Frigidaire FAFS4272LA Installation instructions

Front Load Washers
FAFS4272L R / N / A / W
Signature Features
frigidaire.com
Optional SpaceWise™ Pedestal Drawer Shown
10 Wash Cycles
4.2 Cu. Ft.
Product Dimensions
Height 36"
Width 27"
Depth 30-5/16"
More Easy To Use Features
Certified Allergen Cycle
Removes up to 95% of allergens.
Quick Wash
Wash a full load in just 25 minutes.
Quick Laundry
Wash and dry a full load in just
50 minutes.
Energy Saver Option
Further reduces energy use up to 60%.1
SilentDesign™ Ultra
for quiet operation.
Stay-Fresh Antimicrobial Seal
Optional SpaceWise™
Pedestal Drawer
ENERGY STAR®
NSF® International
Certification
Available in:
1Based on a 15.8 lb. load as tested per DOE Protocol
10CFR430, subpart B, App. J, cl.3.1.
Ready Steam™
Ensures cleaner clothes with improved
stain removal.
Vibration Control System
Advanced vibration control technology
keeps even oversized loads balanced
for smooth, quiet operation. Ideal for
second floor installation.
TimeWise™
Wash time equals dry time — so you
don’t wait for clothes to dry.
Fresh Water Rinse
Our Advanced Rinse Technology
reduces the amount of detergents and
additives that may cause allergies.
Classic
White
(W)
Classic
Red
(R)
Classic
Blue
(N)
Classic
Silver
(A)

Front Load Laundry - Washer
Frigidaire Affinity (L models)
BC
A
B
A
C
Front Load Washers
FAFS4272L R / N / A / W 4.2 Cu. Ft.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FAFS4272L 08/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
Specifications
subject to change.
Product Dimensions
A - Height (Single)
Height (Stacked)
B - Width
C - Depth
Depth with Door Open 90˚
Pedestal Dimensions
A - Height
B - Width
C - Depth
36"
71-1/2"
27"
30-5/16"
51-7/16"
15-1/4"
27"
26-1/4"
Features
Total Capacity I.E.C. (Cu. Ft.)
Controls
Washer Drum Interior
Interior Light / Door Trim
Vibration Control System
Wash System
Advanced Rinse Technology
TimeWise™ Technology
Ready Clean™ / Ready Steam™
Freshwater Rinse
Stay-Fresh Antimicrobial Seal
Automatic Temperature Control
Automatic Water Level Adjustments
Auto Prewash Detergent Dispenser
Auto Bleach Dispenser
Auto Detergent Dispenser
Auto Fabric Softener Dispenser
Time Remaining Indicator
Cycle Status Lights
Cycle Signal / Cycle Signal “On/O ”
Cycle Signal Volume Control
Door Lock Indicator Light
Control Lock / Stay-Put Door
Start / Pause / Cancel Buttons
Energy Saver Option
Delay Start
Integral Water Heater
Tumble Speed (RPM)
Spin Speed (Maximum RPM)
Reversible Door
Sound Package
Adjustable Leveling Legs
Cycles
Wash Cycles / Specialty Cycles
Options
Water Temperature Selections
Water Levels
Spin Speed / Soil Level Selections
Allergen
Optional Accessories
Dryer Stacking Kit
15" Frigidaire Anity® Pedestal Drawers
Classic Red (R)
Classic Blue (N)
Classic Silver (A)
Classic Black (B)
Classic White (W)
Mobile Home Installation Kit
Drain Hose Extension Kit
Certifications
ENERGY STAR®
NSF® Certified Sanitize / Allergen
Specifications
Power Supply Connection Location
Water Inlet Connection Location
Voltage Rating
Connected Load (kW Rating) @ 120 Volts1
Watts @ 120 Volts / Amps @ 120 Volts
Minimum Circuit Required (Amps)
Shipping Weight (Approx.)
4.2
Express-Select™
Stainless Steel
Yes / Chrome
Yes
Tumble Action
Yes
Yes
No / Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Chime / Yes
Yes
Yes
Yes / Yes
Yes
Yes
1 to 16 Hours
Yes, 1000 Watts
33 / 47
1200
SilentDesign™ Ultra
Yes
10 / 0
5
Automatic / Max Fill
5 / 5
Yes
PN # STACKIT4X
(R) PN # CFPWD15R
(N) PN # CFPWD15N
(A) PN # CFPWD15A
(W) PN # CFPWD15W
PN # 137067200
PN # 137098000
Yes
Yes / Yes
Right Top Rear
Left Top Rear
120V / 60Hz / 15A
1.4
1,000 / 8
20
222 Lbs.
1For use on adequately wired 120V, dedicated circuit having 2-wire service with
a separate ground wire. Appliance must be grounded for safe operation. Accessories information available
on the web at frigidaire.com
NOTE: For planning purposes only. Always consult local and national
electric and plumbing codes. Refer to Product Installation Guide for
detailed installation instructions on the web at frigidaire.com.
