Frigidaire FRT17G5JS Instruction Manual

Product No. FRT17G5JSB0 FRT17G5JSB1 FRT17G5JSK0 FRT17G5JSK1
Series R134a R134a R134a R134a
Color stainless (RH) stainless (RH) stainless (LH) stainless (LH)
Volts 115 115 115 115
Wiring Diagram 241582401 241582401 241582401 241582401
Owner's Guide 241857201 241857201 241857201 241857201
Market North America North America North America North America
Energy Guide 241615450 241615450 241615450 241615450
Service Data Sheet 241588203 241588203 241588203 241588203
Installation Instructions 240568303 240568303 240568303 240568303
N05L00001.eps N05DAACLA1.eps N05BBAABA16.eps N05SADAHF11.eps
N05CAABAD1.eps W241582401.eps S241582801.eps
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995506416
08/02/06
(EN/SERVICE/KHB)
390
TOP-MOUNT
REFRIGERATOR
Model No.
FRT17G5JS
Copyright ©All rights reserved.

Publication No: 5995506416 FRT17G5JS
02/08 2
DOOR
22
11
12
18
21
37
21
22
22
13A
13
21C
21C
21
37
18
22
1
7
2
N05DAACLA1
15
8
4
48A
48B

FRT17G5JS Publication No: 5995506416
# Functional Parts 3 02/08
* Non-Illustrated Parts
DOOR
Model Index: AFRT17G5JS (FRT17G5JSB0)
BFRT17G5JS (FRT17G5JSB1)
CFRT17G5JS (FRT17G5JSK0)
DFRT17G5JS (FRT17G5JSK1)
POS. NO PART NO. DESCRIPTION
1 # 241872507 A B C D Gasket-frzr door, black, magnetic
2 # 241872510 A B C D Gasket-refr door, black, magnetic
4 240535101 A B C D Rack-door
7 240337712 A B C D Door-dairy
8 240535001 A B C D Rack-door
11 241623311 A B - - Door, frzr, stainless steel, RH
11 241623312 - - C D Door, frzr, stainless steel, LH
12 241808601 A B C D Label-nameplate
13 240312405 A B C D Door Stop, black, refr
13A 240312406 A B C D Door Stop, black, frzr
15 241623414 A B - - Door, refr, stainless steel, RH
15 241623415 - - C D Door, refr, stainless steel, LH
18 218668003 A B C D Handle-door, black
21 240383406 A B C D Screw, truss hd quad, #10-16 x .500, zinc
21C 218252201 A B C D Screw, #8 truss hd, 10-32CA x 0.500
22 240527102 A B C D Bearing-hinge, black
37 215870636 A B C D Trim-handle, 2.47", black, w/satin AL band
37* 218676004 A B C D Band-decorative, satin aluminum, handle trim
48A 240383901 A B C D Bin-door, 2-liter
48B 240383801 A B C D Bin-door, gallon
* 218490901 A B C D Cleaner, stainless steel

Publication No: 5995506416 FRT17G5JS
02/08 4
CABINET

FRT17G5JS Publication No: 5995506416
# Functional Parts 5 02/08
* Non-Illustrated Parts
CABINET
Model Index: AFRT17G5JS (FRT17G5JSB0)
BFRT17G5JS (FRT17G5JSB1)
CFRT17G5JS (FRT17G5JSK0)
DFRT17G5JS (FRT17G5JSK1)
POS. NO PART NO. DESCRIPTION
1 241652301 A B C D Cover-fan
2 240367001 A B C D Knob-damper control
3 5303001028 A B C D Nut, push-on
4 241523701 A B C D Damper-fan cover
5 # 5308000010 A B C D Fan Blade, red, evaporator fan
8 5300157666 A B C D Bushing-motor mtg, (2)
9 5303292396 A B C D Bracket-motor mtg, front
10 241652215 A B C D Cover-evap coil
10* 240568601 A B C D Seal-coil cover
11 5303208309 A B C D Plug-hole, factory test
12 241557601 A B C D Plug-ice maker harness, rectangular
12A 240374401 A B C D Plug-wtr inlet tube, round, 1"
12A* 241586701 A B C D Plug-foam-wtr-inlet, round
13 # 241854301 A B C D Motor-fan
13* 215474201 A B C D Washer, "slinger", nylon, evap fan shaft
13* 218931001 A B C D Clamp-motor wiring, nylon, w/adhesive tape
14 5303292397 A B C D Bracket-motor mtg, rear
21C 218252201 A B C D Screw, #8 truss hd, 10-32CA x 0.500
22 215774918 A B C D Plug-button, black, upr hinge holes
30 240357103 A B C D Bracket, bottom hinge, black
34 240311303 A B C D Washer, hinge, nylon, (2)
35 240357003 A B C D Bracket, center hinge, black
35A 240336803 A B C D Spacer-hinge, center, black
36 240516402 A B C D Pin-center hinge
37 241611303 A B C D Trim-cabinet corner, black, (2)
38 240356901 A B C D Bracket, upper hinge
40 240354404 A B C D Cover-upper hinge, black
41 5308009759 A B C D Grommet, shelf mtg, 1.25", LH, (4)
42 240578902 A B C D Screw, hex head, 1/4-20 x 5/8
43 241559604 A B C D Roller Assy, fixed, front LH
43* 241559603 A B C D Roller Assy, fixed, front RH
56 240516502 A B C D Pin-lower hinge
58 5304456287 A B C D Screw, hex washer head, 8-15A x 0.500
59 240442707 A B C D Screw-#10-32 X 3/4, black
72 240368303 A B C D Grille/Kickplate, black, lower front
81 5304455650 A B C D Screw, hex washer head, 8-15A x 0.625, low profile
82 5304418225 A B C D Roller, compressor base, rear, (2)
83 5304455655 A B C D Rivet, flat head, 1/4 OD x 1-3/4, roller pin
89 241733906 A B C D Cover-access, with label
89* 241500304 A B C D Screw, hex washer head, 8-18AB x 0.625
92 241710601 A B C D Screw, hex washer hd, 1/4 x 7/8, hinge mtg
* 240479601 A B C D Plug, button, cab liner holes
* 5303321321 A B C D Paint, touch-up, black

Publication No: 5995506416 FRT17G5JS
02/08 6
SHELVES
2

FRT17G5JS Publication No: 5995506416
# Functional Parts 7 02/08
* Non-Illustrated Parts
SHELVES
Model Index: AFRT17G5JS (FRT17G5JSB0)
BFRT17G5JS (FRT17G5JSB1)
CFRT17G5JS (FRT17G5JSK0)
DFRT17G5JS (FRT17G5JSK1)
POS. NO PART NO. DESCRIPTION
11 240358004 A B C D Shelf, freezer
12 241542001 A B C D Diffuser, air, top
13 240362601 A B C D Diffuser, air, bottom
14 241554901 A B C D Switch-light/lamp
15 241555401 A B C D Light Bulb
16 241559801 A B C D Socket-light
17 240368001 A B C D ControlBox
17*# 240388701 A B C D Wiring Harness, control box
18 240360801 A B C D Knob, temp control
21 # 5304421256 A B C D Control,temperature
22A 240468201 A B C D Tube, sensor sleeve, 31 inch, plastic, white
23 # 241621501 A B C D Timer-defrost
23* 5304455649 A B C D Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
24 240372401 A B C D Frame, sliding shelf, full width
24A 240372404 A B C D Frame, sliding shelf, full width, w/hanger tabs
25 240364722 A B C D Cover-crisper pan
25B 241613501 A B C D Control-humidity, RH
25C 241613502 A B C D Control-humidity, LH
26 240364503 A B C D Pan, crisper, (2)
29 240357703 A B C D Trim, shelf, front
31 240530811 A B C D Pan-meat, w/o graphics, clear
40 241711224 A B C D shelf-glass
41 240561501 A B C D Trim-shelf, 22.16", rear
42 240530601 A B C D Track, meat pan hanger, LH
42 240530701 A B C D Track, meat pan hanger, RH
81 5304455650 A B C D Screw, hex washer head, 8-15A x 0.625, low profile
123 215005101 A B C D Screw, hanger/rlr mtg, 8-10 x 7/16
* 241615450 A B C D EnergyGuide

Publication No: 5995506416 FRT17G5JS
02/08 8
SYSTEM
17 21
15
20
14
20
16
60
59
61
58
1
34
34
83
44
41
82
83
82
N05CAABAD1
22
23
23
30
32
85
55
4
6
29
25
25
24
24 25
24
26
84
45
57

FRT17G5JS Publication No: 5995506416
# Functional Parts 9 02/08
* Non-Illustrated Parts
SYSTEM
Model Index: AFRT17G5JS (FRT17G5JSB0)
BFRT17G5JS (FRT17G5JSB1)
CFRT17G5JS (FRT17G5JSK0)
DFRT17G5JS (FRT17G5JSK1)
POS. NO PART NO. DESCRIPTION
1 # 241873404 A B C D Condenser
4 218944002 A B C D Drier-filter, R134a System
6 # 241607001 A B C D Harness-wiring, machine compt
6* # 240388701 A B C D Wiring Harness, control box
14 # 240356220 A B C D Heater-defrost
15 # 5303918275 A B C D Evaporator Kit
16 5308000110 A B C D Strap-evap/heater, aluminum, (2)
17 241801302 A B C D Trough-drain
20 241551902 A B C D Insulation Block
21 # 5303918202 A B C D Thermostat-defrost, kit
22 241665605 A B C D Base-compressor
22* 218252201 A B C D Screw, #8 truss hd, 10-32CA x 0.500
23 218513300 A - C - Grommet-compr mtg, (4)
23 241659701 - B - D Grommet, compressor
24 241812301 A B C D Washer-compr mtg
25 216056401 A B C D Clip-compressor mtg
26 241683601 A B C D Pan-defrost
29 # 5303918347 A - C - Compressor Kit
29 # 5303918352 - B - D Compressor Kit
30 # 241707702 A - C - Starter, PTC
30 # 241707705 - B - D Starter-PTC
32 241715901 A - C - Strap-cover
32 216954300 - B - D Clip, controller
34 240405201 A B C D Grommet, rubber, black, cond tube/wire
41 240433204 A B C D Screw, hex washer head, 8-18 x 5/16
44 5304456288 A B C D Clamp-wiring harness, strain relief, galv steel
45 241500304 A B C D Screw, hex washer head, 8-18AB x 0.625
55 218909913 A B C D Capacitor, run, 220 VAC, 15 microfarad
57 240542601 A B C D Clip-wiring harness
58 218897002 A B C D Screw, hex washer head, 8-32 x 0.375
59 241879301 A B C D Shroud-cond fan
59* 240346701 A B C D Tape-foam seal, shroud
59* 240359403 A B C D Screw-fan shroud, (2)
60 # 241696602 A B C D Motor-condenser fan
61 # 240524101 A B C D Fan Blade, galv steel, condenser fan
82 5304418225 A B C D Roller, compressor base, rear, (2)
83 5304455655 A B C D Rivet, flat head, 1/4 OD x 1-3/4, roller pin
84 240500801 A B C D Tube-drain, rubber, lower
85 241844601 A - C - Tube-connector, suction
85 241665801 - B - D Tube-connector, suction
* 240396801 A B C D Clamp, tube/wiring, nylon, black/natural
* # 5303918263 A B C D Heat Exchanger Kit, suction line
* 5303918222 A B C D Hot Tube Repair Kit, service

Publication No: 5995506416 FRT17G5JS
02/08 10
WIRING SCHEMATIC

FRT17G5JS Publication No: 5995506416
# Functional Parts 11 02/08
* Non-Illustrated Parts
WIRING DIAGRAM
