Owner’s Manual
Amina Gas Table Base - Bronze
WARNING
Improper installation, adjustment, alteration, service or maintenance can cause injury or
property damage. Read the owner’s manual thoroughly before installing or servicing this
result causing property damage, personal injury or loss of life.
Save these instructions for future use. If you are
assembling this unit for someone else, give this
manual to him or her to read and save for the
future.
DANGER
WARNING
WARNING
If you smell gas:
1. Shut off gas to the appliance.
3. If odor continues, keep away from
the appliance and immediately call
e department.
Do not store or use gasoline or other
vicinity of this or any other appliance.
An LP-cylinder not connected for use
shall not be stored in the vicinity of
this or any other appliance.
For outdoor use only.
Item# 160188B AMB
Model# HYFP50095-113

WARNING
Before you assemble or operate this unit, please carefully read this entire manual. Failure to do so
may r
SAFETY INFORMATION
The installation of this unit must adhere to local codes or either the National Fuel Gas Code, ANSI
Z223. 1/NFPA54, OR CAN/CGA-B149.1, National Gas and Propane Installation Code.
THIS UNIT IS INTENDED FOR OUTDOOR USE ONLY! This product shall be used outdoors, in a
ventilated space and shall not be used in any enclosed area.
This unit is to be used with propane gas only! (sold separately)
Do not attach a remote gas supply to this unit.
Only use propane gas for this unit.
Do not use any solid fuel or charcoal for this unit.
LP GAS WARNING: Do not use any more than 1/4in depth lava rocks/pumice stones/LavaGlass®
above the bur
If the propane gas tank is leaking gas, you may hear, see, or smell a hiss. Do the following:
e department for help.
Applying too much propane may result in gas pooling and will not burn. Allow fresh air into the unit
so that the remaining gas may escape.
The max. inlet supply pressure: max. Gas supply 11 in w.c. (2.74kPa)
You must use a propane tank that has a collar to protect the gas valve.
The tank system must be set up for vapor withdrawal.
Discontinue use if any part of the propane tank is damaged. Rust and dents may be hazardous and
should be inspected by a gas supplier.
rocks/pumice stones/LavaGlass®could pop out and cause injury. Should any rocks pop out, discard
them.
Always ensure that lava rocks/pumice stones/LavaGlass®are completely dry before use. Failure to
do so will cause them to crack or pop.
Do not operate unit until all parts are fully assembled.
Do not paint or color any part of this heating unit.
Unit may be hot while in use, do not attempt to move it while in use.
Never leave this heating unit unattended while in use.
This unit is not intended for cooking.
Keep a safe distance to avoid burning skin or clothing.
Do not sit or rest hands or feet on this heating unit.
Keep all electrical cords and fuel supply hose away from heated surfaces.
Use LP propane tanks with the following dimensions: diameter 12 in, height 18 in - capacity 20 lbs.
Page 2

•Combustible material should not be within 72 inches of the top of the unit, or within 48 inches
around the entire unit.
vapors and liquids.
•Do not add water into the unit.
•Do not operate unit if any part has been under water. Immediately call a
technician to inspect the appliance and replace any part of the control system and any gas
control that has been under water.
•Do not disconnect any part while unit is in use.
•Do not store a spare propane tank on or near this unit.
•If the heating unit is indoors, detach the propane tank and leave it outdoors.
•Always remove protective cover before operating (if applicable).
•Do not set a protective cover over the unit until it is turned off and completely cooled down.
•Check for leaks after not using the unit for long periods of time.
•Children should never operate this unit. Children must be supervised while near this unit.
•Keep gas tank at least 5 feet away from unit when lit. (if external tank)
•The maximum gas supply pressure is 250psi.
inspected annually and cleaned regularly.
•Inspect all elements of this heating unit before each use. If there is damage, the burner must be
replaced.
•Keep the hose out from any pathways to eliminate any accidental damage. (if external tank)
•Be aware of the hazards of high temperatures and stay away from the unit to avoid any burns or
injury.
of the U.S. Department of Transportation or the National Standard of Canada CAN/CSA-B339, LP gas
tanks, spheres and tubes for Transportation of Dangerous Goods; and Commission.
gas tank connection.
ks.
•Children and adults should be alerted to the hazards of high surface temperatures and should
stay away to avoid burns or clothing ignition.
•Young children should be carefully supervised when they are in the area of the appliance.
near the appliance.
•Any guard or other protective device removed for servicing the appliance shall be replaced
prior to operating the appliance.
may be required as necessary. It is imperative that the control compartment, burners and
circulating airways of the appliance are kept clean.
IF APPLICABLE:
•Allow heating item to cool completely before placing on lid.
•DO NOT use heating item while lid is installed. Always remove the lid while heating item is in use.
Page 3

SAFETY INFORMATION
Only use the regulator and hose assembly provided with this unit. Replacement parts must be supplied
directly by Bond Manufacturing Co., Inc.
Inspect the burner before use of this unit. If the burner shows any kind of damage, do not operate
the appliance.
NOTE: You must follow all steps to properly assemble this heating item. Make sure the gas
valve is turned “OFF” before assembling. Do NOT attempt to assemble without proper tools.
Min. Clearance
48 in (121.9 cm)
Min. Clearance
48 in (121.9 cm)
Min. Clearance
48 in (121.9 cm)
Min. Clearance
48 in (121.9 cm)
Combustible materials should not be within 72
inches of the top of the unit, or within 48 inches
around the entire unit.
ytQnoitpircseDmetI
AA Flat Washer 3
BB Lock Washer 3
CC Screw M8*20 3
HARDWARE
Before beginning assembly of product, make sure all parts are present. Compare parts with
package contents list and hardware contents list. If any parts are missing or damaged, do not
attempt to assemble the product.
Estimated Assembly Time: 20 minutes
Tools Required for Assembly (not included): Phillips Screwdriver
AA BB CC
Page 4

Item Description Qty
A Firebowl 1
BBody 1
CDrawer 1
DBurner 1
E Guard 1
F Lava Rocks 2 boxes
G Protective Cover 1
H Battery 1
I Control Knob (preassembled) 1
J Electronic Igniter (preassembled) 1
CONTENTS
K 4
L 1
Feet (preassembled)
Table top (not included)
(preassembled)
(preassembled)
(preassembled)
(preassembled)
D
A
B
H
E
I
J
C
F
G
K
L
Page 5

OFF
I
CC
BB
AA
B
L
B
C
Page 6
ASSEMBLY INSTRUCTIONS
1. Check that the control knob (I) for the gas
supply system is turned to the “OFF” position
before starting any assembly.
2. Put the table top (L) upside down on a soft
clean carpet, and then position table base (B) on
the table top. Align the screw holes on the table
base with those of the table top and assemble
them with the at washer (AA), lock washer (BB)
and bolt (CC).
3. Open the drawer (C) and place propane gas
tank (not included) into the metal stand inside
the drawer (C).

4. Turn the cylinder valve on the tank
clockwise to close the propane tank.
Attach the preassembled regulator
from the body (B) to the cylinder valve
by turning the regulator coupling nut
clockwise. Make sure it is fastened
securely and tighten connections by hand
only.
6.
.
5.
C
Close the drawer (C).
Once the tank is attached to the regulator,
make sure the propane gas tank sits on the
metal stand inside drawer (C) completely. Turn the
preassembled wing screw on the outer part of
metal stand clockwise to secure the propane gas
tank tightly.
CYLINDER VALVE
PRESSURE
RELIEF VALVE
BLEED-OFF
VALVE
BLACK COUPLING NUT
REGULATOR
turn clockwise to connect
turn clockwise
to reseal
B
C
Page 7

Page 8
ASSEMBLY INSTRUCTIONS
7. Remove the rubber cap on the electronic ignit
(J) by unscrewing and slide battery (H) into the
battery slot. Make sure the positive side of the
battery faces outwards. Screw the electronic
ignit r cap (J) over the battery tightly.
J
H
8. Pour the lava rocks (F) into the rebowl (A).
To ensure proper function, the guard (E) on this
burner (D) should be free of lava rocks (F) at
all times.
WARNING
F
A
E

T
Before performing a leak test, be sure that no sparks can occur and you are in a spacious outdoor
area. Connect the propane gas tank to the regulator and turn the valve on the unit to the “off”
position. Brush a soap and water mixture on all connections. Turn the gas supply on; push the control
knob in but do not ignite the unit, if bubbles occur on any connection there may be a leak. If you smell
gas or a leak is discovered turn the gas valve off, disconnect propane gas tank and do not use
the appliance until the leak is repaired.
Do not use the heating unit without inspecting the gas hose. If there are signs of wear or abrasion
you must replace the hose (if applicable). Pumice stones/lava rocks/LavaGlass®could pop up and
strike somebody’s face during the
20 minutes after igniting. Flame height should be a yellow/blue color between 2 - 10 inches in height.
on heating item.
OPERATION
Page 9
o Light
To Extinguish
1. Make sure the control knob (I) is in the “off” position.
2. Remove drawer (C) and slowly open the valve on the propane gas tank by turning the knob
counterclockwise.
3. Close the drawer (C) on the body (B).
4. Push and hold in the electronic ignit r (J) to create sparks within the electrode, continue to hold.
5. Push in the control knob (I) and turn to the “low” position. Keep holding down the control knob (I)
5 seconds.
6. If ignition doesn’t occur within a few seconds, release the control knob (I) and rotate to the “OFF”
position. Wait for 5 minutes for gas to clear and then repeat the above lighting instructions.
7.
between the “low” and “high” positions.
1. Turn control knob (I) clockwise to the “low” position; let the knob pop up and continue turning the
control knob (I) to the “off” position.
2. Close the cylinder valve on the propane gas tank if you don’t intend to use it for a long time.

MAINTENANCE
•Before performing any maintenance always disconnect propane gas tank.
•Keep the heating item free and clear from combustible materials.
•Visually inspect burner for obstructions and keep tank enclosure free and clear from debris.
•Use a soft brush to get rid of the mild stains, loose dirt and soil after the burner and pumice stones/
lava ocks/LavaGlass® rare completely cooled down. Wipe down with a soft cloth.
•Harsh weather conditions may cause stubborn stains, discoloration and possibly rust pitting.
•Permanent damage may occur if powder or solvent comes in contact with painted or plastic
components on this heating unit.
•Keep the heating unit stored away from direct sunlight.
•If storing this unit inside, disconnect the propane gas tank from the gas valve.
•Not using manufacturer approved or supplied parts/accessories may result in a defective condition
and void the warranty of this heating unit.
•Always place lid (if applicable) or protective cover on heating item when not in use.
Envirostone®Surface Care
Our Envirostone® material has been sealed with a patented treatment to prevent staining and
moisture absorption, but it does require proper maintenance to ensure the integrity of the surface.
Please see below for recommendations on maintaining your Envirostone®surface for years of
enjoyment:
• Clean any spills immediately to prevent permanent Envirostone®surface staining or damage.
Blot any liquid spills with a clean, dry cloth to avoid spreading of the spill to the rest of the table.
Clean your Envirostone®surface with a soft, clean cloth or sponge. Mix a solution of warm clean
water and mild dish soap to remove any surface dirt or mild spills. Rinse all soap solution off of the
tabletop and dry completely to avoid water spots. Regularly cleaning the Envirostone®surface will
aid in a longer lasting product.
• Do not use petroleum-based or abrasive cleaning products. Do not use any harsh brushes when
cleaning the Envirostone®surface.
• Do not slide products across the Envirostone®surface to avoid permanent scratching and
damage.
• Always use protective mats such as coasters or placemats when eating on an Envirostone®
surface. These protective products will help absorb sweating on cool beverages and will block
out any heat rings from appearing beneath a warm mug or plate. When placing hot dishes on an
Envirostone®surface, always use mats or hot pads.
• Envirostone® surface must be covered at all times when not in use. Cover your product with an
outdoor furniture cover when not in use to protect it from the elements. Store your product indoors
during winter months. Avoiding extreme cold temperatures will prevent cracking of the tabletop.
Page 10

TROUBLESHOOTING
noituloSesuaCmelborP
Igniter pin and burner are wet Dry off with a soft cloth
Igniter battery is incorrectly inserted Check which direction the battery is
inserted
g Co., Inc. fornirutcafunaMdnoBtcatnoCnekorbsinipretingI
a replacement part
Electrode wire is loose or disconnected Reconnect wire to the igniter box located
inside the table behind the igniter box
Electrode wire is shorting between valve
and igniter pin
Contact Bond Manufacturing Co., Inc. for
a replacement part
ytpmet’nsiknatsagehttahtkcehCwoflsagoN
Regulator isn’t connected securely to the
tank
Tighten regulator connection to the gas
tank
sdnebdnasknikrofsesohllakcehCdetcurtsbosiwoflsaG
Burner ports are clogged Turn all gas flow connections off. Insert
an opened paperclip (or similar item) into
each of the burner ports to clear them
out.
Flame is obstructed at burner ports Check that all burner ports are free of any
small lava rocks/pumice stones/Lava-
Glass®pieces
Regulator hose is kinked Straighten hose of all bends or kinks
ytpmet’nsiknatsagehttahtkcehCwoflsagoN
Excess flow safety valve has been
activated
Turn the control knob to the ‘off’ posi-
tion. Close the tank valve and disconnect
propane gas tank. Turn the control knob
to ‘high’; wait 1 minute. Turn the control
knob back to the ‘off’ position. Recon-
nect propane gas tank. Light the fire unit
as indicated in the ‘To Light’ section of
this manual.
’hgih‘otemaflesaercnIsdniwgnitsugrohgiH
ytpmet’nsikna
tsagehttahtkcehCwoflsagoN
Excess flow safety valve has been
activated
See ‘sudden drop in gas flow’ above
Heating unit won’t light
Burner won’t light
while using a match
Heating unit emits a lot
of black smoke
Sudden drop in gas
flow
Flame blows out easily
Page 11

WARRANTY
CONTACT
The manufacturer warranty will be voided by, and manufacturer disclaims any responsibility for, the
following actions:
•
•Use of any component part not manufactured or approved by manufacturer.
•Use and installation other than what is listed in this manual.
Please contact the manufacturer for replacement parts.
Page 12
Please contact one of our Product Specialists for assembly assistance or questions at
1-800-537-8484 or email [email protected]. Specialists are available weekdays 8:00 a.m. to 8:00
p.m. EST or Saturday 9:30 a.m. to 6:00 p.m.
