Frigidaire GLGFS75D User manual

FGFL79D.eps T24G0013.eps T24B0004.eps T24V0026.eps T24T0026.eps T24D0005.eps
316417814d.eps 316417814s.eps
Product No. GLGFS75DBA GLGFS75DQA GLGFS75DSA
Series 30" f/s gas 30" f/s gas 30" f/s gas
Color black bisque white
Market North America North America North America
Wiring Diagram 316417814 316417814 316417814
Owner's Guide 316417100 316417100 316417100
Installation Instructions 316259336 316259336 316259336
Service Data Sheet 316417605 316417605 316417605
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995420238
04/10/28
(EN/SERVICE/ECL)
369
30-INCH FREE-
STANDING GAS
RANGE
Model No.
GLGFS75D
Copyright ©2004 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995420238 GLGFS75D
10/04 2
BACKGUARD

GLGFS75D Publication No: 5995420238
# Functional Parts 3 10/04
* Non-Illustrated Parts
BACKGUARD
Model Index: AGLGFS75D (GLGFS75DSA)
BGLGFS75D (GLGFS75DBA)
CGLGFS75D (GLGFS75DQA)
POS. NO PART NO. DESCRIPTION
1 316416100 A B C Shield, backguard, rear wall
2 316051600 A B C Shield, backguard, inner
2A 316235100 A B C Shield, top, inner
14 316022500 A B C Light/Lamp, indicator, 125 V
15 316411403 A - - Support, backguard, white, RH
15 316411405 - B - Support, backguard, black, RH
15 316411407 - - C Support, backguard, bisque, RH
15A 316411402 A - - Support, backguard, white, LH
15A 316411404 - B - Support, backguard, black, LH
15A 316411406 - - C Support, backguard, bisque, LH
19 316424191 A - - Panel, control, white
19 316424192 - B - Panel, control, black
19 316424193 - - C Panel, control, bisque
20 # 316418203 A B C Clock/Timer, electronic, ES300
20A 316419104 A - - Overlay, clock, white, ES300
20A 316419103 - B - Overlay, clock, black, ES300
20A 316419105 - - C Overlay, clock, bisque, ES300
24 316246000 A - - Switch, rocker, white, oven light
24 # 316246001 - B - Switch, rocker, black, oven light
24 316246002 - - C Switch, rocker, bisque, oven light
24C# 316114000 A - - Switch, speed bake, white
24C# 316114002 - B - Switch, speed bake, black
24C# 316114004 - - C Switch, convection, bisque
36 316220000 A - - Knob, top valve, white, (4)
36 316220002 - B - Knob, top valve, black, (4)
36 316220003 - - C Knob, top valve, bisque, (4)
40 316204920 A - - Panel, manifold, white
40 316204921 - B - Panel, manifold, black
40 316204922 - - C Panel, manifold, bisque
42 316416201 A - - Trim, extrusion, gray
42 316416200 - B - Trim, extrusion, black
42 316416202 - - C Trim, extrusion, tan
46 316040201 A B C Lens, indicator light, red
56 316230701 A B C Shield, backguard, inner
* 316021105 A B C Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 A B C Screw, cup pt, 8-18 x 0.375, chrome
* 316021109 A B C Screw, 8-18 x 0.5, chrome
* 316021110 A B C Screw, 8-18 x 0.5, black

Publication No: 5995420238 GLGFS75D
10/04 4
BURNER

GLGFS75D Publication No: 5995420238
# Functional Parts 5 10/04
* Non-Illustrated Parts
BURNER
Model Index: AGLGFS75D (GLGFS75DSA)
BGLGFS75D (GLGFS75DBA)
CGLGFS75D (GLGFS75DQA)
POS. NO PART NO. DESCRIPTION
1 # 316219500 A B C Pipe, manifold
2 # 5303935236 A B C Valve, 14K burner, w/mtg screw
2A # 5303935235 A B C Valve, 5K burner, w/mtg screw
2B # 5303935232 A B C Valve, 9.5k/12k burner, w/mtg screw
2C # 5303935234 A B C Valve, 9.5K burner, w/mtg screw
* 316215600 A B C Screw, valve mtg., 1/4 - 20
3 # 316219004 A B C Wiring Harness, w/igntr switch
8 # 316135701 A B C Module, spark
10 # 316223400 A B C Burner, sealed, 14K
10A# 316206400 A B C Burner, sealed, 5K
10B# 316212300 A B C Burner, sealed, 12K
10C# 316212400 A B C Burner, sealed, 9.5K
11 # 316272000 A B C Ignitor/orifice assy., top burner, front, 14K, w/holder, tube
11A# 316237700 A B C Ignitor/orifice assy., top burner, rear, 5K, w/holder, tube
11B# 316237702 A B C Ignitor/orifice assy., top burner, rear, 12K, w/holder, tube
11C# 316237800 A B C Ignitor/orifice assy., top burner, front, 9.5K, w/holder, tube
13 # 316405300 A B C Tube, 3/8, aluminum, rgltr to manf, with fittings
14 # 316091706 A B C Regulator, pressure
14* 316021104 A B C Screw, hex, 8-18 x 3/8, nick, (3), regulator brkt
15 316091600 A B C Bracket, regulator
16 # 316405500 A B C Tube, valve to regul., 3/8
17 # 316404900 A B C Valve, safety
17* 08068018 A B C Shield, wire, safety valve
18 # 316404400 A B C Burner, oven
19 # 316428500 A B C Ignitor, oven burner
20 316401401 A B C Baffle, oven burner
21 5303013272 A B C Nut, hex head sems
22 # 316405400 A B C Tube, valve to mixer
23 # 316404300 A B C Burner, broiler
24 # 316409700 A B C Elbow, mixer
25 316401301 A B C Baffle, broil burner
26 # 316428600 A B C Ignitor, burner
26* 316401500 A B C Cover, broil Ignitor
37 316240600 A B C Screw, assy mtg, ignitor/orifice
44 316237900 A B C Orifice, top burner, 14K
44A 316237903 A B C Orifice, top burner, 5K
44B 316237901 A B C Orifice, top burner, 12K
44C 316237902 A B C Orifice, top burner, 9.5K
47 GRLP2 A B C LP Conversion Kit, w/instructions
47* 316248105 A B C Instructions, LP kit
* # 316253700 A B C Wiring Harness, ignitor module
* 5303271648 A B C Screw, wafer hd sq dr, 8-18AB x 0.5

Publication No: 5995420238 GLGFS75D
10/04 6
BODY

GLGFS75D Publication No: 5995420238
# Functional Parts 7 10/04
* Non-Illustrated Parts
BODY
Model Index: AGLGFS75D (GLGFS75DSA)
BGLGFS75D (GLGFS75DBA)
CGLGFS75D (GLGFS75DQA)
POS. NO PART NO. DESCRIPTION
1 316401601 A B C Back, main
2 316402201 A B C Shield, oven top
2* 316437100 A B C Brace, oven top
3 316400102 A - - Panel, bodyside, white, RH
3 316400103 A - - Panel, bodyside, white, LH
3 316400104 - B - Panel, bodyside, black, RH
3 316400105 - B - Panel, bodyside, black, LH
3 316400106 - - C Panel, bodyside, bisque, RH
3 316400107 - - C Panel, bodyside, bisque, LH
4 316201403 A B C Burner Box
5 316272900 A B C Screw, leveling, plastic, rear, (2)
5A 316407200 A B C Leveling Leg Assy, metal, front, (2), bracket & leg
6 316404500 A B C Rack, oven
8 316400603 A B C Panel, oven bottom
12 # 316407101 A B C Switch, oven light/door
14 316116400 A B C Receptacle, oven light
15 5303013071 A B C Bulb/Lamp, oven light
16 08011086 A B C Lens, oven light, glass
17 316087500 A B C Retainer, lens
18 # 316405800 A B C Latch Assembly, oven door
21 316408000 A B C Clip, bodyside
25 316406200 A B C Shield, heat, lower
29 316407301 A B C Glide, drawer, front
30 316217700 A B C Bracket, hinge, RH, main top
30A 316217701 A B C Bracket, hinge, LH, main top
33 316402500 A B C Shield, rear wall
35 316116600 A B C Gasket, flue
36 316208901 A B C Flue
37 # 316217001 A B C Probe, oven temp
39 3202006 A B C Cord, electric power
42 316400703 A B C Shield, wool, lower
43 3131732 A B C Screw, 8-18 x 1.438, oven bottom
44 316246501 A B C Spacer, oven door
49 316234200 A B C Clip, maintop mtg, (2)
54 316404200 A B C Shield, heat
55 316404800 A B C Shield, flue
58A 316403700 A B C Insulation, oven wrapper
58B 316403600 A B C Insulation, oven back
58G 08067973 A B C Insulation, main front
82 316400801 A B C Shield, bake burner
82* 316432800 A B C Clip, wire
86 316407000 A B C Receptacle, hinge
86* 316418901 A B C Screw, trilobe, 10-32 x 5/16"
87 316401200 A B C Bracket, harness
88 316232700 A B C Rod, auto latch
89 # 316415400 A B C Motor, latch/lock
90 316401100 A B C Shield, main front
91 316401000 A B C Shield, front, burner

Publication No: 5995420238 GLGFS75D
10/04 8
BODY

GLGFS75D Publication No: 5995420238
# Functional Parts 9 10/04
* Non-Illustrated Parts
BODY
Model Index: AGLGFS75D (GLGFS75DSA)
BGLGFS75D (GLGFS75DBA)
CGLGFS75D (GLGFS75DQA)
POS. NO PART NO. DESCRIPTION
106 316404100 A B C Bracket, motor mtg.
107 316026701 A B C Cover, fan
108# 316415700 A B C Motor, convection
109 316136400 A B C Blade, fan
110 316136500 A B C Washer, fan motor
111 316136600 A B C Nut, fan retainer
151 316404600 A B C Shield, bodyside
170 5303935180 A B C Anti-tip Kit, w/bracket, screw
170* 316107200 A B C Bracket, anti-tip
170* 316112500 A B C Template, anti-tip
170* 316116000 A B C Screw, concrete, 1.75", anti-tip brkt
264 316404700 A B C Bracket, air dam
* 316416601 A B C Harness, wiring, main
* 316231800 A B C Cover, hole, conv. element
* 5303305324 A - - Paint, touch-up, white
* 5303305345 - B - Paint, touch-up, black
* 5304414035 - - C Paint, touch-up, bisque
* 316021105 A B C Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 A B C Screw, cup pt, 8-18 x 0.375, chrome
* 316021110 A B C Screw, 8-18 x 0.5, black
* 316021132 A B C Screw, 8-18 X 11/16, black
* 316089500 A B C Screw, 10-16 x .486
* 5303271648 A B C Screw, wafer hd sq dr, 8-18AB x 0.5
* 5303285179 A B C Screw, wafer head, 8-32T x 0.500, black
