MenuMODELS:FS-GT21Digital propotional radio control systemHttp://www.flysky-cn.com 1.Introduction.......................................2
2.Services.......................... . ...............2
3.The special symbols..............................34.Safty guides.......................................35.Battery charging notes...........................4
6.Transmitter parameters.........................5
7.Receiver parameters.............................5
8.Receiver connectivity............................6
9.2.4G Operation notes............................8
10.Each part of the transmitter....................10
12.Simulate.............................................13
13.......................14Exploded Drwing..........
11.Transmitter function notes.....................11
14.....................15Packaging with content list..

MODELS:FS-GT22Digital propotional radio control systemHttp://www.flysky-cn.com 1.Introduction2.Services HTTP:WWW.FLYSKY-CN.COM HTTP:WWW.FLYSKY-CN.COM 非常感谢您选择使用 2.4G数码比率遥控产品，如果你是第一次使用该类型产品，请您在使用之前先仔细阅读此说明书，并严格按说明要求进行操作。在操作过程中您如果遇到问题同样可以查看说明书。说明书在使用完后请您妥善保管好，以备后用。再次感谢您使用 的产品，并希望它能给您带来快乐。 如果您在使用过程中发现有问题,请您第一时间先查看数控明书.如果问题还不能解决,您可以跟我们的经销商联系解决.您也可以登陆我们的服务中心网站:

3.The special symbols
Please pay attention to the following symbols when it appears on the manual,and read carefully.
ProhibitionMandatory4.Safty guides
MODELS:FS-GT23Digital propotional radio control systemHttp://www.flysky-cn.comDanger:
Warning:
Attention:
The sequence to shutdown is that turn off the receiver power first, and then the
If the above operations are reverse, it might lead to uncontrolled and cause
停止使用前请您先关闭接收机电源然后关闭发射机电源。以上操作如果反向,可能导致失控,从而产生意外!Accident.
You need to turn the throttle channel(ch2) and inching switch to the lowest before
开机使用时请您勿必先将油门通道（CH2）及微调置最低端。然后打开发射机电源并检查电源电量，再接通接收机电源。You use. Then switch on the transmitter power ,finally connect the receiver.
Before you fly, please make sure the movement of server correspond with the
在飞行前,请您务必先检查伺服器的各项动作是否与对应操纵杆的方向一致,如果不一致,请调整后再使用.direction of joysticks. If inconsistent, please adjust before fly.
Don’t fly in night ,bad weather such as rainy or thundering days .It will interfere the
请您不要在夜晚，刮风或下雨时使用，因为这样的天气环境会对遥控设备产生干扰,从而导致失控而产生意外!
If the operator does not operate by following the instructions,the operator
如果操作者不按正常操作方法操作，可能导致操作者严重受伤，甚至致命危险！may lead to serious injuries, even mortal danger.
If the operator does not operate by following the instructions,the operator
如果操作者不按正常操作方法操作,可能导致操作者严重外伤,重伤或者致命情况!may lead to serious injuries, even mortal danger.
If the operator does not operate by following the instructions,the operator
如果操作者不按正常操作方法操作,可能会导致操作者轻伤,但一般不会对操作者造may lead to minor injuries, but generally it will not cause serious injuries to the operator.成重伤!transmitter power.transmitter signal.Thereby it will create out of control and unexpected accident .

5.Battery charging notes5.01Transmitter charger:A. Install the battery to transmitter with correct direction, and cover it. B. Connect the charger to the connector. commercial powerC. Connect the charger to the transmitter Connector. D. Cut off the power supply immediately after Recharge completed.A. Connect the charger to the commercial power connector. B. Connect the Rechargeable receiver with battery chargerC. Recharge completed, cut off the power supply immediately.MODELS:FS-GT24Digital propotional radio control systemHttp://www.flysky-cn.comIf your transmitter, receiver using a nickel-cadmium, nickel-metal hydride rechargeable battery, you have to well-check before you use. If lack of electricity, it could happen those phenomenon like inadequate control or out of control, resulting accident. So please charge immediately when 如果您的发射机.接收机使用的是镍镉.镍氢等可充电电池,在使用前请您务必检查电池电量.如果电量不足,可能导致控制距离不够或者失控的现象,从而产生意外.所以电池电量不足时请及时充电.If you are using a nickel-cadmium, nickel-metal hydride batteries for recharging, please use our company dedicated charger. If the electrical current is too large and it may lead to temperature over-heated and cause fire burning accident. Please cut off the power supply immediately after recharging. Please take out the battery from the transmitter when you are not using it within a period, it is because the battery may damage the aircraft batteries, thus being exposed.如果您使用的是镍镉.镍氢电池进行充电,请您使用我们公司的专用充电器.因为如果充电电流太大可能导致电池温度太高,从而燃烧起火带来意外。充电完成请您即时切断电源。当您长时间不使用时请您电池从发射机中取出，因为电池可能导致发射机电池片损坏，从而接触不良。5.02Receiver charger:1.将可充电电池按方向装入发射机，并合上电池盖；2.将充电器插入市电接口；3.将充电器充电接头插入发射机充电接口；4.充电完成后，即时将电源切断。1.将充电器插入市电接口；2.将可充电接收机用电池接口与充电器充电接口连接；3.充电完成后,即时将电源切断. lacks of electricity.the battery

MODELS:FS-GT25Digital propotional radio control systemHttp://www.flysky-cn.com6.Transmitter parameters159mm
315mm
7.Receiver parameters1.通道数：2个通道；2.适合机种：车，船；3.发射功率:小于20dbm；4.调制方式：GFSK；5.编码方式：数字；6.数据分辩率：1024级；7.低电压报警功能:有(低于9伏后)；8.数据输出接口:有(3.5音频接口）；9.充电接口：有（内正外负）；10.电源标准:12VDC(1.5AA*8)；11.整机重量：328g;12.天线长度：26mm;13.外型尺寸：159*99*315mm;14.外观颜色：黑色；15.认证:CE FCC；Specifications:Specifications:A.channels:2channels;B.model type:car/boat;C.RF power:less than 20dbmD.modulation:GFSK;E.Code type:digital;F.sensitivity:1024;G.low voltage warning:yes(less than 9V);H.DSC port:yes(3.5mm);I.Charger port:yes;J.power:12vdc(1.5aa*8);K.weight:328g;L.ANT length:26mm;M.size:159*99*315mm;N.color:black;o.certificate:CE FCC;MODEL:FS-GT2MODEL:FS-GR3A1.通道数：3个通道；2.适合机种：车，船；4.调制方式：GFSK；5.数据分辩率：1024级；8.整机重量：5g;9.天线长度：26mm;10.外型尺寸：37.6*22.3*13mm;11.外观颜色：灰色透明；12.认证:CE FCC；A.channels:3 channels;B.model type:car/boat;D.modulation:GFSK;E.sensitivity:1024;G.power:4.5-6vdc;H.weight:5g;I.ANT length:26mm;J.size:37.6*22.3*13mm;K.color:gray semi-transparent;L.certificate:CE FCC;C.frequency band:2.4GF.RF.receiver sensitivity:-100dbm3.频率：2.4G；6.接收灵敏度：－100dbm;7.电源：4.5－6伏；

MODELS:FS-GT26Digital propotional radio control systemHttp://www.flysky-cn.com
Receiver接收机
Servo伺服器
CH1CH28.Receiver connectivitySPC调速器
SWITCH
BATTERY电池
MOTOR马达
8.01 INSTALLATION WHEN A MOTOR CONTROLLER IS USED 带马达模型的安装连接注：在安装接收机时请将接收机天线与水平面垂直放置！且天线尽可能不要靠近金属物！因为这样接收灵敏度最高。(如图1）
开关
Remark:Place the antenna of the receiver vertically with the plane! And don't let it close to the metal thing for assuring its sensitivity.(See pic1)
ReceiverANTFigure 1 (图1)

8.02 INSTALLATION FOR GAS POWERED MODELS 发动机模型的安装
MODELS:FS-GT27Digital propotional radio control systemHttp://www.flysky-cn.com
Battery(1.5AA*4)
SWITCH
Servo伺服器
方向系统
电池开关THROTTLE油门STEERING SYSTEMReceiver 接收机

MODELS:FS-GT28Digital propotional radio control systemHttp://www.flysky-cn.com9.2.4G Operation notesMatch line对码线Figure 1Bind key9.01 Matching (code)A. Install the battery to 2.4G transmitter and shut it down.B./ (Insert the matching lines to the channel BINDCH3 port of the receiver.Figure.
C.Connect the receiver battery to VCC port of the receiver, on the same time the two LED are flashing
D.Press and hold the button on the transmitter, and then switch on the power supply.
F.Release the match button on the transmitter, take out the match line.
E. Observe the LED on the receiver, if find that the LED is not flash anymore andthat means successful
G.Install the server and then test.H.If the tests fail, please repeat the action above.I.If the tests success, then insert the power supply port into VCC, match complete.(The above ways of match is only suitable for FLYSKY 2.4G products)Our products are well matched in the factory, you do not need to match by yourself. But if your are going to match the receiver with other transmitter, or you need to change a new receiver or transmitter, please follow the following steps:and this means the receiver are going to the matching status.
Matched.This process about 5s（)我们的产品在出厂前已经过配对，您无需做配对动作便可使用。但如果您要将接收机跟另外的发射机进行配对使用，或者您要更换新的接收机或者发射机，请您按如下的步聚进行：注:我们的接收发射系统,不跟其它品牌兼容!3.将接收机电池插入接收机的VCC通道接口,此时可看到接收机的LED在闪烁,此表示接收机进入配5.观察接收机上的LED,如果发现LED不再闪烁表示配对成功.(注:此过程大约时间为5S左右）.1.将2.4G发射机装好电池，并关闭发射机。2.将配对线插入接收机的BIND/CH3通道接口（如图1）.4.将发射机上的配对键(BIND)按住，然后打开发射机电源开关。（注：不要松开按键）。6.松开发射机上的配对按键,拔掉接收机上的配对线.7.将伺服器装上并通电测试.8.如果测试NG,则重复以上动作.9.如果测试OK，则将电源接头插入VCC，配对完成。注:以上配对方法,仅适合于FLYSKY的2.4G产品。对状态.LED
Battery电池
Receiver接收
对码按钮(图1)

MODELS:FS-GT29Digital propotional radio control systemHttp://www.flysky-cn.comPower onA.Cut off the receiver power supply.B.Cut off the transmitter power supply.Tx power ONTx power offRx power ONRx power offShut down9.03 Shut down：9.02 power on:A.Connect every part.B.Switch on the power supply C.Connect the power supply of the receiuer.D.Receive LED light solid.E.Finish and use.1.关闭接收机的电源；2.关闭发射机的电源.1.将各部件连接好；2.打开发射机电源开关；3.连通接收机电源；4.接收机LED恒亮；5.使用.of the transmitter.

MODELS:FS-GT210Digital propotional radio control systemHttp://www.flysky-cn.comDSC FOR SIMULATECHARGERTHROTTLE TRIGGER58899POWER SW566772.4G ANTAACCDDEEBAT BOXFFSTEERING WHEEL BBFRONTSIDEBACKGG10.Each part of the transmitterCONTROL BOXST REVTH REVD/RST TRIMTH TRIMPOWER LEDPOWER CHECKBIND

MODELS:FS-GT211Digital propotional radio control systemHttp://www.flysky-cn.com11.Transmitter function notes功能说明：此功能是进行方向控制，当方向舵往右旋转时车子前轮会跟着往右（如图），当方向往舵左旋转时车子前轮会跟着往左（如图）.11.01方向舵控制操作方法：开机后,通过方向舵进行方向控制,方向舵动作大小依据实际情况进行比率调整.方向舵大小动作量可通过D/R进行大小舵量的调整。Function Introduction:This function is to control the direction, when the steering turn to right then the front wheel will turn to right Operation Method:Adjust the dual rate of the steering by adjusting the D/R knob.(as picture), when the steering turn to left then the front wheel will turn to left (as picture).

MODELS:FS-GT212Digital propotional radio control systemHttp://www.flysky-cn.com功能说明：此功能是进行油门(速度)控制，当油门扣机往后打时车子会向前加速（如图），当油门扣机往前推时车子会进行刹车或加速后退(依据不同的调速器)（如图）.操作方法：开机后,通过油门扣机进行前后运行的控制.11.02油门控制Function Introduction:This function is to control the throttle speed, when pull the throtte trigger back,car will accelerate forward (see the picture), throttle trigger, the car will put on the brakes or double ring astern(according to the different ESC) (see the picture). Operation Method:To control it by pushing and pulling back the throttle trigger after power on.the when push

MODELS:FS-GT213Digital propotional radio control systemHttp://www.flysky-cn.comTO COMPUTER USB PORT12.SIMULATE功能说明：操作方法：此功能用于电脑模拟，从而可通过电脑进行练习，及进行电脑模拟比赛。1.将本厂提供的电脑模拟连接线(FS-SM100)一端插入发射机的DSC接口，另一端插入电脑的USB接口，
2.打开发射机电源。3.启动VRC车模应用软件。4.按软件要求进行设定完成后便可进行电脑模拟了。备注：本公司提供的是VRC公司的免费软体，此软件只提供一条基本赛道和一个训练场。如需其它赛道请跟VRC公司联系。谢！Function Introduction:This function is for the virtual RC racing through the computer, you can practise the racing from the computer.Operation Method:1.Hook up the DSC port of your Transmitter to the USB adaptor (fs-sm100) and plug the USB adaptor into your PC notebook.2.Turn on the Transmitter.3.Open the VRC software.4.Follow the on-screen instruction to set.Remark: The VRC software we provided is free which is offer only one basic track and training ground. If you need any other track, please contact VRC Company, thank you!MODEL NO:FS-SM100

13.EXPLODED DRWINGMODELS:FS-GT214Digital propotional radio control systemHttp://www.flysky-cn.com

NO:ModelSumRemarks123456
2 channel 2.4Gtransmitter（FS-GT2)
3channel 2.4Greceiver(FS-Gr3A)MANUALChargerServo(FS-S009)111112OptionalOptionalOptional
MODELS:FS-GT215Digital propotional radio control systemHttp://www.flysky-cn.com
2 通2.4G发射
说明书
充电器
伺服器
可可选选的的
可选的
14.Packaging with content list3通2.4G接收FS-GT2Http://www.flysky-cn.comCopy right 2008@flysky co.,ltdDigital propotional radio control sytemGT2INSTRUCTION MANUAL用户手册FS-SM100模拟线
