FROST UNU U4130 Install guide

1
Fitting instruction
Montageanleitung
Monteringsvejledning
Monteringsvägledning
Montage hanleiding
Manuel de montage
UNU MIRROR
U4130, U4131,U4134 & U4142
Cleaning and maintenance
Surfaces should be cleaned with a microbre
cloth, glass cleaner or other non abrasive and
gentle agents.
Attention:
Never use solvents or aggressive household
cleaners like bleach, acids (e.g. descalers) or
ammonia-based bathroom cleaner to clean
the product. Steel wool and hard brushes can
permanently damage the surfaceof the steel.
Material: Aluminium
Design: Bønnelycke mdd
Manufacturer: FROST A/S
Exclusion of liability
FROST accepts no liability whatsoever
for damage to persons or property that
occurs or has occurred as a result of
improper installation or maintenance,
particularly if the safety instructions
and other points to note listed are not
or have not been observed in full.
Warning and hazard notices
Improper mounting or use can lead to
accidents and serious injuries.
30 mm
U4134: Ø400 mm
2 mm
U4130: Ø600 mm
U4142: Ø800 mm
U4134: 200 mm
U4130: 315 mm
U4131: 555 mm
U4131-BU4130-BU4134-B U4142-B
U4131-WU4130-WU4134-W U4142-W
U4131-CU4130-CU4134-C U4142-C
U4131-GOU4130-GOU4134-GO U4142-GO
U4131-BOCU4130-BOCU4134-BOC U4142-BOC
U4131-BMGU4130-BMGU4134-BMG U4142-BMG
U4131: Ø1000 mm
U4142: 400 mm

2
4x 4x
Ø5 - L40Ø8 - L40
AB
A
B
2x Ø8
U4134: 200 mm
U4130: 315 mm
U4142: 400 mm
U4131: 555 mm
U4134: 200 mm
U4130: 315 mm
U4142: 400 mm
U4131: 555 mm
Use bit PH2
