SERVICE DATA SHEET 318127012 (0306) Rev. A
Electric & Dual Fuel (Gas Cooktop - Electric Oven) Slide-in Range with ES500 & ES550
Electronic Oven Control
°
.
NOTE: The controler's are not field repairable. Only temperature settings can be changed. See oven calibration
*NOTE:Depending on model, the size and shape of touch pads may vary (for example round instead of elliptical). Some
models may also have round push buttons instead of touch pads.
1. This self-cleaning controler offers Bake, Broil, Preheat,
Convection Bake and Convection Roasting modes, Timed and
Delayed Baking, and Cleaning functions. ES550 controls have
the MEATS, CAKES and BREADS features.
2. Convection operates with an element and a fan dedicated to
convection.
3. Slew and dial are replaced by a digit key pad.
4. No external relays.
ES500 & ES550 ELECTRONIC OVEN CONTROL
To avoid the possibility of personal injury and/or property damage, it is important that safe servicing practices be
observed. The following are examples, but without limitation, of such practices.
1. Do not attempt a product repair if you have any doubts as to your ability to complete it in a safe and satisfactory
manner.
2. Before servicing or moving an appliance, remove power cord from electric outlet, trip circuit breaker to Off, or
remove fuse and turn off gas supply.
3. Never interfere with the proper installation of any safety device.
4. USE ONLY REPLACEMENT PARTS CATALOGED FOR THIS APPLIANCE. SUBSTITUTIONS MAY DEFEAT COMPLIANCE
WITH SAFETY STANDARDS SET FOR HOME APPLIANCES.
5. GROUNDING: The standard color coding for safety ground wires is GREEN OR GREEN WITH YELLOW STRIPES.
Ground leads are not to be used as current carrying conductors. IT IS EXTREMELY IMPORTANT THAT THE SERVICE
TECHNICIAN REESTABLISH ALL SAFETY GROUNDS PRIOR TO COMPLETION OF SERVICE. FAILURE TO DO SO
WILL CREATE A POTENTIAL HAZARD.
6. Prior to returning the product to service, ensure that:
• All electric connections are correct and secure.
• All electrical leads are properly dressed and secured away from sharp edges, high-temperature components,
and moving parts.
• All non-insulated electrical terminals, connectors, heaters, etc. are adequately spaced away from all metal
parts and panels.
• All safety grounds (both internal and external) are correctly and securely reassembled.
• All panels are properly and securely reassembled.
SAFE SERVICING PRACTICES
This service data sheet is intended for use by persons having electrical and mechanical training and a level of
knowledge of these subjects generally considered acceptable in the appliance repair trade. The manufacturer
cannot be responsible, nor assume any liability, for injury or damage of any kind arising from the use of
this data sheet.
NOTICE
ES550*
ES500*
Rear of both models

2
set point
First rise overshoot
T°
t (sec)
The convection oven uses the addition of a fan and an element to heat and to move the air already in the oven. Moving
the heated air helps to destratify the heat and cause uniform heat distribution. Cooking times can be reduced by as
much as 30%. The air is drawn in through a fan shroud and the element located on the rear wall of the oven. It is
then discharged around the outer edges of this shroud. The air circulates around the food and then enters the shroud
again. As with conventional electric ranges, there is still an oven vent which discharges through the rear of the cooktop.
To set the control in convection mode, follow these steps:
1.Press the CONV. BAKE/ROAST pad.
2. Enter the desired temperature on the keypad (setpoint).
3. Press the START pad.
The oven will automatically start and the fan will begin to run. To cancel the convection baking/roasting function, press
the CANCEL pad.
NOTE: The fan runs continuously while in the convection mode. The fan will stop if the door is opened while
convection baking/roasting. The bake element will continue to operate if the door is opened.
It is normal to see a temperature overshoot in the
first rise of all modes when you monitor the temperature.
FIRST RISE
When these modes are called, the door locks right after start button is pushed.
CLEAN AND TIMED CLEAN
During a cleaning process, the oven uses bake element .
CLEAN
During a normal bake mode, the controler preheats the oven with the bake element. When the desired temperature
is reached, the controler adds top heat by cycling the broil element on for 12 to 18 seconds per minute . The bake
element is on for the remaining time of the minute. Both elements use full power when they are on but they are never
on at the same time.
NORMAL BAKE
During a preheat mode, the oven uses bake element to reach the controler set point. The element uses full power
when it's on. When the setpoint is reached, the preheat mode is converted in a normal bake mode.
PREHEAT
CONVECTION MODE
OVEN CALIBRATION
Set the electronic oven control for normal baking at 350°F/176°C. Obtain an average oven temperature after a
minimum of 5 cycles. Press Cancel to end bake mode.
Note: Changing calibration affects all the cooking modes but not the clean mode.

3
Note: Only three fault codes are displayed by this control “F1”, “F3”, and “F9”. Generally speaking “F1” implies a control
failure, “F3” an oven probe problem, and “F9” a latch motor problem. In all ocurrences the alarm is accompanied by a display
of “F1”
1. Shorted keypad.
2. Control's internal checksum may
have become corrupted.
3. Control has sensed a potential
runaway oven condition. Control may
have shorted relay, RTD sensor probe
may have gone bad.
1. Open RTD sensor probe/ wiring
problem. Note: EOC may initially
display an "F1", thinking a runaway
condition exists.
2. Shorted RTD sensor probe / wiring
problem. Note: "F3" is displayed
when oven is in active mode or an
attempt to enter an active mode is
made.
3. Abusive operation (safety
thermostat).
4. Safety thermostat opened, or cooling
fan stalled.
1. Door motor failure / jammed. Latch
motor switch failure.
2. Control software failure, or
component failure (relay stuck).
3. Wiring Problem.
Likely Failure Condition/Cause Suggested Corrective Action
Fault Code
1. Replace EOC.
2. Disconnect power, wait 30 seconds and reapply power. If
fault returns upon power-up, replace EOC.
3. Check RTD sensor probe and replace if necessary. If oven
is overheating, disconnect power. If oven continues to
overheat when the power is reapplied, replace EOC.
Severe overheating may require the entire oven to be
replaced, should damage be extensive.
1. Check wiring in probe circuit for possible open condition.
Check RTD resistance at room temperature (compare to
probe resistance chart). If resistance does not match the
chart, replace the RTD sensor probe.
2. Check wiring in probe circuit for possible short condition.
Check RTD resistance at room temperature (compare to
probe resistance chart). If resistance does not match the
chart, replace the RTD sensor probe.
3. Let the oven cool down and restart the function
4. Look for stalled cooling fan, broken safety thermostat
(opens).
1. Press CLEAR key.
2. If CLEAR key does not eliminate problem, turn off power
for 30 seconds, then turn on power.
3. Check wiring of Lock Motor, and Lock Switch A and Door
Switch circuits.
4. Unplug P4, apply power (L1) directly to the Lock Motor, if
the motor does not rotate, replace Lock Motor Assembly.
Plug P4.
5. Check Lock Switch A for proper operation (do they open
and close, check with ohmmeter). The Lock Motor may be
powered as in above step to open and close Lock Switch.
If the Lock Switch is defective, replace Motor Lock Assembly.
6. If all above steps fail to correct situation, replace control.
F3
F1
F9
ELECTRONIC OVEN CONTROL FAULT CODE DESCRIPTIONS AND RTD SCALE
ELECTRONIC OVEN CONTROL
RTD SCALE
Temp. °F Temp. °C Resistance (ohms)
32 ± 1.9 0.0 ± 1.1 1000 ± 4.0
75 ± 2.5 23.9 ± 1.4 1091 ± 5.3
250 ± 4.4 121.1 ± 2.4 1453 ± 8.9
350 ± 5.4 176.7 ± 3.0 1654 ± 10.8
450 ± 6.9 232.2 ± 3.8 1852 ± 13.5
550 ± 8.2 287.8 ± 4.6 2047 ± 15.8
650 ± 9.6 343.3 ± 5.3 2237 ± 18.5
900 ± 13.6 482.2 ± 7.6 2697 ± 24.4
OVEN TEMPERATURE
SENSOR

4
Cooling
Fan
CIRCUIT ANALYSIS MATRIX
Bake
P3
Conv.
P5-7
Lock Motor Switches
A
Bake
Broil
Clean
Unlocked
Locking
Locked
Unlocking
Conv. Bake
X
X
X
X
P5-10
&
P5-11
Door
Switch
COM-NO
X
Broil
P2
ELEMENTS
Conv.Fan
P5-7
Light
P5-4
Door Motor
P5-6
P5-10
&
P5-13
Conv. Roast
Light
Door Open
Door Closed
Warmer
Drawer
Warmer
Zone
X
X
X*
X
X*
X*
X
X
X
X
X
X
NC
NO
NO
NC
NO
NC
NC
NO
* Denotes Topheat ** Stage 1 + Stage 2 Relay will operate in this condition only
ELECTRICAL RATING
Kw Rating See Bake Element 3000W/2253W
240/208 V nameplate Wattage
Broil Element 2750W/2065W Convection 350W/263W
Wattage Element Wattage
Warmer Drawer 450W/120V Warmer Zone 100W/120V
Element Element
EXPLODED VIEW OF CONVECTION SYSTEM
X
X
X
X
X

5
FAN BLADE
The fan blade is mounted in the rear of the unit and has a "D" shaped mounting hole. Only minimum clearance exists
between the oven back, fan blade, and fan shroud. Be careful not to bend blade when removing or installing.
Access to the fan blade is gained by removing the fan shroud, held in place by three screws, from the inside of the oven.
The fan blade is held in place with a hex nut that has left handed threads. When removing this nut, gently hold the
fan blade, and turn the nut clockwise. If one of the blades becomes deformed, it may be bent back into shape using
a flat surface as a reference.
A flat washer is located on the motor shaft between the snap ring on the shaft and the fan blade.
NOTE: If the fan blade is bent and motor vibrations increase, the noise made by the fan will be greater.
MOUNTING PLATE OVEN
The fan motor on the rear of the unit is mounted to the main back (with three screws). There is a mounting plate held
in place between the main back (with 2 screws) and the rear oven wall (with 2 screws). Should it be necessary to replace
the oven cavity, you must remove the 2 screws located inside the unit at the rear of the oven cavity.
FAN MOTOR
The 120 volt fan motor is located on the outside of the rear of the oven.
FAN RELAY
The fan motor runs continuously while in the convection mode unless the door is opened. If the fan does not operate,
check the following:
• Display illuminated on the electronic control.
• Voltage output between terminals P5-7 and Neutral.
• 120 Volts available at fan motor.
• Fan motor coil resistance 56.5 ohms ± 10%.
• Door/light switch.
DOOR LOCK MECHANISM
The appliance is equipped with an electronic oven control and has an auto locking door latch feature. When the self
clean cycle is programmed, the door is locked by a motor operated latch system. The interior of oven does'nt need to
heat up to 500°F/260°C before the door locks. However, until the temperature inside oven reaches 500°F/260°C, the
self-clean program can be canceled and door will unlock immediately. After oven reaches temperatures over 500°F/
260°C, the door will not unlock until temperature drops below 500°F/260°C.

6
Lock in normal
position
Lock engaged
for door removal
HINGE SLOT Door
removed from the range
1. Disconnect range from electrical supply
2. Open door to fully opened position.
3. Pull up the lock located on each hinge support and engage it in the hook of the hinge lever. You may have to apply
a little downward pressure on the door; pull the locks fully over hooks.
4. Grasp door by sides, pull bottom of door up and toward you while rotating the top of door toward range to
completely disengage the hinge levers.
5. To reinstall reverse procedure. Make sure hinge supports are fully engaged before unlocking the hinge levers.
OVEN DOOR REMOVAL AND REPLACEMENT
The Warm and Serve Drawer is designed to keep prepared food warm until it is time to serve. This
feature is available on select gas and electric models. The Warm and Serve Drawer is electrically
operated on both gas and electric models.
Ranges featuring the Warm and Serve Drawer feature are equipped with heavy duty ball bearing
drawer glides. These glides not only support the weight more effectively, they also allow the drawer to
be opened to its full depth.
The warmer control is included in the features of your electronic controls. A 450 watt, 120 volt element
is secured to a metal base located just below the Warm and Serve Drawer. A preheat thermostat
(bimetal disk) is located at the left rear corner of the range, directly above the element terminals. The
system also contains a diode, indicator lamp, and safety thermostat. The diode is located in the wiring
harness a short distance from the safety thermostat.
The safety thermostat is mounted to the rear insulation panel and is actuated during the self-clean cycle. It is used to
open the circuit to the heating element so the warming drawer will not function during the self-clean cycle.
WARM AND SERVE DRAWER (SOME MODELS)

7
WARM AND SERVE DRAWER COMPLETE CIRCUIT (SOME MODELS)
NOTE: The hot surface indicator light will take around 10 minutes to turn ON.
WARMER ZONE CIRCUIT (SOME MODELS)
When the Warm and Serve Drawer is first turned on, a "Preheat" circuit is established to provide full power (120
volts). When the temperature at the preheat thermostat reaches 150°F the thermostat opens, and the warmer
element starts cycling. If the control is placed on a lower setting, it is possible for the temperature in the drawer to
drop enough to allow the preheat thermostat to close again which will allow the element to reenter the "Preheat"
mode at full power.
Hot Surface
Hot Surface Controls

8
GAS COOKTOP REMOVAL
Regulator
Valves
Orifice Holder
Assemblies
Burner Skirts
Burner Heads
Burner Caps
Burner Seals
Manifold
Igniters
1.Shut off gas to range.
2.Disconnect power.
3.Remove gas supply line at the regulator. If necessary, move range out of the cabinet opening.
4.Remove grates and burner caps. Inspect burners.
5.Remove screws securing burner skirts. Inspect electrode, cleanliness, etc.
Note: The electrode can not be removed from orifice holder assembly.
6. Remove knobs.
7. Remove flange nut.
8. Remove Control Panel.
9. Remove switch mounting plate screws.
10. Remove 2 screws from front shield on each side panels.
11. Remove 5 screws from front shield and 4 screws from vent trim to be able to remove console.
12. Remove machine screw on manifold side range securing manifold to cooktop.
13. Remove cooktop assembly from unit.
14. Remove screws all around mounting plate element located under cooktop assembly.
15. Remove glass assembly from burner box.
16. To reassemble cooktop, reverse procedures.
Side panels
Nuts
Knobs
Burner Box
Front Shield
Vent Trim
Cooktop
Assembly
Control
Panel
Switch
Mounting
Plate

AVIS
°
Cette feuille de données d'entretien est destinée aux personnes ayant reçu une formation en électricité et en mécanique,
et qui possèdent un niveau de connaissance jugé acceptable dans l'industrie de réparation des appareils électroménagers.
Le fabricant ne peut être tenu responsable, ni assumer aucune responsabilité, pour toute blessure ou
dommage de quelque nature que ce soit pouvant résulter de l'utilisation de cette feuille de données.
PRATIQUES D'ENTRETIEN SÉCURITAIRES
Pour éviter tout risque de blessure et/ou dommage matériel, il est important que des pratiques d'entretien sécuritaires
soient suivies. Voici quelques exemples de pratiques sécuritaires.
1. N'essayez jamais de réparer un appareil si vous ne croyez pas avoir les compétences nécessaires pour le faire de
manière satisfaisante et sécuritaire.
2. Avant de procéder au service d'entretien ou de déplacer tout appareil ménager, débranchez le cordon d'alimentation de la
prise électrique, réglez le disjoncteur de circuit à OFF, ou enlevez le fusible et fermez le robinet d'alimentation en gaz.
3.N'entravez jamais l'installation adéquate de tout dispositif de sécurité.
4.UTILISEZ QUE les pièces de remplacement énumérées dans le catalogue pour cet appareil. LA MOINDRE
SUBSTITUTION risque de ne pas être conforme aux normes de sécurité établies pour les appareils électroménagers.
5. MISE À LA TERRE: La couleur de codage standard des conducteurs de mise à la terre de sécurité est VERTE ou VERTE À
BARRES JAUNES. Les conducteurs de mise à la terre ne doivent pas être utilisés comme conducteurs de courant. Il est d'une
IMPORTANCE CAPITALE que le technicien d'entretien complète toutes les mises à la terre de sécurité avant de terminer le
service. Si cette recommandation n'est pas suivie à la lettre, il en résultera des risques pour les personnes et les biens.
6.Avant de retourner le produit au service de réparation ou d'entretien, assurez-vous que:
• Toutes les connexions électriques sont correctes et sécuritaires
• Tous les conducteurs électriques sont correctement préparés et sécuritairement à l'abri des bords tranchants, des
composants à température élevée, et des parties mobiles.
• Toutes les bornes électriques, connecteurs, réchauffeurs, etc. dénudés sont espacés convenablement loin de
toute pièce en métal et des panneaux.
• Toutes les mises à la terre de sécurité (interne et externe) sont correctement et sécuritairement ré-assemblées.
• Tous les panneaux sont correctement et fermement remontés.
ES500 & ES550 COMMANDE ÉLECTRONIQUE DE FOUR À CONVECTION
FEUILLE DE DONNÉES D'ENTRETIEN 318127012 (0306) Rev. A
Cuisinière encastrable à alimentation mixte (Plaque de cuisson à gaz - Four électrique)
avec commande de four électronique ES500 & ES550
1
Arrière de chacun des modèles
NOTE: Cette commande de four n'est pas réparable sur place. Seulement des réglages de température peuvent être
faits. Voir étalonnage du four.
*NOTE: La grosseur et la forme des touches peuvent varier selon le modèle (ex.: ronds au lieu d'elliptiques). Certains
modèles peuvent aussi être munis de boutons poussoirs ronds au lieu de touches tactiles.
ES550*
ES500*
1. Cette commande de four convection offre les fonctions
suivantes: cuisson au four, griller, cuisson à convection, rôtissage
à convection, temps de cuisson et temps de cuisson différé ainsi
que les fonctions de nettoyage. Le controlleur ES550 possède
aussi les commandes MEATS, CAKES et BREADS.
2. Le mode convection fonctionne avec un ventilateur et un
élément qui lui sont propre.
3. Cette commande de four possède un clavier digital.
4. Cette commande de four n'a pas de relais externe.

Point de consigne
Dépassement du point de consigne lors de
la première élévation de température
T°
t (sec)
2
Il est normal que la température du four dépasse
le point de consigne désiré lors de sa première
élévation de température pour les différentes
fonctions.
PREMIÈRE ÉLÉVATION DE LA TEMPÉRATURE
Lorsque ces fonctions sont demandées, la porte se verrouille aussitôt que la touche départ est activée.
NETTOYAGE ET NETTOYAGE MINUTÉ
Lorsque la fonction nettoyage est en opération, le four utilise la chaleur de l'élément inférieur.
NETTOYAGE DU FOUR
Durant la fonction de préchauffage, le four utilise la chaleur de l'élément inférieur. Une fois la température dans
le four désirée atteinte, la commande de four active l'élément supérieur environ 6 à 9 secondes par minute.
L'élément inférieur est en fonction pendant les autres secondes. Les deux éléments sont à leur pleine puissance
lorsqu'ils sont en fonction. Par contre ils ne sont jamais en fonction en même temps.
PRÉCHAUFFAGE
Lors de la cuisson traditionnelle, le four utilise la chaleur de l'élément inférieur afin d'atteindre la température réglée.
L'élément est à sa pleine puissance lorsqu'il est en fonction. La commande de four active l'élément supérieur environ
6 à 9 secondes par minute.
CUISSON
Le four à convection utilise un élément et un ventilateur pour chauffer et faire circuler l'air qui se trouve déjà dans le
four. La circulation de l'air chaud permet de déstratifier la chaleur et d'obtenir une répartition de la chaleur uniforme.
Letempsde cuisson peutêtreréduit de prèsde30%. L'air estattirévers l'élément àl'intérieurdu diffuseur duventilateur
situé sur la paroi arrière du four. Il est ensuite libéré autour des extrémités extérieures du diffuseur. L'air circule autour
de l'aliment et pénètre à nouveau dans le diffuseur. Comme dans les cuisinières électriques conventionnelles, il existe
toujours un orifice ventilateur qui évacue l'air à l'arrière de la plaque de cuisson.
Pour régler la commande de cuisson par convection, suivez les deux étapes ci-dessous:
1.Appuyez sur la touche CUISSON À CONVECTION/RÔTISSAGE À CONVECTION.
2.Ajustez la commande du four à la température désirée (point de consigne) à l'aide du clavier.
3.Appuyez sur la touche DÉPART.
Le four et le ventilateur se mettent automatiquement en marche. Pour annuler la fonction de cuisson par convection,
appuyez sur la touche EFFACER.
NOTE: Le ventilateur fonctionne sans interruption durant la cuisson par convection. Le ventilateur s'arrête si la porte
s'ouvre pendant la cuisson/rôtissage par convection. L'Élément chauffant continue à fonctionner si la porte est ouverte.
MODE CONVECTION
Réglez le point de consigne pour une cuisson traditionnelle à 350°F (177°C). Mesurez la température moyenne du four
après un minimum de 5 cycles. Appuyez sur la touche EFFACER pour terminer le mode de cuisson.
Note: Modifier l'étalonnage affecte tous les modes de cuisson mais pas les modes de nettoyage.
CALIBRATION DU FOUR
