . . . . . . . . . 10
Setting Surface Burners . . . . . . . . . . . . . . . . . . . . 11
Before Setting Oven Controls . . . . . . . . . . . . . . . . 14
Oven Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Care and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . 31
Before You Call . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

22017 Electrolux Home Products, Inc. All rights reserved. Printed in the USA
Product Record and Registration . . . . . . . . . . . . . . . . . 2
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . 3
Before Setting Surface Controls. . . . . . . . . . . . . . . . . 10
Setting Surface Burners . . . . . . . . . . . . . . . . . . . . . . . 11
Before Setting Oven Controls . . . . . . . . . . . . . . . . . . . 14
Oven Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Care and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Before You Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Thank you for choosing Frigidaire.
This Use and Care Guide is part of our commitment to
customer satisfaction and product quality throughout the
service life of your new appliance. We view your purchase
as the beginning of a relationship. To ensure our ability to
continue serving you, please use this page to record
important product information.
Need Help?
Visit the Frigidaire web site at www.frigidaire.com
Before you call for service, there are a few things you can
do to help us serve you better.
Read this Use & Care Manual
This manual contains instructions to help you use and
maintain your range properly.
If You Received a Damaged Range...
Immediately contact the dealer (or builder) that sold you the
range.
Save Time and Money
Check the section title “Before You Call”. This section helps
step you through some common problems that might occur.
If you do need service, help is only a phone call away. Call
Frigidaire Customer Services at 1-800-944-9044.
Product Registration
Registering your product with Frigidaire enhances our
ability to serve you. Register online at www.frigidaire.com
or by dropping your Product Registration Card in the mail.
Record model & serial numbers here
Purchase Date
Frigidaire model number
Frigidaire serial number
PRODUCT RECORD AND REGISTRATION
Questions?
For toll-free telephone support in the U.S. and Canada call
1-800-944-9044
For online support and Internet production information visit
www.frigidaire.com.

3
Read all instructions before using this appliance.
This manual contains important safety symbols
and instructions. Please pay attention to these
symbols and follow all instructions given.
Do not attempt to install or operate your appliance
until you have read the safety precautions in this
manual. Safety items throughout this manual are
labeled with a WARNING or CAUTION statement
based on the risk type.
Warnings and important instructions appearing in
this guide are not meant to cover all possible
conditions and situations that may occur.
Common sense, caution, and care must be
exercisedwithinstalling, maintaining, or operating
your appliance.
DEFINITIONS
This is the safety alert symbol. It is used to
alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol
to avoid possible injury or death.
Indicates a potentially hazardous situation
which, if not avoided, may result in death or
serious injury.
Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderate injury.
Indicates installation, operation, maintenance,
or valuable information that is not hazard
related.
Indicates a short, informal reference –
something written down to assist the memory or
for future reference.
WARNING
CAUTION
IMPORTANT
NOTE
If the information in this manual
is not followed exactly, a fire or explosion may
result causing property damage, personal
injury or death.
FOR YOUR SAFETY: Do not store or use
gasoline or other flammable vapors and
liquids in the vicinity of this or any other appli-
ance.
WHAT TO DO IF YOU SMELL GAS:
•Do not try to light any appliance.
•Do not touch any electrical switch.
•Do not use any phone in your building.
•Immediately call your gas supplier from a
neighbor's phone. Follow the gas
supplier's instructions.
•If you cannot reach your gas supplier, call
the fire department.
Installation and service must be performed by
a qualified installer, servicer, or the gas
supplier.
IMPORTANT SAFETY INSTRUCTIONS

4
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT INSTRUCTIONS FOR
UNPACKING AND INSTALLATION
IMPORTANT - Read and follow the below instruc-
tions and precautions for unpacking, installing,
and servicing your appliance:
Remove all tape and packaging before using the
appliance. Destroy the carton and plastic bags
after unpacking the appliance. Never allow
children to play with packaging material. Do not
remove the wiring label and other literature
attached to the appliance. Do not remove model/
serial number plate.
Cold temperatures can damage the electronic
control. When using this appliance for the first
time, or when the appliance has not been used
for an extended period of time, be sure the
appliance has been in temperatures above 32ºF
(0ºC) for at least 3 hours before turning on the
power to the appliance.
Never modify or alter the construction of the
appliance by removing the leveling legs, panels,
wire covers, anti-tip brackets/screws, or any other
part of the appliance.
Be sure to have an appropriate foam-type fire
extinguisher available, visible, and easily acces-
sible located near the appliance.
WARNING
Tip Over Hazard
Range
leveling leg Anti-tip
bracket
• A child or adult can tip the
range and be killed.
• Verify the anti-tip device has
been installed to floor or wall.
• Ensure the anti-tip device is re-engaged to floor
or wall when the range is moved.
• Do not operate the range without the anti-tip
device in place and engaged.
• Failure to follow these instructions can result in
death or serious burns to children and adults.
To check if the anti-tip bracket is installed properly, use
both arms to grasp the rear edge of the range back.
Carefully attept to tilt range forward. When properly
installed, the range should not tilt forward.
Refer to the anti-tip bracket installation instructions
supplied with your range for proper installation.
Air curtain or other overhead range hoods which
operate that operate by blowing a downward air
flow onto a range or cooktop, shall not be used
in conjunction with gas ranges or cooktops
other than when the range or cooktop and hood
have been designed, tested, and listed by an
independent test laboratory for use in combina-
tion with each other.
WARNING

5
IMPORTANT SAFETY INSTRUCTIONS
GROUNDING INSTRUCTIONS
Proper Installation—Be sure your appliance is
properly installed and grounded by a qualified
technician. In the United States, install in accor-
dance with the National Fuel Gas Code ANSI
Z223.1/NPFA No. 54, latest edition and National
Electrical Code NFPA No. 70 latest edition, and
local electrical code requirements. In Canada,
install in accordance with CAN/CGA B149.1 and
CAN/CGA B149.2 and CSA Standard C22.1,
Canadian Electrical code, Part 1-latest editions
and local electrical code requirements. Install only
per installation instructions provided in the litera-
ture package for this appliance.
For personal safety, this appliance must be
properly grounded. For maximum safety, the
power cord must be securely connected to an
electrical outlet or junction box that is the correct
voltage, is correctly polarized and properly
grounded, and protected by a circuit breaker in
accordance with local codes.
It is the personal responsibility of the consumer to
have the appropriate outlet or junction box with
the correct, properly grounded wall receptacle
installed by a qualified electrician. It is the respon-
sibility and obligation of the consumer to contact a
qualified installer to assure that the electrical
installation is adequate and is in conformance
with all local codes and ordinances.
This appliance is equipped with a 3-prong
grounding plug for your protection against shock
hazard and should be plugged directly into a
properly grounded receptacle. Do not cut or
remove the grounding prong from this plug.
For personal safety, the appliance must be
properly grounded. For maximum safety, the
power cord must be plugged into an electrical
outlet that is correctly polarized and properly
grounded.
If a 2-prong wall receptacle is the only available
outlet, it is the personal responsibility of the
consumer to have it replaced with a properly
grounded 3-prong wall receptacle, installed by a
qualified technician.
Avoid fire hazard or electrical shock. Failure to
follow this warning may cause serious injury,
fire, or death.
Avoid fire hazard or electrical shock. Do not use
an adapter plug, use an extension cord, or
remove grounding prong from the power cord.
Failure to follow this warning may cause serious
injury, fire, or death.
WARNING
Do not cut, remove, or
bypass the grounding
plug under any
circumstances.
Grounding type
wall receptacle
Power supply cord
with 3-prong
grounding plug

6
IMPORTANT SAFETY INSTRUCTIONS
Conversion to (L.P.) Gas
This appliance allows for conversion to Liquefied
Petroleum (L.P.) Gas.
If L.P. conversion is needed, contact your local
L.P. Gas provider for assistance.
See the installation instructions packaged with
this appliance for complete installation and
grounding instructions.
IMPORTANT INSTRUCTIONS FOR USING THE
APPLIANCE
Personal injury or death from electrical shock
may occur if the conversion to L.P. gas is not
made by a qualified installer or electrician. Any
additions, changes or conversions required in
order for this appliance to satisfactorily meet the
application needs must be made by a qualified
technician.
Storage In or On Appliance—Flammable
materials should not be stored in an oven or
microwave, near surface burners or elements,
or in the storage or warmer drawer (if
equipped). This includes paper, plastic, and
cloth items, such as cookbooks, plastic ware,
and towels, as well as flammable liquids. Do not
store explosives, such as aerosol cans, on or
near the appliance.
Do not leave children alone - Children should
not be left alone or unattended in the area
where appliance is in use. They should never
be allowed to sit or stand on any part of the
appliance, including the storage drawer, lower
broiler drawer, warmer drawer, or lower double
oven.
WARNING
WARNING
Do not store items of interest to children in the
cabinets above the appliance or on the back-
guards of ranges. Children climbing on or near
the appliance to reach items could be seriously
injured.
Never use your appliance as a space heater to
heat or warm the room. Doing so may result in
carbon monoxide poisoning and overheating of
the appliance.
Do not allow children to climb or play around the
appliance. The weight of a child on an open
over door may cause the appliance to tip,
resulting in serious burns or other injury. An
open drawer when hot may cause burns.
Stepping, leaning, or sitting on the door or
drawers of this appliance can result in serious
injuries and also cause damage to the appli-
ance.
Never cover any slots, holes or passages in the
oven bottom or cover and entire rack with
materials such as aluminum foil. Doing so
blocks air flow through the oven and may cause
carbon monoxide poisoning. Aluminum foil
linings may also trap heat, causing a fire
hazard.
Do not use oven or warmer drawer (if equipped)
for storage.
WARNING

7
IMPORTANT SAFETY INSTRUCTIONS
IIMPORTANT INSTRUCTIONS FOR USING
YOUR GAS COOKTOP
Know which knob or key controls each surface
heating area. Place cookware with food on the
cooking area before turning it on. Turn the
cooking area off before removing the cookware.
Use proper pan size. This appliance is equipped
with one or more surface units of different sizes.
Select cookware with flat bottoms that match the
surface unit heating element. The use of under-
sized cookware may expose a portion of the
flame to direct contact and may result in the
ignition of clothing or other items. Using the
proper cookware on the cooking areas will
improve efficiency.
Always turn knob to the full LITE position when
igniting top burners. Visually check that burner
has lit. Then adjust the flame so it does not
extend beyond the edge of the utensil.
When heating fat or grease, watch it closely.
Grease may catch fire if it becomes too hot.
Do not use water or flour on grease fires.
Smother fire or flame or use dry chemical or
foam-type extinguisher. Cover the fire with a
pan lid or use baking soda.
Use dry potholders. Moist or damp potholders
on hot surfaces may result in burns from steam.
Do not let potholders touch hot cooking areas.
Do not use towels or other bulky cloths.
Do not heat unopened food containers - Build-
up of pressure may cause container to burst
and result in injury.
Wear proper apparel - Loose-fitting or hanging
garments should never be worn while using the
appliance. Do not let clothing or other
flammable materials contact hot surfaces.
Do not touch surface burners or elements,
areas near these burners or elements, interior
surfaces of the oven, or the warmer drawer (if
equipped). Surface burners and elements may
be hot even though they appear cool. Areas
near surface burners and elements may
become hot enough to cause burns. During and
after use, do not touch, or let clothing or other
flammable materials touch these areas until
they are cool. These areas may include the
cooktop, surfaces facing the cooktop, oven vent
areas, oven door, and oven window.
CAUTION
Do not attempt to operate the appliance during
a power failure. If the power fails, always turn off
the appliance. If the appliance is not turned off
and the power resumes, electric surface
elements may resume operation when power is
restored. Once the power resumes, reset the
clock and the oven function.
Use Proper Flame Size — Adjust flame size so
it does not extend beyond the edge of the
utensil. The use of undersized utensils will
expose a portion of the burner flame to direct
contact and may result in ignition of clothing.
Proper relationship of utensil to flame will also
improve efficiency.
CAUTION
CAUTION

8
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of burns, ignition of flammable
materials, and spillage due to unintentional
contact with the utensil, the handle of the utensil
should be positioned so that it is turned inward,
and does not extend over adjacent surface
burners.
Never leave surface burners unattended at high
heat settings — Boil overs cause smoking and
greasy spill overs that may ignite, or a pan that
has boiled dry may melt.
Glazed cooking utensils — Only certain types of
glass, glass/ceramic, ceramic, earthenware, or
other glazed utensils are suitable for cook top
service without breaking due to the sudden
change in temperature. Check the manufacturer’s
recommendations for cook top use.
When you are flaming foods under a ventilating
hood, turn the fan on.
IMPORTANT INSTRUCTIONS FOR USING
YOUR OVEN
Protective liners—Do not use aluminum foil, after-
market oven liners, or any other materials or
devices to line oven bottom, oven racks, or any
other part of the appliance. Only use aluminum as
recommended for baking, such as lining
cookware or as a cover placed on food. Any other
use of protective liners or aluminum foil may
result in a risk of electric shock or fire or a short
circuit.
Use care when opening oven door, lower oven
door, or warmer drawer (some models). Stand to
the side of the appliance when opening the door
of a hot oven. Let hot air or steam escape before
you remove or replace food in the oven.
Keep oven vent ducts unobstructed. Touching
surfaces in this area when the oven is on may
cause severe burns. Do not place plastic or heat-
sensitive items on or near the oven vent. These
items can melt or ignite.
Placement of oven racks - Always place oven
racks in desired location while oven is cool. If rack
must be moved while oven is hot, do not let
potholder contact hot burner or element in oven.
Use potholders and grasp the rack with both
hands to reposition. Remove all cookware and
utensils before moving the rack.
Do not use a broiler pan without its insert. Broiler
pans and inserts allow dripping fat to drain away
from the high heat of the broiler. Do not cover the
broiler insert with aluminum foil; exposed fat and
grease could ignite.
Do not cook food on the oven bottom. Always
cook in proper cookware and always use the
oven racks.
IMPORTANT INSTRUCTIONS FOR CLEANING
YOUR APPLIANCE
Clean the appliance regularly to keep all parts
free of grease that could catch fire. Do not allow
grease to accumulate. Greasy deposits in the fan
could catch fire.
Always follow the manufacturer’s recommended
directions for use of kitchen cleaners and
aerosols. Be aware that excess residue from
cleaners and aerosols may ignite causing
damage and injury.
Clean ventilating hoods frequently - Grease
should not be allowed to accumulate on hood or
filter. Follow the manufacturer’s instructions for
cleaning vent hoods.
Before manually cleaning any part of the appli-
ance, be sure all controls are turned off and the
appliance is cool. Cleaning a hot appliance can
cause burns.
CAUTION

9
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT INSTRUCTIONS FOR SELF
CLEANING OVENS
Do not clean the oven door gasket. The door
gasket is essential for a good seal. Care should
be taken not to rub, damage, or move the gasket.
Do not use oven cleaners. No commercial oven
cleaner or oven liner protective coating of any
kind should be used in or around any part of the
appliance.
Use the self clean cycle to clean only the parts
listed in this manual.
Before using self clean, remove the broiler pan,
any food, utensils, and cookware from the oven,
storage drawer or warming drawer (if equipped).
Remove oven racks unless otherwise instructed.
Some birds are extremely sensitive to the fumes
given off during the self clean cycle of any oven.
Move birds to another well-ventilated room.
IMPORTANT INSTRUCTIONS FOR SERVICE
AND MAINTENANCE
Do not repair or replace any part of the appliance
unless specifically recommended in the manuals.
All other servicing should be done only by a
qualified technician. This reduces the risk of
personal injury and damage to the appliance.
Always contact your dealer, distributor, service
agent, or manufacturer about problems or condi-
tions you do not understand.
Ask your dealer to recommend a qualified techni-
cian and an authorized repair service. Know how
to disconnect the power to the appliance at the
circuit breaker or fuse box in case of an emer-
gency.
Remove the oven door from any unused oven if it
is to be stored or discarded.
Do not touch a hot oven light bulb with a damp
cloth. Doing so could cause the bulb to break.
Handle halogen lights (if equipped) with paper
towels or soft gloves. Disconnect the appliance or
shut off the power to the appliance before
removing and replacing the bulb.
Important Safety Notice - The California Safe
Drinking Water and Toxic Enforcement Act
requires the governor of California to publish a list
of substances known to cause cancer, birth
defects, or other reproductive harms, and
requires businesses to warn customers of
potential exposures to such substances.

10
Control locations of the gas surface burners
Your range is equipped with gas surface burners with
different BTU ratings. The ability to heat food quicker and in
larger volumes increases as the burner size increases.
The small simmer burner is best used for simmering
delicate sauces, etc. This burner is located at the right rear
burner position on the cooktop. The standard burner can be
used for most surface cooking needs. The standard burners
are located at the left front and left rear positions on the
cooktop.
The power burners are best used for bringing large quanti-
ties of liquid rapidly up to temperature or when preparing
larger quantities of food. The power burner is located at the
right front position on the cooktop. Regardless of size,
always select cookware that is suitable for the amount and
type of food being prepared. Select a burner and flame size
appropriate to the pan. Never allow flames to extend
beyond the outer edge of the pan.
Assembly of the surface burner caps and burner
grates
It is very important to make sure that all of the surface
burner caps and surface burner grates are installed
correctly and at the correct locations.
1. Remove all packing material from cooktop area.
2. Discard all packing material (if applicable).
3. Unpack burner grates and position on the cooktop.
•The word REAR is stamped on the back of the burner
grates to help assure that the proper end of the grates
are placed to the rear of the cooktop.
•The grates are designed to rest inside the recess on
the cooktop.
•To install burner grates, place grates flat-side down
and align into the cooktop recess.
•Grates should rest flush against each other and
against the sides of the recess.
IMPORTANT
Figure 1: Proper grate installation
Do not allow spills, food, cleaning agents or any other
material to enter the gas orifice holder opening.
Always keep the burner caps and burner heads in place
whenever the surface burners are in use.
Burner cap lip
Burner cap
Burner head
IMPORTANT
Correct burner cap
placement
Incorrect burner cap
placement
BEFORE SETTING SURFACE CONTROLS

11
Operating the gas surface controls
1. Place cooking utensil on surface burner.
2. Push the surface control knob in and turn counterclock-
wise out of the OFF position.
3. Release the knob and rotate to the LITE position (see
figure 2). Note: All four electronic surface ignitors will
spark at the same time. However, only the burner you
are turning on will ignite.
4. Visually check that the burner has a flame.
5. Turn the control knob counterclockwise to the desired
flame size. The control knobs do not have to be set at a
particular setting. Use the knob indicator settings to
adjust the flame as needed. Do not cook with the
surface control knob in the LITE position. (The elec-
tronic ignitor will continue to spark if the knob is left in
the LITE position.)
In the event of an electrical power outage, the surface
burners can be lit manually. To light a surface burner, hold a
lit match to the burner head, then slowly turn the surface
control knob to LITE. After burner lights turn the knob to
desired setting.
•Do not cook with the surface control knob left in the
LITE position. The electronic ignitor will continue to
spark if the control knob setting remains in the LITE
position.
•When setting any surface control knob to the LITE
position, all electronic surface ignitors will spark at the
same time. However, only the surface burner you are
setting will ignite.
•Never place or straddle a cooking utensil over two
different surface cooking areas at the same time. This
can cause uneven heating results.
•In the event of an electrical power outage, the surface
burners can be lit manually. Use caution when lighting
surface burners manually. To light a surface burner,
hold a lit match to the burner head, then slowly turn
the surface control knob to LITE. After burner lights
push in and turn knob to desired setting.
•When operating the oven, it is possible for residual
heat from the oven to build-up and over time to even-
tually transfer to the surface control knobs located
directly above the oven door.
•Do not place flammable items such as plastic salt and
pepper shakers, spoon holders or plastic wrappings
on the cooktop when it is in use. These items could
melt or ignite. Potholders, towels, or wooden spoons
could catch fire if placed too close to the range
cooktop.
•Do not place aluminum foil or any material that can
melt on the range cooktop. If these items melt they
may permanently damage the cooktop surface.
•The cooktop should not be used during a self-clean
cycle. On some models, turning on any cooktop
surface burner will cause the clean cycle to cancel. If
the clean cycle is canceled, the oven control display
will show “SPr" for 5 seconds. The oven door will
remain locked until the oven has cooled down below
cleaning temperature. If the oven is below cleaning
temperature, the user can start another clean cycle
immediately. If the oven is in cleaning temperature
range, another self-clean cycle can be set once the
door unlocks (up to 4 hours).
IMPORTANT
Figure 2: Operating the gas knob
Do not operate the burner for an extended period of time
without cookware on the grate. The finish on the grate
may chip without cookware to absorb the heat.
OFF
LITE
HI
.
.
CAUTION
SETTING SURFACE BURNERS

12
SETTING SURFACE BURNERS
Setting proper surface burner flame size
For most cooking: Start on the highest control setting and
then turn to a lower one to complete the process. Use the
recommendations below as a guide for determining proper
flame size for various typesof cooking. The size and type of
utensil used and the amount of food being cooked will
influence the setting needed.
Gas Cooktop Burners
The front control gas cooktop comes with a variety of
burners to accommodate different sizes of cookware. The
most powerful burner (18k BTU) for cooking in larger pots
for canning or large amounts of soup or for boiling water is
located at the right front of the cooktop.
The cooktop also has12k, 7.5k, and 5k BTU burners to fit
most cookware and cooking need.
The Simmer Oval burner is in the center of the cooktop and
consists of a center burner and an oval burner. The center
burner of the simmer oval can be set separately from the
oval burner.
Settings based on using medium weight metal or
aluminum pans. Settings may vary using other types of
pans. The color of the flame is key to proper burner
adjustment. A good flame is clear, blue, and hardly visible
in a well lit room. Each cone of the flame should be
steady and sharp. Clean burner if flame is yellow-orange.
Flame Size Type of Cooking
High Flame •Start most foods
•Bring water to a boil
•Pan broiling
Medium Flame •Maintain slow boil
•Thicken sauces and
gravies
•Steaming foods
Low Flame •Keep foods cooking,
poaching and stewing
Figure 3: Gas flame adjustment
Never extend the flame beyond the outer edge of the
utensil. A higher flame simply wastes heat and energy,
and increases the risk of being burned by the gas flame.
NOTE
IncorrectCorrect
IMPORTANT
Figure 4: Gas cooktop with simmer-oval burner
shown in center of cooktop.
Never place or straddle a cooking utensil over two
different surface cooking areas at the same time unless
the cooktop is designed for such a purpose.
CAUTION

13
SETTING SURFACE BURNERS
Setting the Simmer Oval Burner
The simmer oval burner is specifically designed for use with
a griddle, and can be used for simmering sauces or foods in
most pots or pans. There are two knobs which control the
separate functions of the simmer oval.
To turn on the full simmer oval use the control knob located
to the left of the oven mode knob. There is an oval icon
marking above the knob.
To access the center burner only, turn the control knob
located to the right of the oven temperature control knob.
Important: Both the simmer oval control and the center
control may be turned on at the same time.
Home Canning
Be sure to read and observe all the following points when
home canning with your appliance. Check with the United
States Department of Agriculture (USDA) website and be
sure to read all the information they have available as well
as follow recommendations for home canning procedures.
•Use only quality flat bottom canners when home
canning.
•Use a straight-edge to check canner bottom.
•Make sure the diameter of the canner does not exceed
1 inch beyond the surface element markings or burner.
•Start with hot tap water to bring water to boil more
quickly.
•Use the highest heat setting when first bringing the
water to a boil. Once boiling is achieved, reduce heat to
lowest possible setting to maintain that boil.
•Never place or straddle a cooking utensil over two
different surface cooking areas at the same time unless
the cooktop is designed for such a purpose.
Figure 5: Control knob for full oval burner
Figure 6: Center burner control knob

14
Oven vent location
The oven vent is located under the backguard in the rear of
the cooktop. When the oven is on, warm air passes through
this vent. This venting is necessary for proper air circulation
in the oven and good baking results. While the oven is in
operation, it is normal for steam or moisture to appear near
the vent. Do not block oven vent.
Type of oven racks
Oven Rack Descriptions
• Flat oven racks (or the flat handle oven rack) may be
used for most cooking needs and may be placed in
most oven rack positions.
•The offset oven rack (some models) provides addi-
tional step down positions from the standard flat rack
design. The offset design positions the base of the rack
about ½ of a rack position lower than the flat rack and
may be used in most oven rack positions.
•The fully extendable oven glide rack allows you to
effortlessly extend your food away from the oven.
Removing, replacing, and arranging flat or offset
oven racks
To arrange - Always arrange the oven racks when the oven
is cool (prior to operating the oven).
To remove - Pull the oven rack straight forward until it
reaches the stop position. Lift up front of oven rack slightly
and slide out.
To replace - Place the oven rack on the rack guides on
both sides of oven walls. Tilt the front of oven rack upward
slightly and slide the oven rack back into place. Be sure
oven racks are level before using.
Figure 7: Oven vent location
Always use pot holders or oven mitts when using the
oven. When cooking, the oven interior and exterior, oven
racks and cooktop will become very hot which can cause
burns.
Remove all oven racks and clean according to instruc-
tions provided in the Care & Cleaning section of this
manual. Never pick up hot oven racks or parts.
All oven racks should be removed before a clean opera-
tion. Racks left in the oven during the high heat of the
clean function can easily discolor. The ability of the racks
to easily slide in and out along the rack positions may
also be affected.
oven vent
CAUTION
IMPORTANT
oset
oven rack
at handle
oven rack
glide
rack
BEFORE SETTING OVEN CONTROLS

15
BEFORE SETTING OVEN CONTROLS
Removing and Replacing the Glide Racks
The fully extendable Glide rack makes food preparation
easier. This oven rack has glide tracks that allow the rack to
be pulled away from the oven without rubbing the sides of
the oven wall.
To remove - Using one hand, reach through handle
opening and lift up on the release lever located across the
lower front of the rack as shown in Figure 8.
While holding up the release lever, pull the glide rack out of
the oven until the stop position is reached (Figure 9)
Using both hands, grasp the upper and lower portions of the
glide rack. Lift up the front of the rack slightly and continue
to pull the rack away from the oven (Figure 10). Be sure to
grasp both upper and lower rack portions together when
removing or handling the glide rack. The rack portions
move independently and are difficult to handle unless held
together.
To replace - grasp both upper and lower portions of glide
rack, lift and hold the rack level between the oven cavity
walls. Tilt the front of the rack upward slightly and slide the
rack completely into position.
Do not line the oven walls, racks, bottom or any other
parts of the range with aluminum foil or any other
materials or oven liners. Doing so will alter heat distribu-
tion and may cause permanent damage to the oven
interior. During clean the oven temperatures will be hot
enough to melt foil.
Protective Liners — Only use aluminum foil as recom-
mended in this manual. Improper installation of these
liners may result in risk of electric shock or fire.
Figure 8: Grasp handle and lift up on bar
Figure 9: Pull rack to stop position
IMPORTANT
Figure 10: Remove and replace using both hands
To prevent possible damage to the oven, do not attempt
to close the oven door until all the oven racks are fully
positioned back inside the oven cavity.
IMPORTANT

16
OVEN CONTROLS
OVEN MODE SETTINGS
POWERPLUS™ PREHEAT - Use powerplus preheat for
single rack items only and place food in center of oven.
BAKE - Use to select bake function before setting tempera-
ture.
CLEAN - Use to select clean feature cycle before setting
clean with oven temperature selector.
CONVECT BAKE - Use to select convection baking before
setting oven temperature.
CONVECT ROAST - Use to select convection roast for
beef, lamb, pork, and poultry before setting oven tempera-
ture.
BROIL - Use to set broil feature before setting broil with
oven temperature selector.
KEEP WARM - Keep warm provides a low heat for keeping
cooked foods at serving temperature.
OVEN DISPLAY FEATURES
1. OVEN LIGHT - Use to turn internal oven light on and
off.
2. CLOCK - Use clock icon when setting the time of day.
3. TIMER - Oven timers for tracking cooking times. Timers
do not stop or start the cooking process.
OVEN TEMPERATURE SETTINGS
Before setting the oven, both the mode and temp knobs
should be set to OFF. Set both mode and temp knobs to
OFF when finished cooking.
Use to set oven temperatures between 170°F (KEEP
WARM) and 550°F. The CLEAN setting should only beused
after reading all cautions and warnings in the “Self
Cleaning” sections of this manual starting on page 28.
User Preference Settings
The default (factory) settings for sounds, energy saving,
temperature offset, and convection convert are pre-set in
the oven control. These may be changed by accessing the
user preference display while the oven is idle. Once the
user preference menu is activated, the user can make
changes and scroll through a menu of options, choosing
from AUd (audible control setting), ES (energy saving),
UPO (User Programmable Offset for changing the oven
temperature), Aut (automatic convection convert), dEF
(default setting) and rSt (which will reset all preferences to
default settings).
12
3
Oven Minimum and Maximum Control Settings
Feature Min. Temp/Time Max. Temp/Time
BAKE 170°F (77°C)
(KEEP WARM) 550°F (288°C)
POWERPLUS
PREHEAT 170°F (77°C)
(KEEP WARM) 550°F (288°C)
CONVECT BAKE 170°F (77°C)
(KEEP WARM) 550°F (288°C)
CONVECT ROAST 170°F (77°C)
(KEEP WARM) 550°F (288°C)
MEAT PROBE 140°F (60°C) 210°F (99°C)
BROIL 550°F (288°C)
TIMER 0:01 Hr 11:59
CLOCK (12hr) 1:00 Hr 12:59 Hr
CLEAN (Times) 2, 3 OR 4 HOURS
OVEN CONTROLS

17
OVEN CONTROLS
Setting the Clock
The clock icon is used to access the time of day setting.
When the oven is first plugged in or if there has been an
interruption in power to the range, 12:00 will flash in the
display.
To set the correct time of day:
1. Press the clock icon.
2. The display will show a time along with a – key and a +
key in the display below.
3. Press either – or +key to scroll to the correct time of
day and release the key.
4. The control will accept the new set time with a chime,
and the control will show the time of day along with the
two timers that are available.
Oven Lights
The oven lights will turn on automatically when the oven
door is opened. The oven lights may be turned on when the
door is closed by using the oven light key located on the
control panel.
Note: Keep oven lights off while baking. The oven lights
will turn off during a clean cycle and not operate.
To toggle the oven lights on and off:
1. Press oven light symbol .
The interior oven light is covered with a glass shield. The
glass shield must be in place whenever the oven is in use.
To change the interior oven lights, see ““Replacing the oven
light” in the Care & Cleaning section.
Setting the Timer
The minute timers in the oven display serve as extra timers
to help keep track of cooking functions. The timer cannot be
used during a clean cycle or if the meat probe function
associated with the timer display is in use. The minimum
timer setting is 1 minute and the maximum setting is 11:59
(HR:MIN).
To set the timer:
1. Press either TIMER key.
2. The timer display will show
3. 0:00 and a – key and + key on either side of the time
display. NOTE: If the – key is pressed at this time an
invalid key chime will sound.
4. Press the +key to begin to scroll to the desired setting.
If the + key is held, the timer value will increase rapidly.
Once the desired setting is reached, release the key
and the timer will start counting down automatically after
a short time-out.
5. The timer display will show the H:M icon if the timer is
set for more than 1 minute. If the value is under 1
minute, the timer will display the time in seconds and
the H:M icon will not appear.
6. When the timer ends, a reminder chime will sound and
repeat once every 60 seconds for a period of five
minutes. Before the user can program an expired timer
again, the timer key must be pressed.
7. To cancel the timer before the set time expires, press
the TIMER key.
The clock cannot be changed when the oven is set for
cooking or clean is active. Only a 12 hour clock is
available on the Frigidaire Professional model.
NOTE
The minute timers will not start or stop the cooking
process. The minute timers can be used alone or while
using most of the other oven features.
NOTE

18
OVEN CONTROLS
Setting Continuous Bake or 6 Hour Energy Saving
The oven is preset to cook up to 6 hours and to shut off
automatically. For longer periods of cooking, this feature
can be changed to continuous cooking by setting the user
preference and turning the energy saving feature off.
To set the oven for continuous cooking:
1. Press and hold both the light icon and the clock icon at
the same time for a few seconds until the display
sounds an acceptance chime and the display will show
one of the user preferences.
2. Press the +key in the upper part of the display until ES
appears and ON is showing.
3. To turn the energy saving feature off, press the + or –
key in the lower part of the display and OFF will appear
in the display.
4. The control will accept the change in a few seconds and
sound the acceptance chime. The oven is now set for
continuous cooking.
5. To return to the time of day display, press and hold the
light and clock icons at the same time for a few
seconds until the display chimes and fades back to
showing the time of day in the display.
Setting Control for Silent Operation
The oven is set to operate with certain chimes and tones
(default settings) that alert the user to certain oven
functions. The silent operation feature allows the oven
control to be operated without sounds when necessary. By
accessing user preferences, this option can be later
returned to operate with normal programming sounds.
To set the oven control for silent operation:
1. Press and hold both the light icon and the clock icon at
the same time for a few seconds until the display
sounds an acceptance chime. AUd should appear in
the display.
2. If Aud is not showing, press the +key in the upper part
of the display until AUd appears and HI is showing in
the lower part of the display. This is the normal (default)
setting.
3. To turn the energy saving feature to a lower sound or
completely OFF, press the + or –key in the lower part
of the display until LO or OFF appears in the display.
4. When the desired setting appears in the display, release
the key and wait for an acceptance chime.
5. To return to the time of day display, press and hold both
the light and clock icons at the same time for a few
seconds until the display chimes and fades back to
showing the time of day.
Figure 11: Energy saving with ON and OFF options
Changing to continuous bake does not change how the
cooktop controls operate.
IMPORTANT
Figure 12: Default setting for oven control sounds
Figure 13:

19
OVEN CONTROLS
Setting PowerPlus™ Preheat
The PowerPlus™ Preheat feature uses the convection fan
to quickly bring the oven up to the set temperature. Use
powerplus preheat for single rack items only and place food
in center of oven.
Important: When baking delicate items like cakes and
cookies use the regular bake or convection bake mode.
To set powerplus preheat:
1. Turn the oven mode selector to POWERPLUS
PREHEAT. The oven mode light will turn on.
2. Turn the oven temperature selector to the desired
temperature. The convection fan will turn on after 6
minutes and remain on as a convection bake. The
control will chime once the oven is preheated.
3. When finished baking turn both oven selectors to the
OFF position.
Setting Bake
Baking tips
For best bake results:
•Fully preheat the oven before baking items like cookies,
cakes, biscuits, and breads. When using any single
rack, position the rack so that the food is in the center of
the oven.
•The convection fan will be on during preheat and then
turn off and on occasionally as needed.
•For best results when baking cakes using two oven
racks, place racks in positions 6 (offset rack) and 1
(Glide rack) Figure 14.
•When baking using two oven racks, position cookware
as shown in Figure 15. Allow at least 2 inches (5 cm) of
space between cookware for proper air circulation.
•Dark or dull bakeware absorbs more heat than shiny
bakeware. It may be necessary to reduce oven temper-
ature and cook time to prevent overbrowning of some
foods. Dark bakeware is recommended for pies. Shiny
bakeware is recommended for cakes, cookies, and
muffins.
Important: For batter and dough-based baked goods such
as cakes, pastries, and breads, use the regular bake
function for best results. For cookies use the convection
bake function.
.
Use the bake function whenever a recipe calls for normal
baking. When the set bake temperature is reached the
control will sound a chime to alert that the oven is fully
preheated.
Bake may be set for any temperature between (170°F
77°C) and 550°F (288°C).
To set BAKE for oven temperature of 350°F:
1. Be sure to arrange racks to the desired positions for the
item(s) to be baked.
2. Turn the oven mode selector to the BAKE position.
3. Turn the oven temperature selector to 350°F.
4. The PREHEAT and the oven temperature light will turn
on and sound an acceptance tone. The oven will begin
heating.
5. When the set temperature is reached a reminder chime
will sound alerting you to place food in oven. Set either
timer to keep track of actual cooking time if necessary.
6. When finished baking, be sure to return both the
temperature selector knob and the oven mode knob to
the OFF positions.
Note: Do not open oven door too often. Doing so reduces
oven temperature and may extend cooking time.The
convection fan will start after the oven has been heating for
6 minutes. It will stop each time the oven door is opened.
Figure 14: Rack positions Figure 15: Pan spacing
1
2
3
4
5
6

20
OVEN CONTROLS
Convection Cooking
This mode of cooking enables you to obtain the best results
when baking with multiple pans and racks. The oven can be
programmed for convection baking at any temperature
between 170°F to 550°F with a default temperature of
350°F. The convection fan will turn on after 6 minutes and
remain on during the convection baking process.
The convection function uses a fan to circulate the oven
heat uniformly and continuously around the oven
(Figure 16). This improved heat distribution allows for fast,
even cooking and browning results. It also gives better
baking results when using two oven racks at the same time.
Benefits of convection cooking:
•Multiple rack baking.
•Some foods may cook faster.
Convection baking tips:
•Fully preheat the oven before baking items like cookies,
cakes, biscuits, and breads. For best results baking
cookies use convection bake function.
•If your recipe cooking temperature has not been
converted for convection baking, see “Setting Convec-
tion Convert” on page 21 for further instructions on
temperature conversion.
•When using any single rack, position the rack so that
the food is in the center of the oven.
•For best results when baking cakes using two oven
racks, place racks in positions 6 with offset rack and 1
using Glide rack (See Figure 16).
•When baking using two oven racks, position cookware
as shown in Figure 17. Allow at least 2 inches (5 cm) of
space between cookware for proper air circulation.
•Dark or dull bakeware absorbs more heat than shiny
bakeware. It may be necessary to reduce oven temper-
ature and cook time to prevent overbrowning of some
foods. Dark bakeware is recommended for pies. Shiny
bakeware is recommended for cakes, cookies, and
muffins.
•Do not open oven door too often. Doing so reduces
oven temperature and may extend cooking time.
•Most baked goods (except cakes) should be baked on
pans with no sides or low sides to allow air to circulate.
Setting Convection Bake
This mode of cooking enables you to obtain the best results
when baking with multiple pans and racks. The oven can be
programmed for convection baking at any temperature
between 170°F to 550°F.
To set the oven for convection bake and temperature to
350°F:
1. Arrange interior oven racks.
2. Turn the oven mode selector to CONVECT BAKE.
3. Turn the oven temperature selector to 350°F.
4. The convection fan will turn on 6 minutes after the oven
begins heating. Once the oven reaches the set temper-
ature the oven will sound a chime indicating the food
items can be placed in the oven.
5. When finished baking, be sure to return both the
temperature selector knob and the oven mode knob to
the OFF positions.
Figure 16: Convection air flow
Figure 17: Pan spacing recommendations
1
2
3
4
5
6
