FrontRow 230R User manual

user guide
230R receiver
4747 230R Multi-Freq User Guide 4/22/05 3:09 PM Page 2

contents
caring for your system . . . . . . . . . . . . . . .42
transmitters compatible
with the 230R receiver . . . . . . . . . . . . . . .43
Frontrow Tempo channel numbers
and corresponding frequencies . . . . . .44-45
product specifications . . . . . . . . . . . . . . . .46
warranty . . . . . . . . . . . . . . . . . . . . . . .47-49
regulatory compliance . . . . . . . . . . . . . . .50
introduction . . . . . . . . . . . . . . . . . . . . . . . .1
understanding active learning . . . . . . . . . . .2
installation tips . . . . . . . . . . . . . . . . . . . . .3
system guidelines . . . . . . . . . . . . . . . . . . .4
system components . . . . . . . . . . . . . . .5-6
230R receiver features . . . . . . . . . . . . .7-8
setup and operation . . . . . . . . . . . . .9-13
auxiliary input (aux in) . . . . . . . . .14-20
auxiliary output (aux out) . . . . . . .21-22
speaker setup . . . . . . . . . . . . . . . . .23-30
advanced system setup . . . . . . . . .31-35
optional accessories . . . . . . . . . . . . . . . .36-37
230R part number
cross-reference list . . . . . . . . . . . . . . . .38-39
troubleshooting . . . . . . . . . . . . . . . . . .40-41
4747 230R Multi-Freq User Guide 4/22/05 3:09 PM Page 6

introduction
Congratulations on the purchase of your new FrontRow Tempo™active learning system!
You may have heard the term ‘sound field’ used to describe technology that improves
classroom acoustics. Your FrontRow system fits under this category, but we call it an ‘active
learning system’ because it’s about so much more than just sound.
Active learning systems can help engage students, improve attentiveness to the teacher,
build learning success, reduce the achievement gap, foster control and orderliness, improve
test scores, and reduce vocal strain and fatigue for teachers. Numerous studies show that
classrooms using active learning enjoy better student comprehension, increased student
participation, better grades and fewer behavioral referrals.
Read this manual carefully to become familiar with your product and to get the most out of
its many features and options.
1
4747 230R Multi-Freq User Guide 4/22/05 3:09 PM Page 7

understanding active learning and its benefits
?
• distance
• noise
• echo
cough!
• distance
• noise
• echo
?
without active learning
with active learning
2
4747 230R Multi-Freq User Guide 4/22/05 3:09 PM Page 8

Before you set up your system, take a good look around your room. Where are the outlets
located? Where are the computers and other electronic equipment? Where can you put your
receiver so it's easy for you to reach, but out of the way of students and main traffic areas?
Though each classroom is different, there are some general guidelines for both receiver and
speaker placement:
The receiver — should be in the front of the classroom at teacher's eye level when standing,
close to a wall outlet.
4 Compact wall speakers — should be mounted as high as possible and angled down
toward the listeners' ears. Place them around the room so there is even coverage in the listening
area (where the students are seated). Use as many as needed — four is recommended.*
4 Distributed ceiling speakers — space them evenly above the students’ seating area.
A minimum ceiling height of 10 feet is necessary, and 12 feet is even better. Use as many
as needed — a minimum of four is recommended.*
Single Cluster ceiling speaker — should be centered directly over the students’ seating
area. A minimum ceiling height of 12 feet is recommended, and 14 feet is even better.
* For optimal speaker placement, download Sound field Wizard software from our website at www.phonicear.com.
installation tips
3
4747 230R Multi-Freq User Guide 4/22/05 3:09 PM Page 9

system guidelines
To help ensure that you get the most out of your new active learning system, we have put
together the following list of suggested guidelines:
Speak at a normal level — the system is projecting your voice for you.
Periodically check the volume and OptiVoice settings – these are often set and
then forgotten, but if accidentally changed, will affect how your system sounds.
Minimize the effects of feedback – avoid walking too closely to the speakers while
using the transmitter and microphone.
Place receiver in an open location – do not place the receiver in, or close to a metal
cabinet or enclosure. FM signals are effected by metallic objects and the receiver requires
proper cooling and ventilation.
Attach antenna – the receiver will not operate without the FM antenna.
Turn unit off while not in use – turning the unit off when not in use saves energy and
still allows the receiver to recharge the 330T/340T transmitter batteries when connected to
the rear of the receiver.
4
4747 230R Multi-Freq User Guide 4/22/05 3:09 PM Page 10

5
system components
8
910
57
11 12
4
6
12 3
4747 230R Multi-Freq User Guide 4/22/05 3:09 PM Page 11

6
8 aux out cable/(RCA 3.5mm)
(AT0805)
9 aux-in adaptor plug /(1
/4in – Dual RCA)
(310-2544-1342)
10 aux-out adaptor plug/(3.5mm – 2.5mm)
(310-2544-1341)
5 power supply
(040-7402-105)
7 antenna
(AT0831)
11 330T transmitter charging cord
(1.3mm – Dual 1.3mm)
(300-6497-105)
4 microphone/(AT0655 boom
microphone shown here)
12 speaker wire
(AT0581)
(Plenum rated, 24ft/7.3m, 48ft/14.6m,
60ft/18.3m lenths)
6 power cord
(AT0787 for USA/Canada)
(AT0787-EN for England)
(AT0787-EU for Europe)
(AT0787-AU for Australia and
New Zealand)
2 body-worn transmitter
(330T shown here)
1 230R base station receiver
3 speakers (470-2856-119)
(compact wall speaker shown here)
*speakers packaged separately
NOTE: Refer to part number cross-reference list
4747 230R Multi-Freq User Guide 4/22/05 3:09 PM Page 12

7
230R receiver features
front
back
7
2 3
4
56
8
911 12 13 14 16
17
10 15
18
1
4747 230R Multi-Freq User Guide 4/22/05 3:09 PM Page 13

8
3 channel adjustment button
4 FM receiver signal light
1 channel display
6 FM Volume control
5 OptiVoice™control
7 aux Volume control
8 power button
9 power cord jack
10 transmitter charge jack (1.3mm)
11 3-band equalizer adjustment
12 aux in jack (1 /4in)
13 speaker wire terminals
14 number of speakers switch
15 aux out port (RCA)
16 aux out level control
17 squelch adjustment
18 antenna
2 sleep/standby power indicator light
4747 230R Multi-Freq User Guide 4/22/05 3:09 PM Page 14

9
connecting power to 230R receiver
1
230R back
Plug power supply (040-7402-
105) into power port on back of
230R receiver
Plug power cord (AT0787) into
power supply unit (040-7402-105)
1
2
040-7402-105
1
3
2
AT0787
Plug power cord (AT0787) into
wall socket
3
4
Check to see that green light is on,
indicating that unit has power
4
setup and operation
5
Attach antenna to antenna port on
back of 230R receiver
5
4747 230R Multi-Freq User Guide 4/22/05 3:09 PM Page 15

10
Push power button
Confirm that LED channel
display lights
turning on 230R receiver
2
1
2
1
2
4747 230R Multi-Freq User Guide 4/22/05 3:09 PM Page 16

11
Push channel up/down buttons to
change channel setting
Confirm receiver channel matches
transmitter channel
adjusting channel setting
3
1
2
1
2
340T (Front)
NOTE: See “FrontRow Tempo channel
numbers and corresponding frequencies”
section for a complete list of Phonic Ear
channel numbers and corresponding
frequencies.
330T (Back)
or
US/Canada Intl/EU
4747 230R Multi-Freq User Guide 4/22/05 3:09 PM Page 17

12
adjusting OptiVoice™ setting
1Set OptiVoice switch according to room
noise level. Medium position is the rec-
ommended setting for average noise levels.
1
4
high: Use in high noise levels. Helps to ensure top comprehension during critical tasks
such as test-taking or hearing impaired instruction.
NOTE: With each increase in level, there is an increase of approximately 3dB in gain
(volume). This may require a decrease in the receiver volume setting to avoid potential
microphone/speaker feedback.
OptiVoice is a 3-position switch that automatically adjusts the sound quality of the primary
speaker’s voice. It allows teachers to shape the sound of their voice and helps to ensure maxium
speech clarity in low, medium and high noise levels.
low: Use in low-noise situations and for most
natural voice quality.
medium: Best setting for average classrooms
where low-medium noise levels are present.
4747 230R Multi-Freq User Guide 4/22/05 3:09 PM Page 18

13
Follow steps or below to set FM volume to
proper level. Two people are needed to properly set the
volume level. It is difficult to hear your own voice and
make adjustments to it.
setting FM volume
5
1
1
With a sound level meter - Take a level reading in the “A” setting in the center of the room
during normal classroom activity, and another reading of the teacher's amplified voice (with-
out the class activity). The level of the teacher's voice should be set between 10-15 decibels
above room noise level.
Without a sound level meter - First, ask someone to help you set the volume to a com-
fortable listening level. As your listener, they should also be the person making adjustments to
the volume setting. The speaker should begin talking into the microphone at their normal
speaking level while the listener determines the appropriate volume setting. The recommended
volume setting is achieved when the sound from the loudspeakers and the speaker’s voice are
the same level. If the speaker can hear their own voice through the loudspeakers, the volume
setting is too high.
NOTE: The average volume setting is between 4–5, but
may change depending on room acoustics and noise level.
2
12
4747 230R Multi-Freq User Guide 4/22/05 3:09 PM Page 19

14
m
h-
d
ut
el.
connecting CD, TV and other audio sources (optional)
For most connnections from CD
player, TV, stereo or other audio
sources, insert aux-in adaptor plug
(310-2544-1342) into aux in port
1
1
6auxiliary input (aux-in)
310-2544-1342
AT0702-25
or
300-6332-107
Connect audio source to adaptor
plug using AT0702-25 or 300-
6332-107 (optional accessories –
not included with system. See
“Optional accessories” list)
2
2
4747 230R Multi-Freq User Guide 4/22/05 3:09 PM Page 20

15
team-teaching with 211 receiver and handheld
microphone system*
211R (back)
230R (back)
Connect one end of the AT0573-1
cable to Output jack on back of
211R unit
1
2
2
1
Connect the other end to the
aux in jack on back of the 230R
receiver
3
3Extend 211R receiver antenna
7
*Available in U.S. and Canada only.
4747 230R Multi-Freq User Guide 4/22/05 3:09 PM Page 21

16
211R (back)
second teacher,
or student
230R (front)
No channel change is necessary on
the 211R and handheld mic – they
are factory set to match
Make sure that channel numbers
indicated on front of 230R receiver
matches channel number on the
transmitter
4
5
first teacher
340T (front)
5Adjust the Aux Volume control
on front of 230R to proper level
7
7
AT0573-1
Set Volume control on back of
211R to approximately 1/3of the
way to it’s highest level setting
6
6
4
8team-teaching with 211 receiver and handheld
microphone system (cont’d)
330T (back)
or
4747 230R Multi-Freq User Guide 4/22/05 3:09 PM Page 22

17
team-teaching with body-worn personal receiver &
transmitter units
Insert aux-in adaptor plug (310-
2544-1342) into aux in port on
back of 230R
1
Connect aux-in adaptor cord (300-
6332-107) to adaptor plug. (Match
red to red and white to white.)
2
300-6332-107
1
3
receiver
NOTE: Second teacher should be wearing a
transmitter on same channel as receiver (see
diagram on next page)
*
*If a different receiver is used, a different
adaptor cord may be required.
310-2544-1342
2
Plug other end of aux-in adaptor
plug into aux jack on body-worn
receiver
3
9a
4747 230R Multi-Freq User Guide 4/22/05 3:09 PM Page 23

18
team-teaching with body-worn personal receiver &
transmitter units (cont’d)
First Teacher
Make sure the channel number of
230R receiver matches the channel
number of your 330T/340T (or
other transmitter)
3
Second Teacher*
Make sure the channel number on
personal receiver matches channel
number on personal transmitter
4
second teacher
4
230R (front)
first teacher
3
41
receiver
transmitter
330T/340T
9b
Set volume level on personal team-
teaching receiver to 2/3max (6 -7 out
of 10).
5
Set aux volume level on 230R to
comfortable level (between 4 -5).
6
6
5
* Refer to the following page for channel pair combinations
not recommended with a 72MHz system.
32
32
same channel
same channel
4747 230R Multi-Freq User Guide 4/22/05 3:09 PM Page 24
