FROGGYS FOG FFM-SNOW-MAX User manual

1"
SNOW%MACHINE%USER%MANUAL%
Introduction%
Thank you for choosing Froggy’s Fog Snow Machines. Prior to use, we suggest that you carefully read all of the instructions. By
following the suggestions found in this user manual, you can look forward to the reliable and satisfactory performance of your
snow machine for years to come.
I. Specifications:% % % % Figure%A% % % Figure%B% % %
MODEL
FFM-SNOW-MAX
VOLTAGE:
220V/60HZ
POWER:
2500W
TANK CAPACITY (L):
10L / 2.6 Gal
MAX TANK PRESSURE
10 PSI
!
!
!
!
!
Please!follow!these!operation,!safety!and!maintenance!instructions!to!ensure!a!long!and!safe!life!for!your!snow!
machine.!
!
• Remove all packing materials from box and snow machine.
• Route the larger 3/8” tubing from the air compressor (Figure A) to the upper inlet fitting of the stainless fluid reservoir.
• Route the smaller 5/16” tubing from the back of the fluid control valve (Figure B) to the lower fitting on the fluid reservoir.
• Place the fluid reservoir on a level surface with the fill cap facing upwards. Unscrew the reservoir cap and fill with Froggys
Flakes Snow fluid. Stop filling before the fluid reaches the level of the upper air tube and replace cap.
• Plug 220V power cord and the keyed blue machine plug into the DMX Control Unit. Rock the switch position to “I” if DMX
power control is preferred. Adjust the DMX address DIP switches as necessary. Rock the switch to “II” to bypass DMX
control and defer control to the red illuminated power button on the side of the machine. The red illuminated power button on
the side of machine is the main power to the device and must be on position for the DMX control unit to control power to the
Snow Machine.
• The air pressure valve (Figure A) controls the amount of pressure the tank can achieve to push fluid to the machine nozzle.
• The fluid control valve (Figure B) allows a fine tuning of the fluid flow to the nozzle allowing you to control flake size and
quantity of flakes.
• Once you are done using the machine or need to open the fill cap to refill the unit, use the air pressure valve (Figure A) turned
to “O” to relieve any pressure in the system. Before any length of storage allow the machine to run for 10 secs with the
pressure valve (Figure A) set to “0” to allow fluid to fully drain back into the fluid tank.

2"
1. Empty snow fluid from machine.
2. Rinse tank with small amount of distilled water and drain.
3. Partially fill tank with warm distilled water.
4. Clean the sock that may accumulate residue and impede performance, with clear running water.
5. Plug in machine, turn on, then run unit in a well-ventilated area until tank is nearly empty, Unplug and drain left over water.
6. Cleaning is now complete for short-term storage.
7. Long term seasonal storage - After running warm distilled water, run with fresh snow fluid for 5 minutes.
8. Turn off machine and allow it to cool down.
9. Empty tank and wipe machine clean with soft cloth, return machine to original flight case, and store in a cool dry place.
Danger of electric shock
• The unit may be used outside, but it is not waterproof or splash-proof. Keep this device dry and avoid exposure to inclement
weather. If any moisture gets inside the housing, immediately unplug the unit and contact a service technician or your dealer
before using it again.
• Turn off or unplug when not in use. Always unplug your snow machine before filling its tank.
• A properly maintained snow machine should provide years of reliable use.
• For adult operation only. Snow machine must be installed out of the reach of children. Unit should not be ran unattended.
• Never point the nozzle directly at people. Snow machine output can cause a slippery wet spot beneath the machine output.
• Locate the snow machine in a well-ventilated area. Never cover the unit’s vents and provide a free air space around the rear
fan shroud.
• Only specifically designed water based scent additives may be added to the snow fluid. Never add flammable liquids of any
kind (oil, gas, non application specific perfumes) to the snow liquid. Pay attention to all warning labels and instructions
printed on the exterior of your snow machine.
• Use only the high-quality, water-based, Froggys Fog snow fluid. Always make sure there is sufficient liquid in the snow
liquid tank.
• Always empty tank before mailing or transporting this unit.
• Never drink snow liquid. If it is ingested, seek medical guidance immediately. If snow liquid comes in contact with skin or
eyes, rinse thoroughly with water.
• Vapor from this fluid may be irritating to some persons with allergic sensitivity. Do not expose at close range to known
asthmatic. Use in a well-ventilated area.
Save these instructions.

3"
A. Froggy’s Fog® hereby warrants, to the original purchaser, Froggy’s Fog® products to be free of manufacturing defects in
material and workmanship for a period of 1 year (365 days) from the original date of purchase. This warranty shall be valid only if
the product is purchased within the United States of America, including possessions and territories. It is the owner’s responsibility
to establish the date and place of purchase by acceptable evidence, at the time service is sought.
B. For warranty service, please contact us and arrangements will be made for prompt service and an RMA# assigned. All shipping
charges must be pre-paid. If the requested repairs or service (including parts replacement) are within the terms of this warranty,
Froggy’s Fog® will pay return shipping charges only to a designated point within the United States. If any product is sent, it must
be shipped in its original package and packaging material. No accessories should be shipped with the product. If any accessories
are shipped with the product, Froggy’s Fog® shall have no liability what so ever for loss and/or damage to any such accessories,
nor for the safe return thereof.
C. This warranty is void if the available product serial number and/or labels are altered or removed; if the product is modified in
any manner which Froggy’s Fog® concludes, after inspection, affects the reliability of the product; if the product has been repaired
or serviced by anyone other than the Froggy’s Fog® factory unless prior written authorization was issued to purchaser by Froggy’s
Fog®; if the product is damaged because not properly maintained as set forth in the product instructions, guidelines and/or user
manual.
D. This is not a service contract, and this warranty does not include any maintenance, cleaning or periodic check-up. During the
periods as specified above, Froggy’s Fog® will replace defective parts at its expense, and will absorb all expenses for warranty
service and repair labor by reason of defects in material or workmanship. The sole responsibility of Froggy’s Fog® under this
warranty shall be limited to the repair of the product, or replacement thereof, including parts, at the sole discretion of Froggy’s
Fog®.
E. Froggy’s Fog® reserves the right to make changes in design and/or performance improvements upon its products without any
obligation to include these changes in any products theretofore manufactured.
F. No warranty, whether expressed or implied, is given or made with respect to any accessory supplied with the products described
above. Except to the extent prohibited by applicable law, all implied warranties made by Froggy’s Fog® in connection with this
product, including warranties of merchantability or fitness, are limited in duration to the warranty periods set forth above. And no
warranties, whether expressed or implied, including warranties of merchantability or fitness, shall apply to this product after said
periods have expired. The consumer’s and/or dealer’s sole remedy shall be such repair or replacement as is expressly provided
above; and under no circumstances shall Froggy’s Fog® be liable for any loss and/or damage, direct and/or consequential, arising
out of the use of, and/or the inability to use, this product.
G. This warranty is the only written warranty applicable to Froggy’s Fog® products and supersedes all prior warranties and written
descriptions of warranty terms and conditions heretofore published.
PRODUCTS NOT UNDER WARRANTY: Please notify your Froggy’s Fog® service advisor that your product is no longer under
warranty when you request your RMA#. Once the unit has been received, you will be contacted and advised of the cost of carrying
out any repair unless the cost does not exceed $35.00USD, in which case the repair will be performed without seeking your prior
approval. Repaired unit(s) will be shipped back to you upon receipt of payment for all work performed and return freight charges.
All repairs have a 90-day limited warranty, valid from the date the repaired unit is delivered to the shipping agent for return to you,
on replaced parts and repair labor against defects in material and workmanship. The exclusions and limitations set forth in the
original limited warranty apply to the repair warranty. Froggy’s Fog® is not responsible for delays in repairs or shipping. PLEASE
NOTE that it is essential that defective products reach Froggy’s Fog® by no later than the last day of the applicable warranty
period. Warranty claims will not be considered for products received after the expiration of the applicable warranty period.
