Frigidaire GLGF388AQB User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR MARKET
GLGF388ABC GLGF388A GALLERY black North America
GLGF388AQC GLGF388A GALLERY bisque North America
GLGF388ASC GLGF388A GALLERY white North America
Publication No.
5995366993
020226
-EN/SERVICE /ECL
369
GLGF388AQB
GLGF388ASB
WIRING DIAGRAM - # 316255207
SERVICE DATA SHEET - # 316259130
OWNER’S GUIDE - # 316257504
INSTALLATION INSTRUCTIONS -# 316259316

02/02 2
BACKGUARD

GLGF388A Publication No.
5995366993
BACKGUARD
A = GLGF388A (GLGF388ASC)
B = GLGF388A (GLGF388ABC)
C = GLGF388A (GLGF388AQC)
POS. NO PART NO DESCRIPTION
1 316239900 A B C Shield,backguard ,rear wall
2 316051600 A B C Shield,backguard ,inner
2A 316235100 A B C Shield,top ,inner
15 316220202 A - - Support,backguard ,white ,RH
15 316220204 - B - Support,backguard ,black ,RH
15 316220208 - - C Support,backguard ,bisque ,RH
15A 316220203 A - - Support,backguard ,white ,LH
15A 316220205 - B - Support,backguard ,black ,LH
15A 316220209 - - C Support,backguard ,bisque ,LH
19 316232600 A - - Panel,backguard ,white
19 316232601 - B - Panel,backguard ,black
19 316232602 - - C Panel,backguard ,bisque
20 # 316248003 A B C Clock/Timer,EOC
20A 316243300 A - - Overlay,clock ,white
20A 316243301 - B - Overlay,clock ,black
20A 316243302 - - C Overlay,clock ,bisque
36 316220000 A - - Knob,top valve ,white ,(4)
36 316220002 - B - Knob,top valve ,black ,(4)
36 316220003 - - C Knob,top valve ,bisque ,(4)
40 316204920 A - - Panel,manifold ,white
40 316204921 - B - Panel,manifold ,black
40 316204922 - - C Panel,manifold ,bisque
42 316236601 A - C Trim,extrusion ,chrome
42 316236600 - B - Trim,extrusion ,black
56 316230701 A B C Shield,backguard ,inner
* 316021108 A B C Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021109 A B C Screw,8-18 x 0.5 ,chrome
* 316021110 A B C Screw,8-18 x 0.5 ,black

02/02 4
BURNER

GLGF388A Publication No.
5995366993
BURNER
A = GLGF388A (GLGF388ASC)
B = GLGF388A (GLGF388ABC)
C = GLGF388A (GLGF388AQC)
POS. NO PART NO DESCRIPTION
1 # 316204000 A B C Pipe,manifold
2 # 5303935210 A B C Valve,12K top burner ,w/mtg screw
2A # 5303935211 A B C Valve,14K top burner ,w/mtg screw
2B # 5303935212 A B C Valve,5K top burner ,w/mtg screw
2C # 5303935213 A B C Valve,9.5K top burner ,w/mtg screw
* 316134300 A B C Screw,10-24 ,valve mounting
3 # 316219000 A B C Wiring Harness,w/igntr switch
8 # 316135701 A B C Module,spark
10 # 316212300 A B C Burner,sealed ,12K
10A# 316212500 A B C Burner,sealed ,14K
10B# 316206400 A B C Burner,sealed ,5K
10C# 316212400 A B C Burner,sealed ,9.5K
11 # 316237702 A B C Ignitor/orifice assy.,top burner ,rear ,12K,w/holder ,tube
11A# 316237802 A B C Ignitor/orifice assy.,top burner ,front ,14K,w/holder ,tube
11B# 316237700 A B C Ignitor/orifice assy.,top burner ,rear ,5K,w/holder ,tube
11C# 316237800 A B C Ignitor/orifice assy.,top burner ,front ,9.5K,w/holder ,tube
13 # 316207000 A B C Tube,3/8 ,aluminum ,rgltr to manf ,with fittings
14 # 316091706 A B C Regulator,pressure
14* 316021104 A B C Screw,hex ,8-18 x 3/8 ,nick ,(3) ,regulator brkt
15 316091600 A B C Bracket,regulator
16 # 316065003 A B C Tube,valve to regul. ,3/8
17 # 5303208499 A B C Valve,safety ,dual
17* 08068018 A B C Shield,wire ,safety valve
18 # 3131290 A B C Burner,oven
19 # 5303935066 A B C Ignitor,oven kit ,w/nut & instr
20 3131284 A B C Baffle,oven burner
21 5303013272 A B C Nut,hex head sems
22 # 316065002 A B C Tube,valve to mixer
23 # 08067935 A B C Burner,broiler
24 # 316070400 A B C Elbow,mixer
24* 316113400 A B C Spacer,mixer elbow
25 5303210379 A B C Baffle,broiler
26 # 316119302 A B C Ignitor,broiler
37 316240600 A B C Screw,assy mtg ,ignitor/orifice
44 316237901 A B C Orifice,top burner ,12K
44A 316237900 A B C Orifice,top burner ,14K
44B 316237903 A B C Orifice,top burner ,5K
44C 316237902 A B C Orifice,top burner ,9.5K
47 GRLP1 A B C LP Conversion Kit,w/instructions
47* 316248105 A B C Instructions,LP kit
* # 316253700 A B C Wiring Harness,ignitor module
* 5303271648 A B C Screw,wafer hd sq dr ,8-18AB x 0.5

02/02 6
BODY

GLGF388A Publication No.
5995366993
BODY
A = GLGF388A (GLGF388ASC)
B = GLGF388A (GLGF388ABC)
C = GLGF388A (GLGF388AQC)
POS. NO PART NO DESCRIPTION
1 316029416 A B C Panel,main back
2 3131314 A B C Shield,oven top
3 316230102 A - - Panel,bodyside ,white ,RH
3 316230103 A - - Panel,bodyside ,white ,LH
3 316230104 - B - Panel,bodyside ,black ,RH
3 316230105 - B - Panel,bodyside ,black ,LH
3 316230108 - - C Panel,bodyside ,bisque ,RH
3 316230109 - - C Panel,bodyside ,bisque ,LH
4 316201402 A B C Burner Box
5 316129200 A B C Screw,leveling ,plastic ,with stop
6 316067902 A B C Rack,oven
6A 316085400 A B C Rack,broiler pan
7 316212900 A B C Hinge,oven door ,RH
7A 316212901 A B C Hinge,oven door ,LH
8 5303300701 A B C Panel,oven bottom
9 316081900 A B C Pan,broiler
10 316082000 A B C Insert,broiler pan
12 # 316027700 A B C Switch,oven light/door
13 316238800 A B C Rod,light switch
14 316116400 A B C Receptacle,oven light
15 5303013071 A B C Bulb/Lamp,oven light
16 08011086 A B C Lens,oven light ,glass
17 316087500 A B C Retainer,lens
18 # 316213900 A B C Latch,oven door
21 3014099 A B C Spacer,bodyside
25A 5303288580 A B C Shield,heat ,lower
28 3011813 A B C Clip,wire ,bodyside
29 3051162 A B C Glide,drawer ,front
30 316217700 A B C Bracket,hinge ,RH ,main top
30A 316217701 A B C Bracket,hinge ,LH ,main top
33 316232800 A B C Shield,rear wall
35 316116600 A B C Gasket,flue
36 316133002 A B C Flue
37 # 316233900 A B C Probe,oven temp
38 316051700 A B C Shield,heat
39 # 3131425 A B C Cord,electric power
40 3200836 A B C Shield,heat baffle
40* 5303288570 A B C Screw,hd shldr sqdr ,8-18 X 1/2 ,heat shield
41 316233400 A B C Cover,hinge cutout ,RH
41A 316233500 A B C Cover,hinge cutout ,LH
42 5303288578 A B C Shield,bake burner
43 3131732 A B C Screw,8-18 x 1.438 ,oven bottom
44 316246500 A B C Spacer,oven door
49 316234200 A B C Clip,maintop mtg ,(2)
53 5303288579 A B C Shield,main front
53A 08067992 A B C Shield,insulation ,front frame
53B 316211100 A B C Bracket,air dam
55 316107800 A B C Shield,flue
58A 316047705 A B C Insulation,oven wrapper
58B 316218303 A B C Insulation,oven back
58G 08067973 A B C Insulation,main front
72 316234500 A B C Cover,rod end ,light switch
88 316232700 A B C Rod,auto latch
89 # 316135202 A B C Motor,latch/lock
106 316026600 A B C Bracket,motor mtg
107 316026701 A B C Cover,fan
108# 316234601 A B C Motor,fan
109 316136400 A B C Blade,fan
110 316136500 A B C Washer,fan motor
111 316136600 A B C Nut,fan retainer
151 316239300 A B C Shield,bodyside
161# 316211603 A B C Element,convection fan ,350 W

02/02 8
BODY

GLGF388A Publication No.
5995366993
BODY
A = GLGF388A (GLGF388ASC)
B = GLGF388A (GLGF388ABC)
C = GLGF388A (GLGF388AQC)
POS. NO PART NO DESCRIPTION
170 5303935180 A B C Anti-tip Kit,w/bracket,screw
170* 316107200 A B C Bracket,anti-tip
170* 316112500 A B C Template,anti-tip
170* 316116000 A B C Screw,concrete tpg ,1.75 inch ,anti-tip brkt
* # 316253404 A B C Wiring Harness,main
* 5303305324 A - - Paint,touch-up ,white
* 5303305345 - B - Paint,touch-up ,black
* 5304414035 - - C Paint,touch-up ,bisque
* 316021108 A B C Screw,cup pt ,8-18 x 0.375 ,chrome
* 5303280311 A B C Screw,wafer hd sq dr ,10-32 x 0.312
* 5303285179 A B C Screw,wafer head ,8-32T x 0.500 ,black
* 5303271648 A B C Screw,wafer hd sq dr ,8-18AB x 0.5

02/02 10
TOP/DRAWER

GLGF388A Publication No.
5995366993
TOP/DRAWER
A = GLGF388A (GLGF388ASC)
B = GLGF388A (GLGF388ABC)
C = GLGF388A (GLGF388AQC)
POS. NO PART NO DESCRIPTION
1 316011503 A B C Drawer
2 316231400 A B C Liner,drawer
4 316231205 A - - Panel,drawer ,white
4 316231206 - B - Panel,drawer ,black
4 316231209 - - C Panel,drawer ,bisque
7 3051163 A B C Glide,drawer ,rear
16 316202327 A - - Main Top,white
16 316202326 - B - Main Top,black
16 316202329 - - C Main Top,bisque
20 316248501 A - - Grate,gray ,(4)
20 316248500 - B - Grate,black ,(4)
20 316248503 - - C Grate,brown ,(4)
20A 316239801 A - - Grate,gray ,center
20A 316239800 - B - Grate,black ,center
20A 316239803 - - C Grate,brown ,center
22 316213601 A - - Cap,12K burner ,gray
22 316213600 - B - Cap,12K burner ,black
22 316213603 - - C Cap,12K burner ,brown
22A 316213701 A - - Cap,14K burner ,grey
22A 316213700 - B - Cap,14K burner ,black
22A 316213703 - - C Cap,14K burner ,brown
22B 316206601 A - - Cap,5K burner ,gray
22B 316206600 - B - Cap,5K burner ,black
22B 316206602 - - C Cap,5K burner ,brown
22C 316213501 A - - Cap,9.5K burner ,gray
22C 316213500 - B - Cap,9.5K burner ,black
22C 316213503 - - C Cap,9.5K burner ,brown
88 316099500 A B C Pin,guide ,(2)
* 316021108 A B C Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021110 A B C Screw,8-18 x 0.5 ,black
* 5303280311 A B C Screw,wafer hd sq dr ,10-32 x 0.312

02/02 12
DOOR

GLGF388A Publication No.
5995366993
DOOR
A = GLGF388A (GLGF388ASC)
B = GLGF388A (GLGF388ABC)
C = GLGF388A (GLGF388AQC)
POS. NO PART NO DESCRIPTION
3 5303935192 A - - Trim kit-door,3 sided ,white ,w/tape and foil
3 5303935191 - B - Trim kit-door,3 sided ,black ,w/tape and foil
3 5303935193 - - C Trim kit-door,3 sided ,bisque ,w/tape and foil
4 5303935201 A - - Glass,door kit ,white ,outer ,w/foil tape
4 5303935200 - B - Glass,door kit ,black ,outer ,w/foil tape
4 5303935202 - - C Glass,door kit ,bisque ,outer ,w/foil tape
5 316237000 A B C Glass,oven door ,heat barrier
6 316222707 A B C Shield,wool ,oven door
7 316236700 A B C Insulation,oven door
8 316237100 A B C Glass,oven door ,clear ,inner
9 316230605 A B C Liner,oven door
10 316001013 A B C Screw,wafer head ,10-24 X 1.375 ,handle mtg.
10* 316001016 A B C Screw,handle mtg ,10-12 X .750
10B 316008401 A B C Washer,3/4 OD x 1/4 ID ,steel
12 316230900 A B C Seal,oven door
14 316102207 A - C Foil,1.5" x 29" ,aluminum ,clear
14 316102208 - B - Foil,1.5" x 29" ,aluminum ,black
14A 316102202 A - C Foil,4" x 5.5" ,aluminum ,clear ,(2)
14A 316102205 - B - Foil,4" x 5.5" ,aluminum ,black ,(2)
15 316237201 A B C Bracket,glass support ,(2)
16 316117501 A B C Glass,oven door ,heat barrier
17 316117701 A B C Spacer,door glass ,(2)
39 316203001 A - - Handle,door ,white
39 316203000 - B - Handle,door ,black
39 316203003 - - C Handle,door ,bisque
52 316201003 A - - Cap,door trim ,white
52 316201005 - B - Cap,door trim ,black
52 316201007 - - C Cap,door trim ,bisque
60B 5303271648 A B C Screw,wafer hd sq dr ,8-18AB x 0.5
* 316065306 A B C Plate,warning/caution
* 3203618 A B C Rivet,pop
* 316021109 A B C Screw,8-18 x 0.5 ,chrome
* 316021110 A B C Screw,8-18 x 0.5 ,black
* 5303280311 A B C Screw,wafer hd sq dr ,10-32 x 0.312
* 5303285179 A B C Screw,wafer head ,8-32T x 0.500 ,black

02/02 14

GLGF388A Publication No.
5995366993
