FROGGYS FOG Fobbles F4 User manual






1


SPECIFICATIONS

Model HeaterCore CFM Warmuptime
FobblesF4 1400Watts 10,000cfm(Continuous) 6Min

IMPORTANT


DONOTPUTBUBBLEFLUIDINTHEREARFOGFLUIDRESEVOIRBOTTLE.THISWILLDAMAGETHEHEATER
COREANDVOIDTHEWARRANTYOFTHEMACHINE


Themanufacturerwillnotacceptliabilityforanyresultingdamagescausedbythenon‐observanceofthis
manualoranyunauthorizedmodificationtotheequipment.


Donotopentheequipmentanddonotmodifytheequipment. 

Donotexposetoflammablesourcesorgases. 

Alwaysdisconnectthepowerfromequipmentwhennotinuseorbeforecleaning!Onlyhandlethe
power‐cablebytheplug.Neverpullouttheplugbypullingthepower‐ cable.


Makesurethattheavailablevoltageis120VAC. 

Makesurethatthepower‐cableisnevercrimpedordamaged.Checktheequipmentandthepower‐cable
periodically.


Iftheequipmentisdroppedordamaged,disconnectthemainspowersupplyimmediately.Havea
qualifiedengineerinspecttheequipmentbeforeoperatingagain.


Iftheequipmenthasbeenexposedtodrastictemperaturefluctuation(e.g.aftertransportation),donot
switchitonimmediately.Thearisingcondensationmightdamagetheequipment.Leavetheequipment
switchedoffuntilithasreachedroomtemperature.


Onlyusefusesofsametypeandrating. 

Repairs,servicingandpowerconnectionmustonlybecarriedoutbyaqualifiedtechnician. 

THISUNITCONTAINSNOUSERSERVICEABLEPARTS. 


SETUP


Opentheboxtoverifyproductintegrity. Iftheunit’shousingorcableisdamaged,donotplugitinanddo
notattempttouseituntilaftercontactingyourdealerforassistance.


Placefogbubblemachineonalevelflatsurface,removefogliquidreservoircaptowardrearofthemachine.
FillfogfluidreservoirwithFroggysFogBrandFogFluid.Lowerqualityfluidcandamagetheunit. Recap
tank.


Fillbubblereservoiratthefrontwithahigh‐qualitybubblefluid,suchasFroggysFogMaxBubbles.Lesser
qualitybubblefluidscannotwithstandtheincreasedpressureofhotfogandwillburstprematurely.The
bubblesolutioncanbecomedilutedwithfogmoistureovertimeandoccasionallywillneedtobedrained
andrefilledfreshduringuse.


Fobbles F4 -User Manual

2

OPERATION

 Plugthepowercordintoagroundedelectricaloutletandswitchthemainpoweron. 
 StartingOperation
o AfterswitchingonviatheOn/OffswitchthecontrollersLCDscreenwilldisplay“WARMINGUP”.When
theunithasreachedthecorrecttemperature,theLCDdisplaywillshow“READY”andtheunitisnow
readyforoperation
 ManualOutput
o
Formanualoutput,simplypressthe“MANUAL”buttonandholduntilthedesiredamountofoutputis
emitted.

 ConstantBurstOperation
o
Tosetunitforconstantoutput,pressthe“LOCK”button.Tostoptheoutput,simplypressthe“LOCK”
buttonagain.Duringthisoperation,youcanchangethevolumeoutputbypressingthe“UP”and
“DOWN”buttons.

 TimerMode
o
PressthetimerbuttontostarttimerfunctionalityaccordingtotheLCDdisplaysettings. 
 DMXControlMode
o OperatinginaDMXcontrolmodegivestheuserthegreatestflexibilitywhenitcomestocustomizingor
creatingashow.WhenDMXispluggedin,theLCDscreenwillshowtheDMXAddressMenuandallow
adjustmentoftheaddress.Whentheunitislowonfluid,theLCDscreenwillshowtheResetFluidSensor
MenuandafterresettingthefluidsensorbacktotheDMXAddressMenu.WhenDMXcablesare
unplugged,theLCDscreenwillshowthehomemenu.
MAINTENANCE
Cleaningyourfogbubblemachineregularlywillhelpreducecostlypartsreplacementandrepaircharges. 
Pleasefollowtheseinstructionsforsafelycleaningafter40hoursofoperationorbeforestoringthefogbubble
machine,toensurelonglifespan.Tools:Cleanlintfreecloth,coffeefilterorsimilarfinemeshfiltercloth,plastic
orglasscontainerlargerthanthereservoirsize(donotusemetal),distilledwaterandFroggysFogfluid.

1. Allowthemachinetocooldownbeforehandling. 
2. Drainanyfogsolutionthatremainsinthetankintoacontainerthroughthefiltermeshforreuse. 
3. Disposeofanybubblesolutionsandwipetray/wands 
4. Adddistilledwatertofillthefogfluidreservoirapproximately1/3. 
5. Runmachinefor10minutes.Fogwillcomeoutthefirstfewcycles,followedbydistilledwatervapor. 
6. Turnoffthemachineandallowtocooldown,thendrainthedistilledwaterfromthereservoir. 
7. Refillthereservoirapproximately1/3withgoodqualityfogsolution. 
8. Turnfogmachineon,runfor10‐15minutes.Watervaporsteamwillcomeoutthefirstfewcycles,
followedbyfog.Continuesteamingthemachinefor5‐10cycles.

9. Turnoffthemachineandallowtocool,thenwipemachinecleanwithcleanlintfreecloth. 
10. Leavethefogsolutioninthereservoir. Thefogsolutionactsalubricantandconditionerfortheplasticand
rubberpartsinthefluidpump.

11. Storethefogmachineinacool,dryplacewhennotinuse. Avoidfreezingtemperatures,highheat
above120degreesandhumid/damplocationswhichmaycausecontrolboardfailure.

12. Ifpossible,removefromstorageafter6monthsandoperatethefogmachinefor15minutesormore,
thenrepeatstep8–10.










3

LCD DISPLAY SETTINGS

LCDDisplaySettings Description


MachineFunction 
Choosetheprogrammodesfrom1‐4todisplaydifferentprograms: 

1.Fog2.Haze3.Bubble4.BubbleFogger 

FogVolume 

Adjustthefogvolumeoutputwithintherangefrom0%to100%. 

BubbleFanSpeed 

Adjustthebubblefanspeed0‐100%in10%increments 

BoosterFanSpeed 

Adjusttheboosterfansspeed0‐100%in10%increments 

BubbleWandSpeed 

Adjustthewandspeed0‐100%in10%Increments 

TimerInterval 

Adjusttheintervalbetweeneachfogemissionwithintherangeof0
to600S.


TimerDuration 

Adjustthedurationofeachfogemissionwithintherangeof0to
300S.


DMXAddress 

ChoosetheDMXaddressfrom001‐512. 
DMXMode  Choose6or15ChannelMode. 
LEDProgram  ChoosetheLEDprogramwithintherangeof0to20 

LEDChaseSpeed 

ChoosetheLEDchasespeedfrom0‐100%in10%Increments. 

LEDStrobeSpeed 

ChoosetheLEDstrobespeedfrom0‐100%in10%Increments. 

LEDSynctoOutput 
Yes=LEDsworktogetherwiththefogoutput
NO=LEDsarealwayson.


FogFluidSensorReset 

ResetthelowfluidsensorwhenittripsanddisplayNO,chooseYESto
Reset


FogFluidSensorOn/Off 

Deactivatethelowfluidsensor 


4

DMX PROFILES

FobblesF4–DMXCHANNELS
6ChannelMode
DMXChannel  Function  Addressinformation 

DMXChannel1 

FogOutput 
0  9  Off 
10 255 0‐100% 

DMXChannel2 

FanOutput 
0  9  Off 
10 255 0‐100% 

DMXChannel3 

BlowerOutput 
0  9  Off 
10 255 0‐100% 






DMXChannel4 






BubbleSize 
0  24  Off 
25 49 SmallBubbles‐MinimumOutput 
50 74 SmallBubbles‐ModerateOutput 
75 99 SmallBubbles‐MaximumOutput 
100 124 MediumBubbles‐MinimumOutput 
125 149 MediumBubbles‐ModerateOutput 
150 174 MediumBubbles‐MaximumOutput 
175 199 LargeBubbles‐MinimumOutput 
200 224 LargeBubbles‐ModerateOutput 
225 255 LargeBubbles‐MaximumOutput 

















DMXChannel5 
LEDStaticColors  LEDStaticColors 
0  0  9  OFF 
1  10 19 RED 
2  20  29  GREEN 
3  30  39  BLUE 
4  40  49  WHITE 
5  50  59  AMBER 
6  60  69  UV 
7  70  79  RED+GREEN 
8  80  89  RED+BLUE 
9  90  99  RED+WHITE 
10  100 109 RED+AMBER 
11  110 119 RED+UV 
12  120 129 GREEN+BLUE 
13  130 139 GREEN+WHITE 
14  140 149 GREEN+AMBER 
15  150 159 GREEN+UV 
16  160 169 BLUE+WHITE 
17  170 179 BLUE+AMBER 
18  180 189 BLUE+UV 
19  190 199 WHITE+AMBER 
20  200 209 WHITE+UV 
21  210 219 AMBER+UV 
22  220 229 BLUE+WHITE+UV 
23  230 239 RED+GREEN+BLUE+WHITE+AMBER 
24  240 255 RED+GREEN+BLUE+WHITE+AMBER+UV 


DMXChannel6 


LEDColorMacro 
ColorChaseAll24StaticColors
(1,2,3,4,5,6,7,19,12,16,8,13,17,22,9,14,18,21,23,10,15,
20,11,24)

0  9  OFF 

10 

255
10=Changecolorevery10Seconds
LinearIncreaseinSpeed

255=Changecolorevery0.5Seconds 



5

15ChannelMode

DMXChannel1 

FogVolume 
0  9 
NoFunction 
0‐100% 
10 255 0‐100% 

DMXChannel2 

BubbleWandSpeed 
0  9 
NoFunction 
0‐100% 
10 255 0‐100% 

DMXChannel3 

BubbleFanSpeed 
0  9 
NoFunction 
0‐100% 
10 255 0‐100% 

DMXChannel4 

BoosterFan 
0  9 
NoFunction 
0‐100% 
10 255 0‐100% 

DMXChannel5 

RedLED 
0  9 
NoFunction 
0‐100% 
10 255 0‐100% 

DMXChannel6 

GreenLED 
0  9 
NoFunction 
0‐100% 
10 255 0‐100% 

DMXChannel7 

BlueLED 
0  9 
NoFunction 
0‐100% 
10 255 0‐100% 

DMXChannel8 

AmberLED 
0  9 
NoFunction 
0‐100% 
10 255 0‐100% 

DMXChannel9 

WhiteLED 
0  9 
NoFunction 
0‐100% 
10 255 0‐100% 

DMXChannel10 

UltravioletLED 
0  9 
NoFunction 
0‐100% 
10 255 0‐100% 
















DMXChannel11 
LEDColorMacro  LEDColorMacro 
0  0  9  OFF 
1  10 19 RED 
2  20  29  GREEN 
3  30  39  BLUE 
4  40  49  WHITE 
5  50  59  AMBER 
6  60  69  UV 
7  70  79  RED+GREEN 
8  80  89  RED+BLUE 
9  90  99  RED+WHITE 
10  100 109 RED+AMBER 
11  110 119 RED+UV 
12  120 129 GREEN+BLUE 
13  130 139 GREEN+WHITE 
14  140 149 GREEN+AMBER 
15  150 159 GREEN+UV 
16  160 169 BLUE+WHITE 
17  170 179 BLUE+AMBER 
18  180 189 BLUE+UV 
19  190 199 WHITE+AMBER 
20  200 209 WHITE+UV 
21  210 219 AMBER+UV 
22  220 229 BLUE+WHITE+UV 
23  230 239 RED+GREEN+BLUE+WHITE+AMBER 
24  240 255 RED+GREEN+BLUE+WHITE+AMBER+UV 


DMXChannel12 


LEDColorMacroSpeed 
ColorChaseAll24StaticColors
(1,2,3,4,5,6,7,19,12,16,8,13,17,22,9,14,18,21,23,10,
15,20,11,24)

0  9  OFF 

10 

255
10=Changecolorevery10
SecondsLinearIncreasein
Speed

255=Chan
g
ecolorever
y
0.5Seconds 


6


DMXChannel13 

LEDStrobe 
0  9 
NOSTROBE 
32‐255 
10  255 StrobeEffectSLOWtoFAST 

DMXChannel14 

MasterLEDDimmer 
0  9 
NoFunction 
0‐100% 
10  255 0‐100% 

















DMXChannel15 

















OperatingMacro 
OperatingMacro 
0  9  Off 
10 19 25%Fog 
20 29 50%Fog 
30 39 100%Fog 
40 49 10%Haze 
50 59 25%Haze 
60 69 50%Haze 
70 79 100%Haze 
80 89 MinSmallBubbles 
90 99 MedSmallBubbles 
100 109 MaxSmallBubbles 
110 119 MinBigBubbles 
120 129 MedBigBubbles 
130 139 MaxBigBubbles 
140 149 50%Fog50%SmallBubbles 
150 159 50%Fog100%SmallBubbles 
160 169 50%Fog50%MediumBubbles 
170 179 50%Fog100%MediumBubbles 
180 189 50%Fog50%LargeBubbles 
190 199 50%Fog100%LargeBubbles 
200 209 100%Fog50%SmallBubbles 
210 219 100%Fog100%SmallBubbles 
220 229 100%Fog50%MediumBubbles 
230 239 100%Fog100%MediumBubbles 
240 249 100%Fog50%LargeBubbles 
250 255 100%Fog100%LargeBubbles 



SAFETY WARNINGS


Undernormaluse,bubblesolutioncanbuilduponsurfacesbeneathandinfrontofthemachine.Exercisecare
duringusetoavoidslippinghazards.


Keepthisdevicedry. Theunitmaybeusedoutdoorsbutmustbeshieldedfrominclementweather. Turnoff
orunplugwhennotinuse.


Use3‐pronggroundedelectricaloutletonly.Priortousetakecaretodeterminethattheunitisinstalledat
theratedvoltage.


Alwaysunplugyourfogbubblemachinebeforefillingitstank. 

Alwayskeepthefogbubblemachineuprightandlevel. 

Themachineisnotwaterprooforsplashproof.Ifoutsidemoisturegetsinsidethehousing,immediately
unplugandcontactaservicetechnicianoryourdealerbeforeusingitagain.


Nouserserviceablepartsinside.Refertoyourdealerorotherqualifiedservicepersonnel. 

Foradultuseonly.Fogmachinemustbeinstalledoutofthereachofchildren.Neverleavetheunitrunning
unattended.


Neverpointthenozzledirectlyatpeople.Fogmachineoutputisveryhot(300degreesC). 

Nevercovertheunit’svents.Operatemachineinawell‐ventilatedareaandallowfreeairspaceofatleast6”
aroundunit.



7

 Onlyspecificallydesignedwater‐basedscentadditivesmaybeaddedtothefogorbubblefluid.Neveradd
flammableliquidsofanykind(oil,gas,non‐applicationspecificperfumes).Payattentiontoallwarning
labelsandinstructionsprintedontheexteriorofyourmachine.


Useonlythehighquality,FroggysFog,water‐basedfogfluidinthemachine.Alwaysmakesurethereis
enoughliquidinthefogliquidtank.Operatingthisunitwithoutliquidwillcausedamagetotheheater
andpumpsystems.


Alwaysdrainreservoirsbeforemailingortransportingthisunit. 

Neverdrinkfogorbubbleliquid.Ifingestionoccurs,seekmedicalassistance.Forcontactwithskinoreyes,
rinsethoroughlywithwater.


Vaporfromthisfluidmaybeirritatingtosomepersonswithallergicsensitivity. Donotexposeatclose
rangetoknownasthmatic. Useinawell‐ventilatedarea.


1 YEAR LIMITED WARRANTY

 Validfromthedateofpurchase.
 Warrantycoversmanufacturingdefectsonlyanddoesnotcovermisuseorabuseofthemachine.
 Serialnumber,placeofpurchasewithdatedvalidreceiptmustbesubmittedattimeofservice.
 Warrantyisonlyvalidwith‐intheUnitedStates.
 Buyermayberesponsibleforshippingfeesassociatedwithrepairs. 
