FrontRow JUNO User manual

Juno Bluetooth®Audio Receiver
Installation Guide
Image 3
Image 1
Image 2
General Safety Precautions
• Disconnect all electronics from the Juno Tower during installation
of this module
• Do not install or use the module near water or heat sources
• Use only accessories specified by FrontRow
• Refer installation and service to qualified personnel
ESD Warning
The Juno Tower and/or expansion modules can be damaged
by electrostatic discharge (ESD). When handling, care must
be taken so that the devices are not damaged. Damage due
to inappropriate handling is not covered by the warranty.
The following precautions must be taken when installing the
expansion modules:
• Use a conductive wrist strap attached to a good earth ground.
• Always disconnect the power to the Juno from the power outlet.
• Always discharge yourself by touching the grounded bare metal
surface or approved anti-static mat before picking up
an ESD-sensitive electronic component.
• Use an anti-static mat to cover your work surface.
You will need the following items to install this module:
• #1 Phillips screwdriver
Installation
1. Unplug the Juno Tower from the power outlet
2. Lay the Juno Tower down on a flat surface with the back of the Tower
facing up. Remove the 8 screws that attach the back panel to the case
back and remove the back panel (See Images 1 & 2)
3. Locate the area on the lower circuit board where the module will
be installed. (See Image 3). Note that if you already have a
Juno Speaker Expansion module installed this will need to be
removed. You cannot use both the Speaker Expansion and the
Bluetooth module.
4. Remove the Bluetooth module and plastic cover from the packaging.
(See Image 4)
5. Unplug white connector from the main Tower PCB. (See Image 5)
6. Plug white connector into the connector on the Bluetooth module.
(See Image 6)
Image 4
Installation instructions continued on back
Image 5 Image 6

1530-00012/Rev A 0917
Installation - continued
7. There is a 10-pin connector in the middle of the Bluetooth
board and a 3-pin connector at the top. Gently seat the
Bluetooth board onto the main board and press into place,
being very careful not to bend or damage the pins.
TIP: Use the screw holes to help alignment. (See Image 7).
8. Secure the board to the main circuit board using the four
included screws. (See Image 8)
9. Remove the top plastic cover from the back panel and then
replace with the Bluetooth module cover. (See Image 9)
NOTE: If you have a Juno Connect module already installed,
go to step 11.
10. Place the back panel back on the Juno and secure the 8 screws.
(See Image 10)
Image 7
Image 8
Im age 11
Image 13 Image 14
Image 12
Perform these steps if the Juno Connect module is already installed:
11. Remove the Juno Connect module cover. (See Image 11)
12. Place the back panel back on the Juno and secure the 8 screws. (See Image 12)
13. Insert the microphone element into the slot on the back of the Juno Connect module cover, then snap
it into place. (See Images 13 and 14)
Image 9 Image 10
Testing
To test your installation:
1. Power up the Juno.
2. Press the Bluetooth button
to initiate pairing.
3. Go to your Bluetooth
settings on your device
and select the Juno.
4. Play some audio. Adjust
levels accordingly using the
Audio input 4 control from
the Juno LCD.
5. Connect your device to the
3.5mm audio input on the
front of the Juno and play
audio. This will confirm that
the Bluetooth board was
connected properly.
