Frigidaire FRT18ISGH User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT18SGHD1 FRT18SGH R134a System almond 115
FRT18SGHW1 FRT18SGH R134a System white 115
FRT18ISGHD1 FRT18ISGH R134a System almond 115
FRT18ISGHW1 FRT18ISGH R134a System white 115
MARKET
North America
Publication No.
5995343208
000908
-EN/SERVICE/KHB
390
REFRIGERATOR
Model No.
FRT18SGH
FRT18ISGH
©2000 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
REFRIGERATOR
WIRING DIAGRAM - #218758400
OWNER’S GUIDE - # 218972200
SERVICE DATA SHEET - # 218758400
101 Masters Blvd.
Anderson, SC 29624

09/00 2
Publication No. FRT18SGH
5995343208 FRT18ISGH
DOOR

# = Fast-moving Parts 3 09/00
* = Non-Illustrated Parts
FRT18SGH Publication No.
FRT18ISGH 5995343208
DOOR
A = FRT18SGH (FRT18SGHD1)
B = FRT18SGH (FRT18SGHW1)
C = FRT18ISGH (FRT18ISGHD1)
D = FRT18ISGH (FRT18ISGHW1)
POS. NO PART NO DESCRIPTION
1 # 215608916 A B C D Gasket-frzr door,white ,magnetic
2 # 218730605 A B C D Gasket-refr door,white ,magnetic
3 218360701 A B C D Panel-inner door,refr
5A 218758602 A B C D Support-door rack,RH/LH
7 5303304569 A B C D Door-dairy, 12.96" wide, clear, no graphics
8 218763638 A B C D Rack-door,22.36" x 2.04"
9 218360101 A B C D Panel-inner door,frzr
10 5303001308 A - C - Plug-button,almond ,hinge brg hole
10 5308000134 - B - D Plug-button,white ,hinge brg hole
11 5303917796 A - C - Panel-frzr door,almond ,with insulation
11 5303917795 - B - D Panel-frzr door,white ,with insulation
12 218425013 A - C - Nameplate Assy,almond
12 218425012 - B - D Nameplate Assy,white
12* 215008614 A - C - • Label-nameplate,almond
12* 215008613 - B - D • Label-nameplate,white
12* 215518000 A B C D • Magnet-nameplate
12* 218364002 A - C - • Frame-nameplate,almond
12* 218364001 - B - D • Frame-nameplate,white
13 218800300 A B C D Door Stop,plated
13A 218249002 A - C - Door Stop,almond ,frzr section
13A 218249001 - B - D Door Stop,white ,frzr section
14 218915702 A - C - Plug-button,almond
14 218915701 - B - D Plug-button,white
14B 218074002 A - C - Plug-button, almond, refr door front, lower
14B 218074001 - B - D Plug-button, white, refr door front, lower
15 5303917798 A - C - Panel-refr door,almond ,w/insul & brace
15 5304418164 - B - D Panel-refr door,white ,w/brace
18 218668002 A - C - Handle-door,almond
18 218668001 - B - D Handle-door,white
21C 218252200 A B C D Screw,#8 truss hd ,10-32CA x 0.500
22 218519300 A B C D Bearing-hinge
37 215870628 A - C - Trim-handle, 2.47", almond, w/gold band
37 215870627 - B - D Trim-handle, 2.47", white, w/gold band
37A 215867090 A - C - Trim-handle, 29.84", almond, lower, w/band & locks
37A 215867089 - B - D Trim-handle, 29.84", white, lower, w/band & locks
37A* 215782300 A B C D • Lock-handle trim,snap-in
37A* 218676003 A B C D • Band-decorative,gold
37A* 218906701 A B C D • Lock-handle trim,stick-on
48 218592324 A B C D Bin-door,2 liter ,with trim
49 218592323 A B C D Bin-door,gallon ,with trim
58 218749600 A B C D Screw,#10 pan hd ,8-18 x .5
* 5303917276 A B C D Insulation-door,fiberglass ,(bulk)

09/00 4
Publication No. FRT18SGH
5995343208 FRT18ISGH
CABINET

# = Fast-moving Parts 5 09/00
* = Non-Illustrated Parts
FRT18SGH Publication No.
FRT18ISGH 5995343208
A = FRT18SGH (FRT18SGHD1)
B = FRT18SGH (FRT18SGHW1)
C = FRT18ISGH (FRT18ISGHD1)
D = FRT18ISGH (FRT18ISGHW1)
POS. NO PART NO DESCRIPTION
1 218672501 A B C D Cover-fan
2 5303307351 A B C D Knob-damper control
3 5303001028 A B C D Nut,push-on
4 218722200 A B C D Damper-fan cover,black
5 # 218649000 A B C D Fan Blade,black
8 5300157666 A B C D Bushing-motor mtg,(2)
9 5303205118 A B C D Bracket-motor mtg,front
10 218985301 A B C D Cover-evap coil
10* 5303209814 A B C D Nut,"U" type ,8-15A ,fan mtr mtg
11 5303208309 A B C D Plug-hole,factory test
12 215079000 A B - - Plug-harness hole,round
12 215079100 A B - - Plug-wtr inlet tube,round
13 # 218878701 A B C D Motor-evap fan
14 5303322992 A B C D Bracket-motor mtg,rear
17 218973201 A B C D Trough-drain
18 215245000 A B C D Support-evap cover,(2)
19 5303001198 A B C D Tube,rubber
22 215774911 A - C - Plug-button,almond ,upr hinge holes
22 215774901 - B - D Plug-button,white ,upr hinge holes
23 5303269702 A B C D Tube-drain,w/seal ring
24 5303207353 A B C D Seal Ring,drain tube
25 215774100 A B C D Spout-drain tube,w/mounting pins
29 5308000007 A B C D Washer,.34 x .62 x .05 ,nylon
29* 5308000186 A B C D Washer,.34 x .62 x .10 ,nylon
30 5303917777 A B C D Bracket-lower hinge,zinc plate
30* 215882300 A B C D Tapping Plate,lower hinge ,(2)
35 218220102 A - C - Bracket-ctr hinge,almond
35 218220101 - B - D Bracket-ctr hinge,light gray
36 218251300 A B C D Pin-center hinge
37 5303321082 A - C - Trim-cabinet corner,almond
37 5303321081 - B - D Trim-cabinet corner,white
38 3206100 A B C D Bracket-upper hinge
40 3206105 A - C - Cover-upper hinge,almond
40 3206101 - B - D Cover-upper hinge,white
41 5303001609 A B C D Grommet, shelf mtg, 0.69", RH
41* 5308009759 A B C D Grommet, shelf mtg, 1.25", LH
42 215880100 A B C D Screw-hinge mtg, hex washer head, 1/4-20 x 0.685,(2)
43 218724000 A B C D Roller Assy,front ,complete
43* 218703002 A B C D • Roller
43* 5308009761 A B C D • Bolt-roller adj
43* 5308009790 A B C D • Spring-roller adj
43* 5308011326 A B C D • Washer,.34 x .62 x .02 ,nylon
44 5303283014 A B C D Roller Assy,metal housing
45 5303001343 A B C D Screw,hex washer head ,8-15A x 0.500
56 218220300 A B C D Pin-lower hinge
59 218188000 A B C D Screw, pan hd, 10-32 x 0.625, hinge/mull, thrd forming
72 218915402 A - C - Grille/Kickplate,almond ,w/fasteners
72 218915401 - B - D Grille/Kickplate,white ,w/fasteners
73 218896804 A B C D Fastener-grille,button ,(2)
78 5303274237 A B C D Screw-bracket, hex wshr hd, 8-32CA x 0.500
81 5308016566 A B C D Screw, hex wshr hd, 8-15A x 0.625, low profile
83 5308000107 A B C D Bracket-connector
92 5303001479 A B C D Screw-hinge mtg,hex hd ,1/4-20 x 0.875
98 215099711 A - C - Plug-button,almond
98 215099701 - B - D Plug-button,white
* 5303305325 A - C - Paint,touch-up ,almond
* 5303305324 - B - D Paint,touch-up ,white
* 5308016571 A B - - Plug-button,cab liner holes
CABINET

09/00 6
Publication No. FRT18SGH
5995343208 FRT18ISGH
SHELVES

# = Fast-moving Parts 7 09/00
* = Non-Illustrated Parts
FRT18SGH Publication No.
FRT18ISGH 5995343208
SHELVES
A = FRT18SGH (FRT18SGHD1)
B = FRT18SGH (FRT18SGHW1)
C = FRT18ISGH (FRT18ISGHD1)
D = FRT18ISGH (FRT18ISGHW1)
POS. NO PART NO DESCRIPTION
1 218874311 A - C - Mullion,almond
1 218874301 - B - D Mullion,white
5 # 218781003 A B C D Heater-mullion
6 218845602 A B C D Tapping Plate,mullion mtg ,(2)
7 218814800 A B C D Panel-top,refr cavity
8 218872903 A B C D Divider,styrofoam ,w/foil tape
8* 218878500 A B C D Wiring Harness,control/divider
9 218814700 A B C D Panel-bottom,frzr cavity
10 215667501 A B - - Tray-ice,plastic
11 5303288242 A B C D Shelf-freezer, fixed/flat, full width, wire
11* 5303299664 A B C D Spacer-shelf
12 218730000 A B C D Deflector-air
12* 5303001449 A B C D Seal-air deflector,foam plastic ,(2)
13 218631001 A B C D Cover-air deflector
14 # 5309918806 A B C D Switch-light/lamp
15 5303001179 A B C D Light Bulb/Lamp,40 W
16A# 218906801 A B C D Socket-light/lamp
17 5304414816 A B C D Control Box
17* 5308016567 A B C D Nut-anchor
18 5303311079 A B C D Knob-temp control
19 # 5303286905 A B C D Switch-energy saver,rocker type
21 5303321453 A B C D Control-temperature
21* 5303001260 A B C D Screw-control mtg, pan hd ,6-32 x 0.250
22A 5303916855 A B C D Tube, sensor sleeve, plastic ,clear
22B 218731104 A B C D Tube, PVC, white, @ air deflector, insulator
23 # 215846605 A B C D Timer-defrost, 60 Hz, 120 V, 10 hour/21 min
23* 5303001259 A B C D Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
24 218770904 A B C D Shelf-"Spill-Safe"
25 215686501 A B C D Cover-crisper pan,with beam
25A 218905811 A B C D Trim-storage pan cvr,w/humidity hole
25B 5303301393 A B C D Control-humidity
26 3206438 A B C D Pan-crisper
28 3201150 A B C D End Cap-shelf,protector ,frzr shelf
31 215742602 A B C D Pan-meat
34 5303212918 A B C D Container-ice
42 218971202 A B C D Hanger-meat pan,LH
42 218971302 A B C D Hanger-meat pan,RH
46 215357609 A B C D Front-crisper pan
47 218498174 A B C D Insert-pan cover,24.60" x 12.75" ,glass
59 218188000 A B C D Screw, pan hd, 10-32 x 0.625, hinge/mull, thrd forming
67 215357813 A B C D Front-meat pan
81 5303001380 A B C D Screw,truss head ,8-10 x 1.625
123 215005100 A B C D Screw-roller/hanger,8-10 x 0.438
145 218660800 A B C D Clip,plastic ,temp sensor mtg ,snap-in
146 218780800 A B C D Tab-hanger mtg,shelf front
147 218780900 A B C D Tab-hanger mtg,shelf rear

09/00 8
Publication No. FRT18SGH
5995343208 FRT18ISGH
SYSTEM

# = Fast-moving Parts 9 09/00
* = Non-Illustrated Parts
FRT18SGH Publication No.
FRT18ISGH 5995343208
SYSTEM
A = FRT18SGH (FRT18SGHD1)
B = FRT18SGH (FRT18SGHW1)
C = FRT18ISGH (FRT18ISGHD1)
D = FRT18ISGH (FRT18ISGHW1)
POS. NO PART NO DESCRIPTION
1 # 218173900 A B C D Condenser
1* 5303208866 A B C D Spacer-cond tube,black
2 5308000296 A B C D Bracket,condenser mtg ,(4)
2* 5308009617 A B C D Washer,ext tooth lock ,#10 ,grounding
4 # 218944001 A B C D Drier-filter,R134a System
5 218878500 A B C D Wiring Harness,control/divider
6 # 215257004 A B C D Wiring Harness,compressor
7 # 5316254901 A B C D Cord-electric power
8 5303001197 A B C D Cover-wiring
13 # 218429306 A B C D Heat Exchanger,suction line
14 # 3206453 A B C D Heater-defrost
15 # 218955901 A B C D Evaporator
16 5308000110 A B C D Strap-evap/heater,aluminum ,(2)
17 218973101 A B C D Insulator-evap
18 5308013648 A B C D Insulation Block,RH
19 5303007287 A B C D Insulation Plug,RH
20 5308017227 A B C D Insulation Block,LH
21 # 218969902 A B C D Thermostat-defrost
22 218802500 A B C D Plate-compr mtg,with rail
23 218254500 A B C D Grommet-compr mtg,(4)
24 5308003633 A B C D Washer-compr mtg
25 5308003596 A B C D Clip-compressor mtg
26 215372500 A B C D Pan-defrost drain
27 5303001348 A B C D Nut-lock,1/4-20 ,drain pan mtg
28 5303916001 A B C D Pan Retainer Kit,Service
29 # 218846902 A B C D Compressor,R134a ,w/o electricals
30 # 218721103 A B C D Starter/Overload Assy
32 218740800 A B C D Clamp,elec cont mtg ,compressor
41 5308000039 A B C D Screw,hex wshr hd, 8-32CA x 0.500, (7), serrated hd
43 5303001199 A B C D Clamp-wiring harness, strain relief, galv steel
44 5308000133 A B C D Clamp, nylon ,.625 ID
45 5303001343 A B C D Screw, hex washer head, 8-15A x 0.500
45* 218843800 A B C D Screw, hex wshr hd, 8-15A x 0.500, wiring clamps
55 218909901 A B C D Capacitor-run,220 VAC ,15 microfarad
* # 3916557 A B C D Hot Tube Repair Kit,Service

09/00 10
Publication No. FRT18ISGH
5995343208
ICE MAKER

# = Fast-moving Parts 11 09/00
* = Non-Illustrated Parts
FRT18ISGH Publication No.
5995343208
ICE MAKER
C = FRT18ISGH (FRT18ISGHD1)
D = FRT18ISGH (FRT18ISGHW1)
POS. NO PART NO DESCRIPTION
1 5303015131 - - C D Tube-water,71" ,valve-to-IM
2 3206348 - - C D Spring,shut-off arm
3 3206299 - - C D Label,ID plate
4 3206301 - - C D Gear
5 3206303 - - C D Plate-mounting
6 3206305 - - C D Screw-ground wire,8-32 x 0.250
7 # 3206306 - - C D Motor-ice maker
8 3206312 - - C D Spacer-hold switch
9 3206313 - - C D Cam
10 3206315 - - C D Clamp
11 # 3206319 - - C D Thermal Cutoff, ice maker, complete assy
12 # 3206349 - - C D Wiring Harness, ice maker, internal, with plug
12* 3206321 - - C D • Connector Plug,wiring harness
13 # 3206322 - - C D Thermostat Assy,ice maker
15 # 3206324 - - C D Switch,(3)
16 3206326 - - C D Support,phenolic
17 # 5303320545 - - C D Mold-ice maker,Radius Cube ,with heater
18 3206328 - - C D Ejector-ice
19 3206330 - - C D Bearing & Inlet
20 5304408581 - - C D Screw,8-32 x 0.375
21 3206332 - - C D Ice Stripper
22 3206333 - - C D Shut-off Arm
23 5304408582 - - C D Screw, 8-32 x 0.875, mold-to-support, (3)
24 3206335 - - C D Lever Arm
25 3206336 - - C D Screw, 8-18 x 0.562, lever arm/sprt
26 3206337 - - C D Screw-thermo/sprt,4-24 x 0.375, (4)
27 3206338 - - C D Screw, 4-40 x 1.000, hold switch mtg, (2)
28 3206339 - - C D Screw-timing stop,4-40 x 0.375
29 3206323 - - C D Screw,4-24 x 0.750 ,(6)
30 3206341 - - C D Screw-timing adj,8-32 x 1.000
31 3206342 - - C D Insulator
32 3206343 - - C D Plate-valve switch
33 5304408583 - - C D Spring-timing adj
34 5304408584 - - C D Screw,plascrew ,#6 ,(3)
35 5304408585 - - C D Screw
36 3206347 - - C D Cover-ice maker
39 # 3206358 - - C D Wiring Harness,icemaker ,external
41 5308000039 - - C D Screw, hex wshr hd, 8-32CA x 0.500, (7), serrated hd
42 5303001193 - - C D Clamp,.50 ID ,steel ,water tube
43 5303001199 - - C D Clamp-wiring harness, strain relief, galv steel
44 5308000133 - - C D Clamp,nylon ,.625 ID
45 5303001343 - - C D Screw,hex washer head ,8-15A x 0.500
48 5308000200 - - C D Nut,7/16-20 ,nylon
49 5303001147 - - C D Plug-harness hole,(2)
52 215456100 - - C D Tube-water,ice mold fill ,elbow
55 218907301 - - C D Valve-water, single solenoid, 50/60 Hz, 105/120 V
59 5303001191 - - C D Sleeve-tube insert
60 218362500 - - C D Screw,hex washer head ,8-18AB x 1.250
61 218721500 - - C D Bracket-leveling,ice maker
62 215230500 - - C D Screw-IM brkt mtg, pan hd phillips, 8-32T x 0.375
64 5303001549 - - C D Clamp,0.31 ID ,steel ,copper wtr line
* 218699501 - - C D Ice Maker, Radius Cube, 115 V, no instl parts
