Signature Features
Store-More™ Capacity
Our large capacity refrigerator gives you
room to store more.
Store-More™ Gallon
Door Shelf
Door storage gives you room for larger
items like a gallon of milk.
Store-More™ Humidity-
Controlled Crisper Drawers
Keep your fruits and vegetables fresh in
our humidity-controlled crisper drawers.
21 Cu. Ft. Top Mount
SpaceWise™ Adjustable
Glass Shelves
Easily adjust shelves up and down to
create more space for taller items.
Product Dimensions
Height 69"
(Including Hinges & Rollers)
Width 30"
Depth (Including Door) 31-3/4"
More Easy-To-Use Features
Full-Width Freezer Shelf
Gives you more usable space to organize
and store more.
Full-Width Freezer Racks
Gives you more usable door space for
accessibility.
Bright Lighting
Our bright lighting makes it easy to see
what’s inside.
Cool Zone™ Drawer
Conveniently located in the fresh food
section, the Cool Zone™ Drawer is ideal for
deli meats, cheeses and sandwich fixings
or any food items that are frequently used.
Clear Dairy Door
Reversible Door
Door can be installed to open left or right
based on your needs.
ENERGY STAR®
Available in:
Top Mount Refrigerators
FFHT2117L W / B
White
(W)
Black
(B)

Top Mount Refrigerators
Frigidaire Baseline
Specifications
subject to change.
Product Dimensions
A - Height (Incl. Hinges and Rollers)
B - Width
C - Depth (Incl. Door)
Depth with Door Open 90˚
69"
30"
31-3/4"
60"
NOTE: For planning purposes only. Always consult local and national
electric and plumbing codes. Refer to Product Installation Guide for
detailed installation instructions on the web at frigidaire.com.
Accessories information available
on the web at frigidaire.com
1For use on adequately wired 120V, dedicated circuit having 2-wire service
with a separate ground wire. Appliance must be grounded for safe
operation.
Features
Door Design
Door Handle Design
Cabinet Finish (Textured)
Door Stops
Door Hinge Covers
Door Reverse Option
Left-Swing Door
Rollers – Front / Rear
Sound Package
Toe Grille
Refrigerator Features
Interior Lighting
Refrigerator Shelves
Cool Zone™ Drawer
Wine / Can Rack
Store-More™ Crisper Drawers
Humidity Controls
Dairy Compartment
Door Bins
Door Racks
Non-Slip Bin Liner
Tall Bottle Retainers
Gallon Door Storage
Freezer Features
Door Bins
Door Racks
Freezer Shelves
Factory Ice Maker w/ Large Ice Bin
Lighting
Certifications
ENERGY STAR®
Specifications
Total Capacity (Cu. Ft.)
Refrigerator Capacity (Cu. Ft.)
Freezer Capacity (Cu. Ft.)
Power Supply Connection Location
Water Inlet Connection Location
Voltage Rating
Connected Load (kW Rating)
@ 120 Volts1
Amps @ 120 Volts
Minimum Circuit Required (Amps)
Shipping Weight (Approx.)
UltraSoft™
Color-Coordinated
Color-Coordinated
Yes
Color-Coordinated
Yes
Adjustable / Yes
Color-Coordinated
Bright
2 Sliding SpaceWise™
Adjustable Glass
Clear
2 Clear
2
Clear Dairy Door
3 Full-Width White
1
2 Full-Width White
1 Full-Width
Optional (PN # IM115)
Yes
20.5
15.27
5.26
Right Bottom Rear
Bottom Right
120V / 60Hz / 15 or 20A
.54
4.5
15
220 Lbs.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FFHT2117L 08/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
Top Mount Refrigerators
FFHT2117L W / B 21 Cu. Ft.
