Frigidaire FRT18QRCD5 User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT18QRCD5 FRT18QRC R134a white 115
FRT18QRCW5 FRT18QRC R134a white 115
Publication No.
5995307203
980515
-EN/SERVICE /JLT
390
REFRIGERATOR
Model No.
FRT18QRCW5
FRT18QRCD5
©1998 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
REFRIGERATOR
WIRING DIAGRAM - # 218758400
OWNER’S GUIDE - # 218613700
SERVICE DATA SHEET - # 218758400
101 Masters Blvd.
Anderson, SC 29624

05/98 2
Publication No. FRT18QRCW5,FRT18QRCD5
5995307203
P05D0420
26
5A
5A
5A
5A
58
9
1
8
8
14A
21C
2
12
10
11
22
13A 14
18
22
14A
14
15
13
21A
14
21C
21C
18
21C 37
21C
7
3
58
58
14B
49
48
49
48
37A
DOOR

# = Fast-moving Parts 3 05/98
* = Non-Illustrated Parts
FRT18QRCW5,FRT18QRCD5 Publication No.
5995307203
DOOR
A = FRT18QRC (FRT18QRCD5)
B = FRT18QRC (FRT18QRCW5)
POS. NO PART NO DESCRIPTION
1 # 215608906 A - Gasket-frzr door,almond ,magnetic
1 # 215608916 - B Gasket-frzr door,white ,magnetic
2 # 218730606 A - Gasket-refr door,almond ,magnetic
2 # 218730605 - B Gasket-refr door,white ,magnetic
3 218360701 A B Panel-inner door,refr
5A 218758601 A B Support-door rack,RH/LH
7 5303308341 A B Door-dairy,12.96" wide
8 218763613 A B Rack-door,(2)
9 218360101 A B Panel-inner door,frzr
10 5303001308 A - Plug-button,almond ,hinge brg hole
10 5308000134 - B Plug-button,white ,hinge brg hole
11 5303917796 A - Panel-frzr door,almond ,with insulation
11 5303917795 - B Panel-frzr door,white ,with insulation
12 218364002 A - Frame-nameplate,almond
12 218364001 - B Frame-nameplate,white
12 218425005 A - Nameplate Assy,almond
12 218425004 - B Nameplate Assy,white
12* 215008608 A - Label-nameplate,almond
12* 215008607 - B Label-nameplate,white
12* 215518000 A B Magnet-nameplate
13 218800300 A B Door Stop,plated
13A 218249002 A - Door Stop,almond ,frzr section
13A 218249001 - B Door Stop,white ,frzr section
14 5308000181 A - Plug-button,almond
14 5308000090 - B Plug-button,white
14A 218110902 A - Plug-button,almond ,refr door front ,upper
14A 218110901 - B Plug-button,white ,refr door front ,upper
14B 218074002 A - Plug-button,almond ,refr door front ,lower
14B 218074001 - B Plug-button,white ,refr door front ,lower
15 5303917798 A - Panel-refr door,almond ,w/insul & brace
15 5303917797 - B Panel-refr door,white ,w/insul & brace
18 218668002 A - Handle-door,almond
18 218668001 - B Handle-door,white
21A 218251900 A B Screw,#8 oval head ,10-32CA x .625 ,cross recessed
21C 218252200 A B Screw,#8 truss hd ,10-32CA x .5
22 218519300 A B Bearing-hinge
26 3204522 A B Container-egg
37 215870620 A - Trim-handle,2.47" ,almond ,w/chrome band
37 215870619 - B Trim-handle,2.47" ,white ,w/chrome band
37A 215867071 A - Trim-handle,29.84" ,almond ,w/band & locks
37A 215867070 - B Trim-handle,29.84" ,white ,w/band & locks
37A* 215940700 A B * Lock-handle trim,stick-on
48 218592310 A B Bin-door,with trim
49 218592306 A B Bin-door,gallon ,with trim
58 218699800 A B Screw,truss head ,8-15A x 0.500
* 5303917276 A B Insulation-door,fiberglass ,(bulk)

05/98 4
Publication No. FRT18QRCW5,FRT18QRCD5
5995307203
CABINET

# = Fast-moving Parts 5 05/98
* = Non-Illustrated Parts
FRT18QRCW5,FRT18QRCD5 Publication No.
5995307203
A = FRT18QRC (FRT18QRCD5)
B = FRT18QRC (FRT18QRCW5)
POS. NO PART NO DESCRIPTION
1 218672501 A B Cover-fan
2 5303307351 A B Knob-damper control
3 5303001028 A B Nut,push-on
4 218722200 A B Damper-fan cover,black
5 # 218649000 A B Fan Blade,black
6 218448302 A - Cover,almond ,lwr hinge hole
6 218448301 - B Cover,white ,lwr hinge hole
8 5300157666 A B Bushing-motor mtg,(2)
9 5303205118 A B Bracket-motor mtg,front
10 3206451 A B Cover-evap coil
10* 5303209814 A B Nut,"U" type ,8-15(A) ,fan mtr mtg
11 5303208309 A B Plug-hole,factory test
12 215079000 A B Plug-harness hole,round
12 215079100 A B Plug-wtr inlet tube,round
13 # 5303310100 A B Motor-evap fan
14 5303322992 A B Bracket-motor mtg,rear
17 218725700 A B Trough-drain
18 215245000 A B Support-evap cover,(2)
19 5303001198 A B Tube,rubber
22 215774911 A - Plug-button,almond ,upr hinge holes
22 215774901 - B Plug-button,white ,upr hinge holes
23 5303269702 A B Tube-drain,w/seal ring
24 5303207353 A B Seal Ring,drain tube
25 215774100 A B Spout-drain tube,w/mounting pins
29 5308000007 A B Washer,.34 x .62 x .05 ,nylon
30 3206136 A B Bracket-lower hinge
30* 215882300 A B Tapping Plate,lower hinge ,(2)
30* 218368500 A B Shim-lower hinge
32 215217703 A - Plug-button,almond ,cabinet base ,(2)
32 215217701 - B Plug-button,white ,cabinet base ,(2)
35 218220102 A - Bracket-ctr hinge,almond
35 218220101 - B Bracket-ctr hinge,light grey
36 218251300 A B Pin-center hinge
37 5303321082 A - Trim-cabinet corner,almond
37 5303321081 - B Trim-cabinet corner,white
38 3206100 A B Bracket-upper hinge
39 5303001037 A B Shim-upper hinge
40 3206105 A - Cover-upper hinge,almond
40 3206101 - B Cover-upper hinge,white
41 5303001609 A B Grommet,shelf/rod mtg ,RH
41* 5308009759 A B Grommet,shelf mtg ,LH
42 215880100 A B Screw-hinge mtg,hex washer head ,1/4-20 x 0.685,(2)
43 218724000 A B Roller Assy,front ,complete
43* 218703002 A B * Roller
43* 5308009761 A B * Bolt-roller adj
43* 5308009790 A B * Spring-roller adj
43* 5308011326 A B * Washer,.34 x .62 x .02 ,nylon
44 5303283014 A B Roller Assy,metal housing
45 5303001343 A B Screw,hex wshr hd ,8-15A x .5 ,spec
47 218233300 A B Channel-shelf mtg,side ,(2)
48 5303292395 A B Channel-shelf mtg,center
49 218362500 A B Screw,hex washer head ,8-18AB x 1-1/4
56 218220300 A B Pin-lower hinge
58 5308002748 A B Screw,hex wshr hd ,8-15A x .5 ,special
59 218188000 A B Screw,pan hd ,10-32 x .625 ,hinge/mullion,thread forming
78 5303274237 A B Screw-bracket,hex wshr hd ,8-32CA x .5
81 5308016566 A B Screw,hex wshr hd ,8-15A x .625 ,low profile
83 5308000107 A B Bracket-connector
92 5303001479 A B Screw-hinge mtg,hex hd ,1/4-20 x .875
98 215099711 A - Plug-button,almond ,ctr hinge hole
98 215099701 - B Plug-button,white ,ctr hinge hole
* 5303305325 A - Paint,touch-up ,almond
* 5303305324 - B Paint,touch-up ,white
CABINET

05/98 6
Publication No. FRT18QRCW5,FRT18QRCD5
5995307203
SHELVES

# = Fast-moving Parts 7 05/98
* = Non-Illustrated Parts
FRT18QRCW5,FRT18QRCD5 Publication No.
5995307203
A = FRT18QRC (FRT18QRCD5)
B = FRT18QRC (FRT18QRCW5)
POS. NO PART NO DESCRIPTION
1 218874311 A - Mullion,almond ,1
1 218874301 - B Mullion,white ,1
5 # 3018900 A B Harness-wiring,control/divider
5 # 218781003 A B Heater-mullion
6 218279800 A B Tapping Plate,mullion mtg ,(2)
7 218814800 A B Top Panel-refr,HASC
7* 5303001380 A B Screw,truss head ,8-10 x 1.750
8 218814600 A B Divider,styrofoam
9 218814700 A B Bottom Panel-frzr
10 215667501 A B Tray-ice,plastic
11 5303288242 A B Shelf-freezer,fixed/flat ,full width ,wire
12 218730000 A B Deflector-air
12* 5303001449 A B Seal-air deflector,foam plastic ,(2)
13 218631001 A B Cover-air deflector
14 # 5309918806 A B Switch-light/lamp
15 5303001179 A B Light Bulb/Lamp,40 W
16A# 5308000815 A B Socket-light/lamp
17 5303321455 A B Control Box
18 5303311079 A B Knob-temp control
19 # 5303286905 A B Switch-energy saver,rocker type
21 # 5303321453 A B Control-temperature
21* 5303001260 A B Screw-control mtg,pan hd ,6-32 x .25
22A* 5303916855 A B Tube,plastic ,clear ,sensor sleeve
22B 218731104 A B Tube,PVC ,white ,@ air deflector ,insulator
23 # 215267800 A B Timer
23* 5303001259 A B Screw-timer mtg,pan hd ,6-20 x .438
25 5303207340 A B Cover-crisper pan,with beam ,less insert
26 3206438 A B Pan-crisper
28 3201150 A B End Cap-shelf,protector ,upper fzr shelf
31 215742602 A B Pan-meat
34 5303212918 A B Container-ice
36 215919160 A B Frame-half shelf,cantilever
37 218830309 A B TRIM-GLASS SHELF,FRONT,37
42 5304404462 A B Hanger-meat pan,LH
42 5304404463 A B Hanger-meat pan,RH
43 218390517 A B Glass-shelf,12.09" x 14.57"
44 215919809 A B Trim-glass shelf,12.13" ,rear
46 215357606 A B Front-crisper pan
47 218390516 A B Insert-pan cover,glass
59 218188000 A B Screw,pan hd ,10-32 x .625 ,hinge/mullion,thread forming
60 218362500 A B Screw,hex washer head ,8-18AB x 1-1/4
61 215781501 A B Shelf-ice tray,wire
67 215357809 A B Front-meat pan
81 5308016566 A B Screw,hex wshr hd ,8-15A x .625 ,low profile
123 215005100 A B Screw-roller/hanger,8-10 x .438
145 218660800 A B Clip,plastic ,temp sensor mtg ,snap-in
SHELVES

05/98 8
Publication No. FRT18QRCW5,FRT18QRCD5
5995307203
SYSTEM

# = Fast-moving Parts 9 05/98
* = Non-Illustrated Parts
FRT18QRCW5,FRT18QRCD5 Publication No.
5995307203
SYSTEMS
A = FRT18QRC (FRT18QRCD5)
B = FRT18QRC (FRT18QRCW5)
POS. NO PART NO DESCRIPTION
1 # 218173900 A B Condenser
2 5308000296 A B Bracket,condenser mtg ,(4)
2* 5308009617 A B Washer,ext tooth lock ,#10
4 # 218541000 A B Drier-filter
5 # 3018900 A B Harness-wiring,control/divider
6 215257004 A B Harness-wiring,compressor
7 # 5316254901 A B Cord-electric power
7* 218843800 A B Screw,hex wshr hd ,#8 14 x 1/2 ,svc cord clamp
8 5303001197 A B Cover-wiring
13 # 218429306 A B Heat Exchanger,suction line
14 # 3206453 A B Heater-defrost
15 # 3206452 A B Evaporator
16 5308000110 A B Strap-evap/heater,aluminum
17 5303207493 A B Insulator-evap,plastic
18 5308013648 A B Insulation Block,RH
19 5303007287 A B Insulation Plug,RH
20 5308017227 A B Insulation Block,LH
21 # 5316269001 A B Thermostat-defrost
22 218802500 A B Plate-compr mtg,with rail
22* 3051070 A B Screw,hex washer head ,10-24 x 7/16 ,special
23 218254500 A B Grommet-compr mtg,(4)
24 5308003633 A B Washer-compr mtg
25 5308003596 A B Clip-compressor mtg
26 215372500 A B Pan-defrost drain
27 5303001348 A B Nut-lock,1/4-20 ,drain pan mtg
28 5303916001 A B Pan Retainer Kit,Service
29 # 218846901 A B Compressor,R134a ,W/O ELECTRICALS
30 # 218721103 A B Starter/Overload Assy
32 218740800 A B Wire-bale
41 5308000039 A B Screw,hex wshr hd ,8-32CA x .5 ,serrated head
43 5303001199 A B Clamp-wiring harness,strain relief ,galv steel
44 5308000133 A B Clamp,nylon ,.75 OD tube
45 5303001343 A B Screw,hex wshr hd ,8-15A x .5 ,spec
45* 5300141713 A B Screw,hex wshr hd ,8-32 x .625 ,spec
45* 5303207328 A B Screw,hex wshr hd ,8-15A x 1
55 # 216236200 A B Capacitor-run
55 # 218719201 A B Capacitor-run
* # 3916557 A B Hot Tube Repair Kit,Service
