Frigidaire PLEW30S3F User manual

PLEW30S3FC.tif B49202401.eps DPLEW30S3DCA.eps 318049901.eps
Product No. PLEW30S3FCA
31257300760S1
Series 30"
Color stainless
Market North America
Wiring Diagram 318049901
Owner's Guide 318201007
Installation Instructions 318201807
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995469060
06/06/28
(EN/SERVICE/ECL)
377
WARMER DRAWER
Model No.
PLEW30S3F
Copyright ©2006 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995469060 PLEW30S3FCA
06/06 2
BODY

PLEW30S3FCA Publication No: 5995469060
# Functional Parts 3 06/06
* Non-Illustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
10 5304437021 Screw, mounting, 8-18 x 0.25, chrome, (2)
13A 316095500 Switch, infinite, warmer
14 5303051533 Light, indicator
19 318281401 Panel, control, black
32 318228100 Strain relief
36 318017600 Knob, warmer
39 318144005 Cord, service
46 5308006417 Lens, indicator lamp, red, (2)
69 5303323134 Screw, 8-32 x 0.188
81 # 318255300 Element, warmer drawer
84 # 318005103 Thermostat, safety
84A# 318005104 Thermostat, safety
86 316095800 Clip, hold down, warmer element
124 318259300 Channel, drawer, RH, outer
124A 318259301 Channel, drawer, LH, outer
185 318014700 Spacer, oven shield, (4)
196 318100100 Cover, access
198 08008009 Bushing, side panel, nylon, RH, snap
201 318145107 Wrapper, outer
202 318121602 Wrapper, lower
203 318025712 Bracket, side panel, RH
203A 318025702 Bracket, side panel, LH
204 318021908 Decorative plate, black
205 318123714 Panel, side, RH
205A 318123704 Panel, side, LH
207 318143601 Panel, wire cover
209 318247401 Bracket, wall
209* 5303302745 Screw, 10-16x1-1/8, square drive
210 318262300 Bracket, front support, (2)
* 318199735 Wiring Harness
* 08067961 Fastener, clip cable
* 5303323140 Screw, ground, 10-32 x 0.375
* 5303211311 Screw, 8 x 0.500

Publication No: 5995469060 PLEW30S3FCA
06/06 4
DRAWER
85
1
13
13A
80
122
10
10
10
39
4
DPLEW30S3DCA

PLEW30S3FCA Publication No: 5995469060
# Functional Parts 5 06/06
* Non-Illustrated Parts
DRAWER
POS. NO PART NO. DESCRIPTION
1 318142500 Drawer, warmer
4 318280706 Panel, drawer front, stainless
10 5303311174 Screw, 10-24 x 3/8
* 5303304015 Washer, padded
13 318259400 Channel, drawer, RH, inner
13A 318259401 Channel, drawer, LH, inner
39 318219802 Handle, door/drawer, stainless
80 318254400 Gasket, warmer drawer
85 318257600 Rack, warmer drawer
122 318281609 Panel, drawer, black, interior
* 5303300265 Screw, 8-18 X 1/2, (2)

Publication No: 5995469060 PLEW30S3FCA
06/06 6
WIRING DIAGRAM
