Frigidaire FHPC4260LS Installation instructions

Signature Features
frigidaire.com
Stainless
(S)
* Ventilation is convertible to be either ducted outside,
or recirculated inside requiring no ducting. (Recirculated
option requires use of optional Duct-Free Kit.)
‡ For use on adequately wired 120V, dedicated circuit having
2-wire service with a separate ground wire. Appliance must be
grounded for safe operation.
NOTE: Always consult local and national electric codes. Check
local building codes for installation requirements, as they may
vary per locale. Refer to Product Installation Guide for detailed
installation instructions on the web at frigidaire.com.
Specifications subject to change.
Available in:
Features
Nominal Width 42"
Installation Type Island / Peninsula
Ceiling
Style Stainless Steel /
Glass Canopy
Air Discharge Vertical
Air Delivery (CFM) 400
Blower Type Centrifugal
Controls Electronic
Push Button
Fan Speeds 3
Sound Level (dBA) 67.1
Quad Halogen Lights Yes
Dishwasher-Safe Filter Yes
Exhaust Duct Convertible*
Duct Required 6" Round
Optional Accessories
Duct-Free Kit PN # FHPRKT60LS
10' Flue Extension Kit PN # FHP10X60LS
Specifications
Product Dimensions –
Height (With One Cover)
(With Flue Extension)
22-29/32" min.
30" min.
42" max
Width 41-7/8"
Depth 23-5/8"
Voltage Rating 120V / 60Hz / 15A
Amps @ 120 Volts 4.0
Connected Load (kW Rating)
@ 120 Volts ‡ 0.52
Shipping Weight (Approx.) 92 Lbs.
Sones Rating 6.5
42" Stainless Steel
Glass Canopy Island Hood
FHPC4260L S
Glass Canopy Design
Glass and stainless steel construction
is as attractive as it is functional.
Centrifugal Fan
Move air quietly and efficiently — up
to 400 cu. ft. of air per minute.
Halogen Lighting
Four halogen lights provide bright
illumination of the cooktop surface on
an island or peninsula application.
Washable Filters
Dishwasher-safe for easy cleaning.
The aluminum filter provides strength
and durability not found in foam
filters.

Accessories information available
on the web at frigidaire.com
Glass Canopy Island Hood
FHPC4260L S 42" Stainless Steel
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FHPC4260L 02/12 © 2012 Electrolux Home Products, Inc.
Specifications
subject to change.
I/P Vent Hood
FHPC4260LS
Glass Canopy Island Hood Specifications
•Product Shipping Weight (approx.) – 92 Lbs.
•Island / Peninsula Ceiling-Mount Installation
•Ventilation system is preset to exhaust air outside. If outside
ducting is not possible, optional Duct-Free Recirculation Kit
(PN # FHPRKT60LS) is available to convert ventilation to allow air
to recirculate inside. (Refer to Ducted Option Specifications for
outside ventilation.)
•Sones Rating – 6.5
•Voltage Rating – 120V / 60 Hz / 15 Amps
•Connected Load (kW Rating) @ 120 Volts = 0.52 kW
(For use on adequately wired 120V, dedicated circuit having 2-wire
service with a separate ground wire. Appliance must be grounded
for safe operation.)
•Amps @ 120 Volts = 4 Amps
•Always consult local and national electric codes. Check local building
codes for installation requirements, as they may vary per locale.
•Minimum installation height allowed from bottom of hood to standard
36"-high electric or gas cooking surface is 24" - 36". (NOT more than
32" recommended.) For detailed instructions regarding install heights
in 8', 9' and 10' ceiling applications, refer to installation guide on web.
•To prepare mounting surface, adequate structure and support must
be provided, capable of supporting 150 lbs.
Ducted Option Specifications
•For outside ventilation.
•Exhaust Duct Required – 6" round
•For most efficient airflow exhaust, use a straight run or as few
elbows as possible.
•Use metallic flex ducting only to connect rigid duct directly to
transitions (if allowed by code).
•Thermal breaks such as short section of nonmetallic duct, should
be used in areas of extreme cold.
•Cold weather installations should have additional backdraft damper
installed.
•Refer to installation instructions on web for detailed exhaust duct
preparation and converting vent blower system for recirculating inside.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at frigidaire.com for detailed instructions.
Pre-Installation Calculations
•Select hood preference height (P) that is comfortable for user
(24" - 36" minimum allowed, NOT more than 32" recommended).
•Calculate hood height (H) for installation (H = K-C-P).
•Confirm that (H) is within minimum to maximum range for hood. If
not, adjust installation.
•Calculate chimney structure height (S). Use formulas, check
dimensions of hood. Save calculation for use later in installation.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at frigidaire.com for detailed instructions.
Optional Accessories
•Duct-Free Recirculation Kit – (PN # FHPRKT60LS).
•10' Flue Extension Kit – (PN # FHP10X60LS).
