Frontier SB2164 User manual

OM0393SB2176-A
10/10
Serial # XFSB21X100058 and up
OPERATO R'S MANUAL
SNOWBLO
W
ER
SB2164 SB2176

TABLE CONTENT
OM 0393SB-A 1
SPÉCIFICATIONS...............................................................................................................................................3
INTRODUCTION – TO THE PURCHASER ................................................................................................4
SAFETY PRECAUTIONS......................................................................................................................5-11
Before Operation................................................................................................................................5
Notice.................................................................................................................................................6
The Snowblower ................................................................................................................................6
Before Operation......................................................................................................................6
Snowblower Operation.............................................................................................................7
The Tractor ........................................................................................................................................8
General Information..................................................................................................................8
Operating the Tractor...............................................................................................................8
During Operation......................................................................................................................9
Roll-Over Protective Structure (ROPS)....................................................................................9
Maintenance ...................................................................................................................................10
Transport..........................................................................................................................................11
Storage ..........................................................................................................................................11
DECALS ...................................................................................................................................................12
ASSEMBLY...................................................................................................................................................13-40
Snowblower Assembly.....................................................................................................................13
Installation of the Chute for SB2176.................................................................................13-14
for SB2164.................................................................................15-16
Installation of the Snowblower................................................................................................16
Installation of the Hydraulic Hoses.........................................................................................17
Installation of the Electrical Wiring
– TRACTOR WITH CABIN (w/ 5RDF0038)......................................18-22
– TRACTOR WITHOUT CABIN (w/ 5RDF0039 and 5RDF0038)......23-28
Installation of the Switchbox 5RD669285 - Option.................................................................29
Installation of Hydraulic Deflector 5RDF0025 or 5RDF0027- Option................................30-33
Installation of the Tractor side 132" Harness (5RDF0038) - TRACTOR WITH CABIN ..........34-35
- TRACTOR WITHOUT CABIN ....36-38
Installation of the Drift Cutters 5RDF0026 - Option ..........................................................39
Removing the Snowblower.....................................................................................................40

TABLE CONTENT
OM 0393SB-A 2
OPERATION ................................................................................................................................................41-42
Optimum Performances...................................................................................................................41
General Preparation ........................................................................................................................41
Operating Controls ..........................................................................................................................41
Manual Deflector Adjustment ..........................................................................................41
Hydraulic Deflector Adjustment.......................................................................................41
Hydraulic Rotation Adjustment........................................................................................41
Ground Speed ................................................................................................................42
Skid Shoe Adjustment.....................................................................................................42
Snow Removal Methods .................................................................................................................43
MAINTENANCE...................................................................................................................................44-53
Maintenance ....................................................................................................................................44
Storage ............................................................................................................................44
Hydraulic Oil ....................................................................................................................44
Lubrication.......................................................................................................................................45
Regular Inspections.........................................................................................................................45
Troubleshooting..........................................................................................................................46-47
Instruction For Valves Adjustment..............................................................................................48-51
Hydraulic Diagram...........................................................................................................................52
Electrical Diagram............................................................................................................................53
TORQUE SPECIFICATION TABLE ....................................................................................................54-56

SPECIFICATIONS
OM 0393SB-A 3
WorkingWidth 64" 76"
Transport Width 70" 88"
Working Height 27" 27"
Length 39" 39"
Single/Dual Auger Single Single
Auger Diameter 15" 15"
Auger Flighting Thickness 5/16" 5/16"
Impeller Diameter 24" 24"
Impeller Width 7" 8 1/2"
Impeller Shaft Diameter 1 1/4" 1 1/4"
Number of Impeller blades 4 4
Impeller RPM 680 580
Auger RPM 200 185
Skid Shoe Adjustable 6 positions Adjustable 6 positions
Skid Shoe Material High carbon steel High carbon steel
EndPlate Thickness 3/16" 3/16"
Back Plate Thickness 11ga 11ga
Impeller Housing Thickness 11ga 11ga
Impeller Blade Thickness 1/4" 1/4"
Side Panel Bottom Thickness 1/2" 1/2"
Cutting Edge Replaceable Replaceable
Cutting Edge Dimension 3/8" x2" 3/8" x 2"
Chute Base Standard Standard
Parking Stand Standard Standard
Loader Compatibility Current JD300 Series LoaderCarriers Current JD 400 Series Loader
Carriers
Flow/ Pressure 12 to 18 gpm @ 2700 psi 18 to 23 gpm @ 3000 psi
Oil Cooler Standard Standard
V.A.C.System Standard Standard
Fan Drive 89 cc/rev. HydraulicMotor 127cc/rev. Hydraulic Motor
Auger Drive 293 cc/rev. HydraulicMotor 409cc/rev. Hydraulic Motor
Relief Valve Protection Fan, Auger & Rotation Motor Fan, Auger & Rotation Motor
Main Hydraulic Hoses 3/4" 3/4"
Operating Weight (lbs)-hyd. rot. & deflector N/A 760
Shipping Weight (lbs) N/A 1060
Approx. Set-up Time 2 to 3 hours ( including hydraulic pump) 2 to 3 hours ( including hydraulic
pump)
Chute Deflector Adjustment (standard) Manual Manual
Chute Deflector Adjustment (option) -cylinder (2"x6") including hosesandtips -cylinder (2"x8") including hoses
andtips
Chute Rotation (standard)
–
hydraulic motor with electro-hydraulic
valve
–
hydraulic motor with electro-
hydraulic valve
Chute Two-part Two-part
Drift Cutters Option Option

INTRODUCTION
OM 0393SB-A 4
IMPORTANT NOTICE
Frontier loader mounted hydraulic snowblowers are calibrated and tested at the plant in order
to ensure the best possible performance. The calibration of these snowblowers requires the
proper equipment and a certain expertise.
Any partial modification or adjustment made on the snowblower without the written consent of
the manufacturer will automatically void the snowblower warranty.
The adjustments of the hydraulic components must never be modified. A breaking in period is
necessary before the snowblower is operated at full capacity. See the "Operation" section for
more details.
The Frontier loader mounted hydraulic snowblowers is designed to blow snow and not to push
snow. Any use resembling a snow pusher will automatically void the snowblower warranty
TO THE PURCHASER
All products are designed to give safe,
dependable service if they are operated and
maintained according to instructions. Read and
understand this manual before operation.
This manual has been prepared to assist the
owner and operators in the safe operation and
suitable maintenance of the implements. The
information was applicable to products at the
time of manufacture and does not include
modifications made afterwards.
Read and understand this operator's manual
before attempting to put an implement into
service. Familiarize yourself with the operating
instructions and all the safety recommendations
contained in this manual and those labeled on
the implements and on the tractor. Follow the
safety recommendations and make sure that
those with whom you work follow them.
Illustrations
The illustrations may not necessarily reproduce
the full detail and the exact shape of the parts or
depict the actual models, but are intended for
reference only
Direction Reference
Right Hand and Left Hand are determined by
those seen by the operator sitting on the tractor.
The Dealer is responsible for warranty registration of the unit you have purchased. To assist your
dealer in handling your needs, please record hereafter the model number and serial number of your
implement and tractor. It is also advisable to supply them to your insurance company. It will be helpful
in the event that an implement or tractor is lost or stolen.
MODEL :
SERIAL NUMBER :
DATE OF PURCHASE :

SAFETY PRECAUTIONS
OM 0393SB-A 5
SAFETY FIRST
This symbol, the industry's "Safety Alert Symbol", is used throughout this manual and on
labels on the machine itself to warn of the possibility of personal injury. Read these
instructions carefully. It is essential that you read the instructions and safety regulations
before you attempt to assemble or use this unit.
DANGER : Indicates an immediate hazardous situation which, if not avoided, will
result in death or serious injury.
WARNING : Indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION : Indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury.
IMPORTANT : Indicates that equipment or property damage could result if instructions
are not followed.
NOTE : Gives helpful information.
All products are designed to give safe, dependable service if they are operated and maintained
according to instructions. Read and understand this manual before operation. It is the owner's
responsibility to be certain anyone operating this product reads this manual, and all other applicable
manuals, to become familiar with this equipment and all safety precautions. Failure to do so could
result in serious personal injury or equipment damage. If you have any questions, consult your dealer.
BEFORE OPERATION
Children
Tragic accidents can occur if the operator is not
alert to the presence of children. Children are
generally attracted to machines and the work
being done. Never assume children will remain
where you last saw them.
1. Keep children out of the operating area and
under the watchful eye of another responsible
adult.
2. Be alert and turn machine off if children enter
the work area.
3. Before and when backing, look behind for
small children.
4. Never carry children while operating the
machine. They may fall off and be seriously
injured or interfere with the safe operation of
the machine.
5. Never allow children to play on the machine
or attachment even when they are turned off.
6. Never allow children to operate the machine
even under adult supervision.
7. Use extra care when approaching blind
corners, shrubs, trees, or other obstructions
that might hide children from sight.

SAFETY PRECAUTIONS - continued
OM 0393SB-A 6
NOTICE
A safe operator is the best assurance against accidents. All operators, no matter how experienced
they may be, should read this operator's manual and all other related manuals before attempting to
operate the equipment. Please read the following section and pay particular attention to all safety
recommendations contained in this manual and those labeled on the equipment and on the tractor.
THE SNOWBLOWER
Before Operation
1. Read and understand this operator's
manual and the tractor operator's
manual. Know how to operate all
controls and how to stop the unit and
disengage the controls quickly.
2. Never wear loose, torn, or bulky clothing
around the tractor and the snowblower. It
may catch on moving parts or controls,
causing injury.
3. Before and during the snow season,
thoroughly inspect the area where the
equipment is to be used and remove all
objects that may be thrown or cause
damage to the equipment.
4. Set transmission to neutral and
disengage clutch, if equipped, before
starting the engine.
5. Do not operate equipment in wintertime
without wearing adequate winter
garments and protective clothing.
6. Never attempt to make any adjustments
while engine is running. Read this
manual carefully to acquaint yourself
with the equipment as well as the tractor
operator's manual. Working with
unfamiliar equipment can lead to
accidents. Be thoroughly familiar with the
controls and proper use of the
equipment.
7. Keep all safety guards in place and
verify hardware for proper tightening.
8. Check for moving parts excessive wear
regularly. Replace worn parts with
genuine parts.
9. Replace all missing, illegible, or
damaged safety and warning decals.
See list of decals in operator's manual.
10. Keep safety decals clean of dirt and
grime.
11. Do not modify or alter this equipment or
any of its components or any equipment
function without first consulting your
dealer.
12. The use of rear counterweights is
recommended. Weights provide the
necessary balance to improve stability,
traction and steering. Use only those
recommended by your dealer. Please
refer to tractor's operator's manual for
proper ballasting information.

SAFETY PRECAUTIONS - continued
OM 0393SB-A 7
Snowblower Operation
1. Before leaving the tractor unattended,
take all possible precautions. Park the
tractor/snowblower on level ground, place
the transmission in neutral, set the parking
brake, disengage the equipment drive,
lower the equipment to the ground, place
all levers including auxiliary control levers
in neutral, shut off the engine and remove
the ignition key.
2. Before starting the tractor/ snowblower,
remove any ice that has accumulated in
the auger/fan.
3. Prior to operation, clear work area of all
objects that can be picked up and thrown.
Mark all curbs, pipes, etc. that cannot be
moved.
4. Be sure the PTO switch/lever is in OFF
position before starting engine.
5. Exercise extreme caution when operating
on or crossing a gravel drive, walks, or
roads. Stay alert for hidden hazards or
traffic.
6. Do not carry passengers.
7. Adjust collector-housing height to clear
gravel or crushed rock surface.
8. Keep clear of rotating parts. Do not put
hands or feet under, or into snowblower
with engine running.
9. Park the tractor/snowblower on level
ground, place the transmission in neutral,
set the parking brake, disengage the
equipment drive, lower the equipment to
the ground, place all control levers in
neutral, shut off the engine, remove the
ignition key and allow the rotating parts to
stop BEFORE unclogging the collector/fan
housing or chute, and making any repairs,
adjustments or inspections. Use only a 36"
long piece of wood to unclog blower.
10. If the snowblower starts to vibrate
abnormally, disengage the equipment
drive, stop the engine immediately and
check for cause. Excessive vibration is
generally a sign of trouble.
11. Do not run the engine indoors except
when starting engine and transporting
attachment in or out of building. Carbon
monoxide gas is colorless, odorless and
deadly.
12. Do not attempt to operate on steep
slopes. If operating on slopes is
necessary, exercise extreme caution
when changing direction.
13. Never operate snowblower without
guards, and other safety protective
devices in place.
14. Keep clear of chute discharge. This chute
has the capability of throwing objects at
far distances.
15. Do not direct discharge at bystanders or
animals. Ejected objects may cause
injury and never operate snowblower
near glass enclosures, automobiles,
window wells, embankments, etc.,
without proper adjustment of snow
discharge angle.
16. Never operate machine at high transport
speeds on a slippery surface.
17. Use extra caution when backing up.
18. Disengage power to auger/fan when
transporting or when not in use.
19. Never operate the snowblower without
good visibility and lighting.
20. Prolonged exposure to loud noise can
cause impairment or loss of hearing.
Wear a suitable hearing protective device
such as earmuffs or earplugs to protect
against objectionable or uncomfortable
noises.
21. Never allow anyone near the work area.

SAFETY PRECAUTIONS - continued
OM 0393SB-A 8
THETRACTOR
General Information
1. Read the operator's manual carefully before
using tractor. Lack of operating knowledge
can lead to accidents.
2. Do not permit anyone but the operator to
ride on the tractor. There is no safe place
for passengers.
Operating the Tractor
1. Never run the tractor engine in a closed
building without adequate ventilation, as
the exhaust fumes are very dangerous.
2. Adopt safe driving practice. If so
equipped, keep the brake pedals latched
together at all times unless independent
braking is required. Never use
independent braking during transport.
3. Always drive at a safe speed relative to
local conditions and ensure that your
speed is low enough for an emergency
stop to be safe and secure.
4. Reduce speed prior to turns to avoid the
risk of overturning. Keep speed to a
minimum.
5. Always keep the tractor in gear to provide
engine braking when going downhill. Do
not coast.
6. Never allow an open flame near the fuel
tank or battery.
7. Park the tractor/snowblower on level
ground, place the transmission in neutral,
set the parking brake, disengage the
equipment drive, lower the equipment to
the ground, place all levers including
auxiliary control levers in neutral, shut off
the engine and remove the ignition key
BEFORE leaving the tractor.
8. Never park the tractor on a steep slope.
9. Do not attempt to operate on steep slopes.
Avoid sudden uphill turns on steep slopes.
10. Handle fuel with care, as it is highly
flammable.
11. Use approved fuel container.
12. Never add fuel to a running engine or a hot
engine.
13. Fill fuel tank outdoors with extreme care.
Never fill fuel tank indoors. Replace fuel
cap securely and wipe up spilled fuel.
14. Never allow anyone to operate the
snowblower until they have read the
manual completely and are thoroughly
familiar with basic tractor and snowblower
operation.
15. Make sure the tractor is counterweighted
as recommended by your dealer. Weights
provide the necessary balance to improve
stability, traction and steering. Please refer
to tractor's operator's manual for proper
ballasting information.
16. Always make sure all snowblower
components are properly installed and
securely fastened BEFORE operation.
17. Never attempt to start the engine and/or
engage snowblower drive while standing
beside the tractor.
18. Always start the engine from the operator's
seat with all the transmission lever(s) and
snowblower drive lever in neutral.
19. DO NOT bypass the safety system by
shorting across the terminals of the starter
motor to start the engine. This may cause
the tractor to move suddenly.
20. If the safety start system does not work,
consult your dealer immediately.

SAFETY PRECAUTIONS - continued
OM 0393SB-A 9
During Operation
1. Do not allow passengers on the
tractor/snowblower at any time. There is no
safe place for passengers on this
equipment. The operator MUST sit in the
tractor seat.
2. Eye and hearing protection is
recommended when operating the
snowblower.
3. Operate only during daylight hours, or when
the area is well lit with bright artificial light.
4. Park the tractor/snowblower on level
ground, place the transmission in neutral,
set the parking brake, disengage the PTO,
lower the equipment to the ground, place all
control levers in neutral, shut off the engine
and remove the ignition key BEFORE
leaving the operator’s seat.
5. Inspect the snowblower after striking any
foreign object to assure that all snowblower
parts are safe and secure and not
damaged.
6. Be especially observant of the operating
area and terrain. Watch for holes, rocks, or
other hidden hazards. ALWAYS inspect the
area prior to operating snowblower.
7. DO NOT operate snowblower near the
edge of drop-offs or banks.
8. DO NOT operate snowblower on steep
slopes as overturn may result.
9. Operate up and down (not across)
intermediate slopes. Avoid sudden starts
and stops.
10.Drive tractor backwards up steeper slopes
with blower off. Operate blower as you
travel down the slope.
11.Slow down before you change directions on
any slope.
12.Use wheel weights on your tractor to
increase stability on slopes.
13.Never stand alongside of the unit while the
engine is running.
Roll-Over Protective Structure (ROPS) (If so
equipped)
1. DO NOT weld, drill or alter the ROPS.
Damaged ROPS must not be straightened
or used. If damage does occur, consult
your dealer.
2. If the ROPS is lowered or removed from
the tractor for any reason, it must be
erected and/or refitted immediately.
Original bolts or equivalent replacements
must be used and tightened to the correct
torque.
3. Your dealer does not recommend usage of
tractor with ROPS removed.
4. If a fold-down ROPS is used, the ROPS
can be folded down for storage, but it must
be pinned in the upright position prior to
operation.
5. Seat belt usage: With ROPS installed on
the tractor it is imperative that the seat belt
be installed, used and correctly adjusted,
at all times. DO NOT use a seat belt if
operating without ROPS.
6. Additional safety equipment: A fire
extinguisher and first aid kit should be kept
readily accessible.

SAFETY PRECAUTIONS - continued
OM 0393SB-A 10
MAINTENANCE
ALWAYS USE GENUINE PARTS WHEN
REPLACEMENT PARTS ARE REQUIRED
1. Keep the tractor and snowblower properly
maintained.
2. Park the tractor/snowblower on level
ground, place the transmission in neutral,
set the parking brake, disengage the
equipment drive, lower the equipment to the
ground, place all control levers in neutral,
shut off the engine and remove the ignition
key and allow the rotating parts to stop
BEFORE making any snowblower
adjustments.
3. To avoid injury, do not adjust, unclog or
service the snowblower with the tractor
engine running. Make sure rotating
components have completely stopped
before leaving the operator’s seat.
4. Keep the tractor/snowblower clean. Snow
and ice build-up can lead to malfunction or
personal injury from thawing and refreezing
in garage.
5. Always wear eye protection when cleaning
or servicing the snowblower.
6. Service the unit in safety: DO NOT service
the tractor while the engine is running or
hot, or if the unit is in motion. Always lower
snowblower to the ground. If necessary to
service unit with blower raised, securely
support with stands or suitable blocking
before working underneath. Do not rely on
hydraulically supported devices for your
safety. They can settle suddenly, leak
down, or be accidentally lowered.
7. Do not attempt to service machine, clear
obstructions or unplug blockages with the
engine running. Always shut off engine and
allow all motion to cease.
8. The manufacturer will not claim
responsibility for fitment of unapproved
parts and/or accessories and any damages
as a result of their use.
9. Make sure all shields and guards are
securely in place following all service,
cleaning, or repair work.
10. Do not modify or alter this equipment or
any of its components or operating
functions. If you have questions concerning
modifications, consult with your dealer.
11. Do not operate a unit, which is defective or
has missing parts. Make sure that all
recommended maintenance procedures
are completed before operating the unit.
12. Check all controls regularly and adjust
where necessary. Make sure that the
brakes are evenly adjusted.
13. Periodically check all nuts and bolts for
tightness, especially wheel hub and rim
nuts.
14. Snowblower fan and auger must be
checked for tightness. Remove any twine,
wire, etc. that may have wrapped on the
fan or the auger.
15. To avoid serious personal injury: Escaping
hydraulic/diesel fluid under pressure can
penetrate the skin causing serious injury.
Do not use your hands to check for leaks.
Use a piece of cardboard or paper to
search for leaks.
16. Stop engine and relieve pressure before
connecting or disconnecting lines. Tighten
all connections before starting engine or
pressurizing lines.

SAFETY PRECAUTIONS - continued
OM 0393SB-A 11
TRANSPORT
1. When driving the tractor and equipment on
the road or highway under 25 mph, at night
or during the day, use flashing amber
warning lights and the Slow Moving
Vehicle ("SMV") identification emblem.
2. Check local traffic codes that may apply to
unit usage on public roads and highways in
your area. The use of flashing amber lights
is acceptable in most localities. However,
some localities may prohibit their use.
3. Always disengage equipment drive prior to
transporting unit.
STORAGE
Before storing the snowblower, certain
precautions should be taken to protect it
from deterioration.
1. Clean the snowblower thoroughly.
2. Make all the necessary repairs.
3. Replace all safety signs that are damaged,
lost, or otherwise become illegible. If a part
to be replaced has a sign on it, obtain a
new safety sign from your dealer and
install it in the same place as on the
removed part.
4. Repaint all parts from which paint has
worn or peeled.
5. Lubricate the snowblower as instructed
under "Lubrication" section.
6. When the snowblower is dry, oil all moving
parts. Apply oil liberally to all surfaces to
protect against rust.
7. Store in a dry place.
.

DECALS
OM 0393SB-A 12
Replace immediately if damaged
Switches
Rotation Deflector
5RD2500782
5RD2500784
5RD2500608
5RD2500616
5RD2500783
5RD2500783
5RD2500785
5RD2500786
5RD2500790
5RD2500791
5RD2500787 5RD2500788
5RD2500789 5RD2500815
5RD2500833

Our support email:
[e-mail]
