T3-IPS / HV-T3 CABLE RETRACTOR INSTALLATION INSTRUCTIONS
GUIDE BRACKET
T3-IPS (SOLD SEPERATELY)
HANGER SUPPORT
1. PRIOR TO INSTALLING T3-IPS ASSEMBLY (SOLD SEPERATELY) INTO
TABLE (SEE T3-IPS INSTALLATION INSTRUCTIONS), INSERT GUIDE
BRACKET INTO T3-IPS AND SECURE WITH #6 PAN HEAD SCREWS.
(4) #6 PAN HEAD SCREW
2. DETERMINE WHICH SIDE RETRACTOR WILL BE LOCATED
(LEFT-SIDE MOUNTING SHOWN) AND MOUNT HANGER SUPPORT
AGAINST FRONT SIDE OF T3 MOUNTING BRACKET AND CHASSIS
SIDE WITH #6 HARDWARE.
(2) #6 SELF TAPPING
SCREW
CHASSIS SIDE
BACK SIDE OF
T3 MOUNTING
BRACKET
EDGE AGAINST CHASSIS SIDE
FACE AGAINST FRONT SIDE
OF T3 MOUNTING BRACKET
BACK OF T3-IPS
ASSEMBLY
6a. ALIGN RING-PIN HOLES AND INSERT RING-PIN ON ASSEMBLY. FOR
THE ADDITIONAL SECURITY OF A TAMPER-PROOF INSTALLATION,
INSTALL #6-32 x 1/4 LONG FLAT HEAD SCREW, AS SHOWN.
RING-PIN
CLEVIS PIN
6b. LOOSEN ADJUSTABLE HANGER WINGNUT. ALIGN ADJUSTABLE
HANGER HOLES WITH RETRACTOR FLANGE HOLES, ENSURING THE
HANGER IS VERTICAL AS POSSIBLE, AND INSERTCLEVIS PIN. SECURE
CLEVIS PIN WITH HAIR-PIN COTTER.
6c. LIFT RETRACTOR ASSEMBLY TO TAKE UP ALL SLACK AND TIGHTEN
ADJUSTABLE HANGER WINGNUT TO ENSURE ASSEMBLY WEIGHT IS
CARRIED BY THE TABLE. HANGER NUT CAN BE TIGHTENED FOR
ADDITIONAL INSTALLATION SECURITY.
ADJUSTABLE HANGER
NUT LOCATED ON
OPPOSITE SIDE
OF WINGNUT
HAIRPIN-COTTER
#6 FLAT HEAD SCREW FOR
TAMPER-PROOF INSTALLATION

NOZZLE
CAPTURE
BRACKET
(RIGHT)
3. INSTALL ADJUSTABLE HANGER ONTO HANGER SUPPORT WITH CLEVIS
PIN AND SECURE WITH HAIR-PIN COTTER.
CLEVIS PIN
ADJUSTABLE HANGER
HAIR-PIN COTTER
NOTE WINGNUT LOCATION
NOZZLE
CAPTURE
BRACKET
(LEFT)
OR
CHASSIS SUPPORT BRACKET
(2) #6 FLAT HEAD SCREW
#6 FLAT
HEAD
SCREW
#6 PAN HEAD SCREW
4. INSTALL NOZZLE CAPTURE AND SUPPORT BRACKETS
ONTO RETRACTOR WITH #6 HARDWARE.
RETRACTOR
5. SLIDE RETRACTOR ASSEMBLY UP INTO T3-IPS ASSEMBLY.
RING-PIN HOLE
RING-PIN HOLE
RETRACTOR ASSEMBLY
THE RETRACTOR "NOZZLE" ASSEMBLY MAY REQUIRE
LOOSENING IN ORDER TO EASILY INSTALL THE
NOZZLE CAPTURE BRACKET. REMOVE THE UPPER
NOZZLE-FIXING SCREW AND LOOSEN THE LOWER
SCREW - THIS WILL ALLOW THE NOZZLE TO TILT AND
ALLOW INSTALLATION OF THE CAPTURE BRACKET.
ONCE THE CAPTURE BRACKET IS LOCATED, AND
BEFORE FASTENING IT IN PLACE, RE-INSTALL THE
UPPER NOZZLE-FIXING SCREW, AND TIGHTEN BOTH
FIXING SCREWS. INSTALL AND TIGHTEN THE
CAPTURE BRACKET SECURING SCREWS TO
COMPLETE THIS PART OF THE INSTALLATION.
NOTE:
RETRACTOR
NOZZLE
UPPER NOZZLE-
FIXING SCREW
(REMOVE)
LOWER NOZZLE-
FIXING SCREW
(LOOSEN)
