Frigidaire FRU17G4JW1 User manual

REFRIGERATOR
Model number
FRU17G4JW1/2/3
©2001 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
REFRIGERATOR
WIRING DIAGRAM - # 216758400
OWNER’S GUIDE - # 216781800
SERVICE DATA SHEET - #216758400
PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRU17G4JW1 FRU17G4JW 134A white 115
FRU17G4JW2 FRU17G4JW 134A white 115
FRU17G4JW3 FRU17G4JW 134A white 115
MARKET
North America
Publication No.
5995360871
011112
-EN/SERVICE /GS
365
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O BOX 212378, AUGUSTA , GA 30917

11/01 2
Publication No FRU17G4JW1/2/3
5995360871
DOOR

# = Fast-moving Parts 3 11/01
* = Non-Illustrated Parts
FRU17G4JW1/2/3 Publication No.
5995360871
DOOR
A = FRU17G4JW (FRU17G4JW1)
B = FRU17G4JW (FRU17G4JW2)
C = FRU17G4JW (FRU17G4JW3)
POS. NO PART NO DESCRIPTION
1 216522309 A B C Gasket-door,white
9 216527815 A - - Panel-inner door,white
9 216527813 - B C Panel-inner door,frzr
11 216526518 A B C Panel-outer door,white
12 240415201 A B C Label-nameplate,white
13 08016354 A B C Door Stop
14 5303313518 A B C Washer,sealing
18 218762701 A B C Handle-door,white
21A 08005520 A B C Screw-door stop mtg,flat hd metric ,4.0 x 0.7-19.7
21C 218252200 A B C Screw,#8 truss hd ,10-32CA x 0.500
22 216443600 A B C Bearing
22A 216503200 A B C Bearing-hinge,btm
26 216524200 A B C Gasket,secondary
27 5303212828 A B C Clip,panel
32 5309950074 A B C Valve-breather
37 215870619 A B C Trim-handle,2.47" ,white ,w/chrome band
62 131420300 A B C Screw,cr truss head ,8-18AB x 0.750
64 216403700 A B C Plug-button,door base
72 216514100 A B C Shelf,tilt out ,wire
73 216513900 A B C End Cap,tiltout ,LH
74 216514000 A B C End Cap,tiltout ,RH
76 216521800 A B C Support psuedo bin,LH
77 216522100 A B C Support psuedo bin,RH
78 216579500 A - - Rack shelf,psuedo ,32
78 216806100 - B C Rack-door,CONTOUR ,(5)
93 5303161215 A B C Screw
* 216722100 A B C Harness-lid/defrost

11/01 4
Publication No FRU17G4JW1/2/3
5995360871
CABINET

# = Fast-moving Parts 5 11/01
* = Non-Illustrated Parts
FRU17G4JW1/2/3 Publication No.
5995360871
A = FRU17G4JW (FRU17G4JW1)
B = FRU17G4JW (FRU17G4JW2)
C = FRU17G4JW (FRU17G4JW3)
POS. NO PART NO DESCRIPTION
3 216503100 A B C Screen-drain
5 # 216325600 A B C Fan Blade
6 216604200 A B C Breaker Kit w/corners
9 216603300 A B C Breaker Kit w/corners,32" ,top or bottom
10 216740900 A B C Pan-drain assy
10A 216710400 A B C Bracket,top drain pan
10B 216710500 A B C Bracket,btm. drain pan
13 # 216690400 A B C Motor-fan
14 216472300 A - - Switch-light plunger
14 216822900 - B C Light/Lamp,ramp
15 # 216608600 A B C Lamp,light bulb ,40 W ,120 V
16 # 216688600 A B C Socket-light/lamp
18 216807900 A B C Knob-control
19 216204900 A B C Gasket,evap cover
20 216230300 A B C Cover,temp control
21 # 216759100 A B C Control temperature
22 216823500 A B C Clamp,cap tube ,cold control
22A 5303916855 A B C Tube,sensor sleeve ,plastic ,clear
24 5300052943 A B C Screw-clamp,truss hd cr ,control
25 216737100 A B C Cover-evaporator
26 216503300 A B C Ramp,closer ,door
27 5303205738 A B C Screw-hinge,cr ,1/4-20 x 1.000 ,btm
28 216247400 A B C Hinge-bottom
29 216313503 A B C Hose-drain
31 216732400 A B C Pan-drain
32 5308005500 A B C Drain
34 216557600 A B - Shield-light
34 216816200 - - C Shield-light
35 216273000 A B C Clip,drain hose
38 5303925086 A B - Hinge-upper
38 216808900 - - C Hinge-upper
39 5303294372 A B C Nut-insert,hinge
40 5303212912 A B - Cover-hinge
40 216809000 - - C Cover-hinge
41 5303212937 A B - Screw-top hinge
41 5303001479 - - C Screw-hinge mtg,hex hd ,1/4-20 x 0.875
42 216781700 A B C Glass-,fixed ,full width
42A 216458200 A B C Shelf,12.50x27.88 ,white
47 216661601 A B C Baffle-plate
50 216394000 A B C Bracket-motor mtg fan
59 216372800 A B C Basket,(2)
60 5303212693 A B C Slide-basket
62 131420300 A B C Screw,cr truss head ,8-18AB x 0.750
63 216396900 A B C Foot-adjustable
69 5305878546 A B C Bumper-basket
71A 216347500 A B C Screw,quadrex
72 216174000 A B C Grille/Kickplate,white
79 3017666 A B C Nut-insert
80 06594601 A B C Bracket,control
93 5303161215 A B C Screw
93A 5303302760 A B C Screw
101 216835200 - - C Kit-top hinge
132 5303283898 A B C Screw,6-20AB x 3/8
137A 216781600 A B C Frame,fixed ,full width
138A 216492200 A B C Trim-cantilever/fixed shelf,24.21" ,glass,front ,1
144 216781500 A B C Shelf-assy,fixed,glass ,complete
253 216492300 A B C Trim-cantilever/fixed shelf,24.21" ,rear
* 09948773 A B C Insulation,drain tube
* 216502400 A B C Grommet-shelf mtg
* 216504500 A B C Screw,AB ,8-18x.500
* 216758400 A B C Service Data Sheet
CABINET

11/01 6
Publication No FRU17G4JW1/2/3
5995360871
SYSTEM

# = Fast-moving Parts 7 11/01
* = Non-Illustrated Parts
FRU17G4JW1/2/3 Publication No.
5995360871
SYSTEM
A = FRU17G4JW (FRU17G4JW1)
B = FRU17G4JW (FRU17G4JW2)
C = FRU17G4JW (FRU17G4JW3)
POS. NO PART NO DESCRIPTION
1 # 5300083897 A B C Condenser
2 5308000110 A B C Strap-evap/heater,aluminum ,(2)
4 216634500 A B C Drier-filter
5 # 216722200 A B C Harness-main
5* 216695300 A B C Relay
5* 216703900 A B C Thermostat-heater
14 216730700 A B C Heater-defrost
14A# 216730500 A B C Heater-internal
15 # 216737300 A B C Evaporator
15A 216751100 A B C Heat Exchanger
18 216727600 A B C Insulator-evap,styrofoam
19 216727700 A B C Insulator-evap,styrofoam
20 216731000 A B C Thermostat-defrost
23 216744400 A B C Timer-defrost
24 08016580 A B C Bracket
27 216498900 A B C Grommet,compressor
29 # 216681000 A B C Compressor,w/ electricals
30 216681100 A B C Starter
31 216100118 A B C Overload Protector
34 5306594529 A B C Sleeve-compressor
35 5303272328 A B C Screw,Ind hex sems ,1/4-28 unfx ,compressor
43A 216629700 A B C Clip-harness
53 216347800 A B C Cover terminal,cover-comp term
86 216036600 A B C Screw,rwhd (gx-ca) ,8-32 x 1/2
87 08037849 A B C Screw
130 216730400 A B C Support-evaporator
* 216502500 A B C Sleeve-tube insert
